OpenScape 4000 V7
System Components (Hardware, Software)
Service Documentation
A31003-H3170-S102-4-7620

Advertisement

loading
Need help?

Need help?

Do you have a question about the OpenScape 4000 V7 and is the answer not in the manual?

Questions and answers

Related Manuals for Unify OpenScape 4000 V7

Summary of Contents for Unify OpenScape 4000 V7

  • Page 1 OpenScape 4000 V7 System Components (Hardware, Software) Service Documentation A31003-H3170-S102-4-7620...
  • Page 2 Availability and technical specifications are subject to change without notice. Unify, OpenScape, OpenStage and HiPath are registered trademarks of Unify Software and Solutions GmbH & Co. KG. All other company, brand, product and service names are trademarks or registered trademarks of their respective holders.
  • Page 3 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents OpenScape 4000 V7 - System Components (Hardware/ Software) - Contents Hardware ................15 1 Important Information.
  • Page 4 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents 3.7 AP 3700-13 Shelf (OpenScape 4000 Host System) ......... . 49 3.7.1 Shelf Population (Front) .
  • Page 5 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents 4.4.8 Backplane PIN Assignments ............93 4.4.8.1 Backplane Pinning, Connector J1 .
  • Page 6 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents 4.11.5 PNE/PBXXX Application ............142 4.11.5.1 Interfaces .
  • Page 7 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents 4.18.1 Functional Description ............187 4.18.2 LED Indications.
  • Page 8 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents 4.26 STHC ................243 4.26.1 Feature Characteristics .
  • Page 9 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents 4.34.6 PTIMES ..............317 4.35 TMBD.
  • Page 10 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents 4.42.6 Verifying the TMEMW or TMEMUS Board..........372 4.42.7 MDF Assignments .
  • Page 11 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents 5.5.3 LED Indications..............422 5.5.4 Removing the ACPCI/DCPCI .
  • Page 12 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents 5.12.1.1 ICBP Connectors and Switches ..........459 5.12.1.2 Removing the ICBP .
  • Page 13 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents Software................503 1 Highlights and Hints .
  • Page 14 OpenScape 4000 V7 - System Components (Hardware/Software) - Contents A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 15 The OpenScape 4000 PSU has adequate lightning protection at the 230-V port for up to 2 kV. Additional lightning protection is recommended upstream of the connecting line in high-risk areas. The lightning protection A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 16 If this additional primary protection is not installed, lightning strikes above the voltage limits named above may destroy the boards. This may in turn lead to a failure of the entire system or to device overheating (fire risk). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 17 The OpenScape 4000 EcoServer shelf is the base cabinet of the OpenScape 4000 system. The main processor module is based on an x86 architecture as successor of the former DSCXL2. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 18 • Airflow: The direction of the airflow is from left to right (Figure 2 System Overview). • Sliding rails: It is possible to attach sliding rails for rack mounting. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 19 4 USB ports (2x USB 3.0, 2x USB 2.0) • Display port connection for maintenance purposes • Push button for status display • Small display, used for status messages • Run/Fail-LED for CC • Run/Fail-LED for RTM A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 20 Two SSD trays (hot pluggable) are accessible from the front of the system. Two LEDs for each tray will signal if a drive is inserted: • Green LED (Power) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 21 The design is supporting always both interfaces, regardless which EcoServer is active or standby. The signals are connected parallel to both boxes over the CrossConnect cable. So it doesn’t matter which interface will be used. The A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 22 In contrast to the predecessor the EcoServer has two ALIN interfaces in a duplex configuration (each EcoServer has one interface). It is allowed to connect a cable only to one EcoServer ALIN interface. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 23 Pin Pin Signal PFNMI NGAR BAEXF *) ALIN_TST 9 FGND Table 4 EcoServer: ALIN PIN Assignment *) Pin 9 is not connected in the cable. Figure 6 ALIN Connector A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 24 2.5 Replacement of Components Following components are replaceable by service technician: • Replacing Power Supply • Replacing SSD Tray • Removing Empty Tray • Replacing RTC (Real Time Clock) Battery A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 25 Only the components described here may be replaced. Opening of the housing cover is not permitted. If the housing seal is removed or broken, the guarantee for the device becomes null and void automatically and Unify will not give credit for returned goods, regardless of the reason why the device has been returned.
  • Page 26 2. Pull out the SSD tray evenly on both sides (2). 3. Now insert the new SSD tray into the designated opening on the front panel. Figure 10 EcoServer: Replacing SSD Tray A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 27 5. Once you have inserted the battery, push the battery holder back into the designated opening until the lock on the battery holder engages (2). 6. Now push the SSD tray into the front panel again. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 28 The EcoServer contains a function that detects the existence of the cross-connect cable, even if the other end of the cable is open. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 29 3. You can now also remove the cross-connect cable from the standalone server. 4. Now connect the new cross-connect cable to the two EcoServers, starting with the active server. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 30 Switch on the power supply for the second EcoServer. The active server in standalone mode detects the second EcoServer by means of the cross-connect cable and automatically switches from standalone mode to duplex mode. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 31 SHELF FRUs 3 SHELF FRUs This chapter describes the individual shelves and the procedures for removing, replacing and verifying them in a OpenScape 4000 system. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 32 SHELF FRUs Block Diagram OpenScape 4000 3.1 Block Diagram OpenScape 4000 Figure 14 Block diagram OpenScape 4000 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 33 One control board (at the back of the shelf) MCM (Management and Control Module) 3.2.1 CSPCI Shelf (Front View) Figure 15 shows the front view of the CSPCI shelf (duplex). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 34 IMPORTANT: The factory setting for the CSPCI shelf’s power supply coding is always set to ACPCI. To use DC power supplies (DCPCI), you must change the coding according to Figure A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 35 Chamber E: empty Chamber D: Position 3 Figure 16 Coding for power supply configurations ACPCI/DCPCI 3.2.2 CSPCI Shelf (Back View) Figure 17 shows the back view of the CSPCI shelf (mono). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 36 5. Remove the ESD wrist strap. 6. At the back of the shelf, label any unlabeled cables to identify the matching connector locations. 7. Disconnect all cables. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 37 One AC-to-DC shelf power supply (LPC80) • One DC-to-DC shelf power supply (PSUP) • One special slot to access a limited number of highways Connectors Figure 18 shows the connectors on the L80XF backplane. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 38 +5 V and GND. Since the MDF champ connector does not have a power pin, the adapter is only used in the North American (NA) market. Table 5 L80XF Shelf Connectors (Back View) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 39 3. Tighten the screws on the clamps to secure the DC-to-DC shelf power supplies to the shelf. 4. Slide each board into the appropriate slot until you seat them all firmly into the backplane connectors. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 40 Two DC-to-DC shelf power supply units (PSUPs) • 16 peripheral slots, up to 24 ports in narrowband • A special slot for RG or peripheral signaling interface unit (SIU) • One LTUCA board A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 41 A power fail signal (PFPS) connector between the PSDSC and the processor card. In a DC-powered system, the signals may serve as alarm input from an external power supply. Table 6 LTUW Shelf Connectors A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 42 3. Tighten the screws on the clamps to secure the DC-to-DC shelf power supplies to the shelf. 4. Slide each board into the appropriate slot until you seat them all firmly into the backplane connectors. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 43 OpenScape 4000 system as before. All IP-distributed components are administered as a single system over one OpenScape 4000 system connection point. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 44 Slot 1 -6: Peripheral modules • Slot 7: Central control board LTUCA (AP3700-13)/not populated in H3800BB • Slot 8 - 14: Peripheral modules • Up to four power supply units LUNA 2 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 45 Figure 21 AP 3700-9 Front View • Slot 1 - 5: Peripheral modules • Slot 6: Central control board NCUI (AP3700-9)/CBSAP (H3800BB) • Slot 7 - 10: Peripheral modules A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 46 Slot 6: Power supply connection board (DC at the top/AC at the bottom) • Slot 5 -1: Patch panels (8, 20 and 24-port RJ-45 connector/CHAMP plug) • Cable clip for earth connection A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 47 SIVAPAC cables on the backplane for connection to external patch panels or to a main distribution frame (MDF) • Power supply connection board (DC at the top/AC at the bottom) • Cable clip for earth connection A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 48 Connector X109 - X112: SIVAPAC connector for peripheral connections • Connector 116/117: SIVAPAC connector (REALS, ALUM) • Connector 201: DB68mini (for expansion box) • Connector 209: DC connection • Connector 211/212: AC connection A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 49 Figure 25 AP 3700-13 Front View • Slot 1 -6: Peripheral modules • Slot 7: Central control board LTUCA (AP3700-13)/not populated in H3800BB • Slot 8- 14: Peripheral modules A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 50 Slot 7: Power supply connection board (DC at the top/AC at the bottom) • Slot 6 -1: Patch panels (8, 20 and 24-port RJ-45 connector/CHAMP plug) • Cable clip for earth connection 3.7.3 Shelf Population (Back) without Patch Panels A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 51 Power supply connection board (DC at the top/AC at the bottom) • Cable clip for earth connection 3.7.4 AP 3700-13 Backplane Connections Figure 28 shows the AP 3700-13 backplane connections A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 52 Connector X109 - X115: SIVAPAC connector for peripheral connections • Connector X209/X210: DC connection • Connector X211: AC connection • Connector X214: 10-pin plug (RG module) • Connector X220-223: 14-pin plug (4x DBSAP connection) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 53 Survivability Server and the access point NCUI communicate with each other exclusively via the IP network (see also service manual "OpenScape 4000 V7, IP Solutions - IPDA&APE"). IMPORTANT: The factory setting for the CSPCI shelf’s power supply coding is always set to ACPCI.
  • Page 54 SHELF FRUs Survivability Server Figure 30 AP 3700 IP Front View A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 55 SHELF FRUs Survivability Server Figure 31 shows the Slot for Survivability Server DSCXL2+ module Blind panel Power supply module Figure 31 Survivability Server Slot A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 56 SHELF FRUs Survivability Server A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 57 The adapter cables connect to a T1 customer service unit (CSU) or data service unit (DSU). With this cable, Line 1 pairs are the same as those of the TMDNH board, pair 13 transmit and pair 16 receive. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 58 Boards DIU2U Figure 32 DIU2U Board, Front Panel A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 59 Boards DIU2U Figure 33 T1 CSU or DSU Cable Detailed Cable Description T1 Cable Part number: C39195-A7269-Bxxx A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 60 The board is defective or out-of-service. The board is operational and all channels are inactive. Flashing The board is operational and one or more channels are active. Table 8 DIU2U Board LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 61 IMPORTANT: Parameter LWPAR is not used when adding line type MOS. BOS type circuits for North America Installation ADD-BCSU:MTYPE=TMD,LTG=1,LTU=<1-99),SLOT=<25-121>, PARTNO="Q2216-X",FCTID=5,LWVAR="K",LWPAR=<1- 200>,FIDX=1,HWYBDL=A; (Adding a DIU2U to shelf 2 slot 31) ADD-BCSU:MTYPE=TMD,LTG=1,LTU=2,SLOT=31,PARTNO="Q2216- X",FCTID=5, LWVAR="K",LWPAR=1,FIDX=1,HWYBDL=A; MOS type circuits for North America Installation. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 62 The following example shows a BOS circuit for extended superframe format with binary eight zero substitution. CHANGE-LWPAR: TYPE=TMD,TMDTYPE=TMDBOS,BLNO=1,OPMODE=FRAMEESF&BISUB8ON&BDETO The following example shows a MOS circuit for a WORLDCOM/MCI primary rate span A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 63 H500: AMO TDCSU STARTED DIGITAL TRUNKS (FORMAT=S) DEVICE BCGR B-CHANNEL TGRP CCT -------------------------------------------------------- S1CONN 1-02-079-0 1 && 23 CORNUS-V66 S1CONN 1-02-079-1 1 && 23 DIU2U CORNET -------------------------------------------------------- • AMO-REFTA A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 64 Indicates that the far end is in Loss of Frame alarm state and is unable to synchronize on its in coming signal. The far end is transmitting Remote Alarm Indication (RAI) Table 9 Line Status LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 65 LTU 2 SLOT 37 FFFF:FFF0 20 20 20 20 FFFF: 43 41 52 44 20 4C 45 44 20 53 54 41 54 45 20 20 CARD LED STATE A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 66 IMPORTANT: PEN1 is the PEN of the first channel and PEN2 is the PEN of the last channel on the board. 2. Deactivate the board as follows: a) Type DEA-BSSU and press Enter. b) Type the following values, then press Enter. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 67 IMPORTANT: For ISDN applications, first activate the D channel, and then activate the B channels. Activate the channels as follows: a) Type ACT-DSSU and press Enter. b) Type the following values, then press Enter. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 68 IMPORTANT: PEN1 is the PEN of the first channel and PEN2 is the PEN of the last channel on the board. 4.1.7 Verifying the DIU2U Board To verify the operation of the DIU2U board, confirm that the green LED turns on. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 69 DIU-N4 4ports (not for DIU-C) Type of connection: • Fiber optical interface • 75 Ohm copper interface • 100 Ohm copper interface (DIU-N4 only) • 120 Ohm copper interface A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 70 LW at a time. After a reset, the optical interface at the backplane connector becomes active. It is possible to use either Multimode- or Monomode optical fibers. • Line access A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 71 15-pin Sub-Ds (without any adaptor). – AMO TDCSU and parameter LWPS are used to select the impedance. Line termination is set with the AMO LWPAR for the DIUC function. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 72 Input LWLO0_BACK X3-02 Port 0: fiber link data output (back) Output LWLCI0 X1-26 Port 0: fiber link clock in Input Table 11 SiPAC Connector Pins (Seite 1 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 73 +5V power supply Output X22-5; X22-12 ground return for the +5V power Input/Output supply SCAN_IN1 X22-7; X22-6 adapter check Input Table 12 Sub-D X21 and X22 Connectors Pin Assignments A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 74 AMO TDCSU—configures the trunk assignment • AMO LWPAR —configures the following loadware parameter specifications: – With/without CRC4 in the TSL0 – Layer 2 master/slave setting – Line interface Copper/Fiber (HDB3/NRZ) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 75 AMO BCSU—adds the new boards under the branch PER and not DIU. • AMO PETRA—displays the memory contents of the board – Starts and stops trace jobs – Displays trace results. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 76 DIU-N2 / DIU-N4 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 77 Trunk 2 (DIUT2) board. It also provides procedures for removing, replacing, and verifying this board. 4.3.1 Functional Description This board unify the two different cards DIUN2(Q2196) and DIU2U (Q2216) with one technology family on unique PCB. Additionally, two different LW variants will be supported: •...
  • Page 78 Adapters”) and two LEDs which indicates the status of board. LED (green) LED (red) SubD interface 1 (X10) SubD interface 2 (X11) Figure 35 DIUT2 Front panel (S30810-Q2226-X200) 4.3.3.1 Hardware Variants S30810-Q2226-X200 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 79 Connector Type Location Identifier X1 to X9 System interface SIPAC Backplane E1/T1 link 0 DB15 female Front Panel E1/T1 link 1 DB15 female Front Panel Table 15 External Connections A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 80 X1-02, X1-26 Trunks 0 to 7 AB pair BGx_0B X1-06, X1-08 connected X1-10, X2-02 X2-04, X2-06 X2-08, X2-10 X3-02, X3-04 X3-06, X3-08 X3-10, X4-02 Table 17 SIPAC Connector pin assignment A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 81 Boundary scan: test clock connected X7-46 Boundary scan: test mode select connected X7-48 Boundary scan: test data input connected X7-50 Boundary scan: test data output connected Table 17 SIPAC Connector pin assignment A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 82 DIUT2 Cables and adapters IMPORTANT: The Optical interface must be used only in the front connectors. S2 adapter DBM15 to RJ 45 Wiring of a DBM15 plug with a RJ 45 jack. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 83 Type III for connections to clients via ISDN patch panel • Type IV for connection to NTBA via ISDN patch panel (ISDN patch panel uses pin 3-6/4-5 instead of 1-2/4-5 in separated cables) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 84 DIUT2 board. IMPORTANT: Please see that the parameters PARTNO1 and FCTID1 are not required, but if included, then the SSW can check if the information/replacement is correct. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 85 IMPORTANT: For ISDN applications, first deactivate the B channels, and then deactivate the D channel. 1. Deactivate all channels as follows: a) Type DEA-DSSU and press Enter. b) Type the following values, then press Enter. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 86 Type the following values, then press Enter. Field Value ONTYPE <1 - 32> <1 - 8> SLOT <1 - 151> IMPORTANT: For ISDN applications, first activate the D channel, and then activate the B channels. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 87 IMPORTANT: PEN1 is the PEN of the first channel and PEN2 is the PEN of the last channel on the board. 4.3.8 Verifying the DIUT2 Board To verify the operation of the DIUT2 board, confirm that the green LED turns on. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 88 DIUT2 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 89 Figure 37 DSCXL2 board 4.4.1 Hardware Variants S30122-K7732-X (with 2 x 2 GB memory module + HD) S30122-X8004-X35 (with 2 x 2 GB memory module) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 90 From V6 R1.12.0 the RUN and FAIL LEDs can be used to establish visually the run state of each processor and whether any Major or Minor alarms are signalled. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 91 Eight GigE interfaces on the front panel for redundant configuration. The LAN interfaces to the front panel supports IPv4 and IPv6, jumbo frames (9kB), MSI/MSI-X and IO Virtualization (VT-c/VMDq). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 92 DSCXL2 is equipped with a emergency fan switch. This switch will turn on all fans on full speed if a critical temperature is reached. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 93 DSCXL2 board. 4.4.7 Backplane Table 21 DSCXL2 backplane connectors 4.4.8 Backplane PIN Assignments long pin length medium pin length short pin length Table 22 DSCXL2 pin assignment A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 94 RSVD RSVD RSVD AD(30) AD(29) AD(28) AD(2 RSVD RSVD RSVD RSVD 3.3V REQ0# PCI_P AD(3 RSVD RSVD RSVD RSVD BRSVP BRSVP RST# Table 23 DSCXL2 backplane pinning, connector J1 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 95 GND BRSVP2A1 PRST# GNT6# GND BRSVP2A1 BRSVP2B1 DEG# BRSVP2E1 RSVD RSVD GND BRSVP2A1 FAL# GNT5# V(I/O) V(I/O) V(I/O) V(I/O) V(I/O) V(I/O) BRSVP2B4 Table 24 DSCXL2 backplane pinning, connector J2 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 96 RSVD V(I/O) RSVD RSVD +3.3V RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD Table 25 DSCXL2 backplane pinning, connector J4 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 97 RSVD RSVD +3.3V RSVD RSVD RSVD +3.3V RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD +3,3V RSVD RSVD RSVD Table 25 DSCXL2 backplane pinning, connector J4 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 98 DSCXL2 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 99 C39195-A7985-B332 (eSATAp-Cable - front cable between DSCXL2+ and HDTR2) • S30122- X8014-X18 (SATA 2,5”, 250GB HD) 4.5.2 LED and OLED Displays/Keys The front side of the board features includes • one OLED display A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 100 LED for HD activity with the following properties (see Table 26 for LED and OLED displays, and key functions) • one key for board “Reset” Figure 40 DSCXL2+ front A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 101 DSCXL2+ Maintenance eSATAp output plug Host Host Service PC Reset Figure 41 DSCXL2+ board front panel A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 102 Customer-LAN Information An (*) indicates active Ethernet interface in case of bond configuration. Interface bond Interface vlan over eth Interface vlan over bond Table 26 DSCXL2+ LED and OLED displays/keys A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 103 Reset Button Manual reset for DSCXL2+ (The reset button is placed behind the front panel to avoid pushing the button by mistake. Table 26 DSCXL2+ LED and OLED displays/keys A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 104 RUN and FAIL LEDs both to yellow. NOTE: The DSCXL2+ board should only ever be physically (or Reset key pressed) removed when both the RUN and FAIL LED are yellow. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 105 LED flashing LINK/ACT green Connection No connection Transferring or receiving signal SPEED green 100 Mbps 10 Mbps Table 28 DSCXL2+ LED Displays for LAN interface to the RTM board A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 106 DSCXL2+ is equipped with a emergency fan switch. This switch will turn on all fans on full speed if a critical temperature is reached. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 107 DSCXL2 + 1x HD • replace DSCXL2 not planned not planned onboard (APE, with DSCXL2+ duplex CCB) • reuse HD Table 30 DSCXL2+ update and migration concept A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 108 • remove HDTR • replace HDTR • replace HDTR • reuse one HD with HDTR2 with HDTR2 • reuse HDs • reuse HDs Table 30 DSCXL2+ update and migration concept A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 109 OpenScape 4000 (AP3700 19“ architecture) IMPORTANT: The LTUCA does not replace the LTUCX or LTUCE in existing systems. These boards are still used because the LTUCA is not compatible with existing processor boards. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 110 LTUW: S30804-B5367-X/B5385-X and B5388-X L80XF: S30804-B5379-X and B5389-X L80XW: S30804-B5366-X AP3700: S30807-U6620-X 4.6.4 Cable Types The following CAT 5 RJ45 cable types are available for connecting the LTU shelf: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 111 The LTUCA board receives a direct current of 5 V over the backplane. The individual voltages required (1.8 V/3.3 V) are generated by the DC/DC converter on the board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 112 LTUCA A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 113 LTUCA. Because of having a new HW-ID and part number, the LTUCR will be recognized completely as a new board. LTUCR is supported only in HiPath 4000 V6 and OpenScape 4000 V7 and newer versions. The LTUCR (Line Trunk Unit Control Replacement) board (see...
  • Page 114 19” Expansion Box  old color (SAPP-EB): S30805-G5413-X • 19” Expansion Box  new color (SAPP-EB): S30777-U779-X1 • Cabinets: • S30805-G5408-X/A Cabinet UP • S30805-G5404-X/A Cabinet UPR ….A=USA, ….X =IM A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 115 The loadware for the LTUCR board also contains the firmware for the FPGA image (field programmable gateway array). What is new is that this FPGA image can be updated. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 116 FPGA image may take a long time depending on the system configuration (individual shelf startup). An FPGA image update is envisaged as an extremely rare operational event. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 117 ALUM (power failure transfer) • ALIN (alarm interface) • Front reference clock AC or DC cable bushing Figure 47 MCM board 4.8.1 Hardware Part Number S30810-Q2313-X100-* 4.8.2 Interfaces • ALUM • ALIN A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 118 C39195-Z7612-A100 ASW cable to MDF (GER und IM) C39195-Z7612-A200 ASW cable to MDF (GER und IM) C39195-Z7612-A550 ASW cable to MDF (GER und IM) Table 32 ALUM Cables A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 119 The following cables are used for this: S30267-Z304-A9 (int.) or S30267-Z304-A40 (ext.) FRONT_RCLK_N FRONT_RCLK_P CLK_OUT_P CLK_OUT_N (+5 V) for test only BACK_CLK_N Table 35 Front Reference Clock Pin Assignment A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 120 RSVD RSVD RSVD +5 V +3.3 V +3.3 V RSVD RSVD RSVD RSVD +3.3 V RSVD RSVD RSVD RSVD RSVD Table 37 Backplane Pin Assignment (Seite 1 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 121 FAN_T2 FAN_FB RSVD RSVD +12 V FAN_T3 FAN_T4 RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD Table 37 Backplane Pin Assignment (Seite 2 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 122 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 123 IMPORTANT: The NCUI2+ must not be plugged in and unplugged during live operation. Figure 49shows the NCUI2+ board Figure 49 NCUI2+ board 4.9.1 System Diagram Figure 50 shows the NCUI2+ board system diagram. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 124 V.24 9-pin SUB-D connector Service terminal/modem 1 each • Green (RUN) Board status display • Red (FAIL) LED Reset key Reset the board Table 38 LED displays and interfaces A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 125 NCUI2+ board front panel. Green LED for RUN Red LED for FAIL Reset switch V.24 modem interface V.24 service interface LAN interfaces Figure 51 NCUI2+ Board Front Panel A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 126 NCUI2 board. 2. Press the button SAVE configuration to file and enter a name for the file where will be stored the old NCUI2 data. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 127 2. Copy via File Transfer the new version of AMO UCSU (APS: B0-EM0.10.048) in folder :PDS:APSN/S/UCSU@ (C, D and E files) and execute the RELOVL; command Copy the new version for the BGDAT00 file in the folder :PDS:APSU/BGDAT00. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 128 4. Power off the AP. 5. Replace old NCUI2 board with the new NCUI2+ board. 6. Copy the new LW for the new NCUI2+ board in the folder :PDS:APSP/LTG/LGA0/PZKNCI20. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 129 1) in order to get the NCUI2 configuration data saved previous at step 1. 2. Press the button Save all Parameters to save the configuration data to the new NCUI2+ board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 130 NCUI2+ 9. Activate the AP. ACTIVATE-USSU:UNIT=LTG,LTG=1,LTU=17; 10. Verify the LW version of the board in CLI with command: show version CLI output: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 131 Summary of all loadware versions: Loadware ID : 02/08/06 16:07:09 no_label pzknci20, /tffs/ SW_IMAGE.001 Loadware file /tffs/SW_IMAGE.002 doesn’t exist. 11. If the board doesn’t start, please reset the new NCUI board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 132 NCUI2+ A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 133 Ethernet network. Within the local system, the NCUI4 switches up to 256 time slots on eight highways at 2,048 Mbps. IMPORTANT: The NCUI4 must not be plugged in or unplugged during live operation. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 134 NCUI4 (S30810-Q2324-X00/X10) Figure 52 shows the NCUI4 board Figure 52 NCUI4 Board A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 135 V.24 9-pin SUB-D connector Service terminal/modem One each • Green (RUN) Board status display • Red (FAIL) LED Reset key Reset the board Table 39 LED Displays and Interfaces A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 136 NCUI4 board front panel. Green LED for RUN Red LED for FAIL Reset switch V.24 modem interface V.24 service interface LAN interfaces Figure 54 NCUI4 Board Front Panel A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 137 The NCUI4 board receives a power supply voltage of +5 V over the backplane. The individual voltages required (+3.3 V, +2.5 V, +1.8 V, +1.5 V, and 1.2 V) are generated by the DC-to-DC converter on the board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 138 NCUI4 (S30810-Q2324-X00/X10) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 139 102, 103, 104, 105, 106, 107, (108/1, 108/2), 109, 125 (CCITT spec). The connection is done via a DB15 female mini connector. The maximum allowable cable load is 2500PF. This is nearly 15 meters for shielded cable. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 140 V.24 Port C - for modem connection V.24 Port D - for modem connection V.24 Port M - Maintenance Port, for connecting the service PC with the Maintenance tool. Figure 55 PBXXX - Front Panel A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 141 Switch 1 Switch 2 75 default Not used Not used Table 40 Dip switch line 1 configuration Impedance (ohms) Switch 3 Switch 4 Table 41 Dip switch line 2 configuration A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 142 (VPN) that are offered by operators only a very few of the supplementary services of a state-of-the-art ISDN private network will be available. For global networking with OpenScape 4000 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 143 Public exchanges through DASS2 protocol. • Other OpenScape 4000 systems with DPNSS1 protocol if certified. 4.11.6.1 Interfaces The CDG over PBXXX has the following physical characteristics: • Two E1 links (2Mbits PCM) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 144 One maintenance port (M port at the bottom) for asynchronous connection to the maintenance computer. 4.11.6.2 Physical Connections In the Installation Instructions OpenScape 4000 you can find some examples how connect the PBXXX board to the ISDN Mail. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 145 LTU shelf receive ring voltage from two ring generator boards. Ring generator Figure 57 Ring Generator 4.12.1 LED Indications The ring generator does not have any LED indications. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 146 Strom welligkeit 75Vrms 25Hz 67mA 200mV europ.Standard 65Vrms 25Hz 77mA 200mV Schweiz 75Vrms 50Hz 67mA 200mV Frankreich 85Vrms 20Hz 59mA 200mV Table 43 Ringer Settings Table 44 Ringer Settings A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 147 4.12.4 Jumper settings for Ring Voltages S30807-Q6141-X 65V / 25Hz 85V / 20Hz 75V / 25Hz 75V / 50Hz Connector Connector Euro. Standard Switzerland France S30122-K5929-X Connector Figure 58 Jumper settings for Ring Voltages A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 148 To remove the ring generator: 1. Remove the screw that attaches the ring generator to the backplane. 2. Unplug the ring generator from the 10-pin connector on the backplane. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 149 The USERG (Q2468-X) is an option on systems which have large amounts of message waiting and analog telephones. The USERG is installed in slot 19 of an LTU shelf. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 150 Ring Generator A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 151 This display is controlled by the software and loadware and should normally be off. If on, it indicates a real hardware or software error. The green RUN LED should be off. Table 45 RTM Board LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 152 LTU 15 x RJ45 each with 32 Mbps (each of which has 1x HDLC channel with 2 Mbps and 4x PCM64s (256 B channels per LTU, max. 3840 B channels) • V.24 9-pin SUB-D connector (service connector) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 153 REF_RXP DAT_RXP DAT_TXP DAT_RXN DAT_TXN REF_RXN REF_TXN DAT_TXN DAT_RXN DAT_TXN DAT_RXN Standard CAT5 LTUCA “LAN” cable connection Front panel Front panel Figure 63 LAN Cable Connection • V.24 interface A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 154 IMPORTANT: After swapping an RTM module, reload the associated processor (BPA or BPB) with EXEC-REST:UNIT,BPx,RELOAD; This is the only way to ensure correct operation with current LW/SIU data in the RTM. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 155 The SIUX or SIUX2 board resides in an LTUW or L80XP shelf but are functionally part of the service unit. 4.14.1 LED Indications The front panel of the SIUX and SIUX2 board (see Figure 64) has two LEDs: ERR (error) and RDY (ready). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 156 Initial board test is in progress or a fatal board error is detected. Flashing Board loadware is loading or the initial board test passed. Board is functioning normally. Table 47 SIUX Board LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 157 Replace the SIUX board as follows: 1. Slide the board into the appropriate slot until you seat it firmly into the backplane connector. 2. Activate the SIUX board as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 158 Verify the operation of the SIUX board by displaying the status of the L80F or LTUW shelf as follows: 1. Type DIS-SDSU and press Enter. 2. Type the following values, then press Enter. Field Value STATUS LINK <blank> TYPE <ltu#> SLOT <slot#> A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 159 SLC boards is high. 4.15.1 LED Indications A "ready" (green) and a "fail" (red) LED have been integrated on the SLC24 for status control. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 160 Ch A TXDA receive data Ch A Pin 4 N.C. not connected Ground Pin 6 N.C. not connected Table 49 SLCSM Interface X21 Pin Assignments (Seite 1 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 161 HDLC interfaces (High Level Data Link Control) The SLC24 is controlled over an HDLC highway. The ’Extended Line Card Interface Controller’ (ELIC, PEB20550) is used to operate the interface. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 162 -48V (+/-5%), typical power consumption depends on the base stations connected up The +5V and ground connections are arranged on the SLC24 with leading heavy current contacts and normal contacts on the SIPAC contact strip. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 163 OCTAT-P CPU bus CPU bus SaccoB SaccoA ALFs Ser. port1 S_PCM_x Ser. port2 always available only H150 (SLC16) only H300 (SLC24) not used Figure 66 Block Diagram for SLC24 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 164 SLC24 Subscriber Line CMI24 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 165 The board is being loaded with hardware. The board is defective or out of service. The board is operational and all channels are inactive. Table 51 SLMA2 Board LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 166 7 bits. The SLMA2 reads only the first 6 bits (BA0..BA5), in parallel. Figure 67 shows the system architecture of the SLMA2 board. Ring Generator SLMA2 Switching Network SLMR TMC16 Common Control Figure 67 SLMA2 Board, System Architecture A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 167 LTU shelf, only 64 time slots are available and two PCM highways (HI 0/1, Ho 0/1) are connected to the system interface. Interface to the Central Processor HDLC-Highway (interface to central processor): A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 168 The ring voltage is applied to and turned off from each subscriber line near the zero-voltage crossing point by the LW to minimize the impulse noise. Message waiting indication function (MWI) Two types of message-waiting methods are supported. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 169 Multiplexing the indication information from the SICOFI input pins to the IOM2-C/I-channel. • A/D and D/A conversion. • Input impedance matching (resistive or complex), additional gain setting and hybrid balancing (on resistive or complex termination impedances) are fully programmable. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 170 Boundary scan: Test data input Input X2-51 Boundary scan: Test data Output output Table 52 SLMA2 Board Connector Pin Assignment Table 53 lists the tip and ring termination of the SLMA2 board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 171 13 X1-32 X1-34 channel 14 X1-35 X1-37 channel 15 X1-38 X1-43 channel 16 X1-44 X1-45 channel 17 X1-46 Table 53 SLMA2 Board TIP/RING Termination Wires (Seite 1 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 172 IMPORTANT: PEN1 is the pen of the first channel and PEN2 is the pen of the last channel on the board. 2. Display the status of the board until all channels are free as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 173 <1 - 8> SLOT <1 - 151> 3. Activate the channels on the board as follows: a) Type ACT-DSSU and press Enter. b) Type the following values, then press enter. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 174 Field Value STATUS LINK <blank> TYPE LEVEL PER3 <1 - 32> <1 - 8> SLOT <1 - 151> <0 - 15> The SLM board is automatically tested on activation. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 175 The SLMA3 board generates its own ringing voltage and does not require an external ring generator. It supports V.90 (56K) modems with data transmission rates up to 50 kilobits per second (Kbps) The SLMA3 board has SIPAC shelf connectors. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 176 The board is operational and all channels are in the on-hook state. Flashing The board is operational and one or more channels are in the off-hook state. Table 54 SLMA3 Board LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 177 EC 201 185 (EU) terminal §6.1 20/60 (BAPT 221 ZV MÜ 2a) Table 55 Country spread for Board Utilization Based on the DC Functional Range (Seite 1 von 5) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 178 IDA TS PSTN1 §6.2.2.1 indirect South Africa 100 w/o DPT-SWS- terminal 001 2.8.5.1i Table 55 Country spread for Board Utilization Based on the DC Functional Range (Seite 2 von 5) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 179 Ireland (EU) 600 incl. EC 201 185 terminal §6.1 N.A. Derived from TTE 10 (11/97) Table 55 Country spread for Board Utilization Based on the DC Functional Range (Seite 3 von 5) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 180 §5.3.1.2 + only) necessary) (recommended 5.3.2.3 value: 1200) Outside a building: 1800 Table 55 Country spread for Board Utilization Based on the DC Functional Range (Seite 4 von 5) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 181 E V1.0, E V2.0, E V3.0, E V3.1, system versions OpenScape 4000 systems H V1.0 and OpenScape 4000 systems SLMA24 and SLMA can be implemented in mixed mode Table 56 SLMA24 (SLMA2) Properties/Restrictions Compared to SLMA3 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 182 However, only max. 1 RGE/RG module is permitted per shelf. Ring current asymmetrical, grounded. Message Waiting Comtel-3 Indication (MWI) MWI with glow lamps not supported. Table 56 SLMA24 (SLMA2) Properties/Restrictions Compared to SLMA3 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 183 3. When all channels are available, deactivate the board as follows: a) Type DEA-BSSU and press Enter. b) Type the following values, then press Enter. Field Value OFFTYPE <1> A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 184 Verify the operation of the SLMA3 board by displaying the status of the board as follows: 1. Type DIS-SDSU and press Enter. 2. Type the following values, then press Enter. Field Value STATUS LINK <blank> A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 185 RED-GRN VIO-BLU GRN-RED BLU-VIO RED-BRN VIO-ORG BRN-RED ORG-VIO RED-SLT VIO-GRN SLT-RED GRN-VIO BLK-BLU VIO-BRN BLU-BLK BRN-VIO BLK-ORG VIO-SLT Not used. ORG-BLK SLT-VIO BLK-GRN GRN-BLK Table 57 Standard Punch-Down Sequence A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 186 SLMA3 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 187 The SLMAC board generates its own ringing voltage and does not require an external ring generator. It supports V.90 (56K) modems with data transmission rates up to 50 kilobits per second (Kbps) The SLMAC board has SIPAC shelf connectors. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 188 The board is operational and all channels are in the on- hook state. Flashing The board is operational and one or more channels are in the off-hook state. Table 58 SLMAC Board LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 189 4.18.4 Removing the SLMAC Board IMPORTANT: This procedure removes up to 24 analog voice channels from service. NOTE: Static Sensitive Devices! Observe all precautions for electrostatic discharge. Remove SLMAC board as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 190 Replace the SLMA3 board as follows: 1. Slide the board into the appropriate slot until you seat it firmly into the backplane connector. 2. Activate the SLMAC board as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 191 SLMAC board punch-down sequence at the MDF. Cable punch-down is standard. Each channel uses one tip and ring pair. Label the block from channel 00 through 15 or 23, as appropriate. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 192 RED-GRN VIO-BLU GRN-RED BLU-VIO RED-BRN VIO-ORG BRN-RED ORG-VIO RED-SLT VIO-GRN SLT-RED GRN-VIO BLK-BLU VIO-BRN BLU-BLK BRN-VIO BLK-ORG VIO-SLT Not used. ORG-BLK SLT-VIO BLK-GRN GRN-BLK Table 60 Standard Punch-Down Sequence A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 193 4.19.1 Touch Guard WARNING The board is fitted with a touch guard because the onboard heat sinks are energized. Do not remove this touch guard. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 194 2 LEDs for displaying the module status LED (red) LED (green) Figure 71 SLMAE - Front Panel IMPORTANT: To ensure sufficient shielding, provide the board with a shielding panel. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 195 Pair a-Wire b-Wire SIVAPAC SLMAE8, SLMAE MDFU-E Notes (Tip) (Ring) Connector wht/ Port 1 blu/ wht/ Port 2 ora/ Table 62 SLMAE - SIVAPAC Connector Assignment on the Backplane A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 196 Port 4 brn/ wht/ Port 5 gry/ red/ Port 6 blu/ red/ Port 7 ora/ red/ Port 8 grn/ Table 62 SLMAE - SIVAPAC Connector Assignment on the Backplane A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 197 Port 13 grn/ blk/ Port 14 brn/ 15 blk/gry Port 15 gry/blk 16 yel/blu Port 16 blu/yel Table 62 SLMAE - SIVAPAC Connector Assignment on the Backplane A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 198 Port 24 brn/ Table 62 SLMAE - SIVAPAC Connector Assignment on the Backplane RJ45 jack SLMAE8, SLMAE Notes Table 63 SLMAE - Connector Panel Assignment with RJ45 Jacks A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 199 SLMAE RJ45 jack SLMAE8, SLMAE Notes Not used for SLMAE8 (HiPath 3000) Table 63 SLMAE - Connector Panel Assignment with RJ45 Jacks A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 200 Port 6 6 Tip 7 Ring Port 7 7 Tip 8 Ring Port 8 8 Tip Table 64 SLMAE - Connector Panel Assignment with a CHAMP Jack (for U.S. only) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 201 Port 22 22 Tip 23 Ring Port 23 23 Tip 24 Ring Port 24 24 Tip Table 64 SLMAE - Connector Panel Assignment with a CHAMP Jack (for U.S. only) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 202 SLMAE A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 203 128 time slots. Each highway has two uni-directional ports (HI0 - HI3 / HO0 - HO3) • Communicates with the central processor over the 2.048 Mbps HDLC highway through uni-directional ports HDO and HDI A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 204 Ring signal amplitude and frequency is configured by country specific coefficients in loadware. Cadencing is under control of loadware. The SLMAR supplies balanced ring signal with nominal 22VDC offset. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 205 Due to the on hook current requirements there is a limit of two telephones per port on non-boosted battery loops, and one telephone per port on boosted battery loops. • COMTEL3 Messaging Format: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 206 Some models of terminal devices (payphones and other smart phones) draw loop current while on hook to support resident electronics. They may have rechargeable batteries or capacitors which require charging before the device becomes operational. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 207 -63VDC battery (minimum of 18mA) then boosted battery of +63VDC is switched on. The available DC supply is then +63VDC and A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 208 X3-26 X3-6 X3-48 X3-28 X3-8 X3-50 X3-30 X3-10 X4-42 X4-22 X4-2 X4-44 X4-24 X4-4 X4-46 X4-26 X4-6 X4-48 X4-28 X4-8 X4-50 X4-30 X4-10 Table 67 Pin Assignments Upper Connector A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 209 X8-24 X8-4 X8-46 X8-26 X8-6 X8-48 X8-28 X8-8 X8-50 X8-30 X8-10 X9-42 X9-22 X9-2 X9-44 X9-24 X9-4 X9-46 X9-26 X9-6 X9-48 X9-28 X9-8 Table 69 Pin Assignments Lower Connector A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 210 SLMAR A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 211 Service Information When using old analog devices on SLMAV boards that use a Ground Key for consultation, then COFIDX 6 must be set for the function to work correctly. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 212 SLMAV 4.21.1 SLMAV board Figure 72 SLMAV Figure 73 SLMAV board A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 213 FW or LW which executes on the board. 4.21.3.1 Function under FW Red LED Green LED Status Flashing BIST Mode Flashing Hardware Error Table 70 LED Statuses and Their Meanings under FW A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 214 At least one subscriber line circuit is activated. Table 71 LED Statuses and Their Meanings under LW The Power Supply of +5Vdc/-54Vdc will be provided over the System Backplane. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 215 Port 10 gry/red blk/blu Port 11 blu/blk blk/ora Port 12 ora/blk blk/grn Port 13 grn/blk blk/brn Port 14 brn/blk Table 72 SLMAV - SIVAPAC Connector Assignment on the Backplane A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 216 Port 24 brn/vio Table 72 SLMAV - SIVAPAC Connector Assignment on the Backplane RJ45 jack SLMAE8, SLMAE Table 73 SLMAV - Connector Panel Assignment with RJ45 Jacks A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 217 SLMAV RJ45 jack SLMAE8, SLMAE Table 73 SLMAV - Connector Panel Assignment with RJ45 Jacks A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 218 Port 15 15 Tip 16 Ring Port 16 16 Tip 17 Ring Port 17 17 Tip Table 74 SLMAV - Connector Panel Assignment with a CHAMP Jack (for U.S. only) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 219 Port 22 22 Tip 23 Ring Port 23 23 Tip 24 Ring Port 24 24 Tip Table 74 SLMAV - Connector Panel Assignment with a CHAMP Jack (for U.S. only) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 220 SLMAV A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 221 The system-to-terminal distance depends on the type of cable used. The 1000 m provided in this diagram is considered to be the maximum loop length specified by the Integrated Communications Cabling System (ICCS) without taking power feeding into account. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 222 The board is defective or out-of-service. The board is operational and all channels are inactive. Flashing The board is operational and one or more channels are active. Table 75 SLMO24 Board LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 223 3. When all channels are free, deactivate the board as follows: a) Type DEA-BSSU and press Enter. b) Type the following values, then press Enter. Field Value OFFTYPE <1> A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 224 Field Value ONTYPE TYPE PEN1 <PEN1> PEN2 <PEN2> IMPORTANT: PEN1 is the pen of the first channel and PEN2 is the pen of the last channel on the board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 225 WHT-SLT YEL-GRN SLT-WHT GRN-YEL RED-BLU YEL-BRN BLU-RED BRN-YEL RED-ORG YEL-SLT ORG-RED SLT-YEL RED-GRN VIO-BLU GRN-RED BLU-VIO RED-BRN VIO-ORG BRN-RED ORG-VIO Table 76 Standard Punch-Down Sequence (Seite 1 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 226 Wire Color Channel No. RED-SLT VIO-GRN SLT-RED GRN-VIO BLK-BLU VIO-BRN BLU-BLK BRN-VIO BLK-ORG VIO-SLT Not used. ORG-BLK SLT-VIO BLK-GRN GRN-BLK Table 76 Standard Punch-Down Sequence (Seite 2 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 227 One HDLC controller per port -> terminal units can be connected up with exclusive access to the D channel • High-performance processor • Memory, 512 Kbyte flash memory, 236 Kbyte RAM memory for data A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 228 (64 Kbps each) for the transmission of user data as well as a D channel (16 Kbps) for signal data. Telephones with U 0/E interfaces (direct) and telephones with S A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 229 (TRACE) on the peripheral board SLMO and SLMQ for each ACCESS (circuit) with the AMO PETRA. The AMO PETRA also makes it possible to display the contents of the memory on the board (DUMP). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 230 SLMOP A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 231 Figure 77 shows the SLMQ-PNTQ connectivity. OpenScape 4000 5,5 ... 9 km -Bus SLMQ PNTQ 2B1Q point-multipoint Network Figure 77 SLMQ, Connecting S Terminals By Means of PNTQ Adapter A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 232 Observe all precautions for electrostatic discharge. To remove the SLMQ board: 1. Deactivate all channels on the board as follows: a) Type DEA-DSSU and press Enter. b) Type the following values, then press Enter. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 233 1. Slide the board into the appropriate slot until you seat it firmly into the backplane connector. 2. Activate the SLM board as follows: a) Type ACT-BSSU and press Enter. b) Type the following values, then press Enter. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 234 SLM board punch-down sequence at the MDF. Cable punch-down is standard. Each channel uses one tip and ring pair. Label the block from channel 00 through 15 or 23, as appropriate A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 235 RED-GRN VIO-BLU GRN-RED BLU-VIO RED-BRN VIO-ORG BRN-RED ORG-VIO RED-SLT VIO-GRN SLT-RED GRN-VIO BLK-BLU VIO-BRN BLU-BLK BRN-VIO BLK-ORG VIO-SLT Not used. ORG-BLK SLT-VIO BLK-GRN GRN-BLK Table 78 Standard Punch-Down Sequence A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 236 SLMQ A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 237 OpenScape 4000 Optiset E HiPath 4000 Analog Analog (primary) device adapter Distance adapter 18,000 feet SLMQ3 (16 ports) U P0/E U 2B1Q 40000028 Figure 78 SLMQ3 Connectivity Example 1 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 238 SLM Board LED Indications 4.25.3 Removing the SLMQ3 Board IMPORTANT: This procedure removes up to 16 ISDN channels from service. NOTE: Static Sensitive Devices! Observe all precautions for electrostatic discharge. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 239 Replace the SLMQ3 board as follows: 1. Slide the board into the appropriate slot until you seat it firmly into the backplane connector. 2. Activate the SLMQ3 board as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 240 4.25.6 MDF Assignments The SLMQ3 board punch-down sequence is standard. Each channel uses one tip and ring pair. Label the block from channel 00 through 15 or 23, as appropriate. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 241 RED-GRN VIO-BLU GRN-RED BLU-VIO RED-BRN VIO-ORG BRN-RED ORG-VIO RED-SLT VIO-GRN SLT-RED GRN-VIO BLK-BLU VIO-BRN BLU-BLK BRN-VIO BLK-ORG VIO-SLT Not used. ORG-BLK SLT-VIO BLK-GRN GRN-BLK Table 80 Standard Punch-Down Sequence A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 242 SLMQ3 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 243 STHC PNTE only STHC -Trunk -Tie only STHC -Subscriber Subscriber -Tie Figure 80 Connection of Terminals to the STHC Board The STHC board provides digital U and S interfaces. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 244 Extended bus: approximately 500 m Short bus: approximately 150 m Both traffic types, point to point and point to multipoint are supported. 4.26.4 Board Variants S30810-Q2177-X (will be replaced by Q2169-X) S30810-Q2169-X A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 245 STMA board with multimode fiber optic interface (STMA-M) This variant provides a maximum range of 1.24 miles (2 km) for fiber optic transmissions. 4.27.1 Features An STMA board has the following configurable features: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 246 STMA boards cannot be shared between the two features. 13 11 9 7 5 3 1 14 12 10 8 6 4 2 40000022 Figure 81 Example of the Backboning Feature A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 247 • Red and green LED indicators provide error and status information (for details, refer to Table 81). • The fiber optic connector provides connectivity to the ATM network A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 248 The board is defective or out-of-service The board is operational and all channels are inactive. Flashing The board is operational and one or more channels are active. Table 81 STMA Board LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 249 If all four spans are used, then all four D channels must be deactivated. The D channels are numbered as 24, 49, 74, and 99. Using the PEN2 parameter to indicate a range of PENS is not allowed. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 250 This device uses laser technology that can cause eye damage when looked at directly. To replace the STMA board in a OpenScape 4000: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 251 To verify the operation of the STMA board, display the status of the board as follows: 1. Type DIS-SDSU and press Enter. 2. Type the following values, then press Enter. Field Value LINK <blank> <1 - 32> A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 252 STMA <1 - 15> SLOT <1 - 151> <blank> The board is automatically tested on activation. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 253 (to NT): 1000 m (3281 ft.). 4.28.1 LED Indications The front panel of the board contains 8 LEDs (see Table 82). Startup Table 82 STMD Board LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 254 AMO DIMSU • AMO REFTA • AMO PRODE Figure 84 Figure 85 shows STMD board connectivity diagrams. ISDN-PABX public ISDN STMD SLMD Figure 84 Connection PABX - Exchange (STMD) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 255 9 (STMD4) -t- Pins seized by the STMD board transmit -r- receive Table 83 Upper STMD connector Table 84 lists the pin assignments for the lower connector of the STMD board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 256 GNDE Electronic ground 234 X Board address bit 2 235 X Board address bit 3 -5 V Negative electronic voltage Table 84 Lower STMD connectors (Seite 1 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 257 Speech channel A-input to system 239 X GNDE Electronic ground 240 X +5 V Positive electronic voltage Pins seized by the STMD module Table 84 Lower STMD connectors (Seite 2 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 258 +5 V +5 V GNDA GNDE RCLK GNDA GNDE SPHO B SPHO A GNDA GNDE SPHIB SPHIA GNDA GNDE +5 V Voreilender Stift/longer pins Figure 86 STMD Connector Assignment A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 259 The front panel of the board contains 2 LEDs. • Flashprotection is on board. • The cabling to the MDF differs to the SLMS and STMD solution. STMD2 use a 24-twisted-wire cable with no protection. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 260 All circuits idle (no circuit has established a Layer2 connection) Flashing At least one circuit busy (at least one circuit has established a Layer2 connection) Table 85 LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 261 IMPORTANT: The STMI2 must not be plugged in and unplugged during live operation. Figure 87 shows the STMI2 board. Figure 87 STMI2 board 4.30.1 System Diagram Figure 88 shows a system diagram of the STMI2 board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 262 Quantity LEDs and Interface Indications and Purpose V.24 9-pin SUB-D connector For testing Green LED Run or Active status Red LED Fail status Table 87 STMI20 LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 263 STMI20 LED Indications Figure 89 shows the STMI2 board front panel. Green LED for RUN Red LED for FAIL V24 interfaces LAN interfaces Figure 89 STMI2 Board, Front Panel A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 264 Do you want to low-level format the flash file system y/[n]? y Formatting the flash file system! Format ok! If the Format is OK, enter <CTRL> x. Now the STMI2-board will reboot. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 265 Value obtained from file system volume descriptor pointer: 0x66c96a8 The old setting was THU JAN 01 00:00:01 1970 Accepted system dates are greater than THU DEC 27 00:00:00 1990 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 266 <CTRL> x - reboot (warm) [STMI2 Boot CLI]: y Format the flash file system, all files will be deleted. Do you want to format the flash file system y/[n]? y A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 267 STMI2 Do you want to low-level format the flash file system y/[n]? y Formatting the flash file system! Format ok! [STMI2 Boot CLI]: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 268 STMI2 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 269 IMPORTANT: The STMI4 is allowed to be hot plugged. Figure 90 shows the STMI4 board. Figure 90 STMI4 board 4.31.1 System Diagram Figure 91 shows a system diagram of the STMI4 board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 270 Quantity LEDs and interfaces Indications and Purpose V.24 9-pin SUB-D connector For testing Green LED Run or Active status Red LED Fail status Table 89 LED Displays and Interfaces A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 271 LED Displays and Interfaces Figure 92 shows the STMI4 board front panel. Green LED for RUN Red LED for FAIL V24 interfaces LAN interfaces Figure 92 STMI4 Board, Front Panel A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 272 The individual voltages required (+3.3 V, +2.5 V, +1.8 V and 1.2 V) are generated by the DC-to-DC converter on the board. The board is automatically reset if one of the voltages falls below the critical value. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 273 The following essential properties characterize the new TM2LP board: • Same functionality as the discontinued board in each case (refer to Table • Eight ports per board • Protection on the board A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 274 With the new HW platform using a Motorola microprocessor and a new LW Plattform this analog interface offers a greater flexibility to comply the previous boards functionality converging in one. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 275 AMO-COSSU: (Auth. for unrestricted long-distance service) ADD-COSSU: ,10, TA & (Tie trunk without toll code restriction) TNOTCR & (Central call charge registration) CDRC; AMO-ZAND CHA-ZAND: LOADWARE, TM2L, 0; AMO-COT: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 276 The meaning and the value for each parameter depends on the protocol used, AMO TACSU • Configuration for Trunk groups for DTMF ADD-TACSU: <ltg>-<ltu>-<slot>-2, <LAGE> <NO> <COTNO> <COPNO> <DPLN> <ITR> <COS> <LCOS> <LCOSD> <INIGHT> A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 277 ADD-RICHT:MODE=LRTENEW, LRTE=03, LSVC=VCE, TGRP=112, DNNO= *; * ≠ node number in AMO-ZAND AMO-LDAT: ADD-LDAT:LROUTE=03, LSVC=VCE, LVAL=1, TGRP=112, ODR=10, LAUTH=1; AMO-LDPLN: ADD-LDPLN:LDP=131-X, LROUTE=03, LAUTH=1; For Pseudo-DID additional: AMO-TACSU: CHA-TACSU:<ltg>-<ltu>-<slot>-<satz>,DEVTYP=TC,DIALTYPE=DTMF- DTMF,DIALVAR=4-0; A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 278 TM2LP AMO-COP: CHA-COP:20,COPADD,DTN; AMO-COT: CHA-COT:10,COTADD,IBSY&IVAC&INAU&ITB&IFR&INDG&IIDL&DTNE[&DTNI]; AMO-FEASU: CHA-FEASU:A,ICPTDID; A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 279 TM3WI/TM3WO. 4.33.1 Board Variants TM3WI: S30810-Q2477-X000 TM3WO: S30810-Q2476-X000 4.33.2 LED Indications The front panel of the board contains one and one green LED. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 280 CC1K: Connect C wire with 1K. CC: Connect C wire. Table 92 lists the edge-to-edge presentation between the CO and the line card on the three wires for any particular dc signaling protocol. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 281 Unilate Release ---> -(500- isol isol +(3K7- Guard 550) 12K) Blocking ---> X(+1 isol isol isol +(3K7- 12K) Table 92 Edge to Edge Electrical Presentation for Incoming Local Call A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 282 Tone Dialing P(1/ P(1/ Wait for Ring answer Back Answer Speech (DET. (DET. A for B for wire) wire) Table 93 Signal Sense and Control for Incoming Local Call A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 283 (also the start up state before circuit is configure Table 93 Signal Sense and Control for Incoming Local Call Table 94 lists the edge-to-edge presentation for an incoming toll call. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 284 +(3K7- Forward 12K) (when A-On hook Unilater Release ---> -(500- isol isol +(3K7- Guard 550) 12K) Table 94 Edge to Edge Electrical Presentation for Incoming Toll Call A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 285 Ack. Tone Dialing P(1/ P(1/ Extension Ring Free (B (DET. (DET. Back Free) A for B for wire) wire) Table 95 Signal Sense and Control for Incoming Toll Call A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 286 Unilater Release Guard Blocking X(0) X(0) X(0) X(0) X(0) 0 Reset (DET. (DET. A for B for wire) wire) Table 95 Signal Sense and Control for Incoming Toll Call A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 287 CABP: Connect A & B wires ready for dial Pulsing. CA: Connect A wire to 1K ohm. CP: Dial pulsing A & B wires. CCG: Connect C wire to Ground. Table 96 lists the edge-to-edge electrical presentation for an outgoing call. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 288 +22K al (A-On Forward (1150 hook) 1700) Unilater Release <--- isol isol +22K isol isol -(550- Guard 1300) Table 96 Edge to Edge Electrical Presentation for Outgoing Local Call A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 289 STATUS control DET. DET. DET. CP CC Idle X(0) X(0) Seizure Seizure Ack. Dial Tone (option Dialing X(0) X(0) Table 97 Signal Sense and Control for Outgoing Local Call A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 290 X(0) X(0) False Signal Table 97 Signal Sense and Control for Outgoing Local Call 4.33.3 Functions and Features for GUS The TM3WI/TM3WO board has the following analog trunk interface functions: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 291 TM3WI/TM3WO board. Pin # Signal Name Pin # Signal Name Pin # Signal Name +12V Table 98 TM3WI/TM3WO Board Upper Connector X1-X4 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 292 RCLK TCK* TMS* TDI* RGCL TDO* -12V Table 99 TM3WI/TM3WO Board Lower Connector X1-X4 Table 100 lists the pin assignments for the middle connector of the TE3WI/ TM3WO board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 293 TM3WO: Q2476- C_ A_ C_ A_ C_ A_ C_ A_ C_ A_ C_ A_ C_ A_ X000 Table 102 TM3WI/TM3WO Board OpenScape 4000 MDF A & B Wire Designation A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 294 0 - 500 Ohm Not relevant 550 - 1300 Ohm 1 KOhm 22 KOhm 1150 - 1700 Ohm Figure 96 Symbols for the Resistance on A-, B- or C-Wire A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 295 Figure 97 Seizure, Pulse Dial, B-Subscriber Free, Answer * Due to the insignificant current changing, the seizure ack. line signal cannot be detected. ** L1: Long timer 1 (see PTIME) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 296 Figure 98 Seizure, Pulse Dial, B-Subscriber Busy * Due to the insignificant current changing, the seizure ack.line signal can not be detected. ** L1: Long timer 1 (see PTIME) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 297 ( A On-hook ) Blocking * Release guard Idle * Optional, because some central offices do not send this signal Figure 100 A Goes On-Hook Before Dialing or Answering or After Answer A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 298 Clear backward Release forward Blocking * Release guard Idle * Optional, because some central offices do not send this signal Figure 102 A Goes On-hook After Answer (P14 = 1) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 299 ( A On-hook ) Blocking * Release guard Idle * Optional, because some central offices do not send this signal Figure 103 B goes On- or Off-hook After Answer A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 300 Release guard Idle Figure 105 A goes On-Hook after Answer, B Remains Off-Hook * Optional, because some central offices do not send this signal ** P9: Parameter 9 (see PTIME) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 301 S3 = 20 ms delay time for forward release transmission P9 = 10 min time between clear forward and sending MCID-message to P8 = 2 min A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 302 - 1 sec. unit (outgoing) 1 - 250 default: 1 (= 1sec) dial tone detection (outgoing) no detection (default) dial tone has to be detected answer supervision (outgoing) no supervision A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 303 (outgoing) no action system alarm with line testing system alarm without line testing(default) P14: release-variant (outgoing) LONIIS (default) output signal: release forward MGTS output signal: clear forward Shorttimer: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 304 S1 = 20 ms min. seizure ack.transmission time 300 ms min. B-free transmission time 300 ms min. B-busy transmission time 300 ms transmission time of B-busy with override 1500 ms A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 305 (outgoing and incoming) P5 to P10: reserve P11: reserve P12: manual busy override (incoming) no busy override busy override (default) P13: reserve P14: reserve A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 306 Longtimer: reserve reserve min. length of a qualified alarm 1000-30000 ms default: 10000 ms reserve reserve speech channel through connection delay time (incoming) 1000-30000 ms default: 100 ms reserve A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 307 Table 103 TMANI protocols Beyond the existing features of these protocols, TMANI board will support the following features: • Clip Detection (Calling Line Identification Presentation); • Busy Tone Detection; A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 308 4.34.3 Hardware Variants • TMANI: S30810-Q2327-X100, with GEE, with ground start • TMANI-IM: S30810-Q2327-X101, without GEE, without ground start • TMANI-BRA: S30810-Q2327-X182, only for Brasil, without GEE, without ground start A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 309 IMPORTANT: According to U.S. and Canadian installation instructions, analog trunks must be connected over fuse elements in compliance with UL 497A or CSA C22.2 No. 226. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 310 Red LED Green LED Status Action Board not receiving power or not Check plug contact on plugged in correctly. board. Board is out of order. Table 105 TMANI - LED Statuses A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 311 The jumpers must be closed for countries that support the "Ground- Start" feature (the U.S. and Canada). The jumpers must remain open for other countries that support the "Loop-Start" feature. Figure 108 TMANI Jumper position A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 312 Port 5 grn/ red/ Port 6 blu/ red/ Port 7 ora/ red/ Port 8 grn/ red/ Free brn/ Table 106 TMANI - SIVAPAC Connector Assignment on the Backplane A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 313 Free grn/ yel/ Free blu/ Table 106 TMANI - SIVAPAC Connector Assignment on the Backplane RJ45 jack TMANI Notes Table 107 TMANI - Connector Panel Assignment with RJ45 Jacks A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 314 TMANI RJ45 jack TMANI Notes Free Free Free Free Free Free Free Free Free Free Free Free Free Free Table 107 TMANI - Connector Panel Assignment with RJ45 Jacks A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 315 Port 7 7 Tip 8 Ring Port 8 8 Tip Free Free Free Free Free Free Table 108 TMANI - Connector Panel Assignment with CHAMP Jack (for U.S. only) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 316 CHANGE-COSSU:TYPE=LCOSV,LCOSV=1,COPIN=0; CHANGE-COSSU:TYPE=LCOSV,LCOSV=1,INFO="LCR ATTENDANT FOR VOICE"; ADD- COP:COPNO=40,PAR=DTMF&SFRM&RLSA&BR64&TDED&NO1A&DITW&TIM1&NSDL&ID P2&DTM1; CHANGE-COP:COPNO=40,COPTYPE=COPADD,DEV=INDEP,INFO="TMANI-DTMF"; ADD-COT:COTNO=40,PAR=XFER&CHRT&NTON; CHANGE-COT:COTNO=40,COTTYPE=COTADD,DEV=INDEP,INFO="TMANI-DTMF"; ADD-LODR:ODR=99,CMD=ECHO,FIELD=2; ADD-LODR:ODR=99,CMD=END; ADD-LODR:ODR=99,INFO="NQ A2 OPEN"; COPY-PTIME:INIBLOCK=119,TBLK=13; ADD-TACSU:PEN=1-2-79- 0,COTNO=40,COPNO=40,DPLN=0,ITR=0,COS=8,LCOSV=1,LCOSD=1,TGRP=40,C OFIDX=0,CCT="8102159AB001",DESTNO=0,ALARMNO=2,CARRIER=1,ZONE=EMP TY,LIN=0,CIDDGTS=NONE,CBMATTR=NONE,SRCGRP=0,CLASSMRK=EC&G711&G72 9AOPT,TCCID=" ",DITIDX=0,TRTBL=GDTR,RULEIDX=0,INS=Y,DEVTYPE=TC,DEV=TMANIMSG,MF CVAR=0,DGTPR=4808,SUPPRESS=0,DGTCNT=0,TESTNO=1,CIRCIDX=13,CDRINT =1,CCTINFO=0,DIALTYPE=DTMF-DTMF,DIALVAR=0-0,COEX=0; ADD-RICHT:MODE=LRTENEW,LRTE=40,LSVC=VCE,NAME="HKZ-TMANI ",TGRP=40,DNNO=1,REROUT=NO,DTMFTEXT="",ROUTATT=NO,EMCYRTT=NO,INF O="",PDNNO=0,CHARCON=NEUTRAL,CONFTONE=NO,RERINGRP=NO,NOPRCFWD=NO ,NITO=NO,CLNAMEDL=NO,FWDSWTCH=NO; A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 317 Belgium 270+750// 270+750// 140 97 0 150n 150n Banglad 97 6 Bolivia 220+820// 220+820// 97 6 115n 115n 190+1400 //105n 400+590// Brazil 65 6 Table 109 Ptime values for countries A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 318 Denmar 270+750// 270+750// 140 97 0 150n 150n Ecuado 220+820// 220+820// 97 6 115n 115n Egypt Egypt 220+820// 220+820// 97 6 115n 115n Table 109 Ptime values for countries A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 319 65 6 Hondur 220+820// 220+820// 97 6 115n 115n Hungar 270+750// 270+750// 140 97 6 150n 150n Indones 65 6 India -0,5 65 6 Table 109 Ptime values for countries A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 320 150n Luxemb 270+750// 270+750// 140 97 0 ourg 150n 150n Malaysi 400+700// -0,5 65 1 200n Morocc 270+750// 270+750// 97 6 150n 150n Table 109 Ptime values for countries A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 321 115n 115n Pakista 400+700// -0,5 65 6 200n Panam 100+820// 97 6 -5,8 -1,3 400+700// 200n Paragu 220+820// 220+820// 97 6 115n 115n Table 109 Ptime values for countries A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 322 Senegal 220+820// 220+820// -7,9 97 6 115n 115n -4,9 -5,9 Singapo 400+700// 140 97 1 200n Sloveni 270+750// 270+750// 140 97 0 150n 150n Table 109 Ptime values for countries A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 323 United 270+750// 270+750// 140 97 0 Kingdo 150n 150n United 97 6 States America Venezu 220+820// 220+820// 97 6 115n 115n -5,8 -1,3 Table 109 Ptime values for countries A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 324 14 0 97 6 310n //220n 370+620// 13 0 310n Zimbab 400+700// 97 6 200n Table 109 Ptime values for countries SL = Short Line LL = Long Line A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 325 - analog X200 - 2 dBr - 4 dBr SUR 3 X300 - 0 dBr - 2 dBr SUR 4 Table 111 TMBD, DIP-FIX Switches for Line Adaptation A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 326 TMBD board. SPU 1 SPU 3 SPU 4 SPU 2 SUR 1 SUR 2 SUR 3 SUR 4 SUT 4 SUT 1 SUT 2 SUT 3 Figure 109 TMBD Board A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 327 TMC16 Block Diagram 4.36.1 LED Indications The front panel of the TMC16 board (Figure 111) contains two LEDs. Refer to Table 112 for LED indications of the TMC16 board A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 328 The board is operational and all channels are on the on- hook state. Flashing The board is operational and one or more channels are in the off-hook state. Table 112 TMC16 Board LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 329 3. Wait for all LEDs to reach a fast flashing state (this indicates that the board is down). 4. Using the board extractor, unseat the board and remove it from the shelf. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 330 Table 113 shows the U.S. standard trunk board punch-down sequence. Each channel uses one tip and ring pair. Label the block from channel 00 through 15 or 23, as appropriate. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 331 GRN-RED BLU-VIO RED-BRN VIO-ORG BRN-RED ORG-VIO RED-SLT VIO-GRN SLT-RED GRN-VIO BLK-BLU VIO-BRN BLU-BLK BRN-VIO BLK-ORG VIO-SLT Not used. ORG-BLK SLT-VIO BLK-GRN GRN-BLK Table 113 TMC16 Board MDF Punch-Down Sequence A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 332 TMC16 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 333 Call charge pulse detection (50 Hz, 12 kHz, 16 kHz) • Signaling systems – MOSIG – Loop-Start – Ground-Start Figure 112 shows the side view of the TMCOW board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 334 TMCOW Board 4.37.1 Module Variants Table 114 lists the variants of the TMCOW board. Variant Q2288- Country PRC (ASEAN) X110 X120 H, IRL X300 X310 Table 114 TMCOW Board Variants A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 335 4.37.5 Loop Grounding To set loop grounding, set the DIP switches as follows: Switch 7 ON: a-wire grounded with 27 Ω • Switch 8 ON: b-wire grounded with 360 Ω • A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 336 2 dB (km) 3 dB (km) 2 x 62.5 2 x 135 Table 119 TMCOW, Line Attenuation Values Table 120 lists the countries of application for the TMCOW and reference boards. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 337 Broadband Switch Version PTIME P9=1 (13-33Hz) PTIME (13-80Hz) PTIME P9=2 P9=0 S30810-Q2288- up to -Q2288-X-7 ab S30810-Q2288-X-8 S30810-Q2288- up to -Q2288-X10-4 ab S30810-Q2288- X10-5 Table 121 TMCOW Board Hardware Compatibility A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 338 X50-4 S30810-Q2288- ab S30810-Q2288- X60-1 S30810-Q2288- ab S30810-Q2288- X100 X100-1 S30810-Q2288- up to -Q2288-X120-2 ab S30810-Q2288- X120 X120-3 S30810-Q2288- ab S30810-Q2288- X130 X130-1 Table 121 TMCOW Board Hardware Compatibility A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 339 4.38.1 LED Indications The front panel of the TMDID board (Figure 114) contains eight channel and blocking status LEDs. Table 122 lists the LED indications for the TMDID board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 340 A front panel changeover switch for manually selecting a channel by cycling through the channels until the status LED for the desired channel flashes • A front panel blocking switch for manually blocking the selected channel A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 341 3. Wait until all LEDs on the board are flashing. 4. Using the board extractor, unseat the board and remove it from the shelf. 4.38.4 Replacing the TMDID Board Replace the TMDID board as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 342 4.38.6 MDF Assignments In the U.S., cable punch-down is standard (refer to Table 123). Each channel uses one tip and ring pair. Label the block from 00 through 07. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 343 RED-GRN VIO-BLU GRN-RED BLU-VIO RED-BRN VIO-ORG BRN-RED ORG-VIO RED-SLT VIO-GRN SLT-RED GRN-VIO BLK-BLU VIO-BRN BLU-BLK BRN-VIO BLK-ORG VIO-SLT Not used. ORG-BLK SLT-VIO BLK-GRN GRN-BLK Table 123 Standard Punch-Down Sequence A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 344 TMDID A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 345 IMPORTANT: Outbound calls cannot be routed over TMDID trunks. The board has eight trunk circuits that connect to analog trunks. The board supports the protocols Wink Start, Delay Dial, and Immediate Start. Figure 115 TMDID2 Board Type A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 346 Green LED Status Action Board not receiving power or not Check plug contact plugged in correctly. on board. Board is out of order. Table 124 LED Statuses and Their Meanings A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 347 (Tip) (Ring) Connector wht/ Port 1 blu/ wht/ Port 2 ora/ wht/ Port 3 grn/ Table 125 TMDID2 (for selected countries only) - SIVAPAC Connector Assignment on the Backplane A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 348 11 blk/blu free blu/blk blk/ free ora/ blk/ free grn/ Table 125 TMDID2 (for selected countries only) - SIVAPAC Connector Assignment on the Backplane A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 349 TMDID2 (for selected countries only) - SIVAPAC Connector Assignment on the Backplane RJ45 jack TMDID2 Notes free free free Table 126 TMDID2 (for selected countries only) - Connector Panel Assignment with RJ45 Jacks A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 350 1 Ring Port 1 1 Tip 2 Ring Port 2 2 Tip Table 127 TMDID2 (for selected countries only) - Connector Panel Assignment with a CHAMP Jack (for U.S. only) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 351 Port 8 8 Tip free free free free free free free free Table 127 TMDID2 (for selected countries only) - Connector Panel Assignment with a CHAMP Jack (for U.S. only) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 352 3. Wait until all LEDs on the board are flashing. 4. Using the board extractor, unseat the board and remove it from the shelf. 4.39.5 Replacing the TMDID2 Board Replace the TMDID2 board as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 353 1. Type DIS-SDSU and press Enter. 2. Type the following values, then press Enter. Field Value LINK <Blank> <1 - 32> <1 - 8> SLOT <1 - 151> <blank> A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 354 TMDID2 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 355 ISDN CorNet-VN interface: The TMDNH board can be configured to support CorNet-VN operation. 4.40.1 LED Indications Figure 117 shows the LED indicators on the front panel of the TMDNH board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 356 The link is in a red alarm condition. The link is in a yellow alarm condition. The link is not in an alarm condition. Table 129 TMDNH Board, Link Status LED Indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 357 The board is deactivated when the yellow LED is lit and the other LEDs are off. 3. Before removing the board, ensure that the red board status LED is lit, remove the board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 358 To verify the operation of the TMDNH board: 1. Confirm that the LPB LED (red) stops flashing. 2. Confirm that the second LED (red) from the top comes on. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 359 4. Confirm that the top LED (green) lights. 5. Confirm that the red board status LED stops flashing and goes off. 6. Confirm that the green board status LED comes on or is flashing. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 360 TMDNH A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 361 MDF, for example, a ring generator. 4.41.1 Board Variants Q2012-X100 FRG/Austria for WTK1 signaling A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 362 COFIDX = 0 FRG short line COFIDX = 1 FRG long line (-2dB) COFIDX = 2 Austria 4.41.5 Configuring the TMEM Board on the Satellite PABX Using AMOs • AMO COT ANS&NTON&KNOR&ASAT&CONS; optionally: CHRT A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 363 IMPORTANT: This procedure will remove all the channels on this trunk board from service. NOTE: Static Sensitive Devices! Observe all precautions for electrostatic discharge. To remove the TMEM board: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 364 2. Slide the board into the appropriate slot until you seat it firmly into the backplane connector. 3. Activate the board as follows: a) Type ACT-BSSU and press Enter. b) Type the following values, then press Enter. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 365 TMEMW and TMEMUS boards punch-down assignments. Pair No. Wire Color Channel No. Lead Designation WHT-BLU BLU-WHT WHT-ORG ORG-WHT Table 131 TMEM Board Punch-Down Assignments (Seite 1 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 366 GRN-WHT WHT-BRN BRN-WHT WHT-SLT SLT-WHT RED-BLU BLU-RED RED-ORG ORG-RED RED-GRN GRN-RED RED-BRN BRN-RED RED-SLT SLT-RED BLK-BLU BLU-BLK BLK-ORG ORG-BLK Table 131 TMEM Board Punch-Down Assignments (Seite 2 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 367 LTUW or L80XF shelf backplane TMEMUS Tip xmit Switching unit LTUC shelf Ring xmit board TMEMW backplane board Tip recv Ring recv LTU signal cable 40000018 Figure 118 TMEMUS Board Block Diagram A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 368 4.42.3 Connectors and Switches The TMEMW or TMEMUS board (Figure 119) contains: • Four front panel channel and blocking switches (Figure 120 Figure 121) • Switch packs for standard M signaling A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 369 Ch. 1 Ch. 2 Ch. 3 Channel 3 Channel 2 Channel 1 Channel 0 ON OFF 40000020 Figure 120 TMEMW and TMEMUS Board Jumper Settings for Standard M Signaling (ON) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 370 Ch. 1 Ch. 2 Ch. 3 Channel 3 Channel 2 Channel 1 Channel 0 ON OFF 40000021 Figure 121 TMEMW and TMEMUS Board Jumper Settings for Inverted M Signaling (OFF) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 371 3. Using the board extractor, unseat the board and remove it from the shelf. 4.42.5 Replacing the TMEMW or TMEMUS Board Replace the TMEMW or TMEMUS board as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 372 Verify the operation of the TMEMW or TMEMUS board by displaying its status as follows: 1. Type DIS-SDSU, then press Enter. 2. Type the following values, then press Enter. Field Value STATUS LINK <blank> TYPE LEVEL PER3 <1 - 32> A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 373 ORG-WHT WHT-GRN GRN-WHT WHT-BRN BRN-WHT WHT-SLT SLT-WHT RED-BLU BLU-RED RED-ORG ORG-RED RED-GRN GRN-RED RED-BRN BRN-RED RED-SLT SLT-RED BLK-BLU BLU-BLK BLK-ORG ORG-BLK Table 133 TMEMW and TMEMUS Boards MDF Assignments A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 374 TMEMW and TMEMUS A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 375 U-law or A-law companding of the voice signal • Access to PCM highways with flexible time slot channel selection • HDLC link to communicate with the PBXs switching unit A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 376 2. Turn off the board. 3. Reconfigure the board. 4. Assign the expanded line data to the lines by means of the index (CIRCIDX). 5. Turn on the lines and the board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 377 Table 136 Weighted noise level Table 137 lists the transverse conversion loss (TCL) of the TMEW2 board. Frequency (Hz) Min (dB) 300 - 3400 Table 137 Transverse conversion loss A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 378 TMEW2 board. Pin # Signal Name Pin # Signal Name Pin # Signal Name RING +12V -48V DIAL1 -60V Table 140 Lower connector pin assignment A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 379 Observe all precautions for electrostatic discharge. To remove the TMEW2 board: 1. Deactivate all channels as follows: a) Type DEA-DSSU, and then press Enter. b) Type the following values, and then press Enter. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 380 Type ACT-BSSU and press Enter. b) Type the following values, and then press Enter. Field Value ONTYPE <1 - 32> <1 - 8> SLOT <1 - 151> 4. Activate the channels as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 381 <blank> TYPE LEVEL PER3 <1 - 32> <1 - 8> SLOT <1 - 151> <0 - 15> 3. Verify that all the green LEDs on the board are off. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 382 TMEW2 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 383 Settings Loss in the TACSU 600 Ω 600 Ω PZGTBOB0 0 -7/0 long 600 Ω 600 Ω -5/-2 short Table 141 TMLBL Board Loadware Variants (Seite 1 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 384 TMLBL Board Line Attenuation Values 4.44.3 Functions of the Board Operation • Incoming seizure AC ringing voltage The receiver sensitivity ranges from 10 to 90 Hz. • Answering Speech path switched through A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 385 Since the answering criterion is not transmitted back down the transit line, exchange and tie-traffic callers must not be able to reach a local battery line by direct dialling; calls must be extended by the attendant. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 386 This standard operating mode is used for connections to local battery stations, or to remote (duplex) transmitters. Lines can be operated without or with release signal (P1=1:"ring off") and release acknowledgement (P2=1). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 387 DTMF signals. This is useful if a shortage of better tie-lines or transit lines occurs, or if none exist, and allows the remaining local battery lines in a system to be used as tie-lines. All attendant intercept options must be activated. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 388 Add data for pseudo-DTMF-dialling at local battery stations: AD-COT:COTNO=aa,PAR=NTON&RCL&INDG&IIDL&IVAC&IBSY&INAU &ITB&IDND&IFR&IDIS&BRAR(&CHRT&LWNC&IEVT&OVRA); AD-COP:COPNO=bb,COPPAR=RLSA&FDGT&LSUP; COP-PTIME:48,c; CHA- PTIME:TYPE=REST,INIBLOCK=c,BTYPE=PARA,P1=1,P3=0,P7=0,P8=0,P9= AD-TACSU:PEN=?-?-?- ?,CNT=?,COTNO=aa,COPNO=bb,...DEVTYPE=TC,DEV=OB, DGTPR=*,SUPPRESS=0,DGTCNT=0,...CIRCIDX=c,...,DIALTYPE=DP- DP,DIALVAR=0-0; 4.44.4 Configuring the TMLBL Board Using AMOs To configure the TMLBL board use the following AMOs: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 389 • AMO BCSU BCSU:TYPE=PER,LTG=<LTG>,LTU=<LTU>,SLOT=<SLOT>,PARTNO=Q2123-X; BCSU:TYPE=ACGEN,LTG=<LTG>,LTU=<LTU>,SLOT=<SLOT>,PARTNO=Q2058- OPMODE=SY50H85V; (for 25 Hz: OPMODE=SY25H85V) • AMO ZAND AMO ZAND:LWTYPE=TBOB, LWVAR=0 (default) CHA-ZAND:LWTYPE=TBOB,LWVAR=1 (UK) • AMO BUEND AD-BUEND:TGRP=xxx,NAME=???,NO=?,RSV=Y; • AMO WABE AD-WABE:CD=yyy,DAR=TIE(/CO),CHECK=N; A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 390 TMLBL • AMO RICHT AD-RICHT:TYPE=CD,CD=yyy,SVC=VCE,TGRP1=xx,DNNO=?; • AMO COT AD-COT:COTNO=aa,PAR=NTON&LWNC&IEVT&OVRA; • AMO COP AD-COP:COPNO=bb,PAR=RLSA&FDGT&LSUP; • AMO TACSU AD-TACSU:PEN=<lgt>-<ltu>-<slot>- <cct>,CNT=??,COTNO=aa,COPNO=bb, ..TGRP=xx,..DEVTYPE=TC,DEV=OB,...DIALTYPE=DP- DP,DIALVAR=0-0; A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 391 D/A -2 dBr A/D -6 dBr D/A -1 dBr S102 S202 Table 143 TMLR Board DIP-FIX Switches 4.45.3 Signal Exchange Signal interchange and electrical characteristics are specified as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 392 SICOFI parameters of the TMLR board. COFIDX CTRY Level (dBr) Remark A/D D/A A/D D/A -6 -1 0 -7 -5 -2 0 -7 Short line 0 -7 Long line Table 144 SICOFI parameter A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 393 A/b-wire feed • Loop current detection • Incoming pulse signal or MFC-R2 / MFC-Socotel through SIU • Feed voltage reversal • Timed deactivation of feed voltage • A/b-wire splitting A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 394 TMLRB Figure 122 Figure 123 show the side views of two TMLRB board variants. W1-4 Figure 122 TMLRB Board (Q2286-X) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 395 TMLRB board Q2286-X variant. Country Input Artificial Line Line Loss Line < 3 dB 370+(620//310nF) 300+(1000//220nF) -5,0/-1,0 ≥ 3 dB 370+(620//310nF) 300+(1000//220nF) -8,0/+2,0 Table 146 TMLRB Board Loadware Variant Q2286-X A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 396 Ref. No. Inde Q2286- PZG.. long/short TMLSF Q2086-X2 TMLS2 0 / 1 RSA X long TMLSF Q2086-X1 TMLS1 2 Table 148 TMLRB Board and Reference Boards Countries of Application A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 397 Each equipment requires different analog interfaces; from 2-wire connection up to 6-wire connection. The following sections describe the different interfaces. Paging systems (PSE) 2-Wire connection–for paging systems provides the following features: • Monitoring A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 398 Entry of the central operating console of the paging system signalled by pulsed crossover of the a/b-wires or by pulses on the c-wire. 4-Wire connection—for paging systems provides the following features: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 399 Signalling, dialling information by means of the a/b-wires. • Earth potential by means of low impedance on the c-wire before seizure by means of loop on the a/b-wires. • Seizure acknowledge: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 400 • Seizure acknowledge depending on the loop current in the a/b-wires. • Release acknowledgment by means of the c-wire for releases by the system. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 401 2x1000 Ω; this depends on the voltage of the partner equipment or system. In case of a 3-wire connection the c-wire determine the line length because of its required low impedance. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 402 Boundary scan: Test mode select Input 2-50 Boundary scan: Test data input Input 2-51 Boundary scan: Test data output Output Table 149 TMOM2 Board, Physical interface to the OpenScape 4000 Backplane A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 403 The busy status of each circuit is indicated by a separate LED as follows: • The first key selects the circuit • The second key locks the circuit 4.48.3 Loadware Variants • PZGTSFP0 (China - CSN1/Railway) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 404 IMPORTANT: You must set the switches before plugging the board into the shelf. DIP-FIX Switches Variants for HARRIS exchanges (+ 425 Hz) GUS41 2600 HZ HARRIS Table 151 TMSFP Board DIP-FIX Settings for Variant Q2147-X400 (Seite 1 von A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 405 -2,5 -4,5 -2,0 -5,0 -1,5 -5,5 -1,0 -6,0 -7,0 DA = Digital switch to Analog line AD = Analog line to Digital switch Table 152 Transmission Parameters A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 406 TMSFP A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 407 VCM B-channels in one node must lead to a corresponding number of switchable VCM B-channels in the partner node. IMPORTANT: The correct symmetry is the responsibility of the system administrator! A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 408 LAUTH parameter of the AMO). • For call data recording purposes, no special compressed connection attribute is necessary. The current CDR functionality is sufficient for compressed voice connections (e.g.: ZONE / CARRIER). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 409 The nailed connections for voice compression connections must be switched symmetrically in both nodes. IMPORTANT: The nailed connections for voice compression connections must be switched symmetrically in both nodes. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 410 VCM boards on the second shelf. The board can be installed in any free slot in an LTU half. Remember the maximum number of 128 timeslots for every LTU half. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 411 • VCM (under equipped) / 9 TSLs Table 155 Shelf Configuration of VCM Boards with STMD Board On Shelf Figure 124 shows a functional diagram of the VCM board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 412 Hicom side for transmission to the switching network. The VCM emulates a normal DIUN2 board on the system side, and the connection is accordingly switched through to the station line by the call processing system. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 413 B- channel between the two VCM boards. Figure 125 shows an example of a transit connection. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 414 B-channel compressed B-channel Figure 125 Transit Connection Example 4.49.8 Mixed Mode Operation, Voice and Data Figure 126 shows an example of mixed mode operation for voice and data. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 415 Certain station line types, for example, analog fax or modem lines, are not automatically recognized by call processing as data lines, and are therefore not automatically disabled for voice compression. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 416 VCM Voice Compression These lines must be expressly protected from voice compression with the aid of administration and maintenance commands, e.g. using the standard LCR control mechanisms. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 417 Two UACD power boxes IMPORTANT: Two DC-to-DC shelf power supply units (PSUP) on the LTUW shelf If a Powerbox is used as a battery backup, a DC-to-DC power supply is necessary. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 418 The power FRUs on a DC-powered, redundant OpenScape 4000 system are: • Two DC-to-DC shelf power supply units (PSUP) on the CSPCI shelf • Two DC-to-DC shelf power supply units (PSUP) on the LTUW shelf A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 419 The ACPCI converts AC power to DC. The AC input voltage is 90-264 VAC from the utility outlet that provides power to the system (nominal input voltage 110/230 VAC). The nominal input frequency is 50/60 Hz (tolerance: 47-63 Hz). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 420 For the DCPCI, only 48 VDC (tolerance: 36-72 VDC) is directly connected to the back of the backplane. The individual output voltages are: +3.3 V (33 A), + 5 V (33 A) and +12 V (5 A). Figure 128 ACPCI/DCPCI Power Supply A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 421 Cherokee (S30122-K7682-C1) Cable variants: 3-pin for IM: C39195-Z7001-C17 or 3-pin for NA: C39195-Z7001- (IM = International Market, NA = North America) DCPCI: Magne Tek (S30122-K7683-M1) Cherokee (S30122-K7683-C1) Cable variant: S30805-H5298-X14 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 422 To replace the ACPCI, tighten the two screws on each side of the power supply unit. 5.5.6 Verifying the ACPCI/DCPCI To verify the ACPCI or DCPCI, ensure that the green LED is lit. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 423 29..V1 Adjust 5..6 30..V1 Remote Sense 31..Data In 3..4 32..V2 Adjust 33..V2 Remote Sense 1..2 34..Sense Return 35..V1 Current Share 36..V3 Remote Sense Figure 130 ACPCI Input/Output Assignment A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 424 45 Hertz (Hz) and 66 Hz (LPC80 WR Artesyn 50-60 Hz). The LPC80 occupies slot 16 on the L80XF shelf. It distributes the voltages to the shelf power supplies through backplane connectors. LPC80 (WR = Wide Range) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 425 Part Number LPC80: S30122-K7162-X (Artesyn) Part Number LPC80: S30122-K7163-X (Celestica) Part Number LPC80: S30122-K7554-X (Magnetek) Part Number LPC80 WR: S30122-K7554-A (Artesyn) Weight: approximately 4.3 kg (9.5 lbs.) Design: Plug-in unit for 2-slot shelf A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 426 LPC80, battery charger mode: *) Nom. Min. Max. Limit Rated Min. Over voltag voltag voltag power power current range 54,7V 54,3V 55,1V 60V 470W 9A-10A 53,5V 53V 470W 9A-10A A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 427 • Operating switch: I - O • Operation indicator: green LED • Modular power cord, 3-pin: power supply unit LPC80, “ERNI H15” pin assignment (15-pin) Slot EBP B2 016 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 428 The LPC80 has one green LED that is lit when all output voltages are within tolerance (see Figure 133). The LED is off if any DC output voltage is not within tolerance or if AC power is lost. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 429 5.6.4 LPC80 Connectors and Switches The front of the shelf power supply has a receptacle for AC supply cable and a switch for turning the unit on or off (see Figure 133). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 430 5. Plug the AC power supply cable to the wall outlet. 6. Turn on the switch on the LPC80. 5.6.7 Verifying the LPC80 To verify the operation of the LPC80, confirm that the green LED status indicator is lit. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 431 (charging voltage: 54.7 VDC) – Mode 2b: as a battery charger (flashing LED) for wet-cell batteries requiring low charging voltage (53.5 VDC) The LUNA 2 provides voltages specified in Table 157: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 432 Power FRUs LUNA 2 Figure 134 LUNA 2 - Front view A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 433 Power FRUs LUNA 2 Figure 135 LUNA 2 - Back view Figure 136 LUNA 2 (Front and Back View) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 434 Logic signals SI 2 (SLC) current+sens Si 3 (reserved) PFL (DC NGA (AC Power Fail) Power Fail) Identify PIN_A0 Identify Identify PIN_A3 PIN_A1 Table 157 LUNA 2 PIN Assignment A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 435 To verify the LUNA 2, observe the green LED on the front panel. • If the LED is lit, the voltages are OK • If the LED is flashing, the battery is charging properly. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 436 It also occupies slot 16 in a redundant LTUW shelf. Switch Green LED Left PSUP Right PSUP Figure 137 PSUP, Front View Table 158 lists the LED indications of the PSUP. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 437 2. Tighten the screws to secure the PSUP to the shelf. 3. Turn on the PSUP. 5.8.4 Verifying the PSUP To verify the operation of the PSUP, ensure that the green status LED is lit. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 438 5.9.1.1 ACDPX Connectors and Switches The ACDPX (Figure 139) have: • Receptacles for the AC power module input cables • Switches to turn on or off the AC power modules individually A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 439 Do not wear an ESD strap when working on the backup battery. IMPORTANT: This procedure removes the OpenScape 4000 system from service. To remove the ACDPX: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 440 4. Remove the junction box. 5. Remove the tie wrap that secures the AC supply cable to the ACDPX. 6. Unplug the AC supply cable. 7. Remove the ACDPX. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 441 Power FRUs UACD ACDPX AC supply cable Junction box Pressure connectors Figure 140 Removing the ACDPX from the UACD 5.9.1.3 Replacing the ACDPX To replace the ACDPX: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 442 X6 and X7 are not used in the U.S. • Contactor control input • Battery power input The power share and battery input are not used in the U.S. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 443 2. Slide and secure the BAM into the UACD with screws. 3. Reconnect the cables to the applicable BAM circuit board receptacles. 4. Turn on cabinet 1 or cabinet 2, as applicable. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 444 A fully charged backup battery provides power for up to 2 minutes. To verify operation of the BAM, ensure that the OpenScape 4000 system returns to normal operation. 5.9.3 EBCCB IMPORTANT: The EBCCB is not used in the U.S. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 445 6 LTU frames are installed in the entire system when battery management is used, then the power box is configured with two PDPXs and two EBCCBs. Figure 142 EBCCB - Back view A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 446 LPC is routed to the PDPX2 through a cable on the front of the LPC. 5.9.4.1 LPC LED Indications The front of the LPC has two status LEDs (see Figure 144). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 447 ACDPX. The LPC routes output voltages and signals to a terminal block along the left side of the PDPX2 and to a connector along the right side of the PDPX2. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 448 4. At the front of the LPC, connect the output cable connector to the output receptacle. 5. Fasten the two clips onto the output cable connector. 6. At the front of the LPC, plug the AC input plug into the AC input receptacle. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 449 –48 V TALK NEXT CAB, circuit breaker for stack 2 or 4 • POWER SHARE, circuit breaker for current share between two power shelves (when applicable) This is not used in the U.S. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 450 AC power module circuit breakers. 5. Remove the two screws that secure the PDPX2 to the upper and lower front shelf supports. 6. Remove the PDPX2 from the shelf. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 451 LPC1 connector -48V bulk -48V talk LPC2 LPC2 connector -48V bulk next cab -48V talk next cab LPC3 connector LPC3 Power share Screws (not shown) Figure 145 PDPX2 (Front View) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 452 4. At the back of the UACD, replace the battery manager (refer to Section 5.9.2.3, “Replacing the BAM”). 5. Turn on OpenScape 4000 stack 1 or 2, as applicable. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 453 2. Verify the talk circuit breakers by ensuring that the LED on the ring generator board in each cabinet is lit. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 454 For a detailed technical description please refer to the service information INF- 06-000663: https://www.g-dms.com/livelink/ livelink.exe?func=ll&objId=3617209&objAction=view&nextURL=%2Flivelink%2F livelink%2Eexe%3Ffunc%3Dsrch%2ESearchCache%26cacheId%3D58504281 Information for installation of an OpenScape 4000 System please refer to the relevant Installation Instruction. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 455 UACD (PSR930/PSR930E). It consists of the following 19-inch mounting units: • Primary Shelf UACD-A (with the QS841E controller board) • Secondary Shelf UACD-B A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 456 The equipment comes with all circuit breakers already equipped. • The UACD expansion cabinet (UACD Scondary Shelf) has the same structure as the base cabinet minus the base controller. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 457 0,1 °C Safety and Standards Electrostatic Discharge IEC61000-4-2 Radiated Emissions FCC Class A, CISPR 22 level A Safety UL recognized component Table 160 Technical parameters for UACD (Lineage Power) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 458 5.12.1 ICBP The input circuit breaker panel (ICBP) is the main power distribution point for OpenScape 4500 DC systems. The ICBP supplies –48 V power to the Zytron modules (ZYTs). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 459 Three Anderson quick connectors to the three Zytrons for input power • ZYT1, ZYT2, ZYT3, ZYT input cables Screws not shown Screws Figure 149 ICBP, OpenScape 4500, Front View A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 460 5. Remove the nuts that secure the ICBP cable conductors to the circuit breaker terminals. 6. Remove the ICBP power cable. 7. At the back of the ICBP, label and disconnect all cables. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 461 120 VAC receptacle to perform the ECOS ground path impedance test (5A2). Refer to the power and grounding kit instruction booklet. The following are recommended ground reference points: • Effectively grounded metal conduit or metal receptacle outlet A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 462 The front of the panel contains two circuit breakers that distribute the -48 V bulk and talk to the circuit breakers in cabinets stack 1 and 2 or 3 and 4. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 463 DC power modules (up to 3), and four FASTON lugs for reporting power supply alarm status to the ADP. Figure 150 ODP, Front View A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 464 To remove the ODP: 1. Turn off the respective OpenScape 4000 cabinet stack. 2. At the back of the ODP panel, label and disconnect all cables. 3. Remove power on the ICBP. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 465 Reconnect the failure sense wires. c) Reconnect the three DC power module (Zytron) cables. d) Reconnect the cabinet stack1 and 2 talk cables, as applicable. e) Reconnect the power fail cable. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 466 The SUPV receptacle is for the 4-pin RJ11 failure sense wire connector to the ODP panel. • The Input -48 VDC receptacle is for the 2-conductor connector of the input power cable from the ICBP. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 467 Remove the failure sense wire from the ODP and ZYT. b) Remove the current share wire from the ZYT and the adjacent ZYT. 3. At the back of the ZYT, disconnect the input power cable connector. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 468 –48V TALK power supply connectors connector To COCA Zytrons To base unit To NEXT CAB power Figure 154 DD (Back View) 5.12.3.4 Replacing the ZYT Replace the ZYT as follows: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 469 2. At the back of the ZYT, insert the volt-Ohm-millimeter (VIM) probes into the upper connector. See Figure 154 for assistance in determining the connections. 3. Ensure that the VIM indicates that approximately –48 VDC is present. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 470 You will find a detailed description of these power supplies at the following link adress: http://www.lineagepower.com IMPORTANT: The initial installation for the UDCD and their documentation will be covered by local company in US. Figure 155 Lineage Powerbox (complete configuration) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 471 6.1 Attendant Console (AC-Win IP) AC-Win IP is the first enhanced attendant console type connected to OpenScape 4000 via IP. Detailed informations see in the Service Manual for the Attendant Console AC-Win IP. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 472 Devices Attendant Console (AC-Win IP) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 473 Hard disk is inside but is not used by raid. blinking Blue light up and RED light is Hard disk is in HDTR and in use and must not be blinking removed. Table 161 LED indications A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 474 SATA connector on the fringes of the SATA module (in the picture below it is marked with '2' ). Figure 157 HDTR - cabeling A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 475 S30122- X8014-X18 (SATA 2,5”, 250GB HD) 6.3.2 LED Displays The front side of the board features includes • one LED for Drive “A” (Drive Activity) • one LED for Drive “P” (5V Drive Power) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 476 NOTE: The eSATAp cable may be removed only if no HD is inside the tray. 6.3.4 Update and Migration Concept Please refer to Section 4.5.7, “Update and Migration Concept”. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 477 (12 V, ground (GND), speed signal). The fan trays are connected to the backplane by a connection cable. Figure 160 indicates the position of fan trays in the CSPCI shelf. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 478 Fan Tray Fan trays Fan ports Figure 160 Fan tray position Figure 161 shows the numbering of fans. Figure 161 Numbering of fans A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 479 PORT ... Figure 162 DIUN Board IMPORTANT: The AMOM adapter (part number: S30807-K5480-X100 / -X200 / -X300) is not compatible with the APCFL (S30807-K5422-X) and APCFM (S30807-K5446-) adapters. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 480 AMOM. Power Supply State [mA] Sender (maximum) Receiver Total capacity Dissipation State [mW] Sender circuit 67.5 Receiver circuit 262,5 Table 164 Power Supply and Dissipation A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 481 Adapter AMOM Total dissipation Table 164 Power Supply and Dissipation A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 482 Adapter AMOM A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 483 Position Effect Connection Switch S1/1-2 Tx port of the DPNSS connection grounded Line 1 S1/3-4 Rx port of the DPNSS connection grounded Line 1 Table 165 Connection Examples and Cabeling A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 484 APPCU Route 1 Line 2 System port LTU shelf OpenScape 4000 Backplane Figure 163 APPCU Arrangement on OpenScape System Figure 164 shows the pin assignments on a Canon receptacle. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 485 Rx (Gnd switchable by S2/3-4) Ground Tx (Gnd switchable by S2/1-2) Figure 164 Pin assignments on Canon receptacle Figure 165 shows a connection example of line one with 120 Ohms. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 486 120-Ohm cable. 120 Ohms S30267-Z89-A Canon connector strip 15-pin Canon receptacle strip, 9-pin Figure 166 120-Ohm Cable Figure 167 shows another connection example of line 2 with 75 Ohms. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 487 75-Ohm cable. 75 Ohms TNC screw connector TNC screw connector S30267-Z90-A100 Figure 168 75-Ohm Cable Figure 169 shows a cabling diagram between CDG to the British Post. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 488 Canon connector BNC bayonet 15-pin Alarm wires 75 Ohm S30267-Z89-A Figure 169 CDG - British Post Cabling BNC bayonet S30267-Z83-A British Post 15p. Alarm wires Figure 170 CDG Cabling A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 489 IMPORTANT: An optical transmission route must generally be constructed with fiber of the same diameter along the entire path. The use of fibers with different diameters will result in unnecessarily high attenuation at transition points (spliced A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 490 For optical connections, fiber with a bandwidth of ≥ 160 MHz based on 1 km (3 ft) is recommended. The maximum range depends on the fiber types used (refer to Table 166: Table 166 lists the types of optical cables and its ranges. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 491 2 is possible. Full operational status can only be achieved with the connection of 2 adapters. 7.3.5 Characteristic Values for Optical Connections Table 168 lists the characteristic values for the APCFL optical adapter. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 492 = -34 dBm Receiving dynamics min. = 24 dB = -33 dBm ± 3 dB Low Power Detection (red LED) peak Table 169 Characteristics of the APCFM optical adapter A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 493 (SLMQ) is the master frame clock and bit clock. Table 170 lists the UCON board pin designation. Pin Number UCON-S/UCON-M Designation Table 170 Pin Designation of the U Plug on UCON-S/UCON-M Board 2B1Q (Seite 1 von 2) A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 494 Optiset-line telephones to the UCON through one 6-pin mini Western jack (RJ12). Pin Number Designation Table 171 Pin Designations of the U Plug on the UCON-S/UCON-M Board A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 495 UCON-S and UCON-M shall use the same power supply plug with the pins listed in the following table: Table 174 lists the pin number and designations of the UCONs for the power supply jacks. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 496 PSP-4 South-Africa A7-2176-3301 S30122-K5065-X-* PSP-5 USA, Canada A7-2176-6601 S30122-K5066-X-* PSP-6 Australia Table 175 Country Specific Power Supplies Table 176 lists the pin designations for the external power supply plug. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 497 Miniwestern plug RJ45. The power supply has a power jack and operates with 110V/60Hz and 230V/50Hz input voltage as well. A switch is not available to select between these voltages. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 498 UCON U-Converter Pin Number Designation 48...58V 48...58V Table 177 Pin Designation of the External Power Supply Plug A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 499 7. Insert the power-up module into the hot plug connector of the board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 500 4. Position the adapter module over the backplane connector of the board. Ensure that each adapter module’s outer edge corresponds with each outer edge of the board as shown in Figure 173. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 501 8. Perform steps 3 through 7 for the other adapter module. Adapter modules Power-up module To SIVAPAC backplane Catch hook Catch hook Component side Board LEDs 40000039 Figure 173 SIPAC to SIVAPAK Board Adapter 2 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 502 Adapter 1/2 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 503 _highlights_hinweise.fm Highlights and Hints Software Software 1 Highlights and Hints Aktuelle Ausgabe Product Rebranding HiPath 4000 V7 -> OpenScape 4000 V7 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 504 _highlights_hinweise.fm Highlights and Hints Software A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 505 > IP Dirstributed Architecture (IPDA) > OpenScape 4000 LAN Segement”)). Routing to the access points/OpenScape 4000 SoftGates, which is configured for CC-A or CC-B, must also be configured in the OpenScape 4000 Assistant in this case. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 506 The virtual HG 3575 does not require a LAN connection because the LAN connectivity runs internally between IPDA LAN and vHG 3575. This means connection 1 in the next diagram is obsolete for scenarios with OpenScape 4000 SoftGate. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 507 In the case of a OpenScape 4000 SoftGate, it is also possible to have interfaces 2 and 3 run over a physical address. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 508 “Standard Linux Server for standard server deployment”(This means upgrading to cPCI server) • Standard Linux Server for standard server deployment • OpenScape Access • RG 8350 A • EcoServer A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 509 Atlantic LAN IP and MAC addresses are used by the virtual machines for the ADP and for the CCs. Moreover, all ADP services that are present in HiPath 4000 V6 are also available in OpenScape 4000 V7. For an overview please refer to Section 2.1.1, “LAN Interfaces for DSCXL2 Processors”.
  • Page 510 Based on DSCXL2 board the duplex configuration of OpenScape 4000 is realized in one cPCI shelf. The OpenScape 4000 basic shelf contains • two DSCXL2 boards - slot 1 and slot 5 and • one HDTR - slot 3. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 511 Thus, an OpenScape 4000 Assistant/OpenScape 4000 CSTA/OpenScape 4000 platform Administration (portal) is only active on that node on which the virtual machine for the ADP is active. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 512 This is achieved by the DRBD (Distributed Replicated Block Device) software, which replicates the relevant files over the LAN. The current DRBD status can be checked under OpenScape 4000 Administration > Status > DRBD Status. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 513 Section 2.3.5, “Switch Over Scenarios for Duplex and Separated Duplex”. 2.3.4 Separated Duplex Operation OpenScape 4000 separated duplex offers a higher resilience of call control / SWU due to different locations of the communication servers. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 514 (cluster ressources). The data transported via the Atlantic and Corosync LAN is not encrypted and should therefore take place via a trusted network. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 515 • 2x OpenScape 4000 cPCI Communication Server with one DSCXL2 Blade, • one HDTR Blade and • 2x HDDs plus the required software licenses: • OpenScape 4000 Basic License, A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 516 NOTE: Standalone mode only can be used on Separated Duplex and only on node A or node B (not for the Quorum node). Only one of those nodes can have standalone operation enabled at the same time. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 517 • no data loss (e.g. billing, configuration data, etc.). • other virtual machines (ADP, OpenScape 4000 Assistant, OpenScape 4000 CSTA, OpenScape 4000 platform Administration (portal)) are not affected. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 518 (portal) on node A will be turned offline, and the ADP, OpenScape 4000 Assistant, OpenScape 4000 CSTA and OpenScape 4000 platform Administration (portal) on node B will be started up. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 519 • To the external applications, an ADP failover appears as a connection loss and a loss of dynamic data. Thus, the external applications need to reconnect to the ADP. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 520 ADP on node B is active already. Error #4: The node with the active ADP and Quorum node are out of order IMPORTANT: Only valid for separated duplex! A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 521 ADP, OpenScape 4000 Assistant, OpenScape 4000 CSTA, OpenScape 4000 platform Administration (portal) and webservice get active on node 2 . Shut down and start-up are at the same time. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 522 E1 (S2M) (primary rate interface 30 channels) • T1 (primary rate interface 24 channels) • Analog • Native SIP (SIP service provider) Networking interfaces • Basic Rate S0 / Primary Rate E1 (S2M) / T1 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 523 OpenScape 4000 or on the hard disk. All three table types are administered in CmCntrl (CLT type with APL element for applications and SEL for selections) and delivered as subsystems to the APSs. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 524 Subsystems not listed in a selection are always loaded onto the hard disk (HD). 2.6.2 SWU In the following sections you will find information about the Applications Loading Tables of the SWU. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 525 AMOs DBC and APC for a given ARCHITECTURE and a given ARCHITECTURE TYPE. 2.8 Hard Disk The hard disk is part of the DSCXL2 board. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 526 ADD- DLSM:A1,1,F,":DBDA:"&":DBD:"&":TMD:"&":PAS:"&":AMD:"&":DMP:"; ADD-DLSM:A1,1,G,":CGD:"; ADD-DLSM:A1,1,H,":DMS:"&":DSY:"; ADD-DLSM:A1,1,I,":SCR:"; ADD-DLSM:A1,1,J,":GLA:"; ADD-DLSM:A1,1,K,":DIAG:"; Set up of a virtual hard disk on controller 4 (for system backup) ADD-DCSM:A1,4,HD,"STDH6"; ADD- DASM:A1,4,7200&1600&2400&1120&16384&7200&9868,4096&4096&4096&409 6&4096&4096&4096; ADD-DLSM:A1,4,E,":PDS:"; ADD- DLSM:A1,4,F,":DBDA:"&":DBD:"&":TMD:"&":PAS:"&":AMD:"&":DMP:"; ADD-DLSM:A1,4,G,":CGD:"; ADD-DLSM:A1,4,H,":DMS:"&":DSY:"; A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 527 SPoA (Single Point of Access). • offers a security & logging concept and supports secure access solutions (caller ID, callback, encryption,..) for customer connections. • offers provision of standardized remote software with HiSPA. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 528 Service Plug-in. This Service Plug-in connects supported customer systems and products via fast and secured internet connection to our central remote service infrastructure. Figure 13 Smart Services Delivery Platform - SSDP A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 529 Automatic collecting and fast transfer of diagnostic data. • Real-time Inventory Management for supported products. • Easy, fast, secure and standardized remote access. For more information please refer to the SEN intranet: A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 530 OpenScape 4000 Remote Access A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 531 CSTA III protocol, based on the encoding types ASN.1 (Abstract Syntax Notation One) and XML (eXtensible Markup Language). The software can be installed as a OpenScape 4000 integrated installation. For more information please refer to OpenScape 4000 V7, OpenScape 4000 CSTA and Phone Services, Service Documentation. A31003-H3170-S102-4-7620, 11/2015...
  • Page 532 OpenScape 4000 CSTA A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 533 RMX and Linux applications to a backup copy file and restore the data as required. This means that an accurate backup copy of the data and/or software is available in the event of a system failure. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 534 Possible users are customer administrators and service technicians that manage OpenScape 4000 systems. • Session Management – Change Password – Session Manager • License Management Tool • License Management A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 535 Sign CSR signieren – Import Certificate Authority for distribution • Security Mode Configuration • Configuration of PKI Authentication • Customize Banner on Login Page Utilities • XIE web service A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 536 IP boards, and for creating, editing (i.e. updating) and deleting additional user accounts as well. The application is accessible for administrators only and ensures secure password distribution. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 537 Test Simulation of Key Function Activity (TSKA) The TSKA application enables the OpenScape 4000 Assistant user to display and simulate OptiSet, optiPoint and OpenStage devices at a customer's site. TSKA displays: – display messages, A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 538 AMOs and OpenScape 4000 Assistant, but without OpenScape 4000 Manager. Section 4.4.3, “Networks with OpenScape 4000 Manager” addresses networks involving AMOs, OpenScape 4000 Assistant and OpenScape 4000 Manager. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 539 UPLOL, EXEC-UPLO2, that is, AMO commands that read the switch configuration). 7. The OpenScape 4000 Assistant updates its database using the information just queried from the switch. Figure 14 Notification Mechanism A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 540 You can find the following Frequqently Asked Questions (FAQ) in this section: • What happens if I use AMO commands to change the switch configuration, bypassing the OpenScape 4000 Assistant? A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 541 3. the switch configuration (processor speed, number of processors, amount of RAM, etc.). A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 542 AMO batch is large enough, it will eventually overflow the notification queue (see What happens if I execute a lot of AMO commands in a short period of time, A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 543 4.4.3 Networks with OpenScape 4000 Manager IMPORTANT: For informationen on networks with OpenScape 4000 Manager please refer to OpenScape 4000 Manager V7, Installation and Service Manual, Service Documentation. A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 544 OpenScape 4000 Assistant Notification Mechanism and Usage Scenarios A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 545 SIUX Board LED Indications ..........156 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 546 TM3WI/TM3WO Board Lower Connector X1-X4 ....... 292 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 547 TMLRB Board and Reference Boards Countries of Application..... 396 Table 149 TMOM2 Board, Physical interface to the OpenScape 4000 Backplane ....402 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 548 Hard disk layout ............526 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
  • Page 549 MCM board............. 117 A31003-H3170-S102-4-7620, 11/2015 OpenScape 4000 V7, System Components (Hardware, Software), Service Documentation...
