- Page 1 SDXI-U2 Serial ASCII Data Exchange Interface General Description Version 1.15 Date: 08.02.2010 copyright © Stemin GmbH, 2009 – 2010. All Rights Reserved.
- Page 2 SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 Document version version date Name Remark 1.14 30.11.2009 - R. Wuppinger - initial version: after the SDXI-U2 documentation, 23.12.2009 Command set requires Automixer (SW Version 1.24 or higher) 1.15 22.01.2010 R. Wuppinger - command “U2DMxDS=…”...
-
Page 3: Table Of Contents
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 Contents General description.....................5 Protocol SDXI ......................5 Protocol Extension SDXI-U2 (ASCII Mode)............5 Serial Parameters....................5 Availability of Telegrams..................5 Note: Enabling Remote Control ................5 Telegram Specification................... 6 Commands......................7 Definition of General Command Parameter ............7 Version Commands .................... - Page 4 SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 © Stemin GmbH SDXI U2 Protocol Description V1.15.doc page 4 of 15...
-
Page 5: General Description
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 1 General description 1.1 Protocol SDXI The SDXI-U2 (Serial Data Exchange Interface) should allow interacting, controlling and maintaining a variety of different devices. The serial interface was designed without any higher protocol function like a handshake or something equal. This interface allows the communication of embedded devices with a PC and/or among each other. -
Page 6: Telegram Specification
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 1.6 Telegram Specification The following table shows the structure of the SDXI-U2 telegrams: Byte Byte Meaning value / example Index Quantity start byte ‘U’ (0x55H): Start of Telegram telegram version ‘2’ (0x32H): signals that a SDXI-U2 telegram follows (ASCII mode) 2 …... -
Page 7: Commands
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 2 Commands 2.1 Definition of General Command Parameter Parameter Symbol Range Description transmission to data will be send/transmitted to the device the device (device receives data) transmission data will be send/transmitted from the device from the device (device transmits data) Telegram... -
Page 8: Version Commands
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 2.2 Version Commands 2.2.1 Software Version („U2DM<d>SW?<CR>“) Telegram Description This command requests the actual software U2DM<d>SW?<CR> version/info of the device. U2DM1SW?<CR> U2DM<d>SW=<p1>,<p2>,<p3><CR> Device returns the software version: <p1>: SW-Version: (e.g.: 102 = 1.02) <p2>: Application Type 5: Digital Automixer 4 / 2 / 2 <p3>: OEM Version (reserved) -
Page 9: Device Configuration
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 2.3 Device Configuration 2.3.1 Set Baudrate („U2DM<d>COM<c>BD=<bd>“) Telegram Description This command sets the baudrate of the specified U2DM<d>COM<c>BD=<bd><CR> COM port of the device: <c> = COM port 0: COM port actually connected to the device 1: COM 1 of the device 2: COM 2 of the device... -
Page 10: Encoder Commands
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 2.4 Encoder Commands 2.4.1 Encoder Request Value („U2DM<d>EN<e>?<CR>“) Telegram Description This command requests the actual value of the U2DM<d>EN<e>?<CR> selected encoder. <e>: selected encoder U2DM1EN2?<CR> Request the value of encoder 2 <e>: encoder nr = 2 ... -
Page 11: Encoder Rotate Right („U2Dm
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 2.4.3 Encoder Rotate Right („U2DM<d>EN<e>RR<CR>“) Telegram Description U2DM<d>EN<e>RR<CR> This command executes a rotate right action at the selected encoder. <e>: selected encoder U2DM1EN2RR<CR> Executes a rotate right action at encoder 2 ...En Rr ") -
Page 12: Status Commands
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 2.5 Status Commands 2.5.1 Request Channel Status („U2DM<d>CS<c>?<CR>“) Telegram Description U2DM<d>CS<c>?<CR> This command requests the status of the selected channel from the device <c>: selected channel U2DM1CS2?<CR> Requests the channel status of channel 2 ... -
Page 13: Channel Status Set Mute („U2Dm
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 2.5.3 Channel Status Set Mute („U2DM<d>EN<c>MU=<mut><CR>“) Telegram Description U2DM<d>EN<e>MU=<mut><CR> This command sets the mute state of the encoder <e>: selected encoder <mut>: Mute State U2DM1EN2MU=1<CR> Mutes encoder/channel 2 U2DM<d>EN<e>=<scs>,<ev>,<mut>, returns the settings of the selected channel: <onl>,<pkl><CR>...En Mu= ") -
Page 14: Set Device Status Remote Update Time („U2Dm
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 2.5.5 Set Device Status Remote Update Time („U2DM<d>DST=<t><CR>“) Telegram Description U2DM<d>DST=<t><CR> With this command you can set the time period (= t*100 ms) the device automatically sends a the device status telegram containing the status of all channels within one telegram: <t>: time period t*100 ms...Dst= ") -
Page 15: Virtual Talk Station Commands
SDXI-U2 Serial ASCII Data Exchange Interface General Description V1.15 2.6 Virtual Talk Station Commands 2.6.1 Set Virtual Talk Station State („U2DM<d>VTS<vts>=<st><CR>“) Telegram Description This command allows switching of the input U2DM<d>VTS<vts>=<st>[,<p1>]<CR> channels 1...6 of the digital automixer similar to a talk station.
