Summary of Contents for hogar SMART IR HC-IRC-ZW-IN
- Page 1 SMART IR SMART REMOTE SERIES #Magic...
- Page 3 WELCOME TO THE HOGAR IoT WORLD Welcome to Hogar Controls © World of Smart IoT Solution for Smart Spaces. Thank you for trusting us with your space & choosing SMART IR This manual is designed to help you install your SMART IR in an easy and hassle-free manner.
- Page 4 SMART IR TABLE OF CONTENTS 1. USAGE NOTICE 1.1. Warnings and Considerations 1.2. Precautions 2. PRODUCT DETAILS 2.1. Description 2.2. Product Details 2.3. Technical Specifications 3. INSTALLATION 4. APP SETUP 4.1. Login 4.2. Registration...
- Page 5 SMART IR TABLE OF CONTENTS 5. CONFIGURATION 5.1. Adding the IR Controller 5.2. Removing the IR Controller 5.3. IR Settings 5.4. Universal Remote 5.5. Learning Commands 6. RESET 7. PROTOCOL WARRANTY...
- Page 6 Install this device by following the socket type mentioned. Using this product in any manner other than how it this document VOIDS your warranty is referred to in Further, Hogar Controls is NOT liable for any damage incurred due to the misuse of the product.
- Page 7 Avoid pressing hard on the device body, reset button, and connecting ports. This is an electronic device with complex components. Handle and install with care! Kindly take into consideration range performance of the wireless connectivity while installing the device Kindly take into consideration the following as the range and performance of the wireless control systems are highly dependent on them: - Distance between the devices.
- Page 8 1.2. PRECAUTIONS Ensure the below DOs & DON'Ts are followed to enjoy a seamless product experience: - TURN OFF the product before cleaning. - Clean the product with a soft dry cloth. DON'Ts - DON'T drop or disassemble the device. - DON'T touch the device with sharp or hard objects.
- Page 9 2.2. FEATURES - Controls all infra-red household appliances with an IR CONTROLLER (Z-Wave). - Can be controlled using Hogar Pro S/ Hogar Mini S mobile applications. - Can be controlled through voice commands using Google Assistant and Amazon Alexa.
- Page 10 2.3. TECHNICAL SPECIFICATIONS Product Number HC-IRC-ZW-IN Stand by Power ≤0.5W infrared distance 5-6 meters (affected by the environment) Connection type 2.4GHz 802.11b/g/n Operational 0-50°C Temperature Operating humidity ≤85%RH Voice control Compatible with Amazon Alexa and Google Assistants. IR Control Direction Multiple Way Z-Wave Radio Protocol...
- Page 11 4. APP SETUP 4.1. LOGIN - Users can access the Hogar Pro S/ Hogar Mini S Mobile application (Depending on the type of controller you use) by downloading it from either the Play store or App Store. After...
- Page 12 - Enter the Email and the Password in the fields provided and click on the Login button to log into the application as shown in the above screen. Create your account using the Register button if you are a new user.
- Page 13 4.2. REGISTRATION - Click on the Registration button that appears on the screen to create a new user account in the Hogar Pro S/ Hogar Mini S Mobile application. By clicking the Register button, you will be redirected to the Registration tab as shown below.
- Page 14 1. Enter the Email ID/ Phone number in the field provided and click on the Get verification code button as shown above. 2. Enter the password in the field provided. 3. Re-enter the password in the “Confirm new password” field. 4.
- Page 15 You will receive a notification as “Account successfully created” as shown below.
- Page 16 5. CONFIGURATION 5.1. ADDING IR CONTROLLER - Put the controller in pairing or inclusion mode (follow the instructions in the controller's manual) - Press and hold the configuration button until the green led blinks (four times). - A confirmation message is sent by the controller when the device has been added successfully.
- Page 17 5.3. IR SETTINGS - Standard remote - Click the right-side menu. - Pick Add IR from the dropdown menu. - Pick a remote type from the default list, choose the Manufacturer. - Tap "Yes" to confirm your remote after choosing the desired model from the available remotes.
- Page 18 5.5. LEARNING COMMANDS • Click "Add to room" after choosing the type of IR remote to be added. - Click on the IR after choosing "Room" where the remote is allocated. • Press the button and choose the "Learn" option. •...
- Page 19 7. PROTOCOL Z-Wave is a wireless communication protocol that is designed specifically for home automation devices. It operates on a low-power mesh network, which means that all the devices in a Z-Wave network can communicate with each other directly, without the need for a central hub.
- Page 20 Warranty Hogar offers an Exclusive 18-Month Warranty on any product that covers defects in materials and quality under normal use of the Product. The Terms and Conditions of this 1.5 YEARS LIMITED WARRANTY can be viewed on www.hogarcontrols.com or scan...
- Page 21 CONGRATULATIONS You've completed the installation of your smart IR. You can now use your Hogar Pro S/ Hogar Mini S App to control smart your IR seamlessly. Add more devices to your home with our smart home solutions and live smarter.
- Page 22 Hogar Pro App. Add more to your home from our range of smart home automation solutions and live the smart life. Hogar Controls Inc, 46040 Center Oak Plaza, Suite 125, Sterling, Virginia 20166 | Phone : +1 703 844 1160 INDIA Sandhya Techno-1, Khajaguda X Road, support@hogarcontrols.com...
