Summary of Contents for Jaton Video-88PCI-16
- Page 1 Video-88PCI-16/32 Video-88PCI-16/32 Plus nVIDIA TNT2 Vanta ™ nVIDIA RIVA TNT2 M64 ™ User’s Manual version 4.00 C o p y r i g h t © 1 9 9 9 J a t o n C o r p o r a t i o n , U S A...
- Page 2 Contents INTRODUCTION...............4 Great output, reasonable performance......4 The power to propel you ahead .........4 FEATURES.................5 Graphics Architecture............5 2D Acceleration..............5 3D Graphics Processor .............6 Support for Standards ............6 Video ................7 VIDEO SCALER PIPELINE..........7 SYSTEM REQUIREMENT ..........8 CHECK LIST ..............9 HARDWARE DESCRIPTION...........9 HARDWARE INSTALLATION........10 ..........10 NSTALLATION...
- Page 3 PINOUT AND SYNC FREQUENCIES ......17 (DB 15) ......17 NALOG OLOR ISPLAY INOUTS ........17 ONVERSION ABLE DAPTERS -15 P .........18 ONVERSION ABLE ............18 ECHNICAL UPPORT LIMITED WARRANTY.............19 ..............20 THER IMITS ............20 XCLUSIVE BLIGATION ............21 THER TATEMENTS ............21 ERMS AND ONDITIONS : ............22 ERVICES AGREEMENT...
- Page 4 VRML, Web Browsing, Video Conferencing, Video Capture and Playback and more. Equally important, all popular PC standards are supported, including VGA, SVGA, Direct3D and DVD. Video-88PCI-16 and Video- 88PCI-32Plus (nVIDIA TNT2) technologies have the graphics fired up to launch you ahead of the competition right from the start.
- Page 5 Features Video-88PCI-16 (nVIDIA TNT2 / Vanta™) and Video-88PCI-32Plus (nVIDIA TNT2 / M64™) are fulfilling of all the requirements of the mainstream PC graphics market. Graphics Architecture Video-88PCI-16 and Video-88PCI-32Plus (nVIDIA TNT2) architectures process 2 pixels-per-clock cycle enabling single-pass multi-texturing. nVIDIA TNT2’s 32-bit color pipeline, 24-bit Z-buffering, 8-bit stencil buffer...
- Page 6 • Multi buffering (Double, Triple, Quad buffering) for smooth animation 3D Graphics Processor The nVIDIA TNT2’s 3D triangle setup and rendering pipeline represents a major advance graphics device integration. The nVIDIA TNT2 3D pipeline maintains the highest vertex, Z-buffer, texture filtering and rendering accuracy and yet maintains super high rendering throughput to achieve visually stunning interactive 3D: •...
- Page 7 • VESA DDC2B+, DPMS, VBE 2.0 supported Video Video-88PCI-16 and Video-88PCI-32Plus are accelerate full motion video playback under DirectDraw using hardware overlay scaling and color space conversion integrated into the Palette-DAC pipeline. This overlay pipeline features smooth up and down scaling with multitap X and Y sub- pixel interpolation, optional edged enhancement and per-pixel color keying.
- Page 8 that the conversion does not exceed the output range. Four control flags in the color converter provides 16 sets of color conversion coefficients to allow adjustment of the hue and saturation. The brightness of each R G B component can also be individually adjusted, similar to the brightness controls of the monitor.
- Page 9 ± MS Windows® 95/98 or Windows NT™4.0 operating system ± USB supplemental driver for mainboard’s core-logic chipset Check List Video-88PCI-16 Accelerator, or Video-88PCI-32Plus Accelerator Software & Documents CD Quick Start Guide (Printed) Hardware Description PCB Layout PCI's Plate PCBLayout & Specification...
- Page 10 Hardware Installation Installation Procedures !! WARNING !! Discharge static electricity by touching the GROUND such as metal part of your case connected with good power ground before you handle the electronic circuit boards. The manufacturer assumes no liability for any damage, caused directly or indirectly, by improper installation of any components by unauthorized service personnel.
- Page 11 Insert the display Driver CD into your CD-ROM drive (e.g. X:). Autorun file pops up “Welcome” screen (Master Installer) from Jaton’ CD. Click on the “Display Driver” selection bar. Switch to “Settings” tab, then click on “ Advance” button.
- Page 12 Click on “Change”, then “Have Disk”. Browse to “X: \V-88\Win9x\Jaton.INF” (X is the letter of your CD-ROM drive), and click OK. The display device selected “Video-88AGP/PCI- 8/16, nVIDIA Vanta/Vanta LT”, or “Video-88PCI- then press on OK 32Plus, nVIDIA RIVA TNT2 M64”...
- Page 13 settings page of Display Properties and then SELECT the “Test” button in the same page to determine whether your selection works properly. SELECT “Apply” to active the selected mode. Note: The procedure of display driver installation it required setup with service pack3 (Microsoft® Windows NT™4.0) first.
- Page 14 Explain and Suggestion: Windows® 95 Inadvertently, certain configuration files (e.g., msdos.sys, and command.com) have been changed in the system. Proceed to correct that, is re-boot the system with a system (Windows® 95) formatted floppy diskette. There are many reasons to causing the system booting-up with un- appropriated steps.
- Page 15 setup the display frequency without loading video driver. Try to turn it off, or change settings of monitor type in your system. Q: Selection of color, resolution and refresh rate combination that always backs to default after restart the system. Explain and Suggestion: Accordingly, there must be a bug (defected source-code) in video driver, or in the system.
- Page 16 demands for memory bandwidth. Without a set-up engine in a graphics controller, the CPU has to calculate the delta values for edges, color, and textures; the drivers need to handle ten (10) times more extensive data. This results in slower 3D pipeline operations between the CPU and the graphics controller.
- Page 17 Pinout and Sync Frequencies Analog Color Display Pinouts (DB 15) FUNCTION Red Video 1 Green Video 1 Blue Video 1 Not Used Ground Red Return (ground) Green Return (ground) Blue Return (ground) Vcc (+5v DDC Power) Sync Return (ground) Monitor ID (not used) SDA (DDC support) Horizontal Sync Vertical Sync...
- Page 18 Technical Support In the event you have a technical problem with this product, please read the README files in the software CD_ROM. Updated drivers are available through Jaton Web site. Have following information handy when you contact technical support: þ...
- Page 19 (2) years from manufacturing date. This limited warranty applies only to the original purchaser of Jaton Product and is not transferable. This limited warranty does not apply if failure to the Product Registration, or over thirty (30) days from purchase (original invoice date).
- Page 20 Jaton Products interfaces. Proof of purchase will be requiring before any consideration by Manufacturer occurs. Other Limits. The forgoing is in lieu of all other warranties, expressed or implied.
- Page 21 Limited Warranty. Terms and Conditions. Direct Jaton Customer: This warranty applies only for a period of two (2) years from purchase date of Jaton original invoice. Reseller/ Vendor: This warranty applies only for a period of two (2) years from manufacturing date.
- Page 22 Services agreement: (1) All applicants shall completed service request form from Manufacturer. (2) All returned checks would be charged a $20.00 fee by Manufacturer. (3) All repair and replacement services allow 4-6 weeks from the date of receiving by Manufacturer. (4) All products without warranties require service processing fee $20 (payment in advance), which is not refundable.
- Page 23 • Read your manuals before installing peripherals and/or before making changes to the machine’s configuration; • Ask your dealer if there are any known problems with the system requirements or installation procedures for any add-on products that your are purchasing; •...
- Page 24 For Reseller / Vendor Use Only Serial Number - ten or eleven digit code, the serial number consists of the following parts: Packaging Type Manufactured Date Code Production Numerical Code 99 5 000015 Year Month XXXXX-XXXXX S/N: A995000015 123456789123456789123456789123456789abcdefghijklmnop XXXXX 00.0 XXXX XX XXXXXXXX Product Label and Manufactured Date Code...
