- Page 1 CERAMIC COOKTOP Instruction Manual Model Name: LT4-56 Product size : 770x520 mm Built in size : 740x490 mm Voltage : 220 - 240 V, 50/60 Hz Power (total): 8600 W Customer Service 9 AM-5 PM, Mon-Fri +1 (888) 907-5060 (Toll Free)
- Page 2 CONTENTS ·Important safety instructions ……………………………….…..……..……..1 ·Installation ….....................2-4 ·Connect to the power supply ……………………………..…….…...…...4-5 Diagram of the radiant cooktop · …………………………………...….….…5 ·Instructions for use …………………………………………………….…….5-7 ·Safety ……………………………………………………………………………...7 ·Using Cookware ……………………………………………….…………..8 ·Cleaning and maintenance …………………….………….……....9 ·Troubleshooting................ 10-12 ·Customer Service …………………….………….…….…......12...
- Page 3 Notice The cooktop's surface will be hot after cooking, please do not touch! WARNING • Only a professional technician can repair any issues with your stove. Repairs not performed by a professional technician will void the warranty. • Technical details and appliance identification can be found on the specification plate. Refer to this plate before making any electrical connections.
- Page 4 Installation Warning (1). The radiant cooktop must be installed by a qualified professional. We have certified installers available. Do not attempt to install the appliance yourself. (2).The Radiant cooktop must not be installed above refrigerators, freezers, dishwashers or tumble dryers. (3).The wall and the area above the cooktop should be able to withstand heat.
- Page 5 The distance between the underside of the appliance and the separator panel must respect the dimensions given in the figure (mini. 50mm). To ensure proper operation of the appliance, do not block the minimum required clearance (minimum 20 mm) on the countertop for airflow. If an under-counter oven is installed, make sure it has a cooling system.
- Page 6 Connection to power supply: If the cable is damaged or needs or needs replacing, this should be done by technician using the proper tools to avoid any accidents. The installer must ensure the electrical connection is correct and complies with safety regulations.
- Page 7 Electric ceramic stove failure: No heating for 2 minutes after the gear is selected, an "E4" fault will be displayed. Customer Service Email: service@xkitchen.store (Please send relevant videos and pictures to our email address, and attach your Amazon order number. After confirming the problem, we will definitely give you a satisfactory solution.)
- Page 8 zone. The operation of zones is the same. The only difference is that the middle heating zone has three circle zones, you can choose the inner heating circle for a smaller pot for lower power or two and the whole bigger heating circle by pressing the heating zone selection button Sync elements Turning On Sync Elements: Press the button to activate the left up burner, the left down...
- Page 9 Timer confirmation: With repeated pressing on the timer key choose the zone you want to set as the LED light showing. The display shows "00". With the slider set the time in 10-minute steps,press the again,set the time in 1-minute steps. (max.
- Page 10 Using Cookware STAINLESS STEEL Most stainless steel, enamel, iron, ENAMEL ceramic and copper pans can be CERAMIC used on radiant cooktops. COPPER Aluminum pans are not recommended as they may stain the surface, unless they have stainless steel encapsulated bottoms. Hotplates should not be switched on without a pan on top.
- Page 11 CLEANING AND MAINTENANCE IMPORTANT: If the radiant glass surface breaks or you notice cracks in it, disconnect the equipment. Call your Repair Service Technician. Clean the radiant glass surface frequently, when it is cool. Avoid using abrasive products or scouring pads. Clean with a damp cloth and soapy water.
- Page 12 TROUBLESHOOTING If you encounter a problem, review the charts on the following pages first before you call customer service, and you may not need to call for service. If an error occurs in the control operation, a fault code will flash in the display. Record a video of the error code and call for service.
- Page 13 When the cooktop isn't in You can try unplugging first, then use, one of the heating lift and firmly tap the bottom of elements or the outer ring Product malfunction the operating area. Reconnect of the burners lights up and check. If the issue persists, it automatically.
- Page 14 Contact after-sales service and Cracks in the heating Damaged during provide corresponding videos or element transportation pictures. Customer Service Call: 1 - 888 907 5060(Toll Free) Business Hours: 9 AM-5 PM, Mon-Fri Email: service@xkitchen.store - 12 -...
