Excelsior EGIS002 Manual

Gas appliance rangehood interlock system

Advertisement

Quick Links

Gas Appliance Rangehood Interlock System
Key Specifications
1. Interlock Box
Operating Voltage:
Max Rangehood Current Draw:
Max Solenoid Power:
Max Total Loading of Socket Output:
Certification:
2. Solenoid Valve
Solenoid Voltage:
Solenoid Valve:
Solenoid Valve Thread Type:
Solenoid Valve Max Inlet Pressure:
3. Air Pressure Switch
Switch:
Switch Voltage:
Switch Pressure:
Switch Temperature:
Interlock Function
The Excelsior Gas Appliance Rangehood Interlock System is designed to ensure the supply of gas to a
gas appliance is only possible when the connected rangehood is in operating mode.
When installed, the unit detects when the rangehood fan is switched on and running. It then creates
pressure that activates the pressure switch, which in turn energizes the connected gas solenoid valve,
allowing gas to flow to the appliance. If the rangehood fan stops or fails to generate sufficient pressure,
the solenoid valve is de-energized, cutting off the gas supply to the appliance.
Typically, this interlock would be fitted to an approved gas barbecue with flame failure device that is
installed in a residential alfresco area under a suitable Excelsior rangehood.
THIS INTERLOCK MUST ONLY BE USED IN CONJUNCTION WITH
AN APPROVED GAS APPLIANCE THAT HAS A FLAME FAILURE
SYSTEM FITTED
EGIS002
220-240V/50Hz
6A (1400W)
9VA
10A (2400W)
GMA-512102-EA
24V/50Hz
Brahma Model E6G*50*S10*1/2*GMO
½"BSP Female
5kPa
Teren Model 612
9-28VAC/DC
20-300Pa
-10-50
o
C

Advertisement

loading
Need help?

Need help?

Do you have a question about the EGIS002 and is the answer not in the manual?

Questions and answers

Summary of Contents for Excelsior EGIS002

  • Page 1 -10-50 Interlock Function The Excelsior Gas Appliance Rangehood Interlock System is designed to ensure the supply of gas to a gas appliance is only possible when the connected rangehood is in operating mode. When installed, the unit detects when the rangehood fan is switched on and running. It then creates pressure that activates the pressure switch, which in turn energizes the connected gas solenoid valve, allowing gas to flow to the appliance.
  • Page 2 Typical Interlock Installation Arrangement Installation A diagram of the 1. Determine a Suitable Installation Location recommended setup • Select a suitable location for the controller adjacent to the fixed power outlet that is installed to supply power to the rangehood (this is generally within the rangehood top surround).
  • Page 3 For any queries or assistance call Customer Service (Australia Only) 1300 174 876 Hours of operation: Monday to Friday 8am - 5pm EST IMPORTANT: RETAIN THESE INSTRUCTIONS FOR FUTURE USE. Excelsior™ is a trademark of Sitro Group Australia www.sitro.com.au 04403 10/24...
