Summary of Contents for Schwinn 700-0542
- Page 1 CORE HEALTH & FITNESS X BIKE CADENCE PRO MOUNTING KIT ASSEMBLY MANUAL...
- Page 2 ASSEMBLY CADENCE PRO & KIT Required Tools & Parts: • 700-0542: KIT, MOUNTING, PRO, CADENCE, BIKE, X • 700-0008: COMPUTER, SIMPLE, ZM6C • PHILLIPS SCREWDRIVER Procedure 731-8782 110-4344 1. Remove the two screws 110-4344 from the back of the phone holder 731-8782, then remove phone holder.
- Page 3 TWO AAA BATTERIES 3. Remove the battery cover from the computer and install two batteries. If batteries come pre-installed, remove one. Fig. 3 4. Insert the final battery while pressing and holding any of the four buttons on the front of the computer. The display will show the maintenance screen.
- Page 4 7. To pair automatically, press the Mode button( ) The 4-digit alpha-numeric code should match the code on the side of the cadence transmitter and the back of the computer. Tech Tip: If needed, a manual pairing can be done by pressing and holding the Mode button ( ) until the first digits of the 4 digit code (0000) flash.
- Page 5 Cadence Pro 110-3522 12. Secure computer base assembly to Cadence Pro computer with three screws 110-3522 from Cadence Pro kit. Fig. 8 Assembled Computer & Base 110-4174 13. Install computer assembly and secure with two screws 110-4174 from kit. Fig. 9 Page 5...
- Page 6 14. Install the RPM sensor 740-8465 battery side out into the foam mounting block 740-8461, then 740-8465 remove the backing from the double-sided tape 740-8780 and secure at the bottom of the block 740-8480 as shown. 740-8461 Fig. 10 15. Use the included alcohol wipe to clean the shroud where the RPM sensor is to be installed.
- Page 7 17. Mount the magnet 740-8460 on the user right crank arm approximately where shown. Note: Do not secure the magnet in place yet at this point with the magnet holder. Only secure the 740-8460 magnet in place once the magnet and sensor positions have been set in close enough proximity to verify that the computer is...
- Page 8 PART NUMBER 620-8995, REV A All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.
