Summary of Contents for Cubix QX-55
- Page 1 CUBIX ICE MAKER USER’S MANUAL ㆍThis product is designed for indoor use and not for outdoor use. ㆍPlease read this User’s Manual carefully before operating the product, and keep this Manual for future reference...
- Page 2 Safety Warning Please read and save these instructions. Precautions are marked with symbols to prevent accidents which could be caused by incorrect operation. Failure to comply with instructions could result in personal injury and/or property damage. This symbol means that if the user fails to observe the instruction, the danger will cause serious physical injury, death or major property damage.
- Page 3 Warning Warning The Ice Machine must be plugged into a grounded outlet. - Do not use an adapter or an extension cord. - Do not remove the grounding prong. - The unit must be installed in accordance with the state and local electrical and plumbing codes.
- Page 4 Warning Warning Do not bend the power cord severely, or allow it to be pressed by a heavy matter which can cause damage to the cord. - Otherwise, there is a danger of current leak and/or electric shock. Replace damaged power cord and the cord plug whose metal part(s) have become loose.
- Page 5 Warning Warning Provide at least 20cm of space between the product and the wall. - Being too close to the wall may cause product failure. For cleaning or servicing, unplug the power cord, close the feed water valve, and wait until the product comes to a complete stop. - Otherwise, electric shock or physical injury may result.
- Page 6 Warning Warning Do not tilt the product by more than 45 degrees during transportation. - Otherwise, product failure may be caused. Protect the connection hose from being twisted or folded. - Otherwise, water leak or product failure may be caused. Or the water feed may fail.
- Page 7 Caution Caution To keep the ice for a long time, put it in a separate freezer. - The temperature of the ice container of the Ice Maker is maintained by the coldness of the ice, not by any additional freezing function. - Therefore, the ice can melt down after a long time, unless you keep it in a separate freezer.
- Page 8 이나무시스-얼음제빙기 20190210 Major Components Rear View Front View Door Rear Cover Power Drain Switch Connector Front Cover Water Supply Inlet Side View Air cooling Evaporator Nozzle Water Pan Filter Screen Ice Formation Sensor Spray Pipe Pump Ice Container Foam Material Condenser Base Fan motor rotation...
- Page 9 Cautions for Installation Location Away from fire source - There must be no fire source, such as a furnace or gas cooker, in the vicinity, and the ambient temperature range must be between 10℃~40℃ Secure sufficient spacing between the wall..- For satisfactory performance and operation, secure at least 20 cm of space from the wall.
- Page 10 Cautions for Installation Location Indoor use - Do not install outdoors - Lay the drain hose with an appropriate slope for smooth draining. Away from children’s hands - Do not allow a child to take out ice without supervision. - Do not allow children to play around the ice machine.
- Page 11 Installation Unpacking the product - Unpack the product and take out the parts packed inside the produc. Assembling the feet -Assemble the 4 height adjustable feet on the bottom of the Ice Maker. Level Adjustment -Adjust the level of the machine with the height adjustable feet.
- Page 12 Correct Operation 1. The supply water must be from the city service water. 2. The pressure and temperature of the supply water must be 1kgf/㎠~5kgf/㎠(14.22 psig - 71.12 psig), and 10℃~32℃(50℉~70℉), Caution respectively. 3. Please be reminded that condensation may be fomed on the door or on the drain hose and flow on the floor 4.
- Page 13 Electric grounding Be sure to ground to prevent electric shock. Ground terminal Ground If there is a ground terminal terminal If used for an AC 220V outlet with a ground terminal, no additional grounding is required. If there is no earth terminal If used for an AC 220V outlet with a ground terminal, connect the ground wire to the copper plate and bury it in the ground.
- Page 14 Correct Operation Protecting the water supply hose - Do not put a heavy thing or step on the water supply hose Operate at appropriate water pressure and temperature, and ambient temperature; - The pressure and temperature of the supply water must be 1kgf/㎠~5kgf/㎠, and 10℃~32℃, respectively, and the ambient temperature must be between 10℃~40℃.
- Page 15 Disassembling, Cleaning Warning Warning : Unplug the power cord before cleaning the Ice Maker or replacing a part. Otherwise, an electric shock or fire may break out. - Do not spray water on the Ice Maker. Otherwise, there is danger of current leak and/or electric shock. Otherwise, the product can be corroded or damaged.
- Page 16 How to clean Power and water supply must be cut off before cleaning. Open the door of the Ice Maker. Door Loosen and remove the screws on both sides of the panel, and remove the swing flap. Swing flap Remove the sliding panel and clean-up the product Sliding panel Remove the nozzle assembly and...
- Page 17 How to clean Using a sponge block, clean up the dirt in the water pan. Remove and clean-up the filter screen. ※ Caution Make sure to reinstall the filter screen. Otherwise, the nozzles may get clogged. As illustrated in the figure on the right, open the Condenser cover;...
- Page 18 Maintenance / Product specification 1. General Maintenance and Check Procedure ① Please observe the installation and operation instructions provided in this User’s Manual. ②To maintain the proper condition of the Ice Maker and long-term operation without failure, perform the maintenance procedures provided below 2.
- Page 19 Troubleshooting Chart If the machine is judged not to be in good condition, check the following points presented in the table below. Operating Condition Check Point Corrective Action 1. The machine does 1. Power supply 1. Connect power supply 2. Power switch position 2.
- Page 20 BOOSUNGHOTSHU CO., LTD MADE IN KOREA...
