Controller
Product Introductions
APL-301B
ASA TOOLS ENTERPRISE CORP.
2F., No. 346, Sec. 6, Nanjing E. Rd.,
Neihu Dist., Taipei City 11470, Taiwan
Tel: +886-2-27900535
Fax: +886-2-27949952
Email:
asaswdvr@ms16.hinet.net
Website:
www.asa-tool.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the APL-301B and is the answer not in the manual?

Questions and answers

Summary of Contents for ASA Electronics APL-301B

  • Page 1 Controller Product Introductions APL-301B ASA TOOLS ENTERPRISE CORP. 2F., No. 346, Sec. 6, Nanjing E. Rd., Neihu Dist., Taipei City 11470, Taiwan Tel: +886-2-27900535 Fax: +886-2-27949952 Email: asaswdvr@ms16.hinet.net Website: www.asa-tool.com...
  • Page 2 Table of Content ■ Special Thanks to our customer Thank you for choosing our light and powerful electric screwdrivers. To ensure the tool fully utilizes its maximum performance and extend its life, please read this manual before use. -Table of Content- General Safety Warnings .....................
  • Page 3 General Safety Warnings ■General Safety Warnings WARNING : Read all safety warnings and all instructions Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. ■Work area safety -Keep work area clean and well lit.
  • Page 4 Read before use Read before use ■Please read the following notices before use: ‧Set-up Notice -The controller should be used in dry place indoor without the presence of dust and iron grindings. -The controller should be positioned on a stable surface to avoid falling caused by vibration. -The controller should be kept away from high voltage sources and noise generating sources to avoid electromagnetic interference.
  • Page 5 Declaration of Conformity CE/Service ■Declaration of Conformity CE We (ASA Enterprise Corporation) declare under our sole responsibility that the products controller described under this manual are in conformity with the following Directives/ or standardization documents: Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. ■Service Have your controller serviced by a qualified repair person using only identical replacement parts.
  • Page 6 This lowers the risk of screw shaking when fastening. -The attached output terminal can be connected to an external controller for single control purpose. ■ Specification Model APL-301B Item Input Voltage 100~240V 、 50/60Hz (VAC) Output Voltage...
  • Page 7 Product Information ■Parts and functions ‧Speed setting Turn the speed-setting screw through the hole on the side of the power supply with the small screw driver (standard accessory). -Turn clockwise 010 on the scale to increase the speed. -Turn counter-clockwise 100 on the scale to lower down the speed.
  • Page 8 Operation ‧Power setting and AC input socket (C13 specification) -The input voltage of our power supply is ranged between 100-240VAC, 50/60 Hz. Please make sure you use the correct voltage to avoid any damage to the power supply. -Connect one side of the cable to the AC power socket and the other side to the AC input socket (C13 specification).
  • Page 9 Operation ‧Indicator Light Model APL-301B Item ◎ Switch-on After switch on, flash Green light orange light three times, then turn to green light Brakes ◎ No DC voltage output heating protection ◎ No light (temperature set at 75~85 ℃) ◎...
  • Page 10 Operation ‧ Output (DC) Plug - Provide power to the electric screwdriver. - Plug specification Front of the Power Supply 5P plug ‧OUTPUT: Signal output terminal -①、②: Switch on signal output,when the screwdriver switched on, will export DC24Vvoltage. -③、④: Shut-off signal output; when the screwdriver reached its set torque and stopped, no-voltage (DC24V) will be exported.
  • Page 11 Operation ‧DRIVER FUNCTION: External controller use terminal -⑤ 、 ⑥:Automation switch-on signal: Please do the jumper cable connection on the control board (picture 1) from manual to automation (picture2), which enable external controller to conduct the electric screwdrivers. Picture 1 Picture 2...
  • Page 12 Operation ‧Screw hole for the assembly of the power supply and the balancer -There are screw holes at the bottom of the power supply which you can combine the power supply with our SB-series balancer (optional accessory) and the fixed board. Please follow the instruction below: Fixed board Back of the...
  • Page 13 Troubleshooting ■Troubleshooting If the screwdriver does not work properly, follow the check-list below to examine your screwdriver. If none of the following points apply to the problems you encountered, do not open the unit and contact your local sales agent immediately for further guidance. ˙The screwdriver is out of operation - Please check whether the power plug is correctly and tightly plugged into the designated power source.
  • Page 14 Assembly Drawing/Parts List...
  • Page 15 PLASTIC SCREWDRIVER 6 8T2072 SCREW M2.6*L:20 Ø6.5*3.0 7 6B3020 FOOT SAFETY LABEL 9 8T2083 SCREW APL-301B 10 2Y6100 TERMINAL BLOCK 11 2L2102 LEADING WIRE FOR OUTPUT SIGNAL 12 2A2924-CP CONTROL PCB SUB ASS’Y 12a 2F1040 FUSE 13 7L2013 ASA LOGO LABEL...
  • Page 16 Enjoying in Technique of Assemblies Attention! The generic or unsuitable parts might seriously Retailer’s affect the power supply’s lifespan, Stamp please purchase the parts from original manufacturer to secure your rights.
