Page 1
UPS-21xx Series USER MANUAL IOS App Android App Scan to Download APP...
Page 3
SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. This manual contains important instructions that should be followed during installation and maintenance of the UPS and batteries. UPS Tower models are considered acceptable for use in the ambient of 0 ~ 45°C; UPS RT models are considered acceptable for use in the ambient of 0 ~ 40°C; Certification standards •...
Page 4
-CAUTION: Do not dispose of batteries in a fire. The batteries may explode. Dispose of used batteries according to the instructions. -Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes. It may be toxic. -CAUTION –...
Page 5
Special precautions • The unit is heavy: wear safety shoes and use vacuum lifter preferentially for handling operations. • All handling operations will require at least two people (unpacking, lifting, installation in rack system). • Before and after the installation, if the UPS remains de- energized for a long period, the UPS must be energized for a period of 24 hours, at least once every 6 months (for a nor- mal storage temperature less than 25°C).
Page 6
Dieses Schnellinstallationshandbuch enthält wesentliche Informationen für die grundlegende Einrichtung. Für detaillierte Anweisungen und zusätzliche Funktionen beachten Sie bitte das umfassende Benutzerhandbuch, das auf der Website von LevelOne zum Download zur Verfügung steht: www.level1.com Bitte lesen Sie alle Anweisungen sorgfältig durch und befolgen Sie sie während der Installation und des Betriebs des Geräts.
Page 7
Stromkabel, um Geräte mit dem UPS zu verbinden. VORSICHT! Bei der Installation des Geräts stellen Sie sicher, dass die Summe des Ableitstroms des UPS und der angeschlossenen Geräte 3,5 mA nicht überschreitet. VORSICHT! Trennen Sie das Gerät während des Betriebs nicht vom AC-Stromnetz, da dies die Schutzleiterisolierung ungültig macht.
Page 8
Pour des instructions détaillées et des fonctionnalités supplémentaires, veuillez consulter le manuel utilisateur complet disponible en téléchargement sur le site web de LevelOne : www.level1.com. Veuillez lire et suivre attentivement toutes les instructions lors de l'installation et de l'utilisation de l'appareil.
Page 9
ATTENTION ! Lors de l'installation de l'équipement, assurez-vous que la somme du courant de fuite de l'UPS et de l'équipement connecté ne dépasse pas 3,5 mA. ATTENTION ! Ne débranchez pas l'unité de l'alimentation CA pendant l'utilisation, car cela invalidera l'isolation de la mise à la terre de protection. ATTENTION ! Pour éviter les chocs électriques, éteignez et débranchez l'unité...
Page 10
Esta Guí a de Instalación Rápida proporciona información esencial para la configuración básica. Para instrucciones detalladas y caracterí sticas adicionales, consulte el manual de usuario completo disponible para descargar en el sitio web de LevelOne: www.Level1.com. Por favor, lea y siga todas las instrucciones cuidadosamente durante la instalación y operación de la unidad.
Page 11
¡ NO BLOQUEE LAS ABERTURAS DE VENTILACIÓ N ALREDEDOR DE LA CARCASA! ¡ NO CONECTE APARATOS DOMÉ STICOS COMO SECADORES DE PELO A LOS TOMACORRIENTES DE SALIDA DEL UPS! EL MANTENIMIENTO DE LAS BATERÍ ASDEBE SER REALIZADO O SUPERVISADO POR PERSONAL CON CONOCIMIENTO DE BATERÍ...
Page 12
Para instruções detalhadas e recursos adicionais, consulte o manual do usuário completo disponí vel para download no site da LevelOne:www.level1.com. Por favor, leia e siga todas as instruções cuidadosamente durante a instalação e operação da unidade. Leia este manual completamente antes de tentar desembalar, instalar ou operar o UPS.
Page 13
Ez a Gyors Telepí tési Ú tmutató lényeges információkat nyújt az alapvető beállí táshoz. Részletes utasí tásokért és további funkciókért kérjük, tekintse meg a teljes körű felhasználói kézikönyvet, amely letölthető a LevelOne weboldaláról: www.level1.com. Kérjük, gondosan olvassa el és kövesse az összes utasí tást a berendezés telepí tése és üzemeltetése során.
Page 14
FIGYELEM! Ne húzza ki az egységet az AC hálózati áramforrásból üzem közm b e e n r, t ez érvénytelenné teszi a védőföldszigetelést. FIGYELEM! Az elektromos sokk elkerülése érdekében kapcsolja ki és húzza k e iga y z s éget, mielőtt a bemeneti/ kimeneti hálózati kábelt a földelési vezetékkel telepí...
Page 16
Contents Introduction ......................1 1.1 Electronic equipment Protection ................1 1.2 Environmental protection ..................2 Product Overview ....................3 2.1 Weight and Dimension .................... 4 2.2 Rear panels ........................5 Installation ......................6 3.1 Inspecting the equipment ..................6 3.2 Checking the accessory kit ................... 6 3.3 Install the Unit ......................
Page 17
Introduction Thank you for selecting our UPS to protect your electrical equipment. We recommend that you take the time to read this manual to take full advantage of the many features of the UPS (Uninterruptible Power System). Before installing the UPS, please read the booklet presenting the safety instructions. Then follow the indications in this manual.
Page 18
1.2 Environmental protection Products are developed according to an eco-design approach. Substances This product does not contain CFCs, HCFCs or asbestos. Packing To improve waste treatment and facilitate recycling, separate the various packing compo- nents. • The cardboard we use comprises over 50% of recycled cardboard. •...
Page 19
Product Overview 2.1 Weight and Dimension The weights in this table is reference only, please see the labels on the carton for details. Rack Mount models Description Net Weights (kg) Dimensions: D x W x H (mm) Remark UPS-2101 14.3 445*438*85.5 UPS-2102 23.3...
Page 22
Installation 3.1 Inspecting the equipment If any equipment has been damaged during shipment, keep the shipping cartons and pack- ing materials for the carrier or place of purchase and file a claim for shipping damage. If you discover damage after acceptance, file a claim for concealed damage. To file a claim for shipping damage or concealed damage: 1.
Page 23
3.3 Install the Unit Always keep 200 mm of free space behind the UPS rear panel. Check that the indications on the name plate located on the top cover of the UPS meets to the AC-power source and the true electrical consumption of the total load. 1.
Page 24
• Recommended upstream protection UPS model Upstream circuit breaker Tower 3KS C curve-20A • Input terminal and output terminal connection: 0.8N m Tower 3KS Minimum of section required/ Torque Terminal-block capacity Input L, N, G 2.5 mm²/(0.3N.m) 4 mm² conductor cross section Output L, N, G 4 mm²/(0.8N.m) 10 mm²...
Page 25
3.3.1 Rack Mount ⚫ Rack installation Follow steps 1 to 4 for module mounting on the rails.
Page 26
3.4 Connecting the EBM(s) A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and will not harm personnel. Up to 4 EBMs can be connected to the UPS.
Page 28
Operation 4.1 LCD panel The UPS provides useful information about the UPS itself, load status, events, measurements and settings. Online mode Fault indicator indicator (green) (red) Battery mode Bypass mode indicator (orange) indicator (orange) Battery Load Output Escape Down Enter On/Off button Default Password :4732...
Page 29
The following table shows the indicator status and description: The button Function Illustration Press the Button for >100ms & < 1s can power on the UPS with- Power on out utility input at the condition of battery connected When the Unity is powered on, press the button for >1s can turn Turn on on the UPS Turn off...
Page 30
Operation status Cause Description Standby mode The UPS is Off without output. Online mode The UPS is operating normally and protecting the equipment. A utility failure has occurred, and the UPS is powering the equipment with battery. Battery mode 1 beep every 4 sec- Prepare your equipment for shutdown.
Page 31
4.3 Display functions When starting the UPS, the display is in the default UPS status summary screen. Main menu Submenu Display information or Menu function UPS mode, IoT status, date/time, battery status and cur- UPS status rent alarms Event log Displays the events and faults stored [Load] W VA A P%, [Input/Output] V Hz, Measurements...
Page 32
Submenu Available settings Default settings [Auto detection], Auto detection External battery [Manual EBM: 0~4], 0 EBM [Manual Ah: 7~144Ah] Charger current [2A], [4A], [6A], [8A] for long backup model 2A (For compact model) Dry in signal [Disabled], [Remote on], [Remote off], [Forced bypass] disabled [load powered], [on bat], [Low bat], [bat open], [by- Dry out signal...
Page 33
4.6 Starting the UPS on Battery Before using this feature, the UPS must have been powered by utility power with output enabled at least once. Battery start can be disabled. Refer to the Chapter User setting. Battery Load Battery Load Battery Load Input...
Page 34
Communication 5.1 RS232 and USB 1. Communication cable to the serial or USB port on the computer. 2. Connect the other end of the communication cable to the RS232 or USB communication port on the UPS. 5.2 UPS remote control functions •...
Page 35
5.3 IoT Built-in ethernet port and WLAN (optional accessary) port enable market-leading and easy- to-use IoT solutions for: • Winpower View mobile app which allows you to remote monitor UPS(s) and keep in- formed about critical UPS event always. • Remote report UPS faults and status (contact with your service for detail) from APP or registered APP account (Email address).
Page 36
2. Enable the IoT function in LCD (see Settings-> IoT) 3. Search the “WinPower View” from Google Play store or Apple APP store, downloading and installing. 4. Open the app, register an account, log in, follow the instructions of the app. 5.
Page 37
5.4 Modbus TCP Built-in ethernet port offers Modbus TCP feature to facilitate remote monitoring of the UPS into your own software. Contact with your service for protocol details. 5.5 Optional Card Intelligent Card allow the UPS to communicate with different types of devices in variety of networking environments.
Page 38
5.6 UPS Management Software 5.6. WinPower WinPower provides user-friendly interface to monitor and control your UPS. This unique software provides safely auto shutdown for multi-computer systems while power failure. With this software, users can monitor and control any UPS on the same LAN no matter how far from the UPSs.
Page 39
5.6.5 UPS Web Page Open a web browser(Recommend using Google Chrome or Edge), key in IoT device’s IP address, currently IP address show on "LCD Identification Ethernet IP" default DHCP mode. Default username: admin Default password: Admin*1...
Page 40
UPS maintenance 6.1 Equipment care For the best preventive maintenance, keep the area around the equipment clean and dust free. If the atmosphere is very dusty, clean the outside of the system with a vacuum cleaner. For full battery life, keep the equipment at an ambient temperature of 25°C (77°F). The batteries are rated for a 3-5-year service life.
Page 41
• Replacing the internal battery 1. Put the new battery pack into the UPS. 2. Screw back the metal protection covers and the front panel. 3. Testing new batteries. Verify that the replacement batteries have the same rating and brand as the batteries being replaced.
Page 42
6.5 Recycle Contact your local recycling or hazardous waste center for information on proper disposal of the used equipment. Do not dispose of the batteries in the fire. Which may cause battery explosion. The batter- ies must be rightly disposed according to local regulation. Do not open or destroy the batteries.
Page 43
Troubleshooting Typical alarms and faults: To check the UPS status and Event log: 1. Press any button on the front panel display to activate the menu options. 2. Press the button to select Event log. 3. Scroll through the listed events and faults. The following table describes typical conditions.
Page 44
Conditions Possible cause Action Power overload Power requirements exceed the Remove some of the equipment from the UPS. UPS capacity (greater than 105% The alarm resets when the condition becomes of nominal; inactive. LED is On. 1 beep every second. over temperature The UPS internal temperature is Clear vents and remove any heat sources.
Page 45
Specifications 8.1 UPS Block Diagram Input Filter Battery Charger 8.2 UPS Specification Model name UPS-2102 UPS-2103 UPS-2101 Power rating VA/Watt 1000VA/1000W 2000VA/2000W 3000VA/3000W Line mode Efficiency ECO mode Voltage range 160-300V 100% load, 110-160V derating to 50% load linearly Rated frequency 50Hz/60Hz Input Frequency range 40Hz-70Hz (45Hz-55Hz, 54Hz-66Hz @ load>60%) performance...
Page 46
UPS-2102 UPS-2103 Model name UPS-2101 1 main outlet group (with 1 x IEC 1 main outlet group (with 4 x IEC C13) C19 + 4 x IEC C13) Socket (RT) 1 programmable outlet group (with 4 x IEC C13) 1 programmable outlet group (with 4 x IEC C13) 8 x IEC C13 Socket...
Page 47
UPS-2102/UPS-2103 UPS-2101 RT: 438*600*85.5(2U) RT: 438*445*85.5(2U) Dimension Compact RT: 438*505*85.5(2U) (W*D*H) mm IP protection IP20 Physical perfor- level mance Plug solid Optional Wheel Operating RT: 0-40⁰C temperature Tower: 0-45⁰C, 40-45⁰C derating to 80% Relative 0-95% Humidity Environment Operating 0~3000m(the load derating 1 % every up 100m @1000~3000m) Altitude Acoustic Noise <45dB at front 1m...
