No.M162/M163
1:16 RC HIGH SPEED CAR
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M162 and is the answer not in the manual?

Questions and answers

Summary of Contents for OFF-ROAD-PRODUCTS M162

  • Page 1 No.M162/M163 1:16 RC HIGH SPEED CAR USER MANUAL...

  • Page 2: Warnings And Cautions

    The instruction sheet for this product is just for your reference. We reserve the right to make changes or adjustments on the product without prior notification. Please refer to the official information. Warning: Choking hazard! This product contains small parts. NOT suitable for children under 3 years. Contains electrical components and should be kept dry at all times.
  • Page 3 ●Be sure to read thoroughly ●Cutters, nippers and ●As the product contains the manual before you screwdrivers need careful small and sharp parts, begin. Fresh user should handling. assemble and store this seek advice from people product only in places having rich experience in out of the reach of children.
  • Page 4 FCC PART 15 B Notice: CAUTION Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 5: Power Switch

    Power Switch 1. Turn on the power switch of the transmitter, the signal indicator light of transmitter flashes. 2. Press the power button of high speed car, which is on the side of the ESC; the indicator light of high speed car flashes.
  • Page 6 T3A Transmitter ① ST.TRIM (Steering servo strimmer) ② Fn (CH3 Light control) ③ Power switch (OFF-70%TH-100%TH) ④ Indicator light ⑤ CH1: ST (Steering) ⑥ CH2: TH (Throttle) ①ST.TRIM (Steering servo strimmer) If the car cannot go straightly during driving, it can be adjusted through the ST.TRIM. ②Fn (CH3 Light control) Short Press the “...
  • Page 7 ③Power/Speed switch 100% (70% Throttle) (100% Throttle) ④Indicator light Stays on Working well Flash quickly Frequency mating Flash slowly Low battery of transmitter ⑤CH1: ST (Steering) Middle Turn left Turn right...
  • Page 8 Middle *When the car is in reverse situation, it does not the brake function. Install the Tail (Use for M162) Install the tail to the rear shock tower, lock with 4 screws. Install the Transmitter’s Battery Open the transmitter’s battery cover, insert 2 AA batteries according to the indicated positive and...

  • Page 9: Install The Battery

    Install the Battery ①Unlock the fixing tape; ②Insert the battery into the battery box, make sure it’s in place; ③Tighten the battery with the fixing tape; ④Connect the receiver plug to the battery. Charge If charging with a 5V 2A USB adapter. ●When charging, the indicator light of charger is green and flashes;...
  • Page 10 Install Car Shell (Use for M162) 1. Aline the 3 holes of the car shell with holders, then install it. 2. Insert the 3 clips into the holes to lock the car body.
  • Page 11 Install Car Shell (Use for M163) 1. Aline the 4 holes of the car shell with holders, then install it. 2. Insert the 4 clips into the holes to lock the car body. -10-...
  • Page 12 16201/16202 Rear Swing Set Rear hub pins: Pivot balls: Q1602 1PCS M2523 1PCS 16201 (M163) Steering pivot balls Rear hub pins 16240 (M163) 16260 Q1602 16240B (M162) R168Z M23124 16202 (M162) Screw: R168Z M23124 2.3x12mm 1PCS Countersunk flat head screws 16250 Bearing:...
  • Page 13 16400 Metal Gears Main Driving Set Bearing: Screw: 16401 R168Z 2PCS M21035 2x10mm 1PCS M21035 Ball bearing Countersunk flat head screws R1810 2PCS 16405 Ball bearing 16404 16403 R1810 R168Z 16402 16400 16420 Metal Gears Diff Assembly Screw: Bearing: R1810 2PCS M2123 2x12mm...
  • Page 14 16500R/16510R/ B2835A Motor Assembly 16500M Screw: Oil Filled Shock M25845 2.5x8mm 2PCS Countersunk flat Shock absorbers head screws adjuster 16395C M3030 3x3mm 1PCS Spin the suspension adjuster to adjust the Hexagon socket shock absorbers’strength. machine screw Add shock oil B2835 16392B 16393M M3030...
  • Page 15 High Speed Car Assemble Screw: M26104 M23104 M26104 2.6x10mm 10PCS M23104 M26104 Round head screws 16190 M23104 2.3x10mm 6PCS Round head screws 16160M M2684 2.6x8mm 8PCS Round head screws M23114 2.3x11mm 1PCS Countersunk flat head screws 16400 16420 16420 M26104 E45R M2684 16270...
  • Page 16 -15-...
  • Page 17 -16-...
  • Page 18 -17-...
  • Page 19 -18-...
  • Page 20 High Speed Car Assemble (Use for M162) Iron shaft: M20101 1PCS (4PCS) Wheel hex pins 16440 1PCS (4PCS) Wheel hex Nut: 1PCS (4PCS) M4 Wheel lock nut 16440 M20101 16300M2 High Speed Car Assemble (Use for M163) Iron shaft: M20101...

  • Page 21: Spare Parts

    Spare Parts 1601M2 (M162) 1601M3 (M163) 1610A (M162) 1611A (M162) Front Bumper Assembly Body Body Rear Bumper (Metal) (Metal) 16100 (M163) 16110 (M163) 1612B (M162) 16130M Front Bumper Assembly Rear Bumper Assembly Tail Battery Velcro 16150M 16160M 16170 16180 (M162)
  • Page 22 Spare Parts 16210 16220 16230 16240B (M162) Front Upper Suspension Front Lower Suspension Rear Upper Suspension Steering Block Arms Arms Arms (Including Ball Head) (Including Ball Head) (Including Ball Head) 16240 (M163) 16250 16260 M25425 Rear Upper Suspension Rear Lower...
  • Page 23 ESC/REV Fix Frame Motor Assembly (2PCS) 16392B 16393M 16395C 16400 Metal Gears Main Motor Pinions Motor Guard Motor Heatsink Driving Set 16401 16402 16403 16510R (M162) Spur Gear Assembly Drive Gear Centre Drive Shaft Oil Filled Shock (Metal) (Metal) -22-...
  • Page 24 Spare Parts M26124 M23124 M2523 M2665 Countersunk Flat Head Countersunk Flat Head Rear Fixing Pin Step Flat Screws Screws Screws (12PCS) (12PCS) (4PCS) (12PCS) M2384 M2664 M26104 M23104 Round Head Screws Round Head Screws Round Head Screws Round Head Screws (12PCS) (12PCS) (12PCS)
  • Page 25 Spare Parts 16500R (M162) 16500M (M163) 16420 E45R Metal Gears Diff Oil Filled Shock Oil Filled Shock Receiver & ESC 2-in-1 Assembly B2S15K P2050 BD30 Transmitter Battery USB Charging Cable Battery Base P812 M3294 M001 (M162/M163) P810 Round Head Half...
  • Page 26 MADE IN CHINA Instructions must be retained since it contains important information.

This manual is also suitable for:

M163
