  • Page 1 (electronic, mechanical, photocopying, recording or other formats) without written permission from Launch Tech Co., Ltd (hereinafter referred to as "Launch"). The manual is for the use of the products manufactured by Launch, which shall not assume any responsibility for the consequences arising from the use of it to guide the operations of other equipment.
  • Page 2 EVP711 User Manual Contents 1. Product Overview ................................1 2. Product composition and accessories ........................... 1 3. Precautions for Safe Use ..............................2 4. Technical Features ................................2 5. Operating Instructions ..............................3 5.1 Panel Description ................................3 5.2 Main Unit Connection ..............................4 5.3 Main Unit Operation ...............................
  • Page 3 EVP711 User Manual 1. Product Overview EVP711 is an EV battery pack module charging and discharging device developed by Launch. It adopts the most advanced charging and discharging technology, according to the charging and discharging characteristics of lithium and Ni-MH batteries, has built-in various test and maintenance modes, which are suitable for the discharge, charging, cycle charging and discharging tests of various lithium and Ni- MH batteries on the market.
  • Page 4 EVP711 User Manual 3. Precautions for Safe Use (1) Follow the relevant requirements in the user manual to operate the device. (2) When operating the device, please take insulation protection measures and wear dry and clean insulating gloves. (3) In case of abnormality, please disconnect the device’s working power supply and test cable.
  • Page 5 EVP711 User Manual Over voltage, over current, over temperature protection Battery short connection, reverse connection protection Abnormal protection against power cord and main cable failure Fan abnormal protection Shutdown actuator DC breaker + release Alarm prompt Screen prompt + buzzer...
  • Page 6 EVP711 User Manual 5.2 Main Unit Connection DC test cable connection Insert the black DC test cable into the Battery - interface (Black) of the device, and connect the other end to the negative pole of the battery module; insert the red DC test cable into the Battery + interface (Red) of the device, and connect the other end to the positive pole of the battery module.
  • Page 7 EVP711 User Manual Temperature Sampling - Module Sampling Connect one end of the temperature acquisition wire (optional) to the temperature acquisition interface of the temperature and voltage acquisition box, and connect the other end (probes or clips) to the battery cells.
  • Page 8 EVP711 User Manual Parameter Description: Battery Information Pack/module no. The number of the battery pack or module. The nominal capacity of the battery pack, according to the actual input, can be identified Nominal capacity from the rating plate. Battery type Select battery type.
  • Page 9 EVP711 User Manual (3) In the process of discharging, the discharging will automatically stop when any set threshold is reached. Type of stop discharge conditions: discharge time, lower limit of pack terminal, pre- discharge capacity (when there is a limit on discharge capacity), lower limit of single cell (when there is a limit on discharge capacity), and dropout voltage of cells.
  • Page 10 EVP711 User Manual Parameter Description: Battery Information Pack/module no. The number of the battery pack or module. The nominal capacity of the battery pack, according to the actual input, can be identified Nominal capacity from the rating plate. Battery type Select battery type.
  • Page 11 EVP711 User Manual Note: Before starting test, the previously set parameters can be modified using the "Modify Configuration" button. After starting test, the set parameters cannot be modified during the charging process. (3) In the process of charging, the charging will automatically stop when any set threshold is reached.
  • Page 12 EVP711 User Manual Language: Used to change the system language. Wi-Fi:Used to connect the Wi-Fi networks.
  • Page 13 EVP711 User Manual Device upgrade:Used for APP upgrade, including local upgrade and online upgrade functions. APP local upgrade: Copy the upgrade package to the USB. After connecting to the device, select the corresponding upgrade package to upgrade the device. APP online upgrade: After connecting to Wi-Fi, click "Online upgrade" to upgrade the device software to the latest version.
  • Page 14 EVP711 User Manual Develop and maintenance:Only for development and maintenance. About:Used to view system version information, etc.
  • Page 15 EVP711 User Manual 6. Fault Analysis and Troubleshooting Fault Situation Troubleshooting Methods The bottom left corner of Check the communication connection between the tested the screen prompts "Single battery module and the voltage and temperature acquisition cell voltage acquisition box.
  • Page 16 If the device needs to be repaired, please send it back to Launch, and attach the Warranty Card, Product Qualification Certificate, Purchase Invoice and problem description. Launch will maintain and repair the device for free when it is within warranty period. If it is out of warranty, Launch will charge the repair cost and return freight.
