Summary of Contents for Pro-gard Products CSDET23
- Page 1 INSTALLATION GUIDE CARGO STORAGE DRAWER - ELECTRONICS TRAY CSDET23 pro-gard.com 800.480.6680 Released 03.01.24...
- Page 2 TO INSTALL THE CARGO STORAGE DRAWERS Hardware kit Electronics Drawer 4CSD000080 CSDET23 I. The following tools will be required to complete installation A. Hex Keys B. SAE Sockets II. Read all instructions and refer to last page to ensure all parts were received NOTE: The Electronics drawer can be installed in multiple vehicle models.
- Page 3 MOUNT TO THESE SLOTS B. Insert (2) [3X231] screws through the horizontal slots and into the PEM nuts on the mount. The slides will need to be extended and retracted during install to reveal the slots. These slides lock out, and lock in. It may be necessary to fully retract slide to release the locks when revealing slots.
-
Page 4: Installation Complete
V. Assemble and install tray and grommets A. Align handles with holes in the tray and secure with (2) [3X627] 8-32 x 7/8" screws. Repeat on opposite side. B. Align tray with studs on the bottom of the drawer and secure with (4) 1/4-20 whiz nuts. C. - Page 5 pro-gard.com 800.480.6680...
- Page 6 pro-gard.com 800.480.6680...
