- Page 1 Installation and Operation Manual IW-25-5-220V Dehumidifier In-Wall Solution On-Wall Solution IXL Home Pty Ltd 1K Marine Parade, Abbotsford, VIC 3067 1300 727 421 (AUS) / 0800 727 421 (NZ) www.ixlappliances.com.au www.ixlappliances.co.nz Please ensure these instructions remain with the owner.
-
Page 2: Table Of Contents
Table of Contents Safety Notes ..........................2 Identification ..........................4 Electrical Supply ..........................4 Principle of Operation ........................4 Dehumidifier Diagram ........................5 Dimension Diagram ........................6 Dehumidifier Installation General ....................7 In-Wall Solution Only ........................9 On-Wall Solution Only ......................... 10 Optional Condensate Pump Installation ..................12 Operating Instructions ........................13 Maintenance ..........................14 Wiring Schematic ..........................15 Troubleshooting ..........................16... - Page 3 The drain hose must be installed to ensure the proper flow of condensate water to a drain source. ● If the supply cord is damaged, it should be replaced by IXL Home or its service agent or a similarly qualified person in order to avoid a hazard.
-
Page 4: Identification
Serial Number _____________________________ Date of Purchase _____________________________ For additional questions concerning the operation of your dehumidifier, please: Contact IXL Home Customer Care on 1300 727 421 for Australia and 0800 727 421 for ❑ New Zealand. Electrical Supply: Power Supply: 220 V, 50Hz AC Single Phase Outlet Requirement: 3 pin 10 amp plug or it can be hardwired. -
Page 5: Dehumidifier Diagram
IW-25-5-220V Dehumidifier Diagram... -
Page 6: Dimension Diagram
Dimension Diagram In-Wall Solution On-Wall Solution... -
Page 7: Dehumidifier Installation General
Dehumidifier Installation Step 1. Remove metal tie using side cutting pliers, then remove the shipping bracket. Step 2. Fasten mounting tabs (4) with screws provided to the chassis (In-Wall Only) Threaded boss on each mount tab must be oriented in the up position. - Page 8 Step 3. Connect power to the unit using either included 3 meter power cord or the unit can be hardwired. WARNING! Make sure the power supply is isolated at the switchboard before commencing any installation work There are two reserved power cord holes, one on the back and one on the bottom of the unit. Remove appropriate knock out as needed.
-
Page 9: In-Wall Solution Only
IN-WALL ONLY – SEE PAGE 10 for Remainder of ON-WALL Installation Instructions NOTE: If mounting unit to plasterboard, position mounting template so that 1 of the keyhole mounting locations is on a stud. Step 6. Select mounting location between two studs. Step 7. -
Page 10: On-Wall Solution Only
Step 11. The chassis of the unit slips in the wall from the front and is secured by the four mounting tabs with screws (not provided). Ensure the unit is level and the bottom of the unit is supported before screwing through the plasterboard and into the studs. - Page 11 Step 2: Hanging the unit on the wall Position keyhole mounting slots over screws in wall. Ensure centre keyhole hits stud. Allow unit to drop onto screws. Step 3: Secure the unit with the 2 safety mounting screws (not supplied). Step 4.
-
Page 12: Optional Condensate Pump Installation
Optional Condensate Pump Installation: Make sure the power supply is isolated at the switchboard before commencing any installation work 1. Attach the supplied 9.5 mm clear drain-hose and check-valve to the pump connection. 2. Insert included 19mm DIA short clear drain line into pump reservoir. This drain line will eventually connect to water drain tray. -
Page 13: Operating Instructions
Display Board Operating Instructions 1. ON/OFF Control Plug the unit in and the display will show the current room relative humidity. Press the on/off button, and the machine will beep twice indicating it is ready for automatic service. If the humidity is below setpoint, it will remain in standby condition. -
Page 14: Maintenance
2. Setting the Humidity Level Press the setpoint button to set indoor humidity. The humidity display will shift from displaying the actual room humidity level to the current setpoint. The humidity can be in 1% increments from 36-90%. Pressing the SET button increases the setpoint by 1% until you reach 90%, then rolls over to “CO”... -
Page 15: Wiring Schematic
● Mix a 180 ml solution of vinegar (60 ml vinegar + 120ml water) ● Remove diffuser and filter from the face plate so you have access to the drain tray ● Disconnect power to the unit. ● Pour the cleaning solution into the drain tray at the base of the coils. If any cleaning solution gets into the coils, flush with water. -
Page 17: Warranty Information
4. To the fullest extent permitted by law and subject always to Point 1, IXL Home will not be liable for: any loss or damage arising from loss of use, loss of profits or revenue; or for any indirect or consequential loss or damage resulting from any breach of this warranty against defects. - Page 18 9. IXL Home will contact you to make arrangements for service on site. 10. Subject to Point 1, you will be responsible for any costs relating to the provision of your product to a IXL Home Authorised Service Dealer.
- Page 19 Warranty Registration Visit IXL Home website below to register your warranty details online. Australia New Zealand www.ixlappliances.com.au/warranty www.ixlappliances.co.nz/warranty For comments, questions or warranty matters: IXL Home Pty Ltd Australia New Zealand Free Call: 1300 727 421 Free Call: 0800 727 421 service@ixl.com.au...
