Summary of Contents for VPixx Technologies TOUCHPixx
- Page 1 TOUCHPixx (VPX-ACC-8075) User Manual Version 2.0 Phone : (514) 328-7499 1 (844) 488-7499 - Toll Free USA/Canada EMAIL: support@vpixx.com www.vpixx.com...
- Page 3 TOUCHPixx User Manual IMPORTANT VPixx Technologies Inc. reserves the right to modify or otherwise update this document without notice as required by a constantly evolving marketplace, client requests or to adapt to new progress or constraints in engineering or manufacturing technology. The information contained in this document may change without prior notice.
- Page 4 FIGURE 12 VIEWPIXX INSTALLED ON THE STAND ..........................11 FIGURE 13 TOUCHSCREEN ..................................11 FIGURE 14 TOUCHPIXX LOWER SUPPORT BRACKETS ........................... 11 FIGURE 15 TOUCHPIXX LOWER SUPPORT BRACKETS ON VIEWPIXX (1) ....................12 Copyright © 2020 VPixx Technologies Inc. All Rights Reserved...
- Page 5 TOUCHPixx User Manual FIGURE 16 TOUCHPIXX LOWER SUPPORT BRACKETS ON VIEWPIXX (2) ....................12 FIGURE 17 LOWERING THE TOUCHSCREEN ONTO THE LOWER SUPPORT BRACKETS ................. 13 FIGURE 18 LOWER SUPPORT BRACKET INSERTED INTO TOUCHSCREEN SLIT ..................13 FIGURE 19 TOUCHSCREEN UPPER SUPPORT BRACKETS ........................13 FIGURE 20 TOUCHSCREEN TO TOUCHPIXX CONTROLLER CONNECTION .....................
- Page 6 The TOUCHPixx is an innovative touch panel allowing for accurate and deterministic timing. It is fully integrated with our VIEWPixx series monitors and our DATAPixx display driver. The TOUCHPixx can be installed directly on a VIEWPixx monitor or on a table.
- Page 7 TOUCHPixx User Manual Included equipment After unpacking your TOUCHPixx system, verify that it contains the following components. Table 3 – Included Equipment Component Description Visual representation TOUCHPixx screen Mounting bracket TOUCHPixx Controller Stand Support brackets DB25 cable Power supply Hardware kit...
- Page 8 Installing your TOUCHPixx Follow these instructions to install your TOUCHPixx. Note that depending on the exact product you ordered and whether or not it is shipped already mounted on a VIEWPixx or used as is on a tabletop, the installation procedures may vary.
- Page 9 6. Align the Mounting bracket over the VIEWPixx mounting holes and use the four (4) 4-40 x 0.75’’ screws provided with your TOUCHPixx to secure it in place. Only two screw positions are shown in the following figure. The other two screws are located on the other side.
- Page 10 7. Use the four (4) M4 x 10mm screws from your VIEWPixx package/VESA stand and screw them as shown below. 8. Replace the four (4) VIEWPixx screws with the four (4) thumbscrews supplied with your TOUCHPixx, as shown in the following picture.
- Page 11 Figure 9 Adjusting the height of the Stand’s support bracket 12. Install the VIEWPixx assembly on the Stand. For safety reasons, two people are necessary to mount the VIEWPixx assembly on the Stand. Copyright © 2020 VPixx Technologies Inc. All Rights Reserved...
- Page 12 Use a Phillips head screwdriver to tighten the screws (already mounted to the bottom of the mounting bracket) so that the VIEWPixx assembly can no longer be tilted up and away from the Stand. Copyright © 2020 VPixx Technologies Inc. All Rights Reserved...
- Page 13 13. Settle the TOUCHPixx touchscreen on a flat, level surface. Figure 13 Touchscreen 14. Take out the two lower support brackets from your TOUCHPixx package. Figure 14 TOUCHPixx lower support brackets Copyright © 2020 VPixx Technologies Inc. All Rights Reserved...
- Page 14 Figure 16 TOUCHPixx lower support brackets on VIEWPixx (2) 16. Install the touchscreen over the VIEWPixx by bringing it down over the VIEWPixx and inserting the TOUCHPixx lower support brackets into the slits at the bottom of the touchscreen. The touchscreen’s upper support brackets should automatically lock the top portion of the screen in place.
- Page 15 Figure 17 Lowering the touchscreen onto the lower support brackets Figure 18 Lower support bracket inserted into touchscreen slit 17. Secure the touchscreen’s upper support brackets using the thumbscrews previously installed on the VIEWPixx. Figure 19 Touchscreen upper support brackets Copyright © 2020 VPixx Technologies Inc. All Rights Reserved...
- Page 16 18. Connect the touchscreen cable to the TOUCHPixx Controller. Figure 20 Touchscreen to TOUCHPixx Controller connection 19. Connect the TOUCHPixx power supply to the TOUCHPixx Controller and to the wall outlet of your facilty. Figure 21 Touchscreen power supply connection...
- Page 17 Figure 22 DB25 connection (Touchscreen Controller side) Figure 23 DB25 connection (VIEWPixx side) 21. As a final step, remove the protective film from the front surface of the TOUCHPixx. This completes the installation. Copyright © 2020 VPixx Technologies Inc. All Rights Reserved...
- Page 18 By registering, you will have access to the latest software versions, demos and user manuals to support all your VPixx products. Psychtoolbox All TOUCHPixx features can be accessed through the DATAPixx toolbox library included with the Psychtoolbox. The DATAPixx hardware toolbox is fully supported by the Psychophysics Toolbox (PTB) using Matlab or GNU/Octave under OS X, Windows and Linux.
- Page 19 MyVPixx. Low-level ANSI C API Insert the CD labeled “VPixx Technologies Software/Documentation” in your CD/DVD reader and browse it. The “Low Level C API\libdpx\src” folder in the Software folder contains the ANSI C APIs, which are compatible with Windows, MAC OS X and Linux. Do not forget that I/Os are named as DATAPixx I/Os.
- Page 20 MyVPixx account and selecting the proper software tools package for your operating system under the UPDATES tab. Take note that you can also use a TOUCHPixx demo to test the touch experience with your TOUCHPixx by using the vputil application.
- Page 21 Software Tool The vputil tool can be run from the main VPixx Technologies directory under the “Software Tools\vputil\bin” folder. This utility allows the user to control some of the VPixx equipment features. It can also be used to generate built-in test patterns from the equipment.
- Page 22 Do not apply pressure to, or rub, the sensitive product surface. Warranty The TOUCHPixx is warranted against manufacturing defects in materials and workmanship for two years for parts and labor from the date of purchase. Copyright © 2020 VPixx Technologies Inc. All Rights Reserved...
- Page 23 X-Y coordinates with 12-bit precision with an error of +/- 0.244% (+/- 0.13 mm in X and 0.08 mm in Y) Response time 2.5 msec from the touch panel to the VIEWPixx Copyright © 2020 VPixx Technologies Inc. All Rights Reserved...
- Page 24 VPixx Technologies Inc. 630 Clairevue West suite 301 Saint-Bruno, Qc Canada, J3V 6B4 TEL/FAX: (514) 328-7499 TOLL FREE: (844) 488-7499 (USA/CANADA) EMAIL: sales@vpixx.com...
