Arctic SD2 Owner's Manual

Snowplow
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SD2 Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD2 and is the answer not in the manual?

Questions and answers

Related Manuals for Arctic SD2

Summary of Contents for Arctic SD2

  • Page 1 SD2 Owner’s Manual...
  • Page 2 Arctic is the only plow manufacturer using Heavy Armor Galvanizing for their · entire product line. Arctic plows are built to outlast the vehicles they are put on– over 78% of Arctic · plows ever sold are still in service today! Using high quality components, Arctic has the lowest cost of ownership over ·...

  • Page 3: Table Of Contents

    General information about M3493 power unit Hydraulic operation diagrams Hydraulic Installation Power unit M3493 parts list Optional Auxiliary Snowplow light kit Plow Headlights Handheld controller M3493 troubleshooting guide Snowplow maintenance Clearing driveways and parking lots * QUIK*LINK™ is a trademark of Arctic Equipment Manufacturing Corporation...

  • Page 4: Safety And Warnings

    For your safety, warning and information decals have been placed on this product to remind the operator to take safety precautions. It is important that these decals are in place and are legible before operation begins. New decals can be obtained from Arctic Equipment Manufacturing or your local dealer.
  • Page 5 -Do not smoke while working on the vehicle. Gasoline and battery acid vapours are extremely flammable and explosive. -Do not alter the snowplow, or any part without written approval of Arctic Equipment Manufacturing Corporation. -Do not use your hands to search for hydraulic fluid leaks; escaping fluid under pressure can be invisible and can penetrate the skin and cause injury.

  • Page 6: Snowplow Warranty

    Damages on the plow or the truck caused by excessive stacking of snow (All Arctic snowplows have a stop built in, to prevent the blade from contacting the bottom of the bumper. If the blade is pushed too high on the snowbank, the stop will bind and cause the truck’s weight to be supported...
  • Page 7 Failure to do so will nullify any future warranty claims. Replacement parts installed by Arctic dealer will be covered 90 days under the warranty or balance of original purchase warranty, if greater than 90 days. Also, individual parts, components, or accessories are covered 90 days under the warranty (no labour).
  • Page 8 Arctic Standard duty steel blade S2-90S 90”...

  • Page 10: Standard Duty Steel Blade S2-90S 90

    STANDARD DUTY STEEL BLADE S2-90S 90” Item Part number Description Quantity 53769-SE 90” Blade Assembly c/w Cutting Edge 50191-M Eye Bolt Assy 52245-CR Curved Deflector 90” 52239-M Strap 90” 52288-M Deflector Bolt Bag Kit 50999-B Blade Guides GB001 Guide Bolt Assy 53801-B 3/8”...
  • Page 11 Item Part number Description Quantity 53003-B-GA Quadrant Galvanized CS150-10.00-NRS 1 ½” x 10” Cylinder HH-00233-001 ¼” – 28 Grease fittings HH-00973-007 ¾” Nylon Inserts HH-00972-153 ¾” – 16 x 3 ½” HHCS HH-00972-156 ¾” – 16 x 4 ½” HHCS HH-00972-192 1”...
  • Page 12 Arctic Standard duty poly blade S2-90P 90”...

  • Page 14: Standard Duty Poly Blade S2-90P 90

    STANDARD DUTY POLY BLADE S2-90P 90” Item Part number Description Quantity 53849-D Poly Skin 53752-B 3/8” x 6” Steel Cutting Edge 52995-CR Curved Deflector 90” 52996-M Strap 90” 50999-B Blade Guides HH-00971-043 5/16”-18x1” Carriage bolt HH-00294-002 5/16” Hex nut HH-00457-007 5/16”...
  • Page 15 Lift frame Quik*Link™ QL-SD2 (Standard Duty Plow)

  • Page 16: Qliv Sd2 Lift Frame

    SD2 LIFT FRAME QL-SD2 Item Part number Description Quantity 53853-HANDLE QLIV SD2 Lift Frame 53704-M QL-HOP Parts Box 53704-M QL-SD2 Parts Box 53179-M Lift frame Spring Bracket 53864-M QLIV Lock Handle 53178-M Top Plate QLIII Lock 53182-N Lock Spring 52373-M Jack Ass’y...
  • Page 17 SD2 LIFT FRAME QL-SD2 Item Part number Description Quantity 50999-B Blade guides 53858-03-B Arctic Logo Plate HH-00293-088 1/2 -20x1 Hex Head Cap Screw HH-00341-006 1/2 Flat washer HH-00340-003 1/2 Nylon Insert Lock nut 53865-C Power Unit Cover...

  • Page 18: Blade Removal With Quik*Link™ Iii/ Qliv Attachment

    Blade removal with QUIK*LINK™ III / QLIV attachment Lift Frame Jack Spreader bar Safety Pin Handle 1. Locate a spot that is as level as possible. With the blade positioned at 90° to the truck lower the blade and leave the switch in the float position.

  • Page 19: Blade Reinstall With Quik*Link™ Iii/ Qliv Attachment

    Blade reinstall with QUIK*LINK™ III / IV attachment Jack Lift Frame Safety Pin Spreader Bar Handle 1. Drive up to plow assembly until spreader bar is about to make contact with lift frame. 2. Get out of truck to check that the lift frame is aligned with the spreader bar.

  • Page 20: General Information About M3493 Power Unit

    General information about power unit M3493 Warning -Fluid under pressure can pierce the skin and enter the bloodstream resulting in serious injury or death. -Eye protection and protective clothing must be worn when working on any portion of the snowplow. -Remove any jewellery (rings, bracelets, watches, necklaces) that could conduct electricity while working with electrical system.
  • Page 21 Electrical System Frequently problems develop due to an undersized electrical charging and storage system. Generally, the heavier the usage, the heavier the system should be. For heavy usage and in the case where a number of other devices are run off the battery simultaneously, heavier ratings are strongly recommended.
  • Page 22 Directional Valves The M3493 circuit contains 4 directional valves identified as ‘A’, ‘B’, ‘C’ and ‘D’. Valves ‘A’, ‘C’ and ‘D’ are 3 way, 2 position spool valves. Valve ‘B’ is a 2 way, 2 position normally closed poppet valve. A basic directional valve consists of a valve cartridge and a coil.
  • Page 23 Crossover relief valve The crossover relief valves are provided to protect the valves and manifold from the pressure spikes created when the plow strikes an object. The crossover relief valves are similar in construction to a regular direct acting relief valve. Cross over valves when activated bleeds fluid from C1 to C2 or vice versa.

  • Page 24: Hydraulic Operation Diagrams

    Hydraulic operation diagrams...
  • Page 28 ELEC ANGLE ANGLE LOWER DEVICE RAISE RIGHT LEFT MOTOR...

  • Page 29: Hydraulic Installation

    Hydraulic installation...
  • Page 31 Intermediate harness 53420-C Power Unit Cover for Low mount lift frame 52429-01-C Power Unit Cover for Homeowner lift frame 53865-C Power Unit Cover for SD2 lift frame HH-00790-002 Swivel Elbow 90deg CS150-06.00-NRS Lift Cylinder 1 ½” x 6” HH-00794-003 ¼” Pipe to Pipe Swivel...
  • Page 32 Power unit M3493...

  • Page 33: Power Unit M3493 Parts List

    POWER UNIT M3493 PARTS LIST Item Part number Description Quantity FP8111-I Motor, 12 VDC FP2159 Pump Shaft Seal FP7985 Needle Bearing (Pump Shaft to Pump Base) FP21115 Pump base assembly, M3493 FP2318 Bearing, Motor to Pump Base FP6102 Reservoir FP21812 Manifold assembly FP21811 Manifold only...
  • Page 34 POWER UNIT M3493 PARTS LIST Item Part number Description Quantity FP4371 Orifice FP0120 O-ring, 1/2 x 5/8 x 1/16, -014 FP2352 O-ring, 3 3/4 x 4 x 1/8, -240 FP7732 Screw, spring retainer 9/16” -18 FP0130 Spring FP18391 Poppet FP13023 Cross over relief valve assembly FP7899 Screw...
  • Page 35 Optional Auxiliary Light Kit (ALK) 53807-M Electrical Light harness (53810-B) installation instructions...
  • Page 36 Headlight assembly 800084-ALK (c/w 53807-M)
  • Page 37 ALK RECTANGULAR HEADLIGHT KIT 800084-ALK Item Part Number Description Quantity 465091XV Sealed beam 732467 Amber lens 739006 Mounting swivel assembly 298110-36 Sealed beam retaining ring 460028 Double contact bulb 460027 Single contact bulb 280392-00 Socket and bracket assembly 535003 Spring 420943 Sealed beam connector 190055...
  • Page 38 Headlight assembly 800086-ALK (c/w 53807-M) ALK RECTANGULAR HEADLIGHT KIT 800086-ALK Item Part Number Description Quantity 800073-01-D Low Beam Halogen Bulb H7 55W 800073-02-D High Beam Halogen Bulb H1 55W 800074 Amber Signal Bulb 421061-2 Harness, light section 53807-M Auxiliary light kit (wiring only)
  • Page 39 Headlight assembly 800086LED-ALK (c/w 53807-M) ALK RECTANGULAR HEADLIGHT KIT 800086-LED-ALK Item Part Number Description Quantity 800086-LED-01 Driver Side Headlight 800086-LED-02 Curb Side Headlight 800074 Amber Signal Bulb 421061-2 Harness, light section 53807-M Auxiliary light kit (wiring only)

  • Page 40: Handheld Controller

    Handheld controller...
  • Page 41 A-frame, quadrant, lift frame and vehicle undercarriage) without special tools and knowledge could result in personal injury. See an authorized Arctic dealer for service. -Fluid under pressure can pierce the skin and enter the bloodstream resulting in serious injury or death.
  • Page 42 -Clean all parts thoroughly before assembly and lubricate with clean oil. -Do not use Teflon tape on hydraulic connections as it can easily jam the valves and plug the filters in the system, use pipe sealant. Never apply pipe sealant at the end of fitting, always 2- 3 threads back. -X-over pressure could be set using hand (hydraulic) pump.
  • Page 43 MOTOR DOES NOT OPERATE M3493 Is there power on the motor terminal of solenoid, when Are all connections Is there power at switch is activated from (motor/ the positive solenoid) clean and (up or angling)? motor stud? tight? Clean and tighten all Is there power to connections.
  • Page 44 SNOW PLOW DOES NOT RAISE M3493 Does the motor Does motor operate when angle Replace switch or operate when up switch (left/right) is pressed? replace control box. switch is pressed? See chart - Motor does not operate. Is fluid level 3/4" Add UNIVS J13 below filler hole? oil.
  • Page 45 SNOW PLOW RAISES VERY SLOWLY M3493 Is fluid level 3/4" below Add UNIVS J13 oil. filler hole? Adjust relief valve to 2000 psi. Can it be done?Using a gauge in the pressure line, loosen the jam nut and turn adjusting screw clockwise a turn or two and watch the gauge;...
  • Page 46 SNOW PLOW WILL NOT LOWER M3493 Replace Does B (valve) coil switch Is there power to the Is there power (yellow wire) have (control box). B coil? leaving switch magnetism? Are harness Replace cartridge connectors plugged Replace Coil B. Is there power in valve B.
  • Page 47 SNOW PLOW DOES NOT ANGLE TO RIGHT SIDE M3493 Does the motor Replace switch or Does motor operate when up operate when angle replace control box. switch is pressed? switch is pressed? See chart - Motor does not operate. Replace switch Is there power to Is there power Does A coil (green...
  • Page 48 SNOW PLOW DOES NOT ANGLE TO LEFT SIDE M3493 Does the motor Replace switch or Does motor operate when up operate when angle replace control box. switch (left/right) is pressed? switch is pressed? See chart - Motor does not operate. Replace switch Is there power to Is there power...
  • Page 49 PLOW DOES NOT HOLD ANGLE M3493 Check cross over valves X1 and X2. Are cylinders Check pressure operated Clean/ replace. spongy? Can blade check valve CV1 & CV2 Replace seat if be moved 2" to 6" AND a piston. Clean/ necessary.

  • Page 50: Snowplow Maintenance

    In order for the customer to be eligible for warranty every year, the snowplow, inclusive of all components, must be returned to an authorized Arctic dealer every spring for preventative maintenance. Warranty work must be performed by an authorized Arctic dealer. Failure to do so will nullify any future warranty claims.
  • Page 51 Post season maintenance -Inspect the plow assembly (the blade, A-frame, lift frame, spreader bar and mounting kit, all fasteners, pins, retainers, nuts and bolts for tightness) for any damage (cracks, abnormal wear, etc.) and repair or replace part as necessary. Tighten all undercarriage bolts. Apply grease to the centre pin (if applicable).

  • Page 52: Clearing Driveways And Parking Lots

    NOTE: All Arctic snowplows have a stop built in, to prevent the blade from contacting the bottom of the bumper. If the blade is pushed too high on the snow bank, the stop will bind and cause the truck’s weight to be supported by the plow.

This manual is also suitable for:

S2-90sS2-90pQliv sd2
