User Manual
WeatherSens
09-2024 – 01-08-002
09-2024 – 01-08-002

Advertisement

loading
Need help?

Need help?

Do you have a question about the HydroMet WeatherSens WS200 and is the answer not in the manual?

Questions and answers

Related Manuals for KISTERS HydroMet WeatherSens WS200

Summary of Contents for KISTERS HydroMet WeatherSens WS200

  • Page 1 User Manual WeatherSens 09-2024 – 01-08-002 09-2024 – 01-08-002...
  • Page 2 Part V Anemometers ..........................27 WeatherSens MP Series ......................28 WeatherSens WS Series ......................29 Others ............................30 Obligations of the Operator and Disposal Part VI Obligations of the Operator ....................... 31 Dismantling / Disposal ........................ 31 © 2024 | KISTERS...
  • Page 3 KISTERS has been advised of the © 2024 | KISTERS. Any rights not expressly granted herein possibility of such damages.
  • Page 4 Sensor model: WS200, WS500, WS600, WS650 § Sensor model MP-Series: AR200, MP500, MP600, MP650, MPR100, MPS101; MPS100 § Installation Guide WS or MP-Series § Factory Acceptance Test Protocol § 10 m cable M12 SAC 8-pol § Factory setting: SDI-12 Version 1.3 © 2024 | KISTERS...
  • Page 5 Safety Instructions § Read the user manual including all operating instructions prior to installing, connecting and powering up the KISTERS WeatherSens. The manual provides information on how to operate the product. The manual is intended to be used by qualified personnel, i.e. personnel that have been adequately trained, are sufficiently familiar with installation, mounting, wiring, powering up and operation of the product.
  • Page 6 Thank you for choosing our product. We hope you will enjoy using the device. KISTERS manufactures, sells, installs and operates quality instrumentation, data loggers and communication technology. Products are designed with passion for environmental monitoring and with a deep understanding of the quality, accuracy and robustness needed to fulfil the requirements of measurement practitioners in the field.
  • Page 7 IP66 and complies to the WMO Guide to Instruments and Methods of Observation (WMO), section on wind measurements. Note: The datalogger has to poll in 1 second interval and to aggregate vectorial or scalar mean values or any further meteorological and statistical calculation. © 2024 | KISTERS...
  • Page 8 § Wind speed measuring range up to 60 m/s. § Housing consisting of Aluminum alloy with Teflon coating. Not all models are shown in the figure above. © 2024 | KISTERS...
  • Page 9 Ingress protection: IP66. § Temperature from -40 to +70 °C. § Humidity from 5 to 100 % RH. § Wind resistibility from 0 to 60 m/s (AR/MP series) or 45 m/s (WS series). § Vibration resistibility: --- © 2024 | KISTERS...
  • Page 10 Only one interface can be configured and operated. A firmware update can be proceeded at KISTERS authorized and certified Hubs and partners. Usually it is supposed that new firmware versions are developed under maintenance aspects to serve and comply to new and future requirements and features.
  • Page 11 Mounting of sensor must be placed vertically and fixed firmly. Mounting Kit Checklist Mounting method Applicable models Tube1 , Ø 40 - 50 mm MPS100, MPR100/101, AR200, WS series Tube2 , Ø 50 - 60 mm MP series © 2024 | KISTERS...
  • Page 12 Installation 2.2.1 Tube1 Dimensions MPS100, MPR100/101, AR200, WS series Figure 1 – Dimensional Drawing 2.2.2 Tube2 Dimensions MP-Series Mounting Method This chapter contains the following subsections: § Tube1 § Tube2 © 2024 | KISTERS...
  • Page 13 2. M6 screw and spring 3. Cable and plug 4. Fixing rod (OD 50 mm) 2.3.2 Tube2 1. Sensor 2. Bracket 3. Screws 4. Nuts 5. Cable and plug 6. Fixing rod (min OD 50 mm) © 2024 | KISTERS...
  • Page 14 3. Position the sensor in such a way that the South and North sensors are in alignment with the fixed point of reference in the North. Sensor Connector, Cable In this manual, one type of connector used is described. Other customized connectors are not included in the manual. © 2024 | KISTERS...
  • Page 15 Power lines such as Power VCC + and Power GND must be connected. Otherwise, the sensor will not turn on. Figure 3 – 8-pin M12 connector from sensor side Remarks: 1. The interface and protocol are switched through ASCII commands. © 2024 | KISTERS...
  • Page 16 1: Back to ASCII mode. Floating protocol Select MODBUS-RTU $AAQ 02<CR><LF> Floating protocol. AA: address, Default: 00, Switch Lufft 2: Back to Lufft setting $AACFG 2<CR><LF> protocol mode. ** Setting is invalid after power off and needs to be © 2024 | KISTERS...
  • Page 17 $AAX N<CR><LF> Unit 1: Imperial Unit. AA: address, $AACFG 1<CR><LF> Default: 00, 0M! output monitor data 1: Back to ASCII mode. configuration AA: address, MSW, LSW $AAJ MSW,LSW<CR><LF> definition see below Bits Examples $00J 11000000000000000000000000000000, 00000000000000000000000000000000\r\n MP200 © 2024 | KISTERS...
  • Page 18 0<cr><lf> 0D0! 0+WS+WD<cr ><lf> Temperature, 0M2! 0tttn<cr><lf> 0<cr><lf> 0D0! 0+TEMP+H+P humidity, and <cr><lf> pressure Solar Solar 0M4! 0tttn<cr><lf> 0<cr><lf> 0D0! 0+SR<cr><lf> Radiation Radiation 0tttnn<cr><lf> 0D0! 0+WS+WD+TE Parameters Parameters MP+H+P+SR<c 0D1! r><lf> (if required) (see Note below) © 2024 | KISTERS...
  • Page 19 Text-based communication with devices is possible using ASCII protocol. ASCII protocol is network-compatible and serves exclusively for online data requests. The device will not respond to incomprehensible ASCII commands. For more information, see the following subsections: © 2024 | KISTERS...
  • Page 20 Response: ! <CR><LF> Baud rate:19200 $AAZ<CR><LF> Baud rate reading ! BR<CR><LF> Send: AA = the device address. $01Z<CR><LF> Response: ! 19200<CR><LF> Baud rate:19200 #AA0<CR><LF> Wind speed value reading >Value<CR><LF> Send: AA = the device address. #010<CR><LF> © 2024 | KISTERS...
  • Page 21 Value4: air temperature Unit: Value5: barometric pressure m/s, degree,%,°C, hPa #AAAC<CR><LF> Seven parameters reading >Value1, Value2, Value3, Send: Value4, AA = the device address. #01AC<CR><LF> Value5,Value10<CR><LF> Response: Value1:wind speed >4.1,97.0, Value2:wind direction 78.5,29.4,994.3,0<CR><LF> Value3: air humidity © 2024 | KISTERS...
  • Page 22 Length of Data Data CRC-16 1byte 1byte 1byte Numbers of Data 2bytes Write Data Message Address: 0x01, Function Code: 0x06 Request Format: Address Function Code Register Start Address Register Numbers CRC-16 1byte 1byte 2bytes 2bytes 2bytes Return Format: © 2024 | KISTERS...
  • Page 23 3F 7A E1 48 then convert the hex value to IEEE754 Float = 0.98 Wind Angle = 34 7B 43 A8 swap byte order to 43 A8 34 7B then convert the hex value to IEEE754 Float = 336.41 © 2024 | KISTERS...
  • Page 24 Wind speed, to the nearest tenth of a unit. If the data for this field is not valid, the field will be blank. <4> Wind speed units: K = km/hr M = m/s N = knots S = statute miles/hr Default: (knots) <5> Status: A = data valid V = data invalid <CR><LF> Response terminator © 2024 | KISTERS...
  • Page 25 Enabled. Transmitted once per second. 3.1.4.2 $WIXDR Summary The WIXDR protocol provides all weather parameters that are available for the models. Missing parameters, e.g. in the case of an MP500P-HN, are indicated by not assigning any values to them. © 2024 | KISTERS...
  • Page 26 § Please do not ship the goods prior to obtaining the reference number. KISTERS will not reject any equipment that arrives without reference number; however, it may take us longer to process. Custom requirements for items sent to KISTERS for warranty or non-warranty repairs: Check with your national customs/tax authorities for details, processes and paperwork regarding tax exempt return of products.
  • Page 27 10 … 30 V dc Power Consumption 20 mA @ 12 V dc Overall Heating None Operating temperature -40 … +70 °C Operating humidity 5 % … 100 % RH Connector M12 8 pol Connection cable (Accessories) 10 m © 2024 | KISTERS...
  • Page 28 -40 … +70 °C snow cumulation and/or ice accretion. Operating humidity 5 % … 100 % RH 5 % … 100 % RH Connector M12 8 pol M12 8 pol Connection cable 10 m 10 m (Accessories) © 2024 | KISTERS...
  • Page 29 5 % … 100 % RH 5 % … 100 % RH 5 % … 100 % RH Connector M12 8 pol M12 8 pol M12 8 pol Connection cable 10 m 10 m 10 m (Accessories) © 2024 | KISTERS...
  • Page 30 15 mA @ 12 V dc Operating temperature Note: Non-heated – without -40 … +70 °C snow cumulation and/or ice accretion. Operating humidity 5 % … 100 % RH Connector M12 8 pol Connection cable 10 m (Accessories) © 2024 | KISTERS...
  • Page 31 Instead, these old appliances must be collected separately and disposed of via the local collection and return systems. Integrated or provided batteries and accumulators must be separated from the appliances and disposed of at the designated © 2024 | KISTERS...
  • Page 32 At the end of its service life, the lithium-ion battery must be disposed of according to legal provisions. EU WEEE Directive As players in the environmental market, KISTERS AG is committed to supporting efforts to avoid and recycle waste. Please consider: §...
  • Page 33 +64 7 857 0810 sales@kisters.co.nz www.kisters.co.nz Latin America | KISTERS Latin America +57 350 575 4079 sales@kisters-latam.com www.kisters-latam.com North America | KISTERS North America +1 561 459 4876 kna@kisters.net www.kisters.net Spain | KISTERS Ibérica info@kisters.es www.kisters.es © 2024 | KISTERS...
  • Page 34 © 2024 | KISTERS 04/09/2024 © 2024 | KISTERS...
