EMPERO EMP.EKF-6 Quick Start Manual

Convection oven (electrical)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CONVECTION OVEN (ELECTRICAL)
Kasap Tip Dik Buzdolapları
CONTENTS
Page
2
Page
3
Page
3
Page
4
Page
4
Page
4
Page
5
Page
6
Page
8
Page
9
Page
10
Page
13
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMP.EKF-6 and is the answer not in the manual?

Questions and answers

Related Manuals for EMPERO EMP.EKF-6

Summary of Contents for EMPERO EMP.EKF-6

  • Page 1: Table Of Contents

    CONVECTION OVEN (ELECTRICAL) Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...

  • Page 2: Ageneral Information

    CONVECTION OVEN (ELECTRICAL) Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *The Professional Convection Ovens ,that provides high efficiency has been designed to be used in industrial kitchen. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.EKF-6 800x855x721 830x890x730 TECHNICAL INFORMATION Electric Cable Power Fuse Product Code...

  • Page 4: A3 Transportation

    CONVECTION OVEN (ELECTRICAL) TRANSPORTATION *This appliance can not be moved by hand from area to area.It must be moved on pallet with Kasap Tip Dik Buzdolapları forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.

  • Page 5: Csafety Instructions

    CONVECTION OVEN (ELECTRICAL) Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials.The ...

  • Page 6: Doperation

    CONVECTION OVEN (ELECTRICAL) OPERATION Kasap Tip Dik Buzdolapları *Control Panel; A : ON/OFF button B : LAMP BUTTON C : STAGE CHARTER * FAN STAGE * FAN COOKING STAGE * FAN STEAM COOKING D : INDICATOR SET POT E : HEAT TIME (INDICATOR) F : TIMER (MACHINE MIN SETTING) G: STEAM REGULATOR BUTTON * 20% 40% 60% 80% 100% TO THE STAGE, THE STEP IS STEAMED.
  • Page 7 CONVECTION OVEN (ELECTRICAL) Kasap Tip Dik Buzdolapları *Operating; • Connect the appliance to a clean water source , then open the tap. • Connect the plug to the electricity,then press the(energy inlet) button , then (ON) button. • There may be smell and smoke in the first time of installation , because the material inside are heating for the first time , so , adjust the temperature 240 ºC and let it work for 30 minutes while it’s empty .

  • Page 8: Ecleaning & Maintenance

    CONVECTION OVEN (ELECTRICAL) CLEANING & MAINTENANCE Kasap Tip Dik Buzdolapları ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Always turn off the appliance and disconnect from the power supply before cleaning. • Clean the inside of the oven with soft cloth by using oil solvent spray,before the appliance gets cooled exactly.Waste water will flow through waster water outlet after cleaning.

  • Page 9: Ftroubleshooting

    CONVECTION OVEN (ELECTRICAL) Kasap Tip Dik Buzdolapları TROUBLESHOOTING Check if the appliance is plugged in. Check the electrical connections and THE APPLIANCE DOESN’T OPERATE voltage. Check if the fuse is on or off. Check the oven’s lid. Check the heat settings. Check the water connection if the THE APPLIANCE DOESN’T COOK WELL injection system doesn’t operate.

  • Page 10: Gspare Part List- Exploding Drawing

    CONVECTION OVEN (ELECTRICAL) SPARE PART LIST- EXPLODING DRAWINGS Kasap Tip Dik Buzdolapları...
  • Page 11 CONVECTION OVEN (ELECTRICAL) Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE: EMP.EKF-6 PRODUCT NAME P.CODE ARA-KNX.KFR-0005 COVER HANDLE AND LOCK SET M.AKS-KLP-KPK-001 YTL-KNX.KFR-FS-0003 SHELF HANGER PIN JP.M.AKS-MNT-INX-001 HINGE YTL-KNX.KFR-KS-0039 LID FITTING YTL-KNX.KFR-KS-0045 GLASS OPEN PIN YSC-KNX.KFR-LZ-0130 GLASS HOLDER M.CAM-BTMP-004...
  • Page 12 CONVECTION OVEN (ELECTRICAL) TIMING RELAY JP.M.ELK-KNT-ROL-005 JP.M.ELK-KNT-ROL-006 TIMING RELAY Kasap Tip Dik Buzdolapları JP.M.ELK-KLM-040 AVK 6 TERMINAL JP.M.ELK-KLM-008 AVK 6 TERMINAL AVK4 TERMINAL JP.M.ELK-KLM-021 JP.M.ELK-KLM-024 TERMINAL JP.M.ELK-SGR-010 GLASS FUSE 2A JP.M.ELK-MEK-LMT-004 360°C LIMITOR JP.M.ELK-KLM-041 TERMINAL 6.3A LC1K0901M7 CONTACTOR JP.M.ELK-KNT-KNT-020 JP.M.ELK-KNT-KNT-027 LC1D09M7 CONTACTOR M.ELK-SLN-MTL-001 SOLENOID VALVE 230VAC 1/4 T-GM...

  • Page 13: Helectric Circuit Schema

    CONVECTION OVEN (ELECTRICAL) Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA Large lighted 0-1 inner lighting switch Control panel ON/OFF switch Vapor switch C1.C2 Fan motor contactor 230V Heater resistance contactor 230V Vapor valve 230V CTR1.CTR2 Condenser M1.M2 Inner air circulation fan motor 120W 2800d/dk 230V Thermostat signal lamp Vapor signal lamp Timer signal lamp...
