BANDIT V1 - ASSEMBLY GUIDE – Rev. Oct. 2024
THANKS FOR CHOOSING ONE OF OUR KITS!
This manual has been written taking into account the common issues that we often find people experience in
our workshops. The order in which the components are placed on the board is meant to make assembly as
easy as possible.
Some steps are not obvious, so even if you're an experienced DIYer please read the steps thoroughly before
starting. You will be soldering both boards at the same time.
If this is your first project, please read this article before you start assembling the kit:
www.befaco.org/howto/
GOOD LUCK!
The components are placed on the main board, split the boards apart and save the control
Board for later.
RESISTORS
It's strongly recommended to measure the resistors with a multimeter. Color code might be hard to read with blue/green
background.
Qty
Value
Code
1
100k
Brown, black, black, orange, brown
4
150k
Brown, green, black, orange, brown
4
68k
Blue, gray, black, red, brown
4
1k
Brown, black, black, brown, brown
3
47k
Yellow, violet, black, red, brown
2
180k
Brown, gray, black, orange, brown
2
33k
Orange, orange, black, red, brown
1
330k
Orange, orange, black, orange, brown
1
220k
Red, red, black, orange, brown
1
200k
Red, black, black, orange, brown
1
191k
Brown, white, brown, orange, brown
1
22k
Red, red, black, red, brown
FERRITE
To solder the two ferrite beads use a recycled resistor leg passed through each ferrite and proceed as if it were a
resistor. Ferrite beads don't have polarity.
Qty
Name on PCB
2
F1, F2
Name on PCB4
R1, R2, R3, R4, R5, R6, R16, R17, R25, R26,R27, R28, R29, R30
R9, R21, R23, R24
R7, R8, R10, R19
R31, R32, R33, R34
R12, R15, R18
R36, R38
R11, R14
R22
R20
R37
R35
(place this resistor standing in order to fit in the PCB silkscreen)
R13
1
