Installation Manual
Page | 1
REV 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ondo and is the answer not in the manual?

Questions and answers

Summary of Contents for RPI ondo

  • Page 1 June 30, 2023 Installation Manual Page | 1 REV 3...
  • Page 2: Table Of Contents

    June 30, 2023 TABLE OF CONTENTS ELECTRICAL POWER REQUIREMENTS………………………………………………………………3 MECHANICAL CONNECTION OF TOWERS ................3 CABLE FEED THROUGH HOLES ....................4 CPC CABLE CONNECTIONS ....................5 CONDENSATE PAN TUBE CONNECTIONS................6 USER INTERFACE LAN AND USB CONNECTIONS ..............7 INTERNAL ELECTRICAL PLUG POWER CONNECTIONS ............8 DC POWER CABLE CONNECTIONS……………………………………………………………………9 REFRIGERATION POWER SWITCH…………………………………………………………………….10 BATTERY BACK UP &...
  • Page 3: Electrical Power Requirements

    June 30, 2023 Electrical Power Requirements: Most systems featuring cold, warm, or convertible options will require a NEMA L14-20R (receptacle) for each locker column. Each column requires a 115/208-230 VAC/1PH 20amp four wire dedicated circuit. The following diagram is representative of the NEMA L14-20 receptacle. Mechanical Assembly of Towers: After unpacking all the hardware attach the columns to each other as shown with the Metric #4 screws and nuts supplied.
  • Page 4: Cable Feed Through Holes

    June 30, 2023 Cable Feed Through Holes: Note the aligned cable pass through holes. These holes exist on both sides of the columns for passing the appropriate cables between columns. (See images 2,3,4 & 5) Image 2 Image 3 Image 4 Image 5 Page | 4 REV 3...
  • Page 5: Cpc Cable Connections

    June 30, 2023 CPC Cable Connections: Find and attach the corresponding cables from the adjacent column. The Cables are labeled for identification. (See image 6) Attach the CPC connectors to the corresponding CPC connectors in the appropriate column. (See images 7,8, & 9) Image 6 Image 7 Image 8...
  • Page 6: Condensate Pan Tube Connections

    June 30, 2023 Condensate Pan Tube Connections: Feed the clear condensate hoses from each column into the column that houses the condensate pan. Use the same holes that you fed the CPC cables through. (See image 11A) The hoses must be attached under the lowest column brace as level as possible so that the hoses can be pitched towards at the condensate pan.
  • Page 7: User Interface Lan And Usb Connections

    June 30, 2023 User Interface , LAN and USB Connections: Connect the USB cable from the electronics drawer to the USB Find the long USB cable that exits from the rear of the electronics drawer. Route it through the cable pass through holes if needed to reach the User Interface screen.
  • Page 8: Internal Electrical Plug Power Connections

    June 30, 2023 Internal Electrical Plug Power Connections: For systems that have a refrigeration compressor check or insert the 208-230VAC plug into the receptacle referenced in the image. Insert the 120VAC plugs from the User Interface screen(s) and the condensate pan into the appropriate receptacles as indicated in the image below. (See image 13) Image 13 Page | 8 REV 3...
  • Page 9: Dc Power Cable Connections

    June 30, 2023 DC Power cable Connections Some larger systems have multiple electronics drawers with DC power supplies. These electronics drawers will be located in adjacent columns and the power supply voltage needs to be routed to the main drawer.. This is done with large DC CPC connectors and cable(s) (See image 10A, 10B &...
  • Page 10: Refrigeration Power Switch

    June 30, 2023 Refrigeration Power Switch: Note the compressor on off switch is located behind the access panel in the front of the column. This will only turn on or off the refrigeration system. (See image 14) Image 14 Page | 10 REV 3...
  • Page 11: Battery Back Up & Operation

    June 30, 2023 Battery backup connection and operation: • Unlock and remove the front access panel(s) at the bottom of the column that houses the power supply drawer(s). • This panel has the Electrical Power symbol on the front. Depending on the quantity of lockers (“Cubbies”) there may be several power supply drawers.
  • Page 12 June 30, 2023 • Connect the battery wires with terminals to the battery. Some larger systems will have more than one battery. Look for the power insignia to find the power supply drawers which may contain the Batteries. The images below show the battery as shipped with the negative terminal disconnected and after the connection has been made during installation.
  • Page 13 June 30, 2023 To continue refer to the operator’s manual supplied. Page | 13 REV 3...
