Summary of Contents for RinnoVision RV-MAX 360
- Page 1 RV-MAX 360 USER MANUAL Version...
-
Page 2: General Precautions
May be harmful to the eye. The RV-MAX 360 is not intended for continuous use. Allow unit to cool between uses. The product enclosure is designed to be used as a radiator to dissipate the heat generated by the powerful LED lighting. -
Page 3: Battery Maintenance
Check for missing parts, breakage of parts, traces of humidity inside the transparent housing, and any other condition that may affect the equipment’s operation. Do not use the RV-MAX 360 if it has been damaged—for example, if cracked, punctured, or harmed by water. If damaged, have the equipment repaired before use. -
Page 4: Specifications
RV-MAX USER MANUAL SPECIFICATIONS GENERAL SPECIFICATIONS • High-Resolution 360° virtual reality camera • Generates 4K MP4 video files • 6600 lumens light • 6 Light modes • Extra spotlight for side pipe inspection • Ruggedized design • IP68 water and dust ingress protection •... -
Page 5: Maintenance Accessories
Powerful enough to run most NASSCO software platforms. MAINTENANCE ACCESSORIES • Microfiber cleaning cloth • Wet cleaning wipes • USB key POWER CHARGERS • RV-MAX 360 charger • Tablet charger POWER INVERTER • Allows charging using your vehicle’s standard 12V outlet • 300W Page... - Page 6 RV-MAX USER MANUAL EXTENDABLE POLE • Maximum length: 29.5 ft. (extensions available) • 3/8-16 threaded end • Fiberglass material • Electrically and thermally insulated • Anti-rotation oval shape WARNING: While the latches are closed, pull on both ends of the pole to confirm that the sections are not slipping.
-
Page 7: How To Use
Power up the RV-MAX 360 by pressing the power button on the top cap for 3 seconds. This is usually a good time to screw the RV-MAX 360 on the extendable pole or tripod if this wasn’t done already. Page... - Page 8 Make sure that the tablet is correctly connected to the RV-MAX 360’s WiFi hotspot (it will have the same name as the unit’s serial number). Open the RinnoView software and wait for the RV-MAX 360 to connect to it. Page...
- Page 9 RV-MAX 360. Position the RV-MAX 360 so that its axis is parallel to the manhole AND hold it about 3 feet (1 meter) above the manhole rim. ≈ 3 feet (1 meter) (optional) In the RinnoView application, type in a name for the video to be generated &...
- Page 10 RV-MAX USER MANUAL Turn on the RV-MAX 360 light and select the optimal light mode. Select light mode 6” (150mm) - 2’ (600mm) diameter: 50%/50%+ modes 2’ (600mm)-15’ (4500mm) diameter: 100%/100%+ modes 15’ (4500mm) + diameter: 200%/200%+ modes Start/Stop Light The «...
- Page 11 Lower the RV-MAX 360 to the bottom of the manhole at a maximum speed of 10 feet (3 meters) per minute.
- Page 12 RV-MAX USER MANUAL DOWNLOADING THE VIDEO In the RinnoView software, go to the Videos tab and select RV-MAX 360 in the left drop- down menu. (if you want to download a single video) Click on the video’s associated “ ” icon or...
- Page 13 RV-MAX USER MANUAL (if you want to download multiple videos) Check each video’s checkbox and click on the “DOWNLOAD” button. Once the video(s) are done downloading the associated “ ” icon(s) will turn to “ ” Page...
- Page 14 Note also that RinnoView can be installed to any other computer if you’ d like to improve the workflow by avoiding this step. Contact RinnoVision or your local distributor’s technical support if you’re interested and we’ll gladly help you set this...
- Page 15 RV-MAX USER MANUAL The .MP4 video can then be played in VLC Media Player or the compatible NASSCO MACP- certified software of your choice. Page...
- Page 16 RV-MAX USER MANUAL 30-800 Carter, Sainte-Marie QC, Canada G6E 0B2 418-230-4040 info@rinnovision.com Page...
