Summary of Contents for DALIAN GOODDISPLAY CO. DMPH253EG1
- Page 1 25.3-inch Color E-paper Display Signage DMPH253EG1 Dalian Good Display Co., Ltd.
-
Page 2: Product Specifications
25.3 Inch Epaper Signage Product Specifications Customer Standard Description ePaper Display Signage Model Name DMPH253EG1 Date 2024/05/21 Revision Design Engineering Approval Check Design Zhongnan Building, No.18, Zhonghua West ST,Ganjingzi DST,Dalian,CHINA Tel: +86-411-84619565 Email: info@good-display.com Website: www.good-display.com www.good-display.com 2/14 DMPH253EG1... -
Page 3: Table Of Contents
1. Overview ..........4 2. Product Advantages ........4 3. Mechanical Specifications ......4 4. Product Structure ........6 5.USB Display Updates ......... 9 6. WIFI Display Updates .......12 7. Packaging and Installation ......13 8. Precautions ..........14 www.good-display.com 3/14 DMPH253EG1... -
Page 4: Overview
• Dual-state display (retains last image even after power loss) • Display can be updated via USB or WiFi (USB preferred) • Image formats supported: BMP, PNG, JPG 3. Structure Specification Model DMPH253EG1 Screen Size: 25.3 inch Display Screen Type: ACeP Color ePaper Display Screen Resolution: 3200x1800 USB 2.0: One port HOST, one port OTG... - Page 5 Operating System: Android 7.1 CPU: Quad-core ARM Cortex A7 DDR: 1GB eMMC: 8GB Weight: Approximately 4kg Outline Specification Size: 584x340x24mm Operating Temp: 15°C to 35°C Temperature and Storage Temp: -25°C to 50°C Humidity Operating Humidity: 35% to 80% www.good-display.com 5/14 DMPH253EG1...
-
Page 6: Product Structure
25.3 Inch Epaper Signage 4.Product Structure Figure 1: Front View of DMPH253EG1 mounting bracket Figure 2: Back view of DMPH253EG1 www.good-display.com 6/14 DMPH253EG1... - Page 7 ① ④ ⑪ Figure 3: Side View of DMPH253EG1 Power Button Turn the main power on or off. Press the power button briefly to start the sign; the LED light will turn on. Press the power button briefly again to turn off the sign;...
- Page 8 When the sign is powered off and the charger is unplugged, the indicator light will turn off. Type-C Charging Port Connect to a Type-C power adapter. WiFi Antenna Port Connect to the WiFi antenna. HDMI-OUT For internal debugging purposes. Storage Card Slot www.good-display.com 8/14 DMPH253EG1...
-
Page 9: Image Processing
Image Processing Tool" will appear on the D drive. Enter this folder to find the following files. 2. Place the images you want to update on the D drive and save them in a newly created folder. Ensure that the image paths and filenames do not contain any spaces. www.good-display.com 9/14 DMPH253EG1... - Page 10 - Select "No" for Clear screen. - Choose "Second" for Interval Time. - Finally, enter the flashing interval time in seconds in the blank space (default is 30s, if it exceeds 300s, the system will enter sleep mode). www.good-display.com 10/14 DMPH253EG1...
-
Page 11: Copying Images
The processed images will be automatically generated in a folder named XT_Resources, and the converted images will be saved in the "image" folder. 5.3. Copying Images Copy the XT_Resources folder to the root directory of a USB flash drive. www.good-display.com 11/14 DMPH253EG1... -
Page 12: Installing The App
WiFi password to the device. Note: Device reboot is required after network configuration. 6.3. Image Display 1. Check if the device is online in the app. If it is offline, please manually refresh the device status by pulling down. www.good-display.com 12/14 DMPH253EG1... -
Page 13: Packaging And Installation
7. Packaging and Installation 7.1 Please verify if you have received the following items containing the package contents: • E Ink Screen Signage *1 • USB Power Cable *1 E Ink Screen Signage USB Power Cable www.good-display.com 13/14 DMPH253EG1... -
Page 14: Product Installation
4. Ensure waterproofing during usage; avoid water exposure. 5. Be cautious of collisions during usage. 8.3 Storage Precautions Store in a fireproof, moisture-resistant environment (humidity not exceeding 80%), away from high temperatures (not exceeding 50°C), avoiding stacking, dirt accumulation, heavy object pressure and damage. www.good-display.com 14/14 DMPH253EG1...
