Nordic CWC-L0118 Operating Manual

18v cordless window cleaner
Hide thumbs Also See for CWC-L0118:
Table of Contents

Advertisement

Quick Links

Download this manual
18V CORDLESS
WINDOW CLEANER
OPERATING MANUAL
CWC-L0118

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CWC-L0118 and is the answer not in the manual?

Questions and answers

Related Manuals for Nordic CWC-L0118

Summary of Contents for Nordic CWC-L0118

  • Page 1 18V CORDLESS WINDOW CLEANER OPERATING MANUAL CWC-L0118...

  • Page 2: Product Specification

    NORDIC 1. PRODUCT SPECIFICATION Voltage Max Vacuum 1.8kpa Cleaning Width 26cm Tank Volume 76 ml 2. GENERAL POWER TOOL SAFETY WARNINGS Read all safety warnings and instructions. Failure to heed warnings and follow instructions may result in electric shock, fire and/or serious injury.
  • Page 3 NORDIC 2.3 PERSONAL SAFETY • Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool when you are tired or under the influence of drugs, alcohol or medication. A moment of inattention when operating a power tool may result in serious personal injury.

  • Page 4: Intended Use

    NORDIC 2.5 SERVICE Your power tool should be serviced by a qualified specialist using only standard spare parts. This will ensure that it meets the required safety standards. 3. INTENDED USE The product is a battery operated wet and dry vacuum that can be used on wet and dry surfaces (e.g.
  • Page 5 NORDIC • In case of skin or eye contact, follow the instructions below: 1. Immediately rinse with water. Neutralize with a mild acid such as lemon juice or vinegar. 2. In case of eye contact, rinse abundantly with clean water for at least 10 minutes.

  • Page 6: Before You Start

    NORDIC Ambient temperature 40°C max. (only for battery) Do not expose charger and battery pack to water Use battery and charger only in closed rooms Do not incinerate battery pack or charger 6. WINDOW CLEANING SAFETY INSTRUCTION • Always switch the power off and remove the battery before assembling, disassembling, cleaning, and storage.
  • Page 7 NORDIC 2. Align the rib (10) on the filter assembly (9, 11) with the groove in the back of the dust cup (7), then firmly push the filter assembly in until it is seated in the dust cup. 3. Put the sponge filter (12) on the motor unit, so that the two holes on the filter are inserted into the tabs on the motor unit.
  • Page 8 NORDIC Hold the dust cup (2) at an angle to insert the notch at the bottom into the front tab (13) on the motor unit. Then push the dust cup onto the motor unit until it snaps into place. 7.2 DISASSEMBLY ...

  • Page 9: Operation

    NORDIC 8. OPERATION  Keep hair, loose clothing, fingers, and body parts away from openings and moving parts. 8.1 VACUUMING 1. Attach the desired accessory. 2. Press the On/Off button (5) to turn the vacuum cleaner on or off. 3. If you need to change the direction of the vacuum head, press the On/Off button to turn the vacuum cleaner off, push the vacuum head down to rotate it left or right (360°...

  • Page 10: Using The Accessories

    NORDIC  Important: DO NOT tilt the vacuum cleaner backwards, as this will cause liquids to enter the motor unit and be expelled from the air outlet. This can damage the appliance. 8.2 EMPTYING THE DUST CUP 1. Press the On/Off button (5) to turn the vacuum cleaner off.
  • Page 11 NORDIC 9.3 SMALL BRUSH The small brush (16) can be used for a variety of purposes (e.g., sofas, beds, floors, curtains). Only use this tool too vacuum dust. 9.4 SCREEN BRUSH OR UPHOLSTERY NOZZLE The upholstery nozzle (17) can be used to vacuum fabric sofas, (insect) window screens, and various other fabric furnishings.

  • Page 12: Cleaning And Care

    NORDIC 5. Choose a nozzle setting: Spray / Stream / Off. 6. Spray the water or cleaning solution on the cleaning surface, and clean the surface with the scrubber pad. 7. Use the vacuum cleaner with the scraper attachment (15) to vacuum any remaining water .
  • Page 13 NORDIC 9.2 SPECIFIC CLEANING INSTRUCTIONS Our machines have been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper machine care and regular cleaning. 9.2.1 MOTOR UNIT Clean with a soft, moist cloth. Keep the air inlets and outlets free of any obstructions (e.g. dust, hair, lint, etc.).

  • Page 14: Key Components List

    NORDIC 12. KEY COMPONENTS LIST AIR INLET / VACUUM HEAD (NOZZLE) FILTER DUST CUP SPONGE FILTER MOTOR UNIT FRONT TAB DUST CUP RELEASE BUTTONS CREVICE TOOL ON/OFF BUTTON SCRAPER AIR OUTLETS SMALL BRUSH GROOVE UPHOLSTERY NOZZLE NOTCH SPRAY BOTTLE FILTER HOLDER...
  • Page 15 NORDIC...
  • Page 16 NORDIC...
