KAT VR KAT Vehicle Hub User Manual

1．Wear protective gloves and footwear throughout the entire procedure!
2．Scan the left QR code for the Owner's Manual and read it carefully. Scan the right QR
code to watch the video guide.
3．All screws must be tightened very firmly.
*Slight differences may exist depending on the device version.
Scan For Manual
Left
Right
Left
Right
Sit Module
Rubber cover: If needed, you may install it to protect the surface from scratches.
Installation Guide
Mounting the Long Bolts
- Find the sit Module and the long
bolts.
- Rotate the bolts clockwise into the
holes on the inner sides of the sit
module by 2cm.
KAT Vehicle Hub - User Guide
1
Connecting Plate Wrench
3
Install the Right Sit Module
- Remove the 2 hole plugs from the
support rods.
-Identify the Right sit module with
the button and LED light.
-Align the right bolt with the hole on
the right support rod and insert it.
Long bolt
Receiver
3
Scan For Video Guide
Nuts, screws & gaskets
Rubber cover
Mounting the Plate and Nut
- Find the connecting plate, nut and
big gasket.
- Attach the connecting plate as
shown.
- Install the big gasket and then the
nut, do not tighten yet.
- Install the left side in the same way.
