Summary of Contents for Sunco FL 150SW-BR-3050K
- Page 1 Lighting made better. User Manual High Wattage Selectable Flood Light SKU: FL_150SW-BR-3050K support@sunco.com (844) 334-9938...
-
Page 2: What's In The Box
What’s in the Box? Flood Light Get Your Gear Ladder Drill Screwdriver Adjustable Wrench Wire Strippers M8” Allen Wrench... -
Page 3: Before You Start
WARNING: • Not compatible with all dimmers. For more Cancer & Reproductive Harm- www.P65Warnings.ca.gov dimming information, please visit www.sunco.com. • Not compatible with timing devices. 2.) This device must accept any interference that This device complies with Part 15 of the FCC rules. - Page 4 Installation Guide STEP 1 a. Turn off circuit breaker that provides power to the light. STEP 2 a. Connect light wires to supply wires: • Black to Black (Live) • White to White (Neutral) • Green to Bare Copper (Ground) LIVE BLACK NEUTRAL...
- Page 5 Installation Guide (Yoke Mount) STEP 1 a. Thread wires through central bracket hole. b. Mount fixture to surface using the hole pattern provided on the connecting bracket. Set Screw Bolt c. Loosen center bolts and set screw. Lower Bracket M8 Hole 0.31’’...
-
Page 6: Product Details
Product Details Recommended Dimmers Brand Model LEVITON DS710-10Z LEGRAND RH4FBL3PW Specifications Voltage Average Lifetime 120V-277V 50,000 hrs Wattage 80W/100W/150W Lumens 12000,15000,22500lm Beam Angle 130° Moisture Rating WET Location Weight 9 lbs >80 Efficacy Usage 150lm/w Outdoor Housing Material Die Casting Amps 2.0A Dimmable... -
Page 7: Common Troubleshooting
Common Troubleshooting We’ve got you covered! Our troubleshooting If you still need some assistance, feel free to section is here to shed some light and provide contact us. Our team of lighting experts are you with easy-to-follow solutions for any problem. happy to help brighten your day. - Page 8 Common Troubleshooting Flickering Light is flickering when turning on. Check that fixture wiring connections are secure. Light flickering with lights on the same circuit. Prevent circuit overload from lights. Light flickering when turned on. Verify fixture compatibility and that it is grounded. Light flickering when dimmed.
- Page 9 Light Distribution Angle -/+180 -150 -120 AVERAGE BEAM ANGLE (50%): 115.4 DEG 1500 C0/180 115.1 3000 C90/270 115.7 4500 6000 UNIT:cd Luminous Intensity Distribution 1 -303 7500 The lighting distribution angle determines Asymmetric Lighting (Beam Angle): This how light spreads from a source and impacts directs light in a specific direction, reducin glare its illumination.
- Page 10 Lighting made better. support@sunco.com (844) 334-9938 REV1.0...
