FIREPLACE GLASS DOOR
SIZE - SMALL
OWNER'S INSTALLATION
AND OPERATION MANUAL
MODEL: HLFD-SM
SKU: 173249
Overall Door Dimension
Fits Openings
Width X Height
Width
Height
37.5" X 30"
30" to 37" 22.5" to 29.5"
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-866-762-4050, 8:00 am - 4:30 pm CST, Monday
through Friday or email service@bluegrassliving.com
1
www.bluegrassliving.com
200592-01A
Advertisement
Table of Contents
Related Manuals for Bluegrass Living HLFD-SM
Summary of Contents for Bluegrass Living HLFD-SM
- Page 1 FIREPLACE GLASS DOOR SIZE - SMALL OWNER’S INSTALLATION AND OPERATION MANUAL MODEL: HLFD-SM SKU: 173249 Overall Door Dimension Fits Openings Width X Height Width Height 37.5” X 30” 30” to 37” 22.5” to 29.5” Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-866-762-4050, 8:00 am - 4:30 pm CST, Monday through Friday or email service@bluegrassliving.com...
-
Page 2: Safety Information
SAFETY INFORMATION WARNING: Before beginning the installation process, read and study this entire instruction sheet. If you do not understand completely, contact our customer service department online at service@ bluegrassliving.com or by calling 1-866-762-4050. This Fireplace Door Set should only be installed on a masonry fireplace with an operational chimney. Masonry fireplaces are always constructed from bricks and morter. -
Page 3: Hardware Kit Contents
HARDWARE KIT CONTENTS 200595-01 HARDWARE KIT CONTENTS ITEM DESCRIPTION 1/4- 20 X 1/4” Machine Screw 1/4- 20 X 1/2” Thred-Cutting Screw 1/4- 20 X 2” Thumb Screw Screw Clamp (Lintel) Bracket 8-32 X 5/8” Machine Screw (Riser Bar) 8-32 Hex Nut (Riser Bar) Preload Bracket 1/4- 20 X 3 1/2”... - Page 4 ASSEMBLY INSTRUCTIONS Carefully remove contents of the carton and place the Fireplace Door set on a soft, flat, surface to avoid damaging the finish. Lift the door by the sides, not the top frame. CAUTION: Before installing the Glass Door, make sure the fireplace is cool. 1.
- Page 5 ASSEMBLY INSTRUCTIONS Figure 2 3. Fiberglass Insulation NOTE: Fiberglass insulation may irritate your skin; wear gloves when handling. The fiberglass insula- tion provided is heat resistant. Some models may leave some of the insulation exposed on the inside of the fireplace. This is normal and should not be of concern. This insulation is used to protect the metal finish of your frame.The 2”...
- Page 6 ASSEMBLY INSTRUCTIONS 4. The Lintel Bar The lintel bar is the “L” shaped angle iron that supports the bricks along the top of the fireplace open- ing. This bar is built into your masonry fireplace when originally constructed. Measure the width of the lintel bar.
- Page 7 ASSEMBLY INSTRUCTIONS 6. Installing The Door Center the Glass Door against the fireplace opening. (A second person may be necessary to hold the door tightly against the fireplace opening.) Reach inside and slide the Lintel Clamp “D” back or for- ward until the lip of the Lintel Clamp “D”...
-
Page 8: Door Hinge
ASSEMBLY INSTRUCTIONS 8. Removing the Door Panels There are four door panel hinges (two in the top track and two in the bottom track). The door panel hinges are designed to be adjusted. If the door panels are not evenly aligned or if there is too much space between the center of the door panels (when they are in a closed position), you may adjust them as follows: Open the door panels. -
Page 9: Technical Service
In some cases, the riser bar will extend in front of the frame assembly, which is correct. TECHNICAL SERVICE You may have further questions about installation, operation, or troubleshooting. If so, contact Bluegrass Living Inc. by email at service@bluegrassliving.com Please provide your model and serial numbers of your product. - Page 10 ASSEMBLY INSTRUCTIONS ALTERNATE MOUNTING METHOD FOR TOP OF FIREPLACE DOOR ASSEMBLY A 1. There are two slotted brackets attached to the top of the back of the glass door fram. Attach a “Bracket E” to each of the slotted brackets as in Figure A 1. Place the glass door against the fireplace opening, center it, and mark the lintel bar through the slots in the Brackets (2 places).
-
Page 11: Replacement Parts
ASSEMBLY INSTRUCTIONS Note: When not in use, keep Fireplace Doors closed for energy efficiency. This will also prevent drafts into the room. When there is a fire in the fireplace: Keep the glass doors OPEN! Keep the screen mesh doors closed to help keep the sparks contained inside the fireplace. Remember for safety to keep the firewood grate at least seven inches back from the mesh screen. - Page 12 Bluegrass Living, Inc. makes no other warranties regarding this product. Bluegrass Living, Inc.’s liability is limited to the purchase price of the product and Bluegrass Living, Inc. shall not be liable for any other damages whatsoever under any circumstances including direct, indirect, incidental, or conse- quential damages.
