- Page 1 ZD.323.1.4 7” Flat Monitor System Please read this manual thoroughly before operating the unit and keep for further reference. (866) 672-1212 www.ZoneDefenseTruck.com V3 - REV 9/12 AEG...
-
Page 2: Table Of Contents
® quality heavy duty camera systems for rear and side view vehicle use. We provide various camera styles for multi use applications as well as sensor, recording and navigational equipment. ZONE DEFENSE - WE KNOW QUALITY. -
Page 3: Safety Information
Please read this manual thoroughly before beginning. All Zone Defense products are strictly intended to be installed as a supplement and Zone Defense observation systems and/or products are not intented for use as substitutes for rear-view mirror devices, or for any other standard motor vehicle equipment required to be installed on vehicles by law. - Page 4 WARNING: Do not place heavy objects on cables or cover them with rugs or carpet. Do not place cables where they can be pinched or stepped on. Watching videos, broadcasts, DVD’s and/or any images other than from intended driving assistance cameras is prohibited. CAUTION: To avoid damage to electronic circuit, disconnect power to the monitor while doing welding work to the vehicle and/or trailers.
-
Page 5: System Features
SYSTEM FEATURES & SPECIFICATIONS SUBJECT TO CHANGE MONITOR: Display Device: 7” Color TFT-LCD with digital screen Audio output: Max 1.5W Loudspeaker: one 15x24mm round loudspeaker Power supply: 10-32V Power consumption: about 6W Dot pitch: 0.192 (H) x 0.1805 (H) Resolution: 800 (H) x 3 (RGB) x 480 Contrast: 500:1 Brightness: 400cd/m2 Viewing angle: U:50 / D:60, R/L:70... -
Page 6: System Components
SYSTEM COMPONENTS I/F Remote 7” Flat Panel Monitor Infrared Color w/ Audio U Bracket Monitor Mount Rear Camera w/ Adjustment Screws Monitor Sun Shield Center or Fan Mount AV and Power Supply 20-Meter Cable Adapter Cables... -
Page 7: Monitor Operations
MONITOR A 5/8” hole is needed to pass the connector through the exterior wall. Be careful not to drill a hole so large that the grommet will not seal. Before drilling, make sure there are no obstacles in the way of the drill bit. Check MONITOR OPERATIONS 1. -
Page 8: Monitor/Remote Operations
REMOTE OPERATIONS PAL/ AUTO/ NTSC... - Page 9 MUTE (Mute): Press to select ENABLE/ MUTE sound. POWER (Power switch): Press to turn on/ off the monitor. (Horizontal turning of picture): Press to turn picture horizontally. (Vertical turning of picture): Press to turn picture vertically. CH+ (Channel selection +): Press to select channel/ item on menu.
-
Page 10: Connections
BASIC CONNECTIONS Connection of AV conversion cables: Hold the cable, align the side of jack marked with on female 22pin connector with the male 22pin connector marked with then plug in. 1. White 4pin male for Camera 1. 2. Blue 4pin male for Camera 2. 3. -
Page 11: Menu Operations
Reversing display: When the white wire is connected to the positive CAM 1 wire of the left turn signal, the monitor automatically switches to CAM 1 (left side camera) when the left turn indicator is activated. When the blue wire is connected to the positive CAM 2 wire of the right turn signal, the monitor automatically switches to CAM 2 (right side camera) - Page 12 (1) PICTURE BRIGHT, CONTRAST, COLOR, VOLUME, AUTO DIM and SCALE ADJUST options will display on the screen as illustrated below: Press to select BRIGHT. PICTURE BRIGHT CONTRAST COLOR VOLUME AUTO DIM SCALE ADJUST IIIIIIIIIIIIIII....50 Press +/- to adjust the BRIGHT level. Press to select CONTRAST.
- Page 13 Touch to select SCALE ADJUST. Exit menu and again touch display the grid line. PICTURE DIM BRIGHT DIM CONTRAST DIM COLOR VOLUME AUTO DIM SCALE ADJUST Touch +/- to select is selected, touch +/- to scale adjustment. adjust the scale up/down. If selected, pres +/- to adjust the scale left/right.
- Page 14 Press to select CAM 1. OPTION LANG ENGLISH SCALE CAM 1 NORMAL CAM 2 NORMAL CAM 3 NORMAL CAM 4 NORMAL Press +/- to select NORMAL/MIRROR. (3) SYSTEM The COLOR-SYS, BLUE BACK, HORIZONTAL, VERTICAL and ZOOM functions will display on the screen as illustrated below: Press to select COLOR-SYS.
-
Page 15: Technical Support
(4) AUTO SCAN AUTO SCAN, SCAN TIME, CAM 1, CAM 2, CAM 3, CAM 4 options display on the screen as illustrated below: Touch to SCAN TIME. AUTO SCAN AUTO SCAN SCAN TIME CAM 1 CAM 2 CAM 3 CAM 4 Touch +/- to select 1S ~ 90S. - Page 16 3018 22nd Ave S, St. Petersburg, FL 33712 Canadian Sales and Distribution: 7895 49th Ave, Unit 7, Red Deer, AB T4P 2B4 Zone Defense ® (HK) Limited: 1301 Bank of America Tower, 12 Harcourt Rd, Central, Hong Kong Ramco Engineering, 52965 Frederic Dr, Elkhart, IN 46514...
