- Page 1 Preamplifier Power Supply Board APV4004 Manual Version 1. 2. 0 August 2021 TechnoAP Co., Ltd. 2976-15 Mawatari, Hitachinaka-shi, Ibaraki, 312-0012, JAPAN TEL: +81-29-350-8011 FAX: +81-29-352-9013 URL: http://www.techno-ap.com E-mail: info@techno-ap.com...
-
Page 2: Prohibited Matter
Manual APV4004 Safety Precautions / Disclaimer Thank you for purchasing the product of Techno AP Co., Ltd. (hereinafter referred to as "our company"). Before using the product, please read this "Safety Precautions / Disclaimer" and be sure to observe the contents to ensure correct use. - Page 3 Manual APV4004 － Table of contents － １． Overview ..............................................4 ２． Specifications ............................................4 ３． Appearance .............................................. 5 ４． Usage rules ............................................... 6 TechnoAP Co., Ltd.
-
Page 4: １． Overview
Manual APV4004 １． Overview Preamplifier power supply board APV4004 (hereinafter referred to as this device) is a standard VME type power supply board for preamplifiers. There are 4 channels, and the preamplifier voltage +/- 12 V (50 mA or more) and +/- 24 V (50 mA or more) are output from each channel. The output connector is a 9- pin D-type, and the pin layout is NIM standard compliant. -
Page 5: ３． Appearance
Manual APV4004 ３． Appearance Image 1 APV4004 1. POWER: LED for checking VME main power supply. Lights when power is supplied 2. CH1 to 4: 9-pin D-type connector for preamplifier power supply TechnoAP Co., Ltd. -
Page 6: ４． Usage Rules
1. Make sure that all power supplies such as the VME power supply rack and high-voltage power supply are turned off. 2. Connect the preamplifier and APV4004 using the D-subn 9-pin cable as shown in the photo below. Check again that the pin assignments on the preamplifier side and the pin assignments on the APV4004 match. - Page 7 Manual APV4004 TechnoAP Co., Ltd. 2976-15 Mawatari, Hitachinaka-shi, Ibaraki, 312-0012, JAPAN TEL: +81-29-350-8011 FAX: +81-29-352-9013 URL: http://www.techno-ap.com E-mail: info@techno-ap.com TechnoAP Co., Ltd.
