Note: This Product is to be used with Rockets that have 1010 rail buttons. Read all instructions carefully.
PARTS
M4-22mm Bolts
063175
U-Shaped Rail
Connector
063230
Blast De ector
ASSEMBLE LAUNCH RAIL
1.
Assemble rail halves by rst placing
on a at surface. Place U shaped plate
over the joint and align holes.
Upper rail
LAUNCH RAIL KIT
ASSEMBLY INSTRUCTIONS
KEEP FOR FUTURE REFERENCE
8-32 Screws
068248
Plate Nut
M4 Nuts
062115
Upper Rail
063165
Rail Pivot
Lower rail
073250
Tripod Stand
Allen Key
2.
Insert the M4-2mm bolts through
holes and attach M4 nuts. Use the
included Allen Key and a pair of
pliers to secure the plate into place.
Upper rail
063173
Rail Rest
062115
Lower Rail
TOOLS REQUIRED
065097
Hitch Pin
PHILLIPS
SCREWDRIVER
2311
AGES
10
+
063166
Tube Pivot
PLIERS
Lower rail
Advertisement
Summary of Contents for Estes PRO II Series
- Page 1 2311 LAUNCH RAIL KIT AGES ASSEMBLY INSTRUCTIONS KEEP FOR FUTURE REFERENCE Note: This Product is to be used with Rockets that have 1010 rail buttons. Read all instructions carefully. PARTS 063166 8-32 Screws Tube Pivot M4-22mm Bolts 073250 Tripod Stand 068248 063173 Plate Nut...
- Page 2 Loosen knob and place rail into a horizontal position to load rocket. Estimated weight: 3.6 oz. © 2023 Estes Industries, LLC. All rights reserved. Estes Industries, LLC, 1295 H Street, Penrose, CO 81240-9698 Made in: Guangdong, China PN 090004-2311 (8-23)
