THIS APPLIANCE IS MANUFACTURED BY:
AV SYNC
AH68-01409B
THREE-DVD MINI
COMPONENT SYSTEM
DVD/VCD/CD/MP3-CD/CD-R/RW
PLAYBACK
MAX-DJ550
Instruction Manual
COMPACT
COMPACT
DIGITAL AUDIO
DIGITAL VIDEO
V I D E O
OPEN/CLOSE
SLEEP
DIMMER
DISC SKIP
ZOOM
SLOW
REPEAT
REMAIN
SUB TITLE
DECK 1/2
TUNER
TAPE
AUX
BAND
VOLUME
TUNING
SOUND
TUNER
MODE
MEMORY
P.SCAN
ENTER
AUDIO
STEP
TIMER/CLOCK
CANCEL
DIGEST
TIMER ON/OFF
EZ/VIEW
LOGO SLIDE MODE
NTSC/PAL

Advertisement

Table of Contents
loading

Related Manuals for Samsung MAX-DJ550

Summary of Contents for Samsung MAX-DJ550

  • Page 1 THREE-DVD MINI COMPONENT SYSTEM DVD/VCD/CD/MP3-CD/CD-R/RW PLAYBACK THIS APPLIANCE IS MANUFACTURED BY: MAX-DJ550 Instruction Manual OPEN/CLOSE SLEEP DIMMER DISC SKIP ZOOM SLOW REPEAT REMAIN SUB TITLE DECK 1/2 TUNER TAPE BAND VOLUME TUNING SOUND TUNER MODE MEMORY P.SCAN ENTER AUDIO STEP...

  • Page 2: Safety Warnings

    Safety Warnings Precautions Use of controls, adjustments or performance of procedures other CLASS 1 LASER PRODUCT than those specified herein may result in hazardous radiation KLASSE 1 LASER PRODUKT exposure. LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LASER CLASE 1 CAUTION-INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED, AVOID EXPOSURE TO BEAM.

  • Page 3: Table Of Contents

    Disc Playback ..................................16 DivX Playback..................................17 Power Saving Function Displaying Disc Information ..............................19 Fast/Slow Playback................................20 The MAX-DJ550 automatically shuts itself off after 20 minutes in the stop. Skipping Scenes/Songs ..............................21 Angle Function ..................................22 Repeat Playback.................................23 Customized TV Screen Display A-B Repeat Playback................................25 Zoom Function ..................................26...

  • Page 4: Description

    Description —Front Panel— —Rear Panel— STANDBY/ON DEMO/DIMMER SEARCH FUNCTION BUTTONS OR STOP OR TUNING MODE Component Video Output Connectors MIC LEVEL(option) Connect a TV with component vide input jacks to MIC (option) these jacks. PHONES Video Output Connector RECORD/PAUSE Connect the TV's video input jacks (VIDEO IN) to COUNTER RESET the VIDEO OUT connector.

  • Page 5: Remote Control

    Description —Remote Control— Insert Remote Batteries Remove the battery Insert two 1.5V AAA Replace the battery ZOOM button POWER STANDBY/ON button cover on the back of batteries, paying cover. SLEEP button DIMMER, DEMO button the remote by attention to the correct OPEN/CLOSE button pressing down and polarities (+ and –).

  • Page 6: Connecting The Speakers

    Connecting the Speakers Connecting to a TV Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Please be sure to turn off the power and unplug the power cord before moving or installing this unit. Please choose one of three video connection methods.

  • Page 7: Connecting To A Tv(Continue)

    Connecting to a TV(continue) P.SCAN Function (Progressive Scan) Please be sure to turn off the power and unplug the power cord before moving or installing this unit. Please choose one of two video connection methods. Component Video (Best Quallty) Method 3 Press and hold P.SCAN button on the remote controller for over 5 seconds in stop mode.

  • Page 8: Connecting External Components

    Connecting the FM, AM ( MW/LW ) and SW(option)Antennas Connecting External Components If AM reception is poor, connect an Connecting an External Analog Component outdoor AM antenna(not supplied). Example: Analog signal components such as a VCR, Camcorder, and TV. AM Loop Antenna (supplied) FM Antenna (supplied) Audio Cable...

  • Page 9: Setting The Clock

    Setting the Clock Disc Playback For each step, you have a few seconds to set the required options. If you exceed this time, you must start again. Press OPEN/CLOSE Load discs. Switch the system button to open the Press TIMER/CLOCK Press ENTER.

  • Page 10: Divx Playback

    DivX Playback Skip Forward/Back During playback, press the button. • Go to the next file whenever you press button, if there are over 5 Minute Skip function 2 files in the disk. OPEN/CLOSE SLEEP DIMMER • Go to the previous file whenever you press button, if there are over 2 files in the disk.

  • Page 11: Displaying Disc Information

    Displaying Disc Information Fast/Slow Playback You can view playback information on the disc on the TV screen. Fast Playback Press and hold Press INFO button. • Each time the button is held down during playback, the playback speed changes as follows: •...

  • Page 12: Skipping Scenes/Songs

    Skipping Scenes/Songs Angle Function This function allows you to view the same scene in different angles. Press Cursor Briefly press Press INFO button. button to move to • Each time the button is pressed briefly during playback, the previous or next chapter, OPEN/CLOSE SLEEP DIMMER...

  • Page 13: Repeat Playback

    Repeat Playback Repeat playback allows you to repeatedly play a chapter, title, track (song), or directory (MP3 file). To Select a Repeat Playback Mode in the Disc Information Screen JPEG Press Cursor button Press REPEAT button. Press INFO button OPEN/CLOSE SLEEP DIMMER to move to REPEAT...

  • Page 14: A-B Repeat Playback

    A B Repeat Playback Zoom Function This function allows you to enlarge a particular area of the displayed image. Zoom (Screen Enlarge) Function Press Cursor , , Press ZOOM Press ENTER , buttons to Press REP. A B OPEN/CLOSE SLEEP DIMMER Press REP.

  • Page 15: Selecting Audio/Subtitle Language

    Selecting Audio/Subtitle Language Moving Directly to a Scene/Song Audio Language Selection Function Moving to a Title/Track Moving to a Chapter Press Cursor , buttons Press Cursor , Press Cursor or numeric buttons to select Press INFO button. buttons to move to Press INFO button OPEN/CLOSE SLEEP...

  • Page 16: Jpeg File Playback

    JPEG File Playback JPEG Images captured with a digital camera or camcorder, or JPEG files on a PC can be stored on a CD and then played back with this DVD player. Slide Mode Digest Function You can view 9 JPEG images on the TV screen. Press DIGEST Press Cursor , , , buttons...

  • Page 17: Using Disc Menu

    Using Disc Menu Using the Title Menu You can use the menus for the audio language, subtitle language, profile, etc. For DVDs containing multiple titles, you can view the title of each movie. DVD menu contents differ from disc to disc. Depending on the disc, this function may either not work at all or may work differently.

  • Page 18: Setting The Language

    Setting the Language OSD language is set to English by default. Press Cursor Press Cursor Press Cursor SLEEP DIMMER Press ENTER Press MENU button to select the button to select the button to move to DISC SKIP ZOOM SLOW button. button.

  • Page 19: Setting Tv Screen Type

    Setting TV Screen type Adjusting the TV Aspect Ratio (Screen Size) Press Cursor button to move to Press MENU button. The horizontal to vertical screen size ratio of conventional TVs is 4:3, while that of wide screen and high ‘Setup’ and then definition TVs is 16:9.

  • Page 20: Setting Parental Controls (Rating Level)

    Setting Parental Controls (Rating Level) Setting the Password Use this to restrict playback of adult or violent DVDs you do not want children to view. You can set the password for the Parental (rating level) setting. Press Cursor Press Cursor button to Press Cursor Press Cursor...

  • Page 21: Setting The Wallpaper

    SLIDE MODE NTSC/PAL Press RETURN button to return to the previous level. Press MENU button to exit the setup screen. Select this to set the Select this to set the desired Samsung Logo image as image as your wallpaper. your wallpaper.

  • Page 22: Setting The Drc (Dynamic Range Compression)

    Setting the DRC AV SYNC Setup (Dynamic Range Compression) You can use this function to enjoy Dolby Digital sound when watching movies at Video may look slower than the audio if it is connected with digital TV. low volume at night. In this case, adjust the delay time of audio to optimal status to fit the video.

  • Page 23: Listening To Radio

    Listening to Radio Presetting Stations You can store up to: You can listen to the chosen band (FM, MW, (LW),(SW1,2) broadcast stations) 15 FM stations 15 FM stations by using either the automatic or manual tuning operation. OPTION • FM Frequency Modulation 15 AM stations 5 MW stations...

  • Page 24: Listening To A Cassette

    Listening to a Cassette Always treat your cassettes with care; refer, if necessary, to the section entitled “Precautions When Using Audio Cassettes” on page 55. Selecting the Cassette Playback Mode Your micro component system has three cassette playback modes which enable you to listen to both sides of a cassette automatically.

  • Page 25: Recording A Compact Disc

    Recording a Compact Disc You can record a compact disc on a cassette in two different ways: Copying a cassette (DUBBING) You can copy a cassette from Deck 1 to Deck 2. Normal speed dubbing in selecting Tape function mode. Synchronised recording You do not need to adjust the volume, as it has no effect on the recording.

  • Page 26: Recording A Radio Program

    Recording a Radio Program You can record a radio program of your choice. You do not need to adjust the volume, as it has no effect on the recording. Direct recording The direct recording mode enables you to start recording with any track on the compact disc. PREVIOUS/ TUNING NEXT/...

  • Page 27: Timer Function

    Canceling the Timer Timer Function • After having set the timer, it will start automatically as shown by the TIMER indication on the The timer enables you to switch the system on or off at specific times. • If you no longer want the system to be switched on or off automatically, you must cancel the timer. display.

  • Page 28: S.bass/P.sound/Sound Mode Function

    Sleep Timer Function / Mute Function S.BASS/P.SOUND/SOUND MODE Function Sleep Timer Function You can set the timer that the DVD player will shut itself off. SLEEP DIMMER Press SLEEP button. DISC SKIP ZOOM SLOW REPEAT REMAIN SUB TITLE • DECK 1/2 Each time the button is pressed, the selection changes as follows: PREVIOUS/ TUNING...

  • Page 29: Demo Function / Dimmer Function

    DEMO Function / DIMMER Function Connecting Headphones/Microphone(option) You can connect a set of headphones to your mini component system so that you can listen to music or radio programmers without disturbing other people in the room. The earphones must have a 3.5ø jack or an appropriate adaptor. PREVIOUS/ TUNING NEXT/...

  • Page 30: Cautions On Handling And Storing Discs

    Cautions on Handling and Storing Discs Notes on Discs Small scratches on the disc may reduce sound and picture quality or cause breaks in playback. Be especially careful not to scratch discs when handling them. Handling discs Disc Recording Format Do not touch the playback side of the disc.

  • Page 31: Before Calling For Service

    Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact the nearest authorized dealer or Samsung Electronics Service Center. Symptom...

  • Page 32: Notes On Terminology

    Notes on Terminology Specifications RADIO Recorded onto some DVD discs are scenes which have been simultaneously shot LW(option) ANGLE from a number of different angles (the same scene is shot from the front, from the Usable sensitivity 60 dB left , from the right , etc.). SW(option) With such discs, the Angle button can be used to change the angle of view for Usable sensitivity...
