Summary of Contents for Setech YD-13S
- Page 1 SETech YD-13S User's Manual SETech 718, Daechun-Dong, Dalseo-gu, Daegu. TEL : +82-53-585-5261(Main) FAX : +82-53-585-7848 http://www.setech.co.kr e-mail : setech@setech.co.kr...
-
Page 2: Front Panel
1. Outline. This manual is referred to the function and features of Model YD-13S Indicator so that you may use it with comportable and exact. 2. Features. 2-1. Data Hold and Peak Hold function. 2-2. ONE TOUCH DISPLAY AUTO ZERO function. - Page 3 ⓖ The key that finish value fixing on each itmes. ⓗ Z : The key that can adjust to make analog output value zero. S: The key that can adjust output span. Main ☞ Please adjust them 1 or 2 times repeatedly, because Z and S terminal have mutual relation. ( DISPLAY value is not changed when you adjust Z and S value.) 4.
-
Page 4: Dip Switch
(Standard Model) ㉠ SENSOR connection terminal. ㉡ Analog output terminal. ㉢ AC Input terminal. (Standard : 220v, option : 110v) ㉣ It is On above Hi Value. ㉤ It is On at GO value. ㉥ It is On below LO value. ㉦... -
Page 5: Auto Calibration
Press PRG key 4 times to enter Auto Cal mode as shown 0040.0 in left. In the this mode, press and hold ENT key and press ▶ key to accept your input. And then you will return to the calibration mode. The Auto Cal function can be used when user knows the exact amount of a load or when user wants to display an arbitary numbers different from the AUTO CALIBRATION... - Page 6 Press key 7times to enter communication ID mode as shown Id001 in left. After you select value with ▲ key and you press ENT key. Main1. ☞ Input range : 0-255 The ID is necessarily required to connect several Indicators to control together with a host PC.
-
Page 7: Serial Communication Protocol
7. DIP SWITCH SET'G 0.5mV/V 2mV/V 100Hz Volt 8 ON 1mV/V 10Hz 1kHz Amp Main ☞ ㉠ See table below for setup according to the sensor's sensitivity. Sensitivity(mV/V) dip s/w set-up 0.5050 below 0.5mv/v 0.5051~1.0100 1.0mv/v 1.0101~1.5150 1.5mv/v 1.5151~2.0200 2.0mv/v 2.0201~2.5250 2.5mv/v 2.5250~3.0300... - Page 8 2) Special Function. Host (PC) INDICATOR Byte 1(INDICATOR ID) Byte 2 No response Auto Zero Z95AH) Byte 1(INDICATOR ID) Byte 2 Transfer again to disable Peak R(50H) Byte 1(INDICATOR ID) Byte 2 Transfer again to disable Hold set Main ☞ 1) Special Function : When Peak setting provide Host PC, LED PEAK is illuminated.
-
Page 9: Troubleshooting
9. Trouble Shooting. Problem Cause Correction. 1). Defective sensors 1) Check sensor output 2). Wrong Connection 2) Check connection to sensor Display drifts 3). CABLE NOISE 3) Check power line & ground 4). Incorrect Filter Set. 4) Check filter Dip Switches. Programming again, after waiting Display CAL and Program erased... -
Page 10: Voltage Selector
13. The way to change Power Supply. ( Refer to belowing picture) VOLTAGE SELECTOR Termi front Trans Main ☞ If you take out 2pcs painted black with hand, Voltage is indicated on Panel. And then, you move them as follwing pictures. 220V 110V... - Page 11 (option model pin connector pinmap) Relay 8CH Relay (NG output) binary Remark 37Pin 40Pin 0 digit RY1 High RY1 Low RY2 High RY2 Low 1 digit RY3 High RY3 Low RY4 High RY4 Low 2 digit RY5 High RY5 Low 1024 RY6 High 2048...
