User's Manual
Extremely Low Noise 3-phase Microstepping Driver
©2007 All Rights Reserved
Attention: Please read this manual carefully before using the driver!
3/F, Block 2, Nanyou Tianan Industrial Park, Nanshan Dist, Shenzhen, China
T: (86)755-26434369
Web site:
www.leadshine.com
雷赛智能官方代理：雷创智能科技
For
3ND583
Version 1.0
F: (86)755-26402718
E-Mail:
sales@leadshine.com
The content in this manual has been carefully prepared and is believed to be accurate, but no
responsibility is assumed for inaccuracies.
Leadshine reserves the right to make changes without further notice to any products herein to
improve reliability, function or design. Leadshine does not assume any liability arising out of the
application or use of any product or circuit described herein; neither does it convey any license
under its patent rights of others.
Leadshine's general policy does not recommend the use of its products in life support or aircraft
applications wherein a failure or malfunction of the product may directly threaten life or injury.
According to Leadshine's terms and conditions of sales, the user of Leadshine's products in life
support or aircraft applications assumes all risks of such use and indemnifies Leadshine against all
damages.
©2007 by Leadshine Technology Company Limited.
All Rights Reserved
www.leadtronker.com
www.leadtronker.com
Advertisement
Table of Contents
Summary of Contents for Leadshine Technology 3ND583
- Page 1 Leadshine against all damages. 3/F, Block 2, Nanyou Tianan Industrial Park, Nanshan Dist, Shenzhen, China T: (86)755-26434369 F: (86)755-26402718 ©2007 by Leadshine Technology Company Limited. Web site: www.leadshine.com E-Mail: sales@leadshine.com All Rights Reserved 雷赛智能官方代理：雷创智能科技...
- Page 2 Authorized Distributor of Leadshine Technology Contents Contents Table of Contents Short Circuit Protection..................10 Over-current Protection..................10 1. Introduction, Features and Applications..............1 12. Frequently Asked Questions ................10 Introduction ......................1 Problem Symptoms and Possible Causes............11 Features ....................... 1 APPENDIX.......................
-
Page 3: Operating Environment
Environment Avoid dust, oil fog and corrosive gases Ambient Temperature 0℃－+50℃ The 3ND583 is a high resolution 3-phase microstepping driver based on precision current control Operating Operating Temperature 70℃ technology. It’s suitable for driving 3-phase hybrid stepping motors from NEMA size 17 to 34. By... -
Page 4: Connector P1 Configurations
3 and the figure 4. Selecting CW/CCW or PUL/DIR Mode There is a jumper J1 (including pin 1 to pin 9) inside the 3ND583 specifically for selecting pulse signal mode. Settings for the one-pulse mode (PUL/DIR) and for the double-pulse mode (CW/CCW) are shown in the following figure. -
Page 5: Multiple Drivers
6. Power Supply Selection Current Setting The 3ND583 can match medium and small size stepping motors (from NEMA size 17 to 34) made by Leadshine or other motor manufactures around the world. To achieve good driving For a given motor, higher driver current will make the motor output more torque, but at the same performances, it is important to select supply voltage and output current properly. -
Page 6: Wiring Notes
DIP Setting for Dynamic Current current 0.5 second after the last pulse when use automatic idle-current reduction mode. The 3ND583 uses an 8-bit DIP switch to set motor dynamic current, standstill current and Theoretically, this will reduce motor heating to 36% (due to P=I *R) of the original value. -
Page 7: 12. Frequently Asked Questions
Authorized Distributor of Leadshine Technology 3ND583 Microstepping Driver Manual V1.0 3ND583 Microstepping Driver Manual V1.0 11. Protection Functions To improve reliability, the driver incorporates some built-in protections features. Over-voltage Protection When power supply voltage exceeds +51VDC, protection will be activated and power indicator LED will turn red. -
Page 8: Warranty Limitations
Please include a written description of the problem along with contact name and address. Send failed product to distributor in your area or: Leadshine Technology Co., Ltd. Floor 3, Block 2, Nanyou Tianan Industrial Park, Nanshan Dist, Shenzhen, China. Also enclose information regarding the circumstances prior to product failure.
