Installation
Instructions
Questions? 800-765-3237 or visit
BEFORE YOU BEGIN:
Read these instructions carefully
before attempting to install this
product.
Note to Installer – Be sure to leave
•
these instructions with the end user.
Skill Level - Installation of this
•
appliance requires basic mechanical
skills.
Proper Installation is the
•
responsibility of the installer.
Product failure due to improper
•
installation is not covered under the
warranty.
• This product should not be altered
in anyway without manufacturers
consent.
Savercell and Savercell
Plus
www.mediproducts.net
•
IMPORTANT
Instructions for local inspectors use.
•
IMPORTANT
governing codes and ordinances.
FOR YOUR SAFETY:
Be sure all hardwire electrical
•
connections are done by a
certified electrical contractor.
Always wear protective eye, hand
•
and footwear while assembling
this system.
–
Save these
–
Observe all
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for medi Savercell
- Page 1 Savercell and Savercell Plus Installation Instructions Questions? 800-765-3237 or visit www.mediproducts.net BEFORE YOU BEGIN: Read these instructions carefully before attempting to install this product. – • IMPORTANT Save these Note to Installer – Be sure to leave • Instructions for local inspectors use.
-
Page 2: Prepare For The Installation
Prepare for the Installation Parts & Supplies Provided: Savercell Wall Bracket Flip Toggle Fasteners & Bolts User Manual & Testing Guide Tape Screw Gun/Drill Safety Drill Bit Stud Pencil Finder Phillips Head Level & ¼” Hex Bit... -
Page 3: Pre-Installation Steps
PRE-INSTALLATION STEPS Prepare your Wall: Identify the area on the wall where you will be mounting the Savercell system. Check all measurements to ensure there Locate and mark the wall studs directly will be no obstructions. You will need a behind the intended location where the space that is at minimum 18”... - Page 4 Unwrap bracket and dispose of wrapping material, setting aside the wall anchor bolts and toggle anchors. The Savercell Wall Bracket comes with four wall anchors to secure the bracket to the wall. You may use either the ¼” slots or the ¼” holes located near the top of the bracket to secure the bracket to the wall (Highlighted in red below).
-
Page 5: Installation Steps
INSTALLATION STEPS Mounting Bracket to Wall: For installations that involve securing to metal studs, drill out the marked holes using a ½” drill bit, ensuring the hole is in the middle of the studs, if possible. For installations that involve wood studs, pre-drill the marked holes with the appropriate bit for 3/8”... - Page 6 Continue with the appropriate start up procedure, once again ensuring the Savercell can be plugged in to the wall outlet. If installing a Savercell Plus, repeat these steps with the additional wall bracket for the extra battery cell. Once the second wall bracket is installed, you may place the extra battery into the bracket, and continue with the appropriate start up procedure, making sure the extra battery is connected to the Savercell system.
