Summary of Contents for MKS Newport 6123NS
- Page 1 Model 6123NS, 6214, 61945 LIQUID FILTERS ALUMINUM BODY User's Manual MKS Newport Family of Brands – ILX Lightwave ® • Corion ® • New Focus™ • Oriel ® Instruments • Richardson Gratings™ • Spectra-Physics ® M6123 Rev: 08/21/24...
- Page 2 M6123 LIQUID FILTERS USER MANUAL TABLE OF CONTENTS I. INTRODUCTION ..........................3 II. INSTALLATION ..........................4 III. WARRANTY AND RETURNS ......................5 IV. CONTACT US ........................... 6...
-
Page 3: Introduction
M6123 LIQUID FILTERS USER MANUAL I. INTRODUCTION The 61945, 6123NS and 6214 liquid filters are used to remove unwanted infrared radiation from a high intensity beam. Each model is constructed of aluminum, with a space to hold distilled water between two fused silica windows. -
Page 4: Installation
M6123 LIQUID FILTERS USER MANUAL II. INSTALLATION To install the filter: Remove the relief valve (Item 2) from the housing. Fill the inner cavity with distilled water. Reattach the relief valve and ensure that there is no leakage of the distilled water. Check the freedom of operation after installation, as excessive tightening can jam the valve. -
Page 5: Warranty And Returns
M6123 LIQUID FILTERS USER MANUAL III. WARRANTY AND RETURNS Newport warrants that all goods described in this manual (except consumables such as lamps, bulbs, filters, ellipses, etc.) shall be free from defects in material and workmanship. Such defects become apparent within the following period: All products described here, except spare parts: one (1) year or 3000 hours of operation, whichever comes first, after delivery of the goods to the buyer. -
Page 6: Contact Us
M6123 LIQUID FILTERS USER MANUAL CONTACT US To obtain further information regarding sales, technical support or factory service, United States and Canadian customers should contact Oriel Instruments directly. Newport - Oriel Instruments 1791 Deere Avenue Irvine, CA 92606 USA Telephone: 877-835-9620 (toll-free in United States) 800-222-6440 Fax: 949-253-1680...
