TSI Instruments OmniTrak 7591-06 Quick Start Manual

Carbon Monoxide (CO) Module
Model 7591-06
Operation Instructions
1. Power On: Hold down power button on left side of module for 1 second.
2. Power Off: Hold down power button on left side of module until you see
a light sequence of green, yellow, red. That indicates module is off.
3. Charging: Plug USB-C into bottom of module and into power source.
A blinking green light indicates module is charging.
4. Connecting to a Smart Station: Power on module by holding down
the circle on the left for 1 second. A blue LED light will start to blink
indicating Bluetooth® is on.
- The module will appear in the list on the Smart Station.
If not, hit Refresh.
- Press desired module on screen to connect to Smart Station.
A green check mark indicates a successful connection.
- Press Done
Now you're ready to take measurements.
The OmniTrak™ Smart Station can be used in conjunction with any
OmniTrak™ Module to provide immediate feedback as to the conditions in
the immediate area. Take measurements, create reports, and analyze data
provided to help improve conditions. This instrument is a handheld device,
not to be worn on the body, or near an individual's head.
Dispose of battery in accordance with local rules and regulations.
What's Included in the Box
▪ Device
▪ USB-C Cable
NOTE: All modules, by default, are
shipped in 'Sleep Mode' to
protect the battery. It will not
be possible to power on the
Module, using the side button,
until 'Sleep Mode' is disabled.
To disable, plug the module
into a power source and
charge the module for a
few minutes. This process
is required only once.
