- Page 1 Original user manual TRUSS BRACKET 30 WITH U-BOLTS Manufacturer: Rolight Theatertechniek B.V. Josink Kolkweg 10 7545 PR Enschede, The Netherlands Phone (+31)53 432 06 44 info@rolight.nl www.rolight.nl VERSION 01 July 2024 Distributed by ADMIRAL SKU: RIHBAD35 www.admiralstaging.com...
-
Page 2: Table Of Contents
CONTENT LEGEND 1. INTRODUCTION DANGER 2. SAFETY INSTRUCTIONS 3. SCOPE 4. LIMITATIONS OF USE DANGER: Indicates a hazardous 5. TECHNICAL DATA & LOADCHART situation which, if not avoided, will result in 6. IDENTIFICATION death or serious injury. 7. EXPLANATION OF THE ENGRAVING This signal word is to be limited to 8. -
Page 3: Scope
4. LIMITATIONS OF USE CAUTION • A TRUSS BRACKET 30U must be taken out of service immediately if, during use, WARNING repair or maintenance damages are discovered. Exceeding the limitations of use can severely endanger the audience and users. • Remove people from the area during installation. - Page 4 • The support structure, on which the TRUSS CAUTION BRACKET 30U is used, might need to have electric potential bonding. Do not throw the TRUSS BRACKET 30U, • Do not use the TRUSS BRACKET 30U to guide as it might damage the product. currents for electric potential bonding.
-
Page 5: Technical Data & Loadchart
Loads above 338 mm persons (Formerly known as BGI 810-3) Technical data EN 17206:2020 Lifting and load bearing Article code: RIHBAD35 equipment for stages and other EAN: 8720094420646 production areas within the entertainment industry ELL: 500 kg Safety factor... -
Page 6: Identification
Grab the TRUSS TRUSS BRACKET 30U BRACKET 30 and the U-bolts. with U-bolts Article code: RIHBAD35 Step 3 8 720094 420646 Place the TRUSS BRACKET 30U on the truss Batchcode: BAD35-24-01 structure as close as possible to the but preferably in the node point. -
Page 7: Disassembly Instructions
Step 4 WARNING Position the U-bolts around the truss and insert them through the holes in the TRUSS BRACKET 30U. Check the integrity of the TRUSS BRACKET 30U after severe vibrations caused by e.g. sound or wind. 9. DISASSEMBLY INSTRUCTIONS Step 1 Lower the truss construction all the way down. -
Page 8: Storage
Avoid vibrations. Rubbing parts can cause place as often as required but with a excessive wear and tear. minimum of 1x per year. In case of doubt contact ADMIRAL Staging. WARNING If damaged, mark the item clearly and take it out of service. -
Page 9: Warranty
For a period of 24 months we will repair, free of charge, any damage attributable to faulty materials or workmanship under the condition that the equipment is forwarded, freight paid, to our warehouse or one of the ADMIRAL Staging distributors’ warehouses. • The warranty-period begins with the day of the delivery, proven by a purchase receipt like an invoice or delivery note or their copies. -
Page 10: Ec Declaration Of Conformity
7545 PR Enschede The Netherlands Herewith declares that for : Admiral “TRUSS BRACKET 30U”; Article code RIHBAD35 - is in compliance with the Machinery Directive 2006/42/EC annex II - the following harmonized standards have been applied (or parts/clauses of): EN 12100-1-2010,... - Page 11 | www.admiralstaging.com | Josink Kolkweg 10 | 7545 PR Enschede | | The Netherlands | Tel: +31 53 4 301 201 |...
