MAX power MPD592 User Manual

PACKAGE CONTENTS
1 X MPD592
1 X Power cord
1 X User Manual
SPECIFICATIONS
Output Power: 40W
Frequency Response:45-20KHz
SNR:≧65dB
THD:≦10%
Battery:Built-in 3600 mAh 7.4V rechargeable battery
Power supplied: AC Power 90-230V 50/60Hz
Loudspeaker:12 inch x 1(External diameter 305mm)magnetic resistant 4 ohms.
DEVICE FEATURES
1. Product dimensions:25.78"H x16.53"W x 14.37"D
2. BT,wireless stream music from any BT-enabled devices such as mobile phone
3. Built-in MP3 digital decoder for decoding and playing MP3 files.It brings you perfect
sound quality.
4. External TF card and USB socket to enjoy music.
5. With a mini control button for volume adjustment,easy to operate.
6. AC 90-230V charging,supply with power cord.
7. 3600 mAh rechargeable battery.
8. FM digital radio(87.5MHZ-108MHZ),listen to the latest news and music.
9. Able to connect to any audio output equipment,such as mobile
phones/MP3/MP4/laptops,etc.
10. Line: LINE IN can connect to PC,mp3,Phone,or other aux facilities.
INSTRUCTIONS
1. MODE b utton: Shortly pressing for switching among BT ,FM, Line in ,TF Card,USB modes.
2. Shortly pressing to play the previous music under BT,TF Card,and USB
modes.Shortly pressing to play previous radio station under FM mode.Long pressing to fast back under TF
Card,and USB modes.
3. : under BT mode, press TWS button for around 3 seconds to pairing another TWS speaker; Under FM
mode, lightly press Play/Pause & TWS to enter into automatic scan and all the scanned radio stations will be
saved automatically.
4. Shortly pressing to play the next music under BT,TF Card,and USB modes.Shortly pressing to play next
radio station under FM mode.Long pressing to fast forward under TF Card,and USB modes.
5. DC 9V:Charge Jack for built-in battery.When the DC 9V cable plugs in,the indicating LED lights up
6. LINE: LINE IN can connect to PC,mp3,Phone,or other aux facilities.
7. USB Port: Support USB and can play MP3 format music in U disk.
8. TF card Port: Support TF CARD and can play MP3 format music in CARD.
9. MIC1/2: Microphone input
10. Charging Indicator
RED=Charging Light off= Fully Charged
11.VOLUME-/+&MENU PUSH: Master volume adjustment&Menu selection button&PUSH knob enter menu.
12. Menu selection button
13. EQ selection button.
and notebook.
