Bluff EZ-Pull EP Owner's Manual

Edge of dock leveler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EDGE OF DOCK LEVELERS
Owner's Manual
Nov 2020
www.bluffmanufacturing.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZ-Pull EP and is the answer not in the manual?

Questions and answers

Summary of Contents for Bluff EZ-Pull EP

  • Page 1 EDGE OF DOCK LEVELERS Owner’s Manual Nov 2020 www.bluffmanufacturing.com...

  • Page 2: Table Of Contents

    COMPLETE HYDRAULIC SET-UP INSTALLATION INSTRUCTIONS FOR IN-FIELD RETRO-FIT OF EXISTING LEVELER UNIT .......................... 25 Retro-Fit..............................25 COMPLETE HYDRAULIC SET-UP INSTALLATION INSTRUCTIONS FOR IN-FIELD RETRO-FIT OF EXISTING LEVELER UNIT (CONTINUED) ....................26 BLUFF WARRANTY ............................ 27 BLUFF RETURNED GOODS AUTHORIZATION (RGA) ................28...

  • Page 3: Safety Warnings

    • Do not exceed capacity rating • If Dock Leveler is not operating normally, discontinue use. Request maintenance personnel to inspect and contact your local Bluff dealer if necessary • Keep clear of all pinch points that could cause injury •...
  • Page 4 BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS • Keep the operating zone free of foreign objects. CALIFORNIA This product contains chemicals known to the State of California to PROPOSITION 65 cause cancer and birth defects or other reproductive harm WARNING...

  • Page 5: Precautions - Read & Understand

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS PRECAUTIONS - READ & UNDERSTAND Keep hands and feet clear of pinch points. Chock/restrain all transport vehicles, Never Avoid putting any part of your body near remove the wheel chocks until loading or moving parts.

  • Page 6: Owners Responsibility

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS OWNERS RESPONSIBILITY The owner should recognize the inherent danger of the interface between dock and transport vehicle. The owner should, therefore train and instruct operators, the safe use of the dock plate in accordance with the information provided below.

  • Page 7: Parts List

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS PARTS LIST DESCRIPTION PART NUMBER QUANTITY Front Lip EPFL Latch EPLATCH EPEAR Center Section EPCS Mount Plate EPMP EPSA EPLATCHCATCH Bumper EPCB10 Bumper Base EPBUMPBASE EPRB10 Motor (if equipped) EPHYDMTR Cylinder EPHYDCYL Wedge Anchors 3/4" – 10 x 4...

  • Page 8: Installation Procedure: (Type I) Dock Edge With Embedded Steel Channel

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS INSTALLATION PROCEDURE: (TYPE I) DOCK EDGE WITH EMBEDDED STEEL CHANNEL Mechanical Edge of Dock (EP) CAUTION Stand clear of unit when cutting steel banding • Handle is attached to mount plate for shipping purpose only.
  • Page 9 BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS • Tack weld mount plate to embedded channel along top and sides, alternating from right and left of center. • Shim where necessary to keep leveler straight and plumb. • Drill 3/4" anchor holes along the mount plate and install 5 each 3/4" x 4 wedge anchors.
  • Page 10 BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS • Mark the bottom hole location of bumper beam, drill an anchor hole and install a ¾" x 4" wedge anchor bolt. • Re-position the bumper on the dock and weld to embedded channel and secure the bottom of the bumper with an anchor bolt and nut.

  • Page 11: Installation Procedure: (Type Ii) Dock Edge Without Embedded Steel Channel

    An approach plate requires 5 heavy duty expansion shield anchor bolts with ½" flat head socket cap screws such as can be found in Bluff EP Kit 2. Locate the approach plate and drill pilot anchor holes with a 9/16" concrete drill bit. Remove approach plate and drill over pilot holes with a 7/8"...
  • Page 12 BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS • Make certain that the leveler is straight and plumb (shim as necessary). • Drill 3/4" anchor holes along the mount plate and install 5 each ¾"x 4" wedge anchors. If equipped with Hydraulic assist, 4 additional anchors must be installed in the...

  • Page 13: Mechanical Edge-Of-Dock: Operating Instruction

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS MECHANICAL EDGE-OF-DOCK: OPERATING INSTRUCTION Step 1: The vehicle driver reverses the vehicle into position firmly against the dock bumpers. Step 2: The dock operator ensures the vehicle is blocked securely (using either a vehicle...
  • Page 14 BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS Step 3: Pull the EP handle up until the dead bolt hits the bottom of the 2-inch-square tube sleeve. Pull the handle back until the latch mechanism falls into catch position. Push the handle forward to extend the unit outward toward the truck bed.

  • Page 15: Maintenance

    EDGE OF DOCK LEVELERS MAINTENANCE The Bluff EZ-Pull Leveler will provide years of efficient operation if properly maintained. Preventive maintenance should be performed every six months or as needed for normal usage. For efficient operation and proper maintenance of Levelers used for multiple shifts (above normal usage), maintenance should be performed every 30 days.

  • Page 16: Troubleshooting

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS TROUBLESHOOTING The Bluff EZ-Pull Edge of Dock Leveler is a mechanical device requiring leverage and gravity to operate efficiently. PROBLEM CAUSE & SOLUTION • Check to ensure latch is attached to When I raise the dock leveler, the front lip unit.

  • Page 17: Hydraulic Assembly Parts List

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS HYDRAULIC ASSEMBLY PARTS LIST ITEM PART# DESCRIPTION MHYDCYLINDER 6" Stroke, Tie Rod Hyd.Cylinder Y3414B Fitting Reducer MADAPTER90 90 Deg. Elbow Short MADAPTER90XL 90 Deg. Elbow Long YFCV Flow Control Valve MPOWERUNIT AC Hyd-Pwr Unit Y90ML 90 Deg.

  • Page 18: Complete Hydraulic Set-Up Installation Instructions For Factory Issued Hydraulic Unit

    COMPLETE HYDRAULIC SET-UP INSTALLATION INSTRUCTIONS FOR FACTORY ISSUED HYDRAULIC UNIT NOTE For lo-dock applications call your local Bluff Distributor at 800-433-2212. • Mount the MPOWERUNIT on the pump mount bracket EPPMBKT. 3/8"-16 x ¾" Bolts • Mount the MHYDCYLINDER onto the lower bracket EPHLBKT.
  • Page 19 BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS • Mount the switch (MPUSHBUTTON) on the interior of the building wall.
  • Page 20 BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS Only qualified personnel should attempt to perform the following wiring CAUTION instructions.

  • Page 21: Wiring Instructions

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS Wiring Instructions NOTE All wiring should be done in accordance with local electric codes. • The unit requires 120 Volt, Single Phase current. • The photo below shows how to hook the incoming power and the connection to Junction Box on the unit.

  • Page 22: Important Note

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS Important Note • Items ship without hydraulic fluid. FILL THE RESERVOIR WITH COMMON GRADE HYDRAULIC FLUID. (Common grade fluid is ISO 46). For areas of sub-freezing temperatures, a lighter grade (ISO 32) may be used.

  • Page 23: Hydraulic Edge Of Dock Levelers: Operating Instructions

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS HYDRAULIC EDGE OF DOCK LEVELERS: OPERATING INSTRUCTIONS • With truck back into position and trailer door open, depress the reverse button until the latch falls into position. See illustration below. • Once the latch falls into position, release the reverse button and depress the forward push button.

  • Page 24: Troubleshooting (For Hydraulic Edge Of Dock Units)

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS TROUBLESHOOTING (FOR HYDRAULIC EDGE OF DOCK UNITS) SYMPTOMS POSSIBLE PROBLEM Leveler will not pivot • No grease in hinge and tube joints. • No hydraulic fluid in tank. • Missing or broken component.

  • Page 25: Complete Hydraulic Set-Up Installation Instructions For In-Field Retro-Fit Of Existing Leveler Unit

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS COMPLETE HYDRAULIC SET-UP INSTALLATION INSTRUCTIONS FOR IN-FIELD RETRO-FIT OF EXISTING LEVELER UNIT Retro-Fit The leveler selected for the retro-fit hydraulic package must be in acceptable NOTE working condition. • Lift the front lip of the EZ-Pull leveler to expose the brackets as shown below.

  • Page 26: Complete Hydraulic Set-Up Installation Instructions For In-Field Retro-Fit Of Existing Leveler Unit (Continued)

    BLUFF MANUFACTURING INC. EDGE OF DOCK LEVELERS COMPLETE HYDRAULIC SET-UP INSTALLATION INSTRUCTIONS FOR IN-FIELD RETRO-FIT OF EXISTING LEVELER UNIT (CONTINUED) • Clean the surface and weld the brackets as shown below • Anchor the lower bracket to side of dock.

  • Page 27: Bluff Warranty

    Bluff Manufacturing. This limited warranty is made only to the original purchaser, which shall be deemed to mean that person or organization to which the product is originally shipped or installed.

  • Page 28: Bluff Returned Goods Authorization (Rga)

    Manufacturing for approval. All requests must be submitted with a date stamped photograph of item to be returned. If approval is given, an RGA number will be given by Bluff Manufacturing. This RGA number must appear on all documents involving the returned goods.
