Summary of Contents for SATION SW10 Series
- Page 1 2016 KNX Switch Actuator Manual Zhuhai Sation Technology Co.,Ltd. 2015-12-17...
-
Page 2: Table Of Contents
1. Content Switch Actuators................4 SATION-SW10X Technical data............4 Products appearance..............6 Overview functions...................7 Device technology................8 Device parameters.............8 Dimension drawing and circuit diagram........10 Contact us..................13 Appendix.................14 - 2 -... - Page 3 Copyright Clarify Copyright ownership belongs to Zhuhai Sation Technology Co,.Ltd. shall not be reproduced ,copied,or used in other ways without permission.Otherwise Zhuhai Sation Technology Co,.Ltd will have the right to pursue legal Responsibilities. Notice 1. Please carefully read this manual before using the product 2.
-
Page 4: Switch Actuators
. Actuator category 1.1 SATION-SW10X Technical data KNX-Bus Voltage 21…31V DC Power supply Supply current < 12mA characteristics Consumption < 250mW Current range 0.5A...22A Nominal Control way 4-fold/6-fold/8-fold/12-fold output Rated Voltage 110~440V AC(50/60Hz) characteristics Rated Current 16 Amax Leakage Loss Per Load 1.5W... - Page 5 requirement Size 90mm X 72（144）mm X 63mm Mechanical Weight 0.3/0.6kg Parameters On 35mm mounting rail（EN60715 Installation EN50022） Appearance Grey-black、PVC Panel Color code:PANTONE 5395C Approvals KNX EN50090-1\-2 CE Mark EMC index can be referred to the Appendix - 5 -...
-
Page 6: Products Appearance
2.1 Product Appearance： SW0004.161 SW0006.161 SW0012.161 - 6 -... -
Page 7: Overview Functions
2 Overview functions This booklet provides all the details for the SATION switch actuators products, including the installation and programming details And how to use switch actuators. For ease installation, the product of this series comply with EN60715 standard, installed on a 35mm railway,. -
Page 8: Device Technology
3.Device Technology 3.1 Device parameters SATION switch actuator, the modular equipment are designed according to proM design requirements, is convenient to install on 35mm U-shape rails of the distribution box. Connected to the EIB/KNX system by the bus terminals.Actuators connect to the load, using a group of pressure type high voltage terminal blocks with two joints, and each output can be individually controlled.The equipment is suitable for... - Page 9 —load connection terminals 7.62mm terminal operation and indication —button distribute physical address/ programming —LED flashing indicates normal operation of the application layer —contact point indicator —Switch on: light on —Switch off: light out Enclosure —IP 20； According to EN60529 Safety level —II；...
-
Page 10: Dimension Drawing And Circuit Diagram
—Shunt compensated 3680W/CH Mercury vapor light —Uncompensated 3000W/CH —Shunt compensated 3680W/CH 3.2 Dimension drawing and circuit Diagram 3.2.1 SATION-SWI01 Switch actuator 4-fold 230VAC 16A 3.2.1.1 Dimension drawing (mm）: 108.00 µ µ µ µ µ µ 0.8 Nm SATION-SW0006.161 3.2.1.2 Circuit Diagram:... - Page 11 3.2.2 SATION-SWI02 Switch actuator 8-fold 230VAC 16A 3.2.2.1 Dimension Diagram ( mm) : 144.00 µ µ µ µ µ µ µ µ 0.8 Nm SATION-SW0008.161 3.2.2.2 Circuit Diagram: AC-L AC-N µ µ µ µ µ µ µ µ 0.8 Nm SATION-SW0008.161...
- Page 12 3.2.3.1 Dimension Diagram: 216.00 µ µ µ µ µ µ µ µ µ µ µ µ 0.8 Nm 0.8 Nm SATION-SW0012.161 0.6 Nm 25 26 27 3.2.3.2 Circuit Diagram: AC-L AC-N µ µ µ µ µ µ µ µ µ µ...
-
Page 13: Contact Us
4 Contact Us Zhuhai Sation Technology Co,.Ltd. 3F-2.BlogB1, No.1 software Road. Zhuhai Hi-tech zone ,Guangdong, China519000 TEL：0756-3628171 3628181 FAX：0756-2612730 https://www.sation.com.cn Factory Shenzhen H.Y Display Co,.Ltd. TEL：0755-27336598 FAX：0755-27301699 - 13 -... -
Page 14: Appendix
5. Appendix SWI01 Switch Actuators EMC (CE) Standard in the chart below. Index Name Standard No. Grade Requirement Remark Performance Criteria Contact 4KV/Air 8KV (EN61000-4-2) 80MHz-2GHz: 3V/m (EN61000-4-3) 2G-2.7GHz: 1V/m ±1KV (EN61000-4-4) SURGE L-N ±1KV (EN61000-4-5) L-PE ±2KV EN61000-6-1 C/S (EN61000-4-6) 3V/m (EN61000-4-8) DIPS... - Page 15 II SWI01 Switch Actuators Safety (CE) Standard in the chart below. Items Required level Performance Remarks EN60947-3 √ Isolation strength test √ Inflaming retarding test √ Temperature rise test √ Corrosion resisting test √ Electrical life test √ On-off volume control test √...
