Dear Customer, Thank you for choosing the Lotus industrial model combi boiler unit intended to be used as part of the heating system and designed to be the primary source of heating and hot water. We hope that the unit will create an environment in which you will enjoy thermal comfort and all domestic hot water needs.
Page 5
The following information is intended to help you throughout the entire documentation. Further documents apply in combination with this installation and maintenance manual. Lotus® assume no liability for any damage caused by non-observance of these manuals. Applicable documents The following additional documents are provided with the appliance: For the owner of the system: Brief user’s instructions...
Page 6
Note the weight of the product and the handling instructions applied to the packaging. A handling device, e.g. pallet truck or similar, to manually move the Lotus industrial model boiler unit must be use to avoid any manual handling injuries.
4. Technical Data Sheet boiler unit & Primary Circuit Electrical input (max) 10 -30 kw Electrical supply voltage 400 VAC 3P1N Electrical supply frequency 50/60 HZ Peak current intensity 45-135 AMP TOTAL Absorbed electrical power Electrical supply rating RCD/ MCB rating 300 MA Internal fuse rating 63 AMP...
Page 8
Automatic bypass valve None Primary circulating pump ---- On top of boiler Automatic air vent unit Temporary filling loop Connection points fitted within unit Secondary system operating pressure minimum 1 bar Secondary system operating pressure 2 bar 70°C Flow & Secondary flow temperature (radiator model) 50°C return Secondary flow temperature underfloor model...
The room where the boiler will be placed should be under normal indoor environmental conditions. The boiler should not be installed in areas of high humidity, or places where there is a possibility of excessive heat or freezing. The unit should be located on a solid, flat & level surface due to the weight of the unit and being on wheels. If required the wheels can be removed and the unit bolted to the solid floor for added security.
It is mandatory to connect the boiler to the individual grounding line. If this is not done, the device will not be commissioned by LOTUS authorized service, the device will be out of warranty and LOTUS shall not be liable for any possible damages / problems.
Any device selected must be suitable for use and not unduly affect the flow rate capacity to the Lotus industrial model boiler unit, consult the manufacturer of the device for details. If any anti calcification treatment is not applied, combi boiler device will be out of guarantee.
The Lotus industrial model boiler unit initial primary system cold needs to be filled step by step and complete adding water must be done up to top when the boiler tempreature is around the upper limit. Then air purge can be placed.
Positioning the Lotus industrial model boiler unit Decide where the Lotus industrial model boiler unit is to be installed. Reference must be made to the dimensions of the unit and the minimum access space requirements. For maintenance the boiler should...
Page 14
Fig 6. Auto program screen with no time selected Select operating time and day interval by means of the arrow keys and confirm by pressing the enter (center of arrow keys) the corresponding square will turn black and saved to memory. To deselect again just highlight again by means of the arrow key and select it again by pressing the enter key (center of arrow keys), this will clear the selection.
Page 15
Fig 7. Auto program screen with winter timings selected...
7.Installation – Plumbing The pipework from the Lotus industrial model boiler unit to the hot outlet fittings should be in 25 mm pipe with short runs of 15mm pipe to showers and basins. Small bore pipe can be used to suit some taps but runs should be kept as short as possible.
Page 17
99°C or greater should be used. Connections to the Lotus industrial model boiler unit primary flow and return must be in 32 mm o/dia. pipe. . The maximum radiator and area capacity value declared on manifacturer catalogue and website should not be exceeded.
Before working on the appliance, TURN OFF the power supply and secure against restart. The Lotus industrial model boiler unit electrical installation must be carried out by a competent person in accordance with any relevant regulations in force at the time of installation and the requirements of these instructions to ensure correct operation.
2.f) If Lotus Combi will be used in boiler heating mode , the internal room temperature sensor should be connected in heating return line or immersed into the boiler with a housing , and setting shoud be arrage related to required temperature in external supplying boiler.
Page 20
Check all earth bonding links are connected, are tight and un-damaged. Starting up of the boiler is only carried out by LOTUS authorised service personnel. Starting up of the boiler should only be carried out by authorised professional companies or service personnel who have a valid agreement with the manufacturer and distributor.
Page 21
informing the user of the distance of the boiler to flammable materials, fire protection and safety gaps to be left from the walls To meet the requirements for safe and economic operation of the boiler, the following conditions must be met: ...
Page 22
Commissioning of the boiler unit must only be carried out by a Lotus® approved installer. 9.1. Filling the Lotus industrial model boiler unit Cold Water Supply Open all domestic hot water taps supplied by the boiler , turn on the mains water supply to the boiler and open the mains water isolating valve on DHW outlet line on the boiler unit.
Page 23
Open the filling loop isolating valves and allow primary system to fill until the level on the screen of the Lotus industrial model boiler unit reads approx. 2.0 bar. e) Purge air from all radiators and air vent points in the primary system.
This must include: a) DHW supply – Explain how the complete Lotus industrial model boiler unit is used to provide only heated hot water. Central Heating – Explain how the central heating system works. Explain the operation of the programmable PCB thermostat and the settings that have been programmed.
Page 25
Fig 8. PCB1 Circulation Pump connection point P2 The pump can be linked with the Lotus industrial model boiler unit under position P1 of the main control board (see Fig. 4,5 & 8) this will provide a 230V when required, following manufactures instruction of the pump.
Interior cleaning. k) Read error codes, correcting the error (record the error and send it to the Lotus technical support if necessary). Software update if necessary (Card replacement is done in service and not software download).
11.3.Operation of Primary System Safety Valve (4 bar boiler unit) a) Ensure the primary flow valve is closed from the filling loop connection b) Check the safety ventil is not dripping. 11.4.Operation of Secondary System Safety Valve (3 bar boiler unit) a) Ensure the secondary flow valve is closed from the filling loop connection b) Check the safety ventil is not dripping.
1151 System pressure sensor error 12.3. System check After first energizing the device, model number will be appeared below of LOTUS brand. If it didnt appear , ( boiler will not run correctly) TURN OFF the electrical supply. Press and hold the SET & WINTER buttons while the electrical supply is turned back on. Use the related button to select and apply the correct model.
Press SET to complete. The system check comprises of the following parameters; -5C – 115C (125 means short circuit, -125 means open circuit) Boiler unit Temp Sensor -5C – 115C (125 means short circuit, -125 means open circuit) Room Temp Sensor Pressure Sensor 2 Bars (reference point shows 1 bar level) Flow Sensor...
Page 30
a)Protection Function 1: Freeze protection of the boiler This function protects the boiler unit against frost. The device must be energized for this feature to be active. If the boiler temperature drops below 5 °C, the circulation pump and the boiler run for 5 minutes.
Page 31
The boiler will lock out and display an error code advising sensor error (Fault Code 1121) e) Protection Function 1: Freeze protection of the boiler This function protects the boiler unit against frost. The device must be energized for this feature to be active.
12.6. Pump Failure Detection Pump failure Probably reason Solution Increase the system pressure within Noisy pump Cavitation due to insufficient the permissible range suction pressure Check the delivery head and set it to a lower head if necessary Increase setpoint Building does not Thermal output of the Change the control mode from Δp-c...
13.1. Winter/ Summer Mode Short self-test is performed at the moment of initial power-up. At the time of the first power-up, everything is closed, except “Protection function 1 and 2” (section 12.5: Protection features) WINTER MODE: Operate the boiler if the conditions are appropriate (see Operation lower and upper threshold table). ...
Bottom Type Distance Working Working Unit Limits Limits Water Flow Switch (10) On/off Central Heating Temperature Sensor NTC- (11) 0-10K NTC- Boiler temperature sensor (13) 0-10K Central Heating Pressure Sensor (24) Central Heating / Room Temperature NTC- Sensor (27) 0-10K Boiler Temperature Limit Thermostat Feeding Voltage Boiler Pressure Valve Mechanical...
Page 35
When the ON / OFF button is pressed [ON]: The LED of the corresponding button lights up. All functions and buttons are available. Press the ON / OFF button again [OFF]: The LED of the corresponding button goes out. ...
Page 36
Pressing the ENTER button (navigation centre) switches to the MENU screen. Pressing it again will bring up the main display screen. Switch to Delay Mode after 30 seconds of inactivity. Delay Mode 10 min. active, then dimming until any key is pressed. When the ENTER button (Navigation/Centre) is pressed, the MENU screen is displayed.
Page 37
Operational Information Display Unit Boiler temperature °C Heating temperature °C Water temperature °C Total Working Time h/m/s Total Boiler Operation Time h/m/s Future Maintenance Date dd/mm/yyyy Auto Programme Description Select operating time interval and day of operation with built in time clock. There are 3 x 3hour operating time intervals a 6-hour time interval and a 9 hour time interval for all day operation.
Page 38
Settings Customer Setup Display Mode Keep recent settings Y / N Clock Setting hh/mm/ss Language Selection EN / EN Temperature Display °C / °F Restore Factory Settings Y / N...
Page 39
The water supply does not have a Chloride content greater than 250ppm. m) Units are not installed with uncontrollable heat sources (E.g. Wood Burning Stoves). n) The guarantee card must be completed and sent back to LOTUS as soon as possible for registration.
Any valves and controls fitted are of LOTUS recommended type and specification. g) The unit has not been modified or tampered with in any way and has been regularly maintained as detailed in these instructions.
Page 41
