- Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com HT-SATELLITE-EXT Add-on Microphone for the HT-CALIPSO all-in-one collaboration bar USER MANUAL June 2, 2023 Hall Technologies June 2, 2022 Page 1 of 10...
-
Page 2: Important Safety Instructions
8. Protect the power cord from being walked on or pinched particularly at plugs. 9. Only use attachments / accessories specified by the manufacturer. Refer all servicing to qualified service personnel. Hall Technologies June 2, 2022 Page 2 of 10... -
Page 3: Table Of Contents
Introduction ..............................4 Overview ............................4 Features............................4 Package Contents ..........................4 Product Views ............................. 5 Connectors & Indicators ..........................6 Applications ..............................7 Installation ..............................8 Troubleshooting ............................8 Specifications .............................. 9 Hall Technologies June 2, 2022 Page 3 of 10... -
Page 4: Introduction
Introduction OVERVIEW The HT-SATELLITE-EXT is an add-on microphone for the HT-CALIPSO all-in-one meeting collaboration bar to extend pickup distance. It is ideal for huddle rooms, small and medium conference rooms. FEATURES Quick and easy connection using the included USB to RJ45 adapter. -
Page 5: Product Views
Product Views TOP VIEW BOTTOM VIEW Hall Technologies June 2, 2022 Page 5 of 10... -
Page 6: Connectors & Indicators
4 x omnidirectional microphone arrays for picking up audio Output connection to the HT-CALIPSO bar or the next HT-SATELLLITE-EXT upstream towards the HT-CALIPSO bar. DOWN Connect the next HT-SATELLITE-EXT microphone to extend coverage Hall Technologies June 2, 2022 Page 6 of 10... -
Page 7: Applications
Application Hall Technologies June 2, 2022 Page 7 of 10... -
Page 8: Installation
UP side and that the next daisy-chained microphone is connected to the DOWN side of the first microphone to the UP side of the next microphone. c. Verify no more than three total HT-SATELLITE-EXT microphones are connected d. Verify the HT-CALIPSO is properly powered... -
Page 9: Specifications
Humidity 10% to 90%, non-condensing Power Supply Powered by HT-CALIPSO bar Power Consumption 1.5W (Max) Device Dimension (W x H) 123.01mm x 36mm / 4.84” x 1.42” Product Net Weight .29kg/0.638lbs Hall Technologies June 2, 2022 Page 9 of 10... - Page 10 © Copyright 2022. Hall Technologies All rights reserved. 1234 Lakeshore Drive, Coppell, TX 75019 halltechav.com / support@halltechav.com (714)641-6607 Hall Technologies June 2, 2022 Page 10 of 10...
