- Page 1 60cm Ovens HWO60S7EB5, HWO60S7ELG5, HWO60S7EX5, HWO60S7EG5, HWO60S7MB5, HWO60S7MB6, HWO60S4LMB3, HWO60S7MX5, HWO60S7MX6 INSTALLATION GUIDE NZ AU...
- Page 3 CONTENTS Safety and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Components required .
- Page 5 SAFETY AND WARNINGS WARNING! Electric Shock Hazard Turn the oven off at the wall before replacing the oven lamp or before carrying out any work or maintenance on it. Failure to follow this advice may result in electrical shock or death. WARNING! Fire Hazard Failure to follow this advice may result in serious...
- Page 6 SAFETY AND WARNINGS WARNING! Hot Surface Hazard Accessible parts may become hot when in use. To avoid burns and scalds, be careful not to touch any hot part and keep children away. Use oven mitts or other protection when handling hot surfaces such as oven shelves or dishes.
- Page 7 COMPONENTS REQUIRED TOOLS Supplied Not supplied Screws (2) Powered driver Cross-head screwdriver...
- Page 8 PRODUCT AND CAVITY DIMENSIONS Mounting under cooktop The cabinetry should follow the dimensions shown . This allows for sufficient airflow behind the oven and between the oven and cooktop for cooling . If the cabinetry base is fully sealed, an opening should be provided to allow cool air to enter .
- Page 9 PRODUCT AND CAVITY DIMENSIONS Standalone Installation If the oven is mounted without a cooktop above, the cabinet depth and height can be reduced . An opening should be provided at the top of the cabinetry to allow hot air to exit . If the bottom of the cabinetry is sealed, an opening should be provided to allow cool air to enter .
- Page 10 CHECK CAVITY 1 . Measure cavity dimensions . Ensure all minimum specifications have been met . Refer to page 8 and 2 . Ensure any cooktop ventilation requirements have been considered . entry...
- Page 11 CONNECT POWER This oven must be connected to the mains power supply only by a suitably qualified person. The mains lead must not be clamped, bent, trapped, or come into contact with hot parts of the appliance . This oven must be earthed . Before connecting the oven to the mains power supply, check that: The domestic wiring system is suitable for the power drawn by the oven (as specified on the rating plate)
- Page 12 FIT THE PRODUCT 1 . Lift the product into the cavity, align the oven with surrounding cabinetry and appliances . 2 . Using the product as a guide, pre- drill 2 x 3mm pilot holes . 3 . Secure the oven to the cavity using the 2 x #3 .5x25 screws provided .
- Page 13 INSTALLER CHECKLIST To be completed by the installer Ensure the oven is level and securely fitted to the cabinetry . Open the oven door slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim . This is to ensure correct air circulation . Should the lower trim become damaged, straighten the trim and ensure the oven door opens fully without obstruction .
- Page 16 WWW .HAIER .COM .AU 70067494 | 432409A 12.24 WWW .HAIER .CO .NZ...
