P&C INSERT-36-1A Quick Start Manual

INSERT-36-1A
36" Built-In Insert Range Hood
AVAILABLE FINISHES / COLOR OPTIONS
INSERT-36-1A
Stainless-Steel
KEY FEATURES
Built-In Style Range Hood
Offers premium performance in a discreet package. This hood is specifically
crafted to be fully integrated within your overhead cabinets, for a seamless
finish.
3 Fan Speeds
Featuring three-speed settings, delivering optimal airflow for any cooking
situation, ensuring effective ventilation whether you're simmering, sautéing, or
frying.
Quiet CFM Motor
Experience cleaner kitchen air with our efficient range hood. Its dependable
motor effectively removes smoke, grease, and odours while operating at
minimal noise levels, ensuring a peaceful cooking environment.
LED Lighting
Energy-efficient, long-lasting LED lights effectively illuminate your cooking
surface, enhancing the visibility of the cooking process.
Push Button Control
Located on the front of the unit, these controls make regulating the hood
functions more convenient. From modifying the fan speed to adjusting the
light settings, giving you complete control of the cooking process.
Dishwasher-Safe Honeycomb Filters
These highly functioning filters remove grease and odours when cooking.
These removable filters can be cleaned in the dishwasher, ensuring that your
hood is continually efficient.
Notes: Porter & Charles reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Warranties: Please see the Use & Care manual or Porter & Charles website for a statement of limited
warranty. For more information on our entire line of products, go to www.porterandcharles.ca or call 905.829.3980 © Porter & Charles. All rights reserved.
GENERAL PROPERTIES
Built-in under cabinet insert range hood
Includes door-cover and spacer for 12", 13", and 15" cabinet depth
Stainless steel
Ducted/Vented
FEATURES
2 x LED lights
3 speed adjustment
Electronic push buttons
2 x Dishwasher safe honeycomb filters
6" Duct adaptor included
DIMENSIONS
Product Dimensions: W/H/D (In/mm) - 12" Cabinet Depth
35 (895mm) / 9 (251mm) / 11
1/4" 7/8"
Product Dimensions: W/H/D (In/mm) - 13" Cabinet Depth
35 (895mm) / 9 (251mm) / 12
1/4" 7/8"
Product Dimensions: W/H/D (In/mm) - 15" Cabinet Depth
35 (895mm) / 9 (251mm) / 14
1/4" 7/8"
Cut-Out Dimensions: W/D (In/mm) - 12"-13"-15" Cabinet Depth
32 (827mm) / 10 (263mm)
9/16" 3/8"
TECHNICAL SPECIFICATIONS
Power Supply: 110-120V ~ 60Hz ~ 15 Amp
Rated Input Power: 218W
Motor Power: 216W
Air flow - CFM Rating: 374 CFM
Lighting Power: 2x1 W
*Supplied with a 5ft long electrical cable.
- 12 (295mm - 310mm)
5/8" 3/16"
- 13 (321mm - 337mm)
5/8" 1/4"
- 15 (372mm - 387mm)
5/8" 1/4"
