- Page 1 Heat Exchanger Liquid cooling small Liquid to air heat exchanger Part No.: 2300110 ► User´s Manual Doc ID: 901592-000 July 2021 Version 1.1...
- Page 2 This manual and the information herein have been assembled with due diligence. INHECO GmbH does not assume liability for any misprints or cases of damage resulting from misprints in this manual. If there are any uncertainties, please feel free to contact sales@inheco.com. How to contact INHECO, page 5.
-
Page 3: Table Of Contents
........................4 XPLANATION OF YMBOLS 1.3.................... 5 XPLANATION OF BBREVIATIONS AND LOSSAR 1.4............................. 5 ARRANTY 1.5. INHECO ........................5 OW TO CONTACT PRODUCT DESCRIPTION ........................6 2.1............................6 NTENDED 2.2..........................6 COPE OF ELIVERY 2.3..........................7... -
Page 4: Important Notes
The word NOTE indicates important steps or measures that need to be followed to ensure the correct function of the unit. Contact INHECO in case there are any uncertainties of how to operate or how to handle the unit. Your opinion about this manual provides us with valuable insights on how we can improve this document. -
Page 5: Explanation Of Abbreviations And Glossar
Broken seals on INHECO devices lead to the loss of warranty as well. INHECO will only accept parts / devices for return that do not pose a threat to the health of our staff. In particular, the devices may not have been used in Biosafety Level 3 and 4 environments or have been exposed to radioactive or radiation materials. -
Page 6: Product Description
In case of parcel or product damages, make photos of the damaged boxes and products and email them to techhotline@inheco.com without delay. Transportation damages must be reported to INHECO within 7 days of delivery. Figure 1: Scope of delivery. INHECO... -
Page 7: Functional Elements
Exchanger . The identification label must not be removed. If it has become illegible or falls off, it has to be replaced by a new identification label. New labels can be ordered at INHECO. Figure 3: Examples of identification label. -
Page 8: Technical Data
Temperature Operation +15°C to +32°C [+59°F to 90°F] Transportation and -20°C to + 60°C [+14°F to 140°F] storage non condensing Figure 4: Drawing of the device; all values are shown in mm. INHECO Doc ID: 901592-000 June 2021 Version 1.1... -
Page 9: Safety Instructions
Ensure that there is no other device installed next to the unit increasing the inlet air temperature for the unit above the specified temperatures. In case of doubt, please contact INHECO for further analysis. Ensure a minimum of at least 200 mm or 8 inches of free space between the ventilation openings and adjacent devices or walls. -
Page 10: Technical Alterations
Technical Alterations Do not alter the product. Any modification or change which is not approved by INHECO leads to the loss of warranty. Broken seals on INHECO devices lead to the loss of warranty as well. Use only original parts provided by INHECO. Parts provided by other suppliers can impair the functionality of the unit. -
Page 11: Installation
This causes the quick-release to pop open. When the quick-release couplings are disconnected, the internal water lock of both, the Heat Exchanger and MTC cooled device, is automatically closed so that no significant amount of coolant can run out. INHECO Doc ID: 901592-000 June 2021 Version 1.1... - Page 12 To further increase safety, a locking clip is also included to prevent accidental opening of the quick release coupling. An unlocking clip makes it easier to open the quick-release coupling if required. Figure 7: How to use the locking and unlocking clip. INHECO Doc ID: 901592-000 June 2021 Version 1.1...
-
Page 13: Daily Use
MTC/STC device, always make sure that the pump and the fans of the unit are working. 5.2. Checking the liquid level Figure 8: Use the viewing window and ensure that it is as full as possible that no noise of the pump is audible. INHECO Doc ID: 901592-000 June 2021 Version 1.1... -
Page 14: Maintenance
INHECO needs the below mentioned information including the serial numbers of your devices and the error code report. With this information INHECO can help you to trouble-shoot the reason for the operation failure. Please provide the following when contacting INHECO for support:... -
Page 15: Decontamination And Cleaning
6.4. Return to INHECO only with RMA Number INHECO devices must be repaired by INHECO only. Parts must not be exchanged by the user. Exchange of parts or broken seals can lead to the loss of warranty. Spare Parts must be ordered from INHECO. -
Page 16: Transportation And Storage
INHECO will only accept parts / devices for return that do not pose a threat to the health of our staff. In particular, the devices may not have been used in Biosafety Level 3 and 4 environments or have been exposed to radioactive or radiation materials. -
Page 17: Accessoires
7.3. Cooling Liquid Product Name Description Part Number MANNOL Antifreeze Transfers heat load from the liquid cooled MTC/STC 2300104 AG11 (-40) device to the Heat Exchanger Liquid cooling small Longterm INHECO Doc ID: 901592-000 June 2021 Version 1.1... -
Page 18: Appendix
8. Appendix 8.1. EC Declaration INHECO Doc ID: 901592-000 June 2021 Version 1.1... -
Page 19: Document History
4.1 Installation of the heat exchanger: Figure 5 edited; 4.2 Connecting a liquid cooled MTC/STC device: Description edited; June 2021 EC Declaration added July 2021 4.1 Installation of the heat exchanger: Figure 7 added INHECO Doc ID: 901592-000 June 2021 Version 1.1...
