Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
Operation
Maintenance
Specifications
All information in this Owner's Manual is current at the time of
publication. However, HYUNDAI reserves the right to make
changes at any time so that our policy of continual product
improvement may be carried out.
This manual applies to all models of this vehicle and includes
descriptions and explanations of optional as well as standard
equipment.
As a result, you may find material in this manual that does not
apply to your specific vehicle.
Please note that some models are equipped with Right-Hand
Drive (RHD). The explanations and illustrations for some
operations in RHD models are opposite of those written in this
manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SX2e EV and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai SX2e EV

Summary of Contents for Hyundai SX2e EV

  • Page 1 Maintenance Specifications All information in this Owner’s Manual is current at the time of publication. However, HYUNDAI reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all models of this vehicle and includes descriptions and explanations of optional as well as standard equipment.
  • Page 2 CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the Department of Transportation and other government agencies in your country.
  • Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.

  • Page 5: Table Of Contents

    Table of contents Information/Getting started with your electric vehicle Vehicle information Seats & Safety system Instrument Cluster Convenience Features Driving your vehicle Driver Assistance System Emergency situations Maintenance Index...
  • Page 7 1. Information/Getting started with your electric vehicle Information ........................1-2 About "Getting started with your electric vehicle" ............1-4 Understanding your electric vehicle ................1-5 Characteristics of your electric vehicle...............1-5 Precautions when using the high voltage battery............1-7 Other precautions for electric vehicle management ..........1-8 Charging your electric vehicle..................1-9 Safety precautions for charging your electric vehicle ..........1-9 Checking basic information on charging your electric vehicle .......

  • Page 8: Information/Getting Started With Your Electric Vehicle

    HYUNDAI we build. Your Owner’s Manual will introduce you to the features and operation of your new HYUNDAI. To become familiar with your new HYUNDAI, so that you can fully enjoy it, read this Owner’s Manual carefully before driving your new vehicle.
  • Page 9 Safety messages Your safety, and the safety of others, is very important. This Owner’s Manual provides you with many safety precautions and operating procedures. This information alerts you to potential hazards that may hurt you or others, as well as damage to your vehicle. Safety messages found on vehicle labels and in this manual describe these hazards and what to do to avoid or reduce the risks.

  • Page 10: About "Getting Started With Your Electric Vehicle

    Returning used vehicles (for Europe) HYUNDAI promotes an environmentally sound treatment for end of life vehicles and offers to take back your HYUNDAI end of life vehicles in accordance with the European Union (EU) End of Life Vehicles Directive. You can get detailed information from your national HYUNDAI website.

  • Page 11: Understanding Your Electric Vehicle

    Understanding your electric vehicle Electric vehicles are driven using a battery and an electric motor. Understand the characteristics of your electric vehicle and check the features that you must know before driving it. Characteristics of your electric vehicle The characteristics that differentiate electric vehicles from gasoline and diesel vehicles are as follows: •...
  • Page 12 • When the high voltage battery or its related components require inspection and maintenance, we recommend that you contact an authorized HYUNDAI dealer.

  • Page 13: Precautions When Using The High Voltage Battery

    • If a collision occurs and the vehicle is impacted, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer to check the battery connection status. • Using the V2L function may reduce the driving distance due to the use of the high voltage battery energy, and repeated use of the V2L function may cause a decrease in the life of the high voltage battery.

  • Page 14: Other Precautions For Electric Vehicle Management

    Only use or install genuine parts. High voltage cut-off switch High voltage cut-off switch is a device located inside the motor compartment to block the battery’s high voltage when your vehicle is inspected at an authorized HYUNDAI dealer. 2C_HighVoltageCutoffSwitch WARNING •...

  • Page 15: Charging Your Electric Vehicle

    Charging your electric vehicle Check the detailed information about charging an electric vehicle and charge your vehicle. Electric vehicles can be charged via an AC charger or DC charger installed at public charging stations. If the vehicle cannot be moved to a public charging station in the event of an emergency, you can charge the vehicle via the In-Cable Control Box (ICCB) with a power source (AC 220 V).
  • Page 16 Information/Getting started with your electric vehicle Basic safety precautions for charging WARNING • Before charging, apply the Electronic Parking Brake (EPB) with the brake pedal pressed, shift to P (Park) and turn off the vehicle. Movement of the vehicle while charging may result in property damage, serious injury, or death.
  • Page 17 Information • While charging, the gear cannot be shifted from P (Park) to any other gear. • Ensure the vehicle door is unlocked before disconnecting the charging connector. The unlock button on the charging connector does not work when the vehicle door is locked.
  • Page 18 • If there is any sign of damage, corrosion, or rust on the charging connector and plug, or if the connection of the charging connector and plug feels loose, do not use the cable. We recommend that your vehicle be inspected by an authorized HYUNDAI dealer.

  • Page 19: Checking Basic Information On Charging Your Electric Vehicle

    Precautions when handling and storing the charging cable CAUTION • Always keep the charging connector and plug dry and clean. • Ensure that the connectors, plugs, and control box (portable charger) of the charging cable are not submerged or in contact with water. •...
  • Page 20 Information/Getting started with your electric vehicle CAUTION • Battery performance and life may deteriorate if the DC charger is used constantly. Use of DC charging should be minimized in order to help prolong high voltage battery life. Use AC charging unless DC charging is necessary. •...
  • Page 21 Checking the charging status Check the State of Charge (SOC) of the high voltage battery via the charge indicator lamp inside the charging door. 1. With the vehicle door unlocked, press the open indicator on the charging door to open the charging door.
  • Page 22 Information/Getting started with your electric vehicle Checking information on the charging label Open the charging door and check the information on the charging label. The charging label shows safety symbols and the rated input specifications for charging. 1C_ChargingLabelLocation 1C_ChargingLabel The actual image may differ from the illustration. Name Description Warning for high voltage...
  • Page 23 If the charging connector is not disconnected due to battery being fully discharged or a wiring failure, open the hood and pull the emergency cable. 2C_EmergencyChargingCable • If the charging connector does not disconnect after pulling the emergency cable, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 1-17...

  • Page 24: Using An Ac Charger

    Information/Getting started with your electric vehicle Using an AC charger AC charging is the most common charging method for electric vehicles. Charge your electric vehicle using an AC charging cable installed in public charging stations or separately purchased AC charging cable. •...
  • Page 25 Charging with an AC charger Follow the instructions below to charge the vehicle with an AC charger. 1. With the vehicle started, apply the Electronic Parking Brake (EPB) while pressing the brake pedal. 2. Turn all switches off, shift to P (Park), and turn off the vehicle. 3.

  • Page 26: Using A Dc Charger

    Information/Getting started with your electric vehicle 8.Hold the charging connector handle, and pull the charging connector to disconnect it from the charging inlet. CAUTION Do not forcibly disconnect the charging connector without pressing the unlock button on the charging connector. It may damage the charging connector or the charging inlet on the vehicle.
  • Page 27 Understanding the DC charging connector The exterior of the DC charging cable is as follows: 2C_DCCharger Charging with a DC charger Follow the instructions below to charge the vehicle with a DC charger. 1. With the vehicle started, apply the Electronic Parking Brake (EPB) while pressing the brake pedal.
  • Page 28 Information/Getting started with your electric vehicle 6.When charging is complete, hold the charging connector handle and pull out the charging connector to disconnect it from the charging inlet. • Depending on the DC charger types, some DC chargers may not have a charger connector unlock button.

  • Page 29: Using A Portable Charger (Iccb)

    To prevent property damage or injury due to fire or explosion, follow the instructions below. • Only use a genuine HYUNDAI portable charger (if equipped). • Do not let children operate or touch the portable charger. Doing so may lead to unexpected accidents.
  • Page 30 Information/Getting started with your electric vehicle Understanding portable chargers The configuration of a portable charger and the display of the operation indicator are as follows: ONE1Q011087L (1) Power plug (2) Control box (3) Charging connector 2C_ICCBCharger Icon Name Color Description POWER Green Turns on when the power is on.
  • Page 31 • If the same symptom repeats after resetting the portable charger, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. • If there is no status change for more than 1 minute, the portable charger is switched to power saving mode, and the display light is turned off.
  • Page 32 Information/Getting started with your electric vehicle Charging with a portable charger Follow the instructions below to charge the vehicle with a portable charger. 1. Connect the power plug of the portable charger to the electrical outlet at your home. • The power indicator light on the control box turns green. 2.
  • Page 33 7. Remove the charging connector protection cap of the portable charging cable, hold the charging connector handle, and connect it to the AC charging inlet of the vehicle. Push it until you hear a click. • When charging starts, the estimated charging time is displayed on the instrument cluster for about one minute.

  • Page 34: Electric Vehicle

    Information • You can set up or cancel scheduled charging using the HYUNDAI Bluelink app on your smartphone. For more information, refer to the infotainment system manual. • Charging may start immediately after a charger is connected to the vehicle, depending on the charging time calculated when setting up the scheduled charging.

  • Page 35: Stopping Charging Immediately

    - If the vehicle is charged normally using another charger, contact the charger manufacturer for a solution. - If the vehicle is not charged even when using another charger, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 1-29...

  • Page 36: Using Electric Vehicle Functions

    Information/Getting started with your electric vehicle Using Electric Vehicle functions Electric vehicle provides driving information and high voltage battery information. You can set various electric vehicle functions in Electric vehicle. Checking the Electric Vehicle screen configuration Follow the instruction below to enter Electric vehicle mode and check the screen configuration.
  • Page 37 Name Description You can check the energy consumption and energy economy history. Ĥ You can set various options related to electric vehicle charging. You can set a scheduled departure time by which charging is complete and the cabin temperature is Next departure preconditioned.

  • Page 38: Checking Energy Information

    Information/Getting started with your electric vehicle Checking energy information You can check the energy consumption and energy economy history. 1. On the infotainment screen, move to Home screen. 2. On the Home screen, select Electric vehicle > • Check the energy information. Checking the energy consumption On the infotainment screen, select Electricity use.

  • Page 39: Setting The Next Departure Time

    Checking the energy economy history On the infotainment screen select Energy consumption history. • You can check the history of electric energy economy with the date and distance of previous driving. 1C_EVEconomyHistory Setting the next departure time You can set an anticipated departure time for scheduled charging and target temperature.
  • Page 40 Information/Getting started with your electric vehicle 1. On the infotainment screen, move to Home screen. 2. On the Home screen, select Electric vehicle > Ĥ > Next departure. 3. Set the anticipated departure schedule. 1C_NextDeparture 4. Set anticipated time (1) and temperature (2) the vehicle departure after charging. 5.

  • Page 41: Setting The Options For The Ac Charger

    Setting the options for the AC charger You can set the options for the AC charger including scheduled charging and charging current. 1. On the infotainment screen, move to Home screen. 2. On the Home screen, select Electric vehicle > Ĥ > AC charger. 3.

  • Page 42: Setting The Target Battery Charge Level

    Information/Getting started with your electric vehicle Setting the charging current Set the charging current when using an AC charger. 1C_ACChargingCurrent Setting the target battery charge level You can set the target battery charge level when charged with an AC charger or a DC charger.

  • Page 43: Setting A Battery Discharging Limit When Using Vehicle To Load (V2L)

    1. On the infotainment screen, move to Home screen. 2. On the Home screen, select Electric vehicle > Ĥ > Charging limit. 3. Set each of the target battery charge level for AC charger and DC charger. • The charging level can be changed by 10 %. •...

  • Page 44: Setting Electric Vehicle Specialized Functions

    Information/Getting started with your electric vehicle 1. On the infotainment screen, move to Home screen. 2. On the Home screen, select Electric vehicle > Ĥ > Electricity use settings (V2L). 3. Set the desired battery discharging limit (%). • The battery discharging limit can only be set below the current battery charge. •...
  • Page 45 Manual operation 1. On the infotainment screen, move to Home screen. 1C_BatteryConditioning 2. On the Home screen, select Electric vehicle > Ĵ > Battery conditioning and select Activate to use manually. Linked to navigation route Linked to navigation route If you set a DC charging station as a destination or waypoint on your navigation, the Battery Conditioning function maintains the battery temperature ideal for DC charging while considering the arrival time.
  • Page 46 Information/Getting started with your electric vehicle Setting Utility mode Utility mode allows the high voltage battery to be used instead of the 12 V battery for purposes other than driving. You can use the audio and lights of the vehicle without worrying about discharging the battery and even use the indoor V2L feature.
  • Page 47 Using Plug & Charge (for Europe) When charging with a DC charger, you can use the Plug & Charge function to charge your electric vehicle quickly and easily. Setting the Plug & Charge Follow the instructions below to charge your electric vehicle setting the Plug & Charge. 1.
  • Page 48 Around the course, around the current site, around the selected destination or charging stations of interest is searched. If you choose the charging station, the detailed information is provided. Information When you sign up for HYUNDAI Bluelink service, the available chargers at each charging station is displayed. 1-42...
  • Page 49 Follow the instructions below to search for nearby charging stations: 1. On the infotainment screen, move to Home screen. 2. On the Home screen, select Electric vehicle > > Charging station list. 1C_ChargingStationListMenu • You can choose among "Route", "Current position", Destination, and "Favorite". •...

  • Page 50: Using V2L Function

    Information/Getting started with your electric vehicle Using V2L function With the Vehicle to Load (V2L) feature, you can turn on electronic devices by connecting them to the high voltage battery. Safety precautions when using the V2L function Before using V2L function, carefully read all the safety information below and follow precisely.
  • Page 51 Precautions for operating the cooling fan WARNING 2C_MotorRoomHotCaution When using the V2L, the cooling fan in the vehicle motor compartment can operate automatically even if the vehicle is turned off. Do not put your hand near the cooling fan in the V2L operating state. Precautions for handling and using the V2L connector CAUTION •...
  • Page 52 Information/Getting started with your electric vehicle Precautions when using electric/electronic products CAUTION • Before using the product, check the precautions and how to use the product referring to the product manual. • Only use products that have obtained national safety certification. •...

  • Page 53: Using Electricity Outside The Vehicle

    Using electricity outside the vehicle Before using V2L function, carefully read all the safety information and precautions on “Safety precautions when using the V2L function” and follow the instructions. Follow the instructions below to connect the V2L connector to the charging inlet on the vehicle and supply power to an electronic product.

  • Page 54: Using Electricity Inside The Vehicle

    Information/Getting started with your electric vehicle Using electricity inside the vehicle You can connect home appliances or electric devices to the power outlet inside the vehicle and use them conveniently. WARNING Do not use an electric heating appliances like electric kettle, toaster, or iron in the vehicle. It may cause a fire and injury.
  • Page 55 • If the electronic device does not work even though the green indicator is on, reconnect the electronic device plug to the power outlet. • V2L discharging mode shuts off if the vehicle is off using indoor V2L on the vehicle state of ON.

  • Page 56: Solving V2L Problems

    Information/Getting started with your electric vehicle Solving V2L problems If a problem occurs while using the V2L function, the V2L stops and a related messages appears on the instrument cluster. Check the cause of the message and take an appropriate measure referring to the table below.

  • Page 57: Aux. Battery Saver

    Aux. Battery Saver+ if equipped WARNING 2C_BatterySaverIndicator When the function is activating the indicator lamp illuminates and high voltage electricity flows into the vehicle. Follow the instruction below to prevent electrical shock or injuries. • Do not touch the high voltage electric wire (orange), connector, and all electric components and devices.

  • Page 58: Driving Your Electric Vehicle

    Information/Getting started with your electric vehicle Driving your electric vehicle Check how to use the devices inside the vehicle that you must know for driving, such as starting, braking, and shifting the electric vehicle. Starting and stopping the vehicle Follow the instructions below to start or stop the vehicle. CAUTION •...
  • Page 59 Stopping the vehicle 1. Stop the vehicle completely by pressing the brake pedal. 2. Apply the EPB while pressing the brake pedal, and press the reduction gear’s P button to shift to P (Park). 3. Press the Start/Stop button. • The ¢ indicator on the instrument cluster turns off. Information There are other Start/Stop button positions besides the ON/OFF.

  • Page 60: Checking Electric Vehicle Driving Information

    Information/Getting started with your electric vehicle Checking electric vehicle driving information During vehicle operation, the instrument cluster displays the main information, such as distance to empty, real-time energy status, battery charge level, and warning messages, via the user interface and indicators. Factors affecting the distance to empty The distance to empty refers to the distance that can be driven by the current charged battery level and is displayed on the bottom of the instrument cluster while driving the...
  • Page 61 Change in the distance to empty when 100 % charged In case the distance to empty has been reduced due to learning of the driving habit or the driving conditions, you can increase the distance to empty again by continuously driving following the “Tips for enhancing the distance to empty”.
  • Page 62 Information/Getting started with your electric vehicle Tips for enhancing the distance to empty The distance to empty vary depending on the charge level of the high voltage battery, weather, temperature, duration of the battery use, terrain, driving habits, etc. You can increase the distance to empty by driving the vehicle following the instructions below.
  • Page 63 Checking the real-time energy status (CHARGE/POWER gauge) The CHARGE/POWER gauge displays the charging and discharging status of the electric energy produced by the regenerative braking and the energy consumption of the electric motor. Type A 2C_PowerChargeGaugeA Type B 2C_PowerChargeGaugeB • CHARGE: Shows the charging status of the electric motor when vehicle is decelerating or driving on a downhill road (being charged by the regenerative brakes).
  • Page 64 Information/Getting started with your electric vehicle Checking the State of Charge (SOC) The SOC indicator is displayed at the bottom of the CHARGE/POWER gauge and shows the charge level of the high voltage battery as a percentage. The lower the number, the more the vehicle needs to be charged, and 100 % indicates a full charge.
  • Page 65 CAUTION If the warning light illuminates while driving or does not go off, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. Checking the warning lights Check the cause of the warning lights referring to the table below and take appropriate measures.
  • Page 66 WARNING • Do not drive with a warning message displayed. • If a warning message does not go off after taking measures, we recommend that you have the vehicle immediately inspected and repaired by an authorized HYUNDAI dealer. 1-60...
  • Page 67 Check electric There is a problem with the immediately tow the vehicle to vehicle system electric vehicle control system. an authorized HYUNDAI dealer and have it inspected and repaired. If it illuminates alone, it did not fail. This warning message is displayed when the power of the •...
  • Page 68 HYUNDAI dealer for inspection and repair. Immediately stop the vehicle in a Stop safely and safe place. We recommend that...
  • Page 69 AC charger or DC for proper operation or a genuine Please check the charger. HYUNDAI portable charger. AC(DC) charger • The external AC charger • If the same problem occurs, we stopped the charging.

  • Page 70: Countermeasures For Accidents Or Fire

    • Immediately turn off the vehicle and evacuate to a safe place with your key. • Contact the emergency rescue service such as a fire department, or an authorized HYUNDAI dealer. WARNING Never touch the submerged electric vehicle. This may lead to an accident such as an electric shock or fire.

  • Page 71: If The Electric Vehicle Needs Towing

    If the electric vehicle needs towing If towing is required, lift all wheels to tow. Towing with the wheels on the ground may damage the vehicle’s motor components. CAUTION When a vehicle fire occurs due to the battery, there is a risk of a second fire. Contact the fire department when towing the vehicle.

  • Page 72: Other Precautions For Electric Vehicle Accidents

    • When you paint or apply heat treatment to the vehicle as a result of an accident, the performance of the high voltage battery can be reduced. If heat treatment is required, we recommend that you contact an authorized HYUNDAI dealer. • Use or install only genuine parts. Third-party parts or modified parts may damage the...

  • Page 73: Vehicle Data Collection And Event Data Recorders

    Vehicle data collection and event data recorders This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.

  • Page 75: Vehicle Information

    2. Vehicle information Exterior overview (Front View) ..................2-2 Exterior overview (Rear View) ..................2-3 Interior overview......................2-4 Center console overview ....................2-6 Steering wheel control overview.................. 2-10 Motor Compartment Overview ..................2-11 Dimensions ........................2-12 Electric vehicle specifications ..................2-13 Bulb wattage........................2-14 Tires and wheels ......................2-15 Load and speed capacity tires..................2-15 Air conditioning system ....................2-16...

  • Page 76: Exterior Overview (Front View)

    Vehicle information Exterior overview (Front View) Front view 1C_OutsideVehicleFrontOverview The actual shape may differ from the illustration. (1) Electric charging door .................... 5-57 (2) Hood ........................5-46 (3) Front light ......................5-63, 9-43 (4) Tires and wheels ..................... 9-22 (5) Outside rearview mirror ..................5-34 (6) Wide sunroof ......................

  • Page 77: Exterior Overview (Rear View)

    Exterior overview (Rear View) Rear view 1C_OutsideVehicleRearOverview The actual shape may differ from the illustration. (1) Door ..........................5-21 (2) Rear combination light .................5-63, 9-49 (3) Tailgate ........................5-50 (4) Antenna ........................ 5-108 (5) High mounted stop light ..................9-49 (6) Rear window wiper blades .

  • Page 78: Interior Overview

    Vehicle information Interior overview Left-hand drive 1C_SideInsideVehicleOverview The actual shape may differ from the illustration. (1) Inside door handle .....................5-22 (2) Integrated Memory System (if equipped)............. 5-27 (3) Outside rearview mirror control switch ..............5-35 (4) Outside rearview mirror folding button ..............5-35 (5) Central door lock switch..................
  • Page 79 Right-hand drive 1C_SideInsideVehicleOverview_RHD The actual shape may differ from the illustration. (1) Inside door handle ..................5-22 (2) Integrated Memory System (if equipped) ............. 5-27 (3) Outside rearview mirror control switch ..............5-35 (4) Outside rearview mirror folding button ..............5-35 (5) Central door lock switch ................... 5-22 (6) Power window switches ...................5-39 (7) Power window lock button..................5-40 (8) Headlight leveling device (if equipped) ..............5-65...

  • Page 80: Center Console Overview

    Vehicle information Center console overview Left-hand drive 1C_CenterInsideVehicleOverview The actual shape may differ from the illustration. (1) Instrument cluster ....................4-2 (2) Horn ......................... 5-32 (3) Driver’s front air bag ....................3-44 (4) Start/Stop button ......................6-5 (5) Rotary shifter (Rotary gear shift dial) ..............6-9 (6) Infotainment system ....................
  • Page 81 (11) USB port/charger..................5-107, 5-98 (12)USB port/charger convert button ................5-98 (13)USB charger......................5-98 (14)Wireless charging system indicator ..............5-100 (15)Power outlet....................5-97 (16)Wireless smartphone charging system ............5-100 (17) Seat warmer ....................3-19 (18)Air ventilation seat ....................3-21 (19)Heated steering wheel (if equipped) ..............5-31 (20)Auto Hold button....................
  • Page 82 Vehicle information Right-hand drive 1C_CenterInsideVehicleOverview_RHD The actual shape may differ from the illustration. (1) Instrument cluster.....................4-2 (2) Horn .........................5-32 (3) Driver’s front air bag ....................3-44 (4) Start/Stop button ......................6-5 (5) Rotary shifter (Rotary gear shift dial) ..............6-9 (6) Infotainment system .................... 5-109 (7) Hazard warning flasher switch ................8-2 (8) Automatic climate control system ................
  • Page 83 (11) USB port/charger ..................5-107, 5-98 (12)USB port/charger convert button .................5-98 (13)USB charger ......................5-98 (14)Wireless charging system indicator ..............5-100 (15)Power outlet ......................5-97 (16)Wireless smartphone charging system ............... 5-100 (17) Seat warmer ......................3-19 (18)Air ventilation seat ....................3-21 (19)Heated steering wheel ....................5-31 (20)Auto Hold button ....................

  • Page 84: Steering Wheel Control Overview

    Vehicle information Steering wheel control overview 1C_SteeringWheelControlOverview The actual shape may differ from the illustration. (1) Lighting control lever....................5-63 (2) Wiper and washer control lever................. 5-74 (3) Paddle shifter ......................6-16 (4) Driving Assist button....................7-81 (5) Cluster display controls ..................4-23 (6) Vehicle Distance button................

  • Page 85: Motor Compartment Overview

    Motor Compartment Overview 1C_MotorRoomOverview The actual motor compartment in the vehicle may differ from the illustration. (1) Coolant reservoir ......................9-12 (2) Windshield washer fluid reservoir ................9-15 (3) Brake fluid reservoir ....................9-14 (4) Fuse box ........................9-30 (5) Battery (12 V) ......................9-19 (6) Front trunk .......................

  • Page 86: Dimensions

    Vehicle information Dimensions Items mm (in.) 4,355 (171.46) Overall length N Line: 4,385 (172.63) Overall width 1,825 (71.85) 215/60 R17 1,575 (62.01) / 1,580 (62.20) Overall height 1,575 (62.01) / 1,580 (62.20) 235/45 R19 N Line: 1,575 (62.01) / 1,580 (62.20) 215/60 R17 1,591 (62.63) Front tread...

  • Page 87: Electric Vehicle Specifications

    Electric vehicle specifications Type A Type B Long Long Items Long Long Standard range Standard range range range (N Line) (N Line) Max. output 114.6 (kW) Motor Max. torque (N·m) Capacity 48.9 48.6 64.8 64.8 (kWh) Battery (Lithium- Power ion) output (kW) Voltage (V) Charger...

  • Page 88: Bulb Wattage

    Vehicle information Bulb wattage Light bulb Bulb type Wattage Headlight High Daytime running light/Position light Front Type A PY21W 21 W Turn signal light Type B Side repeater light Tail/Stop light Type A PY21W 21 W Turn signal light Type B Rear Backup light W16W...

  • Page 89: Tires And Wheels

    Tires and wheels Inflation pressure kPa (psi) Wheel nut Items Tire size Wheel size Normal load Maximum load torque kgf·m (lbf·ft, N·m) Front Rear Front Rear 215/60R17 7.0J X 17 11-13 (79-94, Full size tire 250 (36) 250 (36) 107-127) 235/45R19 7.5J X 19 NOTICE...

  • Page 90: Air Conditioning System

    Heat pump 180±10 g (6.35±0.35 oz.) Compressor lubricant Without heat pump 180±10 g (6.35±0.35 oz.) We recommend that you contact an authorized HYUNDAI dealer for more information. Vehicle weight and luggage volume Item Value Standard 2,100 kg (4,630 lbs.) Gross vehicle weight Long range 2,185 kg (4,817 lbs.)

  • Page 91: Reference Weight And Distance When Towing A Trailer

    Reference weight and distance when towing a trailer The following table indicates the maximum trailer weight for your vehicle. Do not exceed the maximum allowable trailer weight. The maximum trailer weight includes the weight of the trailer, any cargo, and equipment or items attached to the trailer. The towing load in excess of these limits can seriously affect vehicle steering and performance, and may damage the motor and drivetrain.

  • Page 92: Recommended Lubricants And Capacities

    Vehicle information Recommended lubricants and capacities To help achieve proper vehicle performance and durability, use only lubricants of the proper quality. These lubricants and fluids are recommended for use in your vehicle. Lubricant Volume Classification Reduction gear fluid 2.8-2.9 ℓ (3.0-3.1 US qt.) HK ATF 65 SP4M-1 with heat pump 13.1 ℓ...

  • Page 93: Vehicle Identification Number (Vin)

    Vehicle Identification Vehicle certification label Number (VIN) Frame number 2C_CertificationLabelPosition The vehicle certification label attached on the driver’s (or front passenger’s) side 2C_VINPosition center pillar gives the vehicle The vehicle identification number (VIN) is identification number (VIN). the number used in registering your vehicle and in all legal matters pertaining to its ownership, etc.

  • Page 94: Motor Number

    Air conditioner other relevant provisions of Directive 1995/5/EC. compressor label Further information including the manufacturer’s declaration of conformity is available on HYUNDAI website as follows: http://service.hyundai-motor.com Open source software notice This vehicle contains software with open 2C_AirconCompLabel source licenses.

  • Page 95: Seats & Safety System

    3. Seats & Safety system Important safety precautions ..................3-2 Always wear your seat belt..................3-2 Restrain all children ..................... 3-2 Airbag hazards......................3-2 Driver distraction ......................3-2 Never drink or take drugs and drive ................3-3 Control your speed ...................... 3-3 Keep your vehicle in safe condition................

  • Page 96: Important Safety Precautions

    Seats & Safety system Important safety Driver distraction Driver distraction presents a serious and precautions potentially deadly danger, especially for inexperienced drivers. Safety should be You will find many safety precautions and the primary concern when behind the recommendations throughout this wheel and drivers need to be aware of the section, and throughout this manual.

  • Page 97: Never Drink Or Take Drugs And Drive

    Never drink or take drugs and drive Drinking alcohol or taking drugs can reduce your ability to respond to changing conditions and emergencies. Do not drink or take drugs and drive, and do not let your friends drink or take drugs and drive.

  • Page 98: Seats

    Seats & Safety system Seats 1C_FrontSeatOverview Driver's seat [A] (1) Forward or rearward (2) Seatback angle (3) Seat height/Seat cushion angle (4) Lumbar support (5) Relaxation comfort seat switch (if equipped) (6) Headrest Front passenger's seat [B] (1) Forward or rearward (2) Seatback angle (3) Seat height (4) Relaxation comfort seat switch (if equipped)
  • Page 99 Infotainment system 1C_AdjustSeatAVN Press the Ų button, and then select Vehicle > Seats (if equipped) from the infotainment system, you may use various convenience functions. • Link to climate settings for auto-adjustment: The seat warmer, and air ventilation seat is automatically controlled depending on the ambient temperature and set climate control temperature.

  • Page 100: Safety Precautions

    Seats & Safety system Safety precautions Seat belts Always fasten your seat belt before Adjusting the seats so that you are sitting starting any trip. At all times, passengers in a safe and comfortable position plays should sit upright and be properly an important role for the safety of the restrained with a seat belt.

  • Page 101: Front Seats

    Front seats Reclining seatback Sitting in a reclined position when the WARNING vehicle is moving can be dangerous. Even when buckled up, the protections of your To prevent serious injury or death: restraint system (seat belts and/or • Never attempt to adjust the seat while airbags) is greatly reduced by reclining the vehicle is moving.
  • Page 102 Seats & Safety system Seatback angle Seat adjustment if equipped The front seat can be adjusted by using the levers located underneath the front part of the seat or the knob on the outer side of the seat. Forward and rearward adjustment 2C_AdjustSeatBackmanual To recline the seatback: 1.
  • Page 103 Lumbar support (if equipped) NOTICE To prevent damage to the seats: • Always stop adjusting the seats when the seat has been adjusted as far forward or rearward as possible. • Do not adjust the seats longer than necessary when the vehicle is turned off.
  • Page 104 Seats & Safety system Seatback angle adjustment Lumbar support (if equipped) 2C_AdjustSeatBackAuto 2C_AdjustSeatBackCushionAuto To recline the seatback: To adjust the lumbar support: 1. Push the control switch forward or 1. Press the front portion of the switch (1) rearward. to increase support or the rear portion of the switch (2) to decrease support.
  • Page 105 Using the relaxation comfort seat Information Driver/passenger relaxation comfort seat switch Press the auto return button to return to the original seat position after operating the Relaxation comfort seat. Using the seat adjustment switch other than the auto return button may restrict the downward cushion movement.

  • Page 106: Rear Seats

    System. If relaxation comfort seat does not operate even after resetting the Integrated Memory System, we recommended that you contact an authorized HYUNDAI dealer. 2C_RearSeatRecline To recline the seatback: 1. Pull up the seatback folding lever. 2. Hold the lever and adjust the seatback of the seat to the desired position.
  • Page 107 Folding the rear seats WARNING The rear seatbacks can be folded to • Never allow passengers to sit on top of facilitate carrying long items or to the folded down seatback while the increase the rear cargo volume in the vehicle is moving.
  • Page 108 Seats & Safety system To unfold the rear seatback: 3. Route the seat belt webbing to the both sides of the rear seats to prevent the 1. Lift and push the seatback rearward belts from being damaged. while lifting up the front portion of the folding lever.

  • Page 109: Headrest

    Armrest • Adjust the headrests so that the middle of the headrest is at the same height as the top of the eyes. 2C_RearArmrestFlip The armrest is located in the center of the 2C_HeadrestRightPosition rear seat. Pull the armrest down from the •...
  • Page 110 Seats & Safety system Front seat headrests NOTICE 2C_FrontHeadrestOverview 2C_AdjustHeadrestCaution The driver’s and front passenger’s seats If you recline the seatback towards the are equipped with adjustable headrests front with the headrest and seat cushion for the passengers safety and comfort. raised, the headrest may come in contact with the sunvisor or other parts of the Adjusting the height up and down...
  • Page 111 Removal/Reinstall To reinstall the headrest: To remove the headrest: Manual adjustment seat Manual adjustment seat 2C_InstallHeadrestManual Power adjustment seat 2C_RemoveHeadrestManual Power adjustment seat 2C_InstallHeadrestAuto 1. Recline the seat back by pressing 2C_RemoveHeadrestAuto seatback angle knob or switch (3). 1. Recline the seatback (2) with the seatback angle knob or switch (1).
  • Page 112 Seats & Safety system Removal/Reinstallation Rear seat headrests To remove the headrest: 2C_RearHeadrestOverview The rear seats are equipped with 2C_AdjustRearHeadrestUp headrests in all the seating positions for 1. Raise the headrest as far as it can go. the passenger’s safety and comfort. 2.

  • Page 113: Seats Warmers

    Seats warmers NOTICE if equipped To prevent damage to the seat warmers Seat warmers are provided to warm the and seats: seats during cold weather. • Never use a solvent such as paint During mild weather or under conditions thinner, benzene, alcohol or gasoline to where the operation of the seat warmer is clean the seats.

  • Page 114: Air Ventilation Seats

    • Do not change the seat covers. button is pressed to the ON position. • If the air vents do not operate, restart the vehicle. If there is no change, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 3-20...

  • Page 115: Seat Belts

    • Never modify seatbelt or install devices that may prevent seatbelt assembly from removing slack. • Do not use a seat belt if the webbing or hardware is damaged. We recommend that the seat belt be replaced by an authorized HYUNDAI dealer. 3-21...

  • Page 116: Seat Belt Warning Light

    Seats & Safety system Front passenger’s seat belt warning WARNING As a reminder to the front passenger, the Damaged seat belts and seat belt front passenger’s seat belt warning lights assemblies do not operate properly. illuminates for about 6 seconds each time Always replace: the Start/Stop button is turned on regardless of seatbelt fastening.
  • Page 117 For rear center seat Rear passenger’s seat belt warning • As a reminder to the rear passenger, the rear passenger’s seat belt warning lights illuminates for about 6 seconds each time the Start/Stop button is in the ON position regardless of seat belt fastening.

  • Page 118: Seat Belt Restraint System

    Seats & Safety system Seat belt restraint system NOTICE If you cannot smoothly pull the seat belt Lap/shoulder belt out from the retractor, firmly pull the seat belt out and release it. After release, the To fasten your seat belt: belt may be pulled out smoothly.
  • Page 119 Height adjustment To release your seat belt: Adjust the height of the shoulder belt so Press the release button (1) in the locking that it lies across your chest and midway buckle. over your shoulder nearest the door, not over your neck. To adjust the height of the seat belt anchor: •...
  • Page 120 • NEVER inspect, service, repair or replace the pretensioners by yourself. We recommend that the pretensioners be inspected, serviced, repaired, or replaced by an authorized HYUNDAI dealer. • Do not hit the seat belt assemblies. 2C_RetractPretensioner (1) Retractor pretensioner seat belt...
  • Page 121 SRS control module be inspected by an authorized HYUNDAI dealer as soon as possible. Information 2C_RearRetractorPretensionerOverview The pretensioner seat belt system •...

  • Page 122: Additional Seat Belt Safety Precautions

    Seats & Safety system Additional seat belt safety Seat belt use and children precautions Infant and small children Most countries have Child Restraint Seat belt use during pregnancy System laws that require children to The seat belt should always be used travel in approved Child Restraint System during pregnancy.
  • Page 123 Larger children One person per belt Children under age 13 and who are too When two people (children or adults) are large for a booster seat should always sitting together, never attempt to use a occupy the rear seat and use the available single seat belt.

  • Page 124: Care Of Seat Belts

    This should be done even if no damage is rear seat than in the front seat. Children visible. We recommend that you consult too large for a Child Restraint System an authorized HYUNDAI dealer for must use the seat belts provided. assistance. Most countries have child restraint regulations that require children to travel in approved Child Restraint Systems.

  • Page 125: Selecting A Child Restraint System (Crs)

    Child Restraint System types • After an accident, we recommend that your vehicle inspected by an authorized There are three main types of Child HYUNDAI dealer to check the Child Restraint Systems: rearward-facing, Restraint System, seat belts, ISOFIX forward-facing, and booster seat Child anchorages, and top tether Restraint Systems.
  • Page 126 Seats & Safety system Rearward-facing Child Restraint System Forward-facing Child Restraint System 2C_ALRSeatBelt 2C_ALRSeatBelt_2 With a rearward-facing Child Restraint A forward-facing Child Restraint System System, the collision forces are absorbed provides restraint for the child’s body by its shell instead of the child's body. The with a harness.

  • Page 127: Installing A Child Restraint System

    Installing a Child Restraint After selecting a proper Child Restraint System for your child and checking that System the Child Restraint System fits properly in a seating position, there are three general WARNING steps for a proper installation: Before installing your Child Restraint •...
  • Page 128 Seats & Safety system Suitability of each seating position for belted & ISOFIX Child Restraint Systems according to UN regulations (for Europe) (Information for vehicle users and CRS manufacturers) • Yes: Suitable for fitment of the designated category of CRS. •...
  • Page 129 Information • If the headrests prevent proper installation of a CRS, the headrests of the seating position shall be readjusted or entirely removed. • Never place a rearward facing Child Restraint System on the front passenger seat, unless the airbag is deactivated. Seat number Position in the vehicle Seating positions...
  • Page 130 Seats & Safety system ISOFIX anchorage and top tether ISOFIX anchorages have been provided in anchorage (ISOFIX anchorage the left and right outboard rear seating system) for children positions. Their locations are shown in the illustration. There are no ISOFIX The ISOFIX system connects a Child anchorages provided for the center rear Restraint System to the vehicle during...
  • Page 131 If necessary, we recommend tightens. that the vehicle be inspected by an • Never attach more than one Child authorized HYUNDAI dealer. Restraint System to a single anchorage. This may cause the anchorage or attachment to come loose or break.
  • Page 132 Seats & Safety system Securing a Child Restraint System To install the top tether anchor: seat with Top Tether Anchorage 1. Route the Child Restraint System top system tether strap over the seatback. Route the tether strap under the headrest and between the headrest posts, or route the top tether strap over the top of the vehicle seatback.
  • Page 133 Securing a Child Restraint System 3. Remove as much slack from the belt as with a lap/shoulder belt possible by pushing down on the Child Restraint System while feeding the When not using the ISOFIX system, all shoulder belt back into the retractor. Child Restraint Systems must be secured to a rear seat using the lap/shoulder belt.

  • Page 134: Airbag - Supplemental Restraint System

    Seats & Safety system Airbag - supplemental restraint system Left-hand drive 1C_AirbagOverview The actual airbags in the vehicle may differ from the illustration. (1) Driver’s front airbag (2) Passenger’s front airbag (3) Side airbag (4) Curtain airbag (5) Front center side airbag (6) Front passenger airbag ON/OFF switch 1C_AirbagOverview 3-40...
  • Page 135 Right-hand drive 1C_AirbagOverviewRHD The actual airbags in the vehicle may differ from the illustration. (1) Driver’s front airbag (2) Passenger’s front airbag (3) Side airbag (4) Curtain airbag (5) Front center side airbag (6) Front passenger airbag ON/OFF switch 1C_AirbagOverviewRHD 3-41...
  • Page 136 Seats & Safety system Your vehicle is equipped with a • Make sure that all occupants sit upright Supplemental Airbag System for the with the seatback in an upright driver’s and front passenger’s seats. position, centered on the seat cushion with their seat belt on, legs comfortably The front airbags are designed to extended, and their feet on the floor...

  • Page 137: Srs Components

    SRS Components 1C_AirbagPartsOverview The SRS consists of the following components: (1) Driver’s front airbag module (2) Passenger’s front airbag module (3) Side airbag modules (4) Curtain airbag modules (5) Front retractor pretensioner (6) Airbag warning light (7) SRS control module (SRSCM) / Rollover sensor (8) Front impact sensors (9) Side impact sensors (acceleration) (10)Side impact sensors (pressure)

  • Page 138: Where Are The Airbags

    Seats & Safety system Where are the airbags? WARNING To reduce the risk of serious injury or Driver’s and passenger’s front death from inflating front airbags: airbags • Seat belts must be worn at all times to Driver’s front airbag help keep occupants positioned properly.
  • Page 139 To reactivate the passenger’s front airbag: Passenger's front airbag ON/OFF switch (if equipped) The purpose of the switch is to disable the passenger’s front airbag to help reduce the risk of injury or death from an inflating airbag to certain front passenger seat occupants due to age, size, or medical condition.
  • Page 140 • If the seat or seat cover is damaged, we certain side impact collisions, depending recommend that your vehicle be on the crash severity. inspected by an authorized HYUNDAI dealer. 3-46...
  • Page 141 If necessary, we They are designed to help protect the recommend that the airbag be heads of the front seat occupants and the inspected by an authorized HYUNDAI rear outboard seat occupants in certain dealer. side impact collisions.

  • Page 142: How Does The Airbags System Operate

    Seats & Safety system How does the airbags system • The front airbags completely inflate and deflate in an instant. It is virtually operate? impossible for you to see the airbags The SRSCM (Supplemental Restraint inflate during an accident. It is much System Control Module) continually more likely that you simply see the monitors all SRS components while the...
  • Page 143 Driver’s front airbag (1) WARNING To reduce the risk of serious injury or death from an inflating airbag: • Never place a child restraint in the front passenger seat. Always properly restrain children under age 13 in the rear seats of the vehicle. •...

  • Page 144: What To Expect After An Airbag Inflates

    • We recommend that your vehicle steer or operate other controls. inspected by an authorized HYUNDAI dealer to inspect your vehicle and WARNING replace components as required before To prevent objects from becoming operating your vehicle again.

  • Page 145: Do Not Install A Child Restraint System On The Front Passenger's Seat

    Do not install a Child Restraint Noise and smoke from inflating airbag System on the front When the airbags inflate, they make a passenger's seat loud noise and may release powder inside the vehicle. After the airbag inflates, you may feel discomfort while breathing. This may be due to the impact of the airbag or the seat belt with your chest and it may also be due to breathing residual powder...

  • Page 146: Srs Warning Light

    ACC position and wait for 3 minutes before the vehicle is towed to prevent We recommend that your vehicle be unintended air bag deployment. inspected by an authorized HYUNDAI dealer inspect the SRS as soon as • We recommend that all air bag repairs possible.
  • Page 147 1C_AirbagSensorOverview (1) SRS control module/Rollover sensor (2) Front impact sensor (3) Side impact sensor (Pressure) (4) Side impact sensor (Acceleration) 1C_AirbagSensorOverview 3-53...
  • Page 148 Seats & Safety system Airbag inflation conditions Side and curtain airbags are designed to inflate when an impact is detected by side Front airbags collision sensors depending on the severity of impact resulting from a side impact collision. Although the driver’s and front passenger’s airbags are designed to inflate in frontal collisions and side and curtain airbags are designed to inflate in...
  • Page 149 Airbag non-inflation conditions 2C_AirbagNonOperatingConditionSidlingCrash 2C_AirbagNonOperatingConditionMinorCrash In an angled collision, the force of impact In certain low-speed collisions, the may direct the occupants in a direction airbags may not deploy. The airbags are where the airbags would not be able to designed not to deploy in such cases provide any additional benefit, and thus because they may not provide benefits...

  • Page 150: Srs Care

    Start/Stop button is in the ON position or continuously remains on, we recommend that the system be immediately inspected by an authorized HYUNDAI dealer. 2C_AirbagNonOperatingConditionTurnoverCrash We recommend any work on the SRS Front airbags may not inflate in rollover...

  • Page 151: Additional Safety Precautions

    Additional safety precautions Airbag warning labels Passengers should not move out of or change seats while the vehicle is moving. A passenger who is not wearing a seat belt during a collision or emergency stop can be thrown against the inside of the vehicle, against other occupants, or be ejected from the vehicle.

  • Page 153: Instrument Cluster

    4. Instrument Cluster Instrument cluster ......................4-2 Instrument cluster control...................4-3 Gauges and meters......................4-3 Reduction gear shift indicator ..................4-6 Warning and indicator lights..................4-7 Cluster display messages..................4-19 Cluster display ....................... 4-23 Cluster display control....................4-23 View modes........................ 4-23 Vehicle settings (infotainment system) ...............4-26 Setting your vehicle ....................4-26...

  • Page 154: Instrument Cluster

    Instrument Cluster Instrument cluster Type A 1C_ClusterOverview Type B 1C_ClusterOverview_2 The actual cluster in the vehicle may differ from the illustration. For more information, refer to the “Gauges and meters” section in this chapter. (1) Speedometer (2) Power/Charge gauge (3) Odometer (4) Distance to empty (5) Battery SOC (State of Charge) gauge (6) Warning and indicator lights...

  • Page 155: Instrument Cluster Control

    Instrument cluster control Gauges and meters Instrument panel illumination Speedometer Type A Infotainment system You can adjust the brightness of the instrument panel illumination in the infotainment system. Select Cluster/Head-up display > Brightness. Information The infotainment system may change after software updates. For more information, refer to the manual provided 2C_Speedmeter in the infotainment system and the quick...
  • Page 156 Instrument Cluster Power/charge gauge State of charge (SOC) gauge for high voltage battery Type A 2C_PowerChargeGauge 2C_BatteryLevelGauge Type B • The SOC gauge shows the charging status of the high voltage battery. • The low percentage number on the indicator indicates that there is not enough energy in the high voltage battery.
  • Page 157 Outside temperature gauge Odometer 2C_OutsideTemp 2C_Odometer The outside ambient temperature appears in The odometer indicates the total distance the lower portion of the cluster display. The that the vehicle has been driven and is temperature reads in Celsius or Fahrenheit used to determine when periodic depending on the units selected in the maintenance is required.

  • Page 158: Reduction Gear Shift Indicator

    Instrument Cluster Reduction gear shift indicator Distance to empty Type A 2C_ShiftPosition 2C_DistanceToEmpty The automatic transmission shift Type B indicator in the lower portion of the cluster display indicates the current gear or P (Park). Regenerative braking level indicator 2C_DistanceToEmpty_2 The distance to empty is the estimated distance the vehicle can be driven with the remaining electric energy.

  • Page 159: Warning And Indicator Lights

    When the vehicle is ready to be driven. HYUNDAI dealer. • ON: Normal driving is possible. • OFF: Normal driving is not possible, or a Power down indicator light problem has occurred.
  • Page 160 When the charging connector illuminated while driving, we is connected to the vehicle, the green recommend that your vehicle be light illuminates for about 1 minute. inspected by an authorized HYUNDAI dealer. High voltage battery level warning light ª...
  • Page 161 If this occurs, drive safely and we • Whenever the brake fluid level in the recommend that you have your vehicle reservoir is low. inspected by an authorized HYUNDAI - If the warning light illuminates with dealer. the parking brake released, it...
  • Page 162 Avoid high speed driving and abrupt braking. We recommend that your vehicle be inspected by an authorized HYUNDAI dealer as soon as possible. This warning light illuminates: • When the Start/Stop button is in the ON Information position.
  • Page 163 If the MDPS warning light remains equipped) illuminated while driving, we • Low washer fluid (if equipped) recommend that your vehicle be inspected by an authorized HYUNDAI • Tire Pressure Monitoring System (TPMS) malfunction dealer. If the issue is resolved, the Master Warning Light turns off.
  • Page 164 It illuminates for about 3 be inspected by an authorized seconds and then goes off. HYUNDAI dealer. • When one or more tires are significantly under-inflated. (The location of the This warning light blinks: under-inflated tire appears on the •...
  • Page 165 For more information, refer to the “Driver authorized HYUNDAI dealer as soon as Attention Warning (DAW)” section in possible. chapter 7. For more information, refer to the “Forward Collision-Avoidance Assist...
  • Page 166 This indicator light blinks: recommend that your vehicle be inspected by an authorized HYUNDAI • White: When the steering wheel assist dealer. is cancelled. For more information, refer to the “Lane This warning light blinks: Following Assist (LFA)”...
  • Page 167 For more information, refer to the unblocked when Lane Safety is set, we “Intelligent Speed Limit Assist (ISLA)” recommend that your vehicle be section in chapter 7. inspected by an authorized HYUNDAI dealer. This indicator light blinks: • Green: When Lane Keeping Assist is operating.
  • Page 168 LED headlight related part. indicator light If this occurs, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer as soon as possible. NOTICE Driving with the LED headlight warning light on or blinking may reduce LED This indicator light illuminates: headlight life.
  • Page 169 If any of these occur, we recommend that This indicator light blinks for a few your vehicle be inspected by an seconds: authorized HYUNDAI dealer. When the smart key is not in the vehicle, you cannot start the vehicle. 4-17...
  • Page 170 Instrument Cluster Rear fog indicator light Light ON indicator light This indicator light illuminates: This indicator light illuminates: When the rear fog lights are on. When the position lights or headlights are Low beam indicator light High Beam Assist indicator light if equipped This indicator light illuminates: This indicator light illuminates:...

  • Page 171: Cluster Display Messages

    Start/Stop button moves to the ON remains yellow while driving, we position. recommend that your vehicle be inspected by an authorized HYUNDAI 2. Shift the gear to P (Park). dealer. 3. Press the Start/Stop button again, then For more information, refer to the the vehicle turns off.
  • Page 172 Start/Stop button, we recommend that the vehicle be inspected If this message appears on the cluster and by an authorized HYUNDAI dealer. there are no other external electronic devices connected to the vehicle, we recommend that your vehicle be...
  • Page 173 Door, Hood, Tailgate open indicator Low tire pressure 2C_DoorOpenWarning 2C_TPMSHighLine This warning appears if any door or hood This warning message appears if the tire or tailgate is left open. The warning pressure is low. indicates which door is open on the For more information, refer to the “Low cluster display.
  • Page 174 Check headlight LED if equipped This message appears if there is a problem with the LED headlamp. We recommend that your vehicle be inspected by an authorized HYUNDAI dealer. Check Active Air Flap system This warning message appears in the 2C_RearWiperMode...

  • Page 175: Cluster Display

    Cluster display Cluster display control 2C_ClusterMenuSwitch Switch Function MODE button for changing view modes MOVE switch for changing items SELECT/RESET button for setting or resetting the selected item View modes View modes Explanation This mode displays Driver Assistance system such as Lane Keeping Driving Assist Assist, Smart Cruise Control, and Lane Following Assist etc.
  • Page 176 Instrument Cluster Driving Assist view Utility view In the Utility view, using the (UP, DOWN) switch, you may change through items in the following order. Current trip 2C_DrivingAssistMode LKA/SCC/LFA/HDA Displays the state of Lane Keeping Assist, Manual Speed Limit Assist, Smart Cruise Control, Lane Following Assist, and 2C_CurrentTripInfo Highway Driving Assist.
  • Page 177 After charging Tire pressure 2C_TPMSReset 2C_AfterChargingInfo The tire pressure screen appears to reset Trip distance, total driving time, average the TPMS system. energy consumption, and instant energy consumption after the vehicle has been For more information, refer to the "Tire recharged are displayed.

  • Page 178: Vehicle Settings (Infotainment System)

    Instrument Cluster Vehicle settings Setting your vehicle (infotainment system) Vehicle Settings in the infotainment system provides user options for a the settings including door lock/unlock features, convenience features, driver assistance settings, etc. Vehicle Settings menu • Driver assistance • Drive mode 2C_AVNOverview 1.

  • Page 179: Convenience Features

    5. Convenience Features Accessing your vehicle....................5-6 Smart key........................5-6 Immobilizer system..................... 5-11 Hyundai Digital Key ......................5-12 Digital key (smartphone) ....................5-12 Digital key (card key) ....................5-17 Used vehicle/Digital key maintenance..............5-20 Limitations of the system ..................5-20 Door locks ........................5-21 Operating door locks from outside the vehicle ............5-21 Operating door unlocks from inside the vehicle .............
  • Page 180 Windows ........................5-38 Power windows ......................5-39 Wide sunroof ........................5-42 Power sunshade ......................5-43 Tilt open/close ......................5-43 Slide open/close ......................5-44 Automatic reversal ....................5-44 Resetting the sunroof....................5-45 Sunroof open warning ....................5-46 Hood ..........................5-46 Opening the hood...................... 5-46 Closing the hood ......................5-47 Front trunk........................5-47 Opening the front trunk .....................5-47...
  • Page 181 5. Convenience Features Head-up display ......................5-58 Head-up display settings ..................5-58 Head-up display information ..................5-59 Precautions while using the Head-up display ............5-59 Vehicle system OTA update..................5-60 Downloading software ....................5-60 Approving software update ..................5-60 Preparing software update..................5-61 Updating software ..................... 5-61 Exterior lights .........................5-63 Lighting control......................5-63 High beam operation....................5-64...
  • Page 182 Wipers and washers.......................5-74 Front windshield wipers.....................5-74 Front windshield washers ..................5-75 Rear windshield wiper....................5-76 Rear windshield washers ...................5-76 Automatic climate control system................5-77 Automatic heating and air conditioning ..............5-78 Manual heating and air conditioning ................5-79 System operation ...................... 5-85 System maintenance ....................5-87 Windshield defrosting and defogging.................
  • Page 183 5. Convenience Features Interior features ......................5-96 Cup holder ........................5-96 Sunvisor ........................5-97 Power outlet ....................... 5-97 USB charger........................5-98 Wireless smartphone charging system ..............5-100 Vehicle to load (V2L)....................5-102 Clock ......................... 5-102 Coat hook ......................... 5-102 Floor mat anchor(s)....................5-103 Cargo net holder ......................

  • Page 184: Accessing Your Vehicle

    4. Make sure the doors are locked by pulling the outside door handle. Touch sensor type 2C_SmartKeyOverview_2 Your HYUNDAI uses a smart key that is used to lock or unlock the driver's and passenger's doors and the rear tailgate, and start the vehicle.
  • Page 185 WARNING Information • To fold the outside rearview mirror Do not leave the Smart Key in your vehicle simultaneously when the door is with children that are unattended or locked, press the Ų button, and unsupervised. then select Vehicle > Lights > Children could unintentionally press the Welcome mirror/light >...
  • Page 186 Convenience Features Touch sensor type Setting the door lock/unlock prevention feature The doors may lock or unlock if the touch sensor of the outer door handle is recognized while washing your car or due to heavy rain. To prevent unintentional door lock or unlock, press the lock button on the smart key and immediately press the unlock button along with the lock button for...
  • Page 187 A maximum of two smart keys can be registered to a single vehicle. If you happen to lose your smart key, it is recommended that you should immediately take the vehicle and remaining key to your authorized HYUNDAI dealer or tow the vehicle, if necessary.
  • Page 188 If you have a problem with the smart key, we recommend that you contact an authorized HYUNDAI dealer. If the smart key is in close proximity to your mobile phone, the signal could be blocked by your mobile phone’s normal operational signals.

  • Page 189: Immobilizer System

    If an improperly recommended that you contact an coded key (or other device) is used, the authorized HYUNDAI dealer. vehicle is disabled. WARNING When the Start/Stop button is in the ON position, the immobilizer system This product contains a button battery.

  • Page 190: Hyundai Digital Key

    2. After selecting Digital Key > Set Up Digital Key from the My Hyundai App in the smartphone, register the digital key according to the guidance in the smartphone screen.
  • Page 191 3. From the infotainment system, press Information the Ų button, and then select Vehicle > Digital key > Smartphone • The NFC Antenna position on Samsung key and press the Save button from the device can be found in the following infotainment system screen.
  • Page 192 Convenience Features Using the digital key (smartphone) Information The driver can lock or unlock the door by • The location of the NFC Antenna on the placing the smartphone on the outside smartphone may vary by phone model, door handle, and the vehicle can be so please contact the smartphone started by placing the smartphone on the manufacturer for details.
  • Page 193 Locking/Unlocking the doors Information • If the driver places the digital key If a shared digital key (smartphone) is (smartphone) NFC antenna to the used for the first time, the activating time driver’s or passenger’s door handle may take longer. authentication pad for more than 2 seconds, the door locks or unlocks.
  • Page 194 Convenience Features Deleting all registered digital key Information (smartphone) • If the registered digital key (smartphone) is deleted, the digital key saved in the smartphone is also deleted. • If the digital key is deleted from the smartphone, the digital key (smartphone) registered in the vehicle is also deleted.

  • Page 195: Digital Key (Card Key)

    Digital key (card key) Information if equipped • When there is a digital key (card key) already registered in the vehicle, a new How to register Digital key (card Key) digital key (card key) cannot be To use the card key as a digital key, follow registered.
  • Page 196 Convenience Features NOTICE Information You cannot lock your vehicle using the • The digital key (card key) may not work digital key (card key) if any of the under the following conditions: following occurs: - The digital key (card key) is not •...
  • Page 197 Deleting your digital key (card key) Linking/Unlinking profile How to link user profile 1. Press the Ų button, and then select User profile > Link digital key (smartphone) in the infotainment system. 2. Select "Link" to connect the registered smartphone’s digital key and the user’s profile.

  • Page 198: Used Vehicle/Digital Key Maintenance

    Convenience Features Used vehicle/Digital key Vehicle personalization operation maintenance • The personalization function linked with digital key works when the profile linked smartphone is placed on the Purchasing used vehicle outside door handle authentication pad When purchasing a used vehicle, make to lock or unlock the doors.

  • Page 199: Door Locks

    Door locks 3. Carefully pull out the cover (3) while continuing to press the release button to remove the cover and expose the key cylinder. Operating door locks from 4. Insert the mechanical key into the key outside the vehicle cylinder and rotate (4) clockwise to unlock the vehicle and Using the smart key...

  • Page 200: Operating Door Unlocks From Inside The Vehicle

    Convenience Features With the central door lock/unlock Information switch • In cold and wet climates, door lock and Driver’s door door mechanisms may not work properly due to freezing conditions. • If the door is locked/unlocked multiple times in rapid succession with either the vehicle key or door lock switch, the system may stop operating temporarily in order to protect the circuit and...
  • Page 201 In case of an emergency WARNING Do not leave the elderly, children, or animals unattended in your vehicle. An enclosed vehicle can become extremely hot and the elderly, unattended children or animals who cannot escape the vehicle may be seriously injured or killed. WARNING 2C_HowToLockDoorInEmergency Always park your vehicle properly.

  • Page 202: Auto Door Lock/Unlock Features

    Convenience Features Auto Door lock/unlock Automatically Unlock On vehicle off features When this feature is set in the infotainment system, all the doors are Your vehicle is equipped with features unlocked automatically when the vehicle that automatically locks or unlocks your is turned off.

  • Page 203: Child-Protector Rear Door Locks

    Theft-alarm system Child-protector rear door locks This system helps to protect your vehicle and valuables. The horn sounds and the hazard warning lights blinks continuously if any of the following occur: • A door is opened without using the smart key. •...

  • Page 204: Rear Occupant Alert (Roa)

    Convenience Features Rear Occupant Alert Information (ROA) • Do not lock the doors until all passengers have left the vehicle. If a Rear Occupant Alert is provided to help door is opened after the system is prevent the driver from leaving with any armed, the alarm is activated.

  • Page 205: Integrated Memory System (Ims)

    Memory System while the vehicle is moving to prevent serious injury or death. Information • If the battery is disconnected, the memory settings are erased. • If the Integrated Memory System does not operate normally, we recommend that you contact an authorized HYUNDAI dealer. 5-27...

  • Page 206: Storing Memory Positions

    Convenience Features Storing memory positions Resetting the Integrated Memory System 1. Make sure the Start/Stop button is in the ON position and the gear is in P 1. Make sure that the gear is in P (Park) (Park). and the vehicle is ON, and then open the driver’s door.

  • Page 207: Seat Easy Access Operation

    - Vehicle > Seats > Seat Easy Access > requires increased steering effort. We Driver seat easy access > recommend that you contact an Off/Normal/Extended authorized HYUNDAI dealer and have the system inspected as soon as possible. Information The infotainment system may change after software updates. For more...

  • Page 208: Tilt/Telescopic Steering

    2C_AdjustSteeringWheelManual location as soon as possible. We To adjust: recommend that your vehicle be inspected by an authorized HYUNDAI 1. Pull down the lock release lever (1). dealer as soon as possible. 2. Adjust the steering wheel to the desired angle (2) and distance forward/back (3).

  • Page 209: Steering Wheel Heater

    • Automatic temperature control Information The heated steering wheel starts to Sometimes the lock release lever may not automatically control the steering engage completely. Pull down on the lock wheel temperature after being release lever, readjust the steering wheel manually turned ON. again, and then pull back up on the lock - When HIGH is manually selected: release lever to lock the steering wheel in...

  • Page 210: Horn

    Convenience Features Horn Haptic warning/Steering wheel vibration warning If haptic steering wheel is available, the Driver Assistance system vibrates the steering wheel to warn the driver when the system indicates hazardous situations. Setting haptic warning (if equipped) With the vehicle on, press the Ų 2C_Horn button and then select: To sound the horn, press the area...

  • Page 211: Mirrors

    Mirrors Day/night rearview mirror if equipped Inside rearview mirror Before driving your vehicle, check to see that your inside rearview mirror is properly positioned. Adjust the rearview mirror so that the view through the rear window is properly centered. WARNING Make sure your line of sight is not obstructed.

  • Page 212: Outside Rearview Mirrors

    Convenience Features Outside rearview mirrors Electrochromic mirror if equipped 2C_SideViewMirror 2C_InsideRearViewMirrorECM Your vehicle is equipped with both left-hand and right-hand rearview [A] Sensor mirrors. The mirrors can be adjusted with When the vehicle is ON (¢ indicator is the mirror adjustment control switch. ON), the glare from vehicle headlights Adjust the rearview mirrors to your behind you is automatically controlled by...
  • Page 213 NOTICE NOTICE • Do not scrape ice off the mirror face. • The mirrors stop moving when they This may damage the surface of the reach the maximum adjusting angles, glass. but the motor continues to operate while the switch is pressed. Do not •...

  • Page 214: Reverse Parking Aid

    Convenience Features Reverse parking aid • Enable on driver approach If Vehicle > Lights > Welcome if equipped mirror/light > On driver approach is selected in the infotainment system, the mirror unfolds when the vehicle is approached with the smart key in possession.
  • Page 215 Resetting reverse parking aid user settings Reverse parking aid user settings mode mode You may change the angle of the outside To change the outside rearview mirror rearview mirror if it is difficult to see the angle back to the basic angle, shift the rear view with the basic downward mirror gear to R (Reverse), and adjust the mirror angle provided when reversing.

  • Page 216: Windows

    Convenience Features Windows Front / Rear 1C_WindowOpenClose (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window (7) Power window lock switch / Electronic child safety lock 5-38...

  • Page 217: Power Windows

    If the power windows do not operate detent position (5). Release the window properly after resetting, we recommend switch when you want the window to that you contact an authorized HYUNDAI stop. dealer. WARNING Make sure body parts or other objects are out of the way before closing the windows.
  • Page 218 Convenience Features Automatic reversal WARNING if equipped Make sure body parts or other objects are safely out of the way before closing the windows to avoid injuries or vehicle damage. Objects less than 4 mm (0.16 in.) in diameter caught between the window glass and the upper window channel may not be detected by the automatic reverse window and the window does not stop...
  • Page 219 Remote window opening/closing WARNING feature Do not allow children to play with the if equipped power windows. Keep the driver’s door power window lock button in the LOCK position. Serious injury or death may result from unintentional window operation by a child. NOTICE •...

  • Page 220: Wide Sunroof

    Convenience Features Wide sunroof Information if equipped • The remote window opening/closing feature operates only with the Safety If your vehicle is equipped with a sunroof, Power Windows equipped. you can slide or tilt your sunroof with the sunroof switch located on the overhead •...

  • Page 221: Power Sunshade

    Power sunshade Tilt open/close 2C_WideSunroofSunblindOpen 2C_WideSunroofTiltOpen Use the power sunshade to block direct • Push the sunroof switch up and sunroof sunlight coming through the sunroof glass tilts open. If the power sunshade glass. is closed, the sunshade opens first and then the sunroof tilts.

  • Page 222: Slide Open/Close

    Convenience Features Slide open/close Automatic reversal 2C_WideSunroofSlideOpen 2C_WideSunroofAutoReverse • Push the sunroof switch rearward to the If the power sunshade or sunroof glass senses any obstruction while closing, it first detent position. The sunroof glass opens. If the power sunshade is closed, reverses direction then stops.

  • Page 223: Resetting The Sunroof

    Resetting the sunroof NOTICE • Do not continue to push the sunroof switch after the sunroof is fully opened, closed, or tilted. Damage to the sunroof motor may occur or may cause the sunroof system to malfunction. • Using the sunroof for a long time may make noise caused by dust accumulated between the sunroof and vehicle body.

  • Page 224: Sunroof Open Warning

    Convenience Features Hood Information If the sunroof is not reset after the vehicle battery is disconnected or discharged, or Opening the hood the sunroof fuse is blown, the sunroof 1. Park the vehicle and apply the parking may not operate normally. brake.

  • Page 225: Closing The Hood

    Front trunk Closing the hood 1. Before closing the hood, check in and around the motor compartment to Opening the front trunk ensure the following: • Any tools or other loose objects have 1. Open the hood. been removed. 2. Pull up the release lever (1) and open •...

  • Page 226: Tailgate

    Convenience Features Tailgate WARNING if equipped • Never store cigarette lighters, propane cylinders, or other flammable/explosive materials in the Opening the tailgate vehicle. These items may catch fire and/or explode if the vehicle is exposed Opening from outside to hot temperatures for extended periods.

  • Page 227: Closing The Tailgate

    Closing the tailgate Emergency tailgate safety release Lower the tailgate lid and press down until it locks. Always check it is secure by pulling on the handle. WARNING 2C_EmergencyPowerTailgateOpen To unlock and open the tailgate manually from inside the cargo area, perform the following: 2C_GasLift 1.

  • Page 228: Power Tailgate

    Convenience Features Power tailgate NOTICE if equipped • Do not close or open the power tailgate manually. This may cause damage to the power tailgate. If it is necessary to Power tailgate operating close or open the power tailgate conditions manually when the battery is The power tailgate operates when the discharged or disconnected, do not...

  • Page 229: Operating The Power Tailgate

    • Do not modify or repair any part of the power tailgate by yourself. We recommend that you contact an Power tailgate open/close button authorized HYUNDAI dealer. (Smart key, instrument panel) • Do not operate the power tailgate Type A under the following conditions.
  • Page 230 Convenience Features Power tailgate open/close button While the tailgate is opening, press the button to stop power tailgate operation. (Inside the power tailgate) When the tailgate is opened, press and hold the power tailgate open/close button to close the tailgate. If you release the button while the tailgate is closing, power tailgate operation stops with a warning sound for 5 seconds.

  • Page 231: Setting The Power Tailgate

    User height setting Information 1. Position the tailgate manually to the The power tailgate may stop operating if height you prefer. the automatic reverse feature operates 2. Press the power tailgate open/close more than two times while attempting to button located inside the tailgate for open or close the tailgate.

  • Page 232: Resetting The Power Tailgate

    • Never allow anyone to occupy the recommend that your vehicle be tailgate of the vehicle at any time. The inspected by an authorized HYUNDAI cargo area is a very dangerous location dealer. in the event of a collision because it is part of the vehicle’s crush zone.

  • Page 233: Smart Tailgate

    Smart tailgate 1. Settings To use smart tailgate, it must be if equipped enabled from the in the infotainment system. Press the Ų button and then select: • Vehicle > Door > Smart Tailgate Information The infotainment system may change after software updates.

  • Page 234: Deactivating Smart Tailgate

    Convenience Features Deactivating smart tailgate Information If you press any button on the smart key • Smart tailgate may not operate during the Detect and Alert stage, the properly if: smart tailgate is deactivated. - The smart key is close to a radio Using the smart key: transmitter such as a radio station or •...

  • Page 235: Electric Charging Door

    Electric charging door Information • The charging door warmer Opening the electric charging automatically stops when it operates more than 20 minutes. If the Ī button door is deactivated, the charging door warmer is also deactivated. NOTICE Do not pry on the charging door or use unauthorized tools to open the charging door.

  • Page 236: Convenience Features

    Convenience Features Head-up display NOTICE if equipped • If the charging door does not open or close because ice has formed around it, tap lightly or push on the door to break the ice and release the door. • Make sure that the charging door is closed before driving the vehicle.

  • Page 237: Head-Up Display Information

    Precautions while using the Information Head-up display The infotainment system may change • It may sometimes be difficult to read after software updates. For more information on the Head-Up Display in information, refer to the manual provided the following situations. in the infotainment system and the quick - The driver is improperly positioned in reference guide.

  • Page 238: Vehicle System Ota Update

    Convenience Features Vehicle system OTA • Do not tint the front windshield glass or add other types of metallic coating. update Otherwise, the head-up display image may be invisible. if equipped • Do not place any accessories on the The OTA (Over-the-Air) software update dashboard or attach any objects on the feature allows you to wirelessly update windshield glass.

  • Page 239: Preparing Software Update

    Preparing software update Updating software If you press the Start button on the screen, the vehicle begins installing the update automatically. The following conditions must be satisfied: • The vehicle must be off. • The gear must be in P (Park). •...
  • Page 240 “OTA Software Update” page any vehicle software. on the HYUNDAI brand web or scan the • Do not open the hood or replace the QR code on the screen. battery in the vehicle during the update.

  • Page 241: Exterior Lights

    Exterior lights Even with the AUTO headlight feature in operation, it is recommended to manually turn ON the headlights when driving at night or in a fog, driving in the rain, or Lighting control when you enter dark areas, such as To operate the lights, turn the knob at the tunnels and parking facilities.

  • Page 242: High Beam Operation

    If an indicator stays on and does not flash turn on. or if it flashes abnormally, one of the turn signal bulbs may be burned out and may require replacement. We recommend that you contact an authorized HYUNDAI dealer. 5-64...

  • Page 243: Rear Fog Light

    Battery saver function One touch turn signal To use One touch turn signal, push the To prevent the battery from being turn signal lever up or down to position discharging, the system automatically (B) and then release it. turns off the position light when the driver turns the vehicle off and opens the The lane change signals blink 3, 5, or 7 driver's door.

  • Page 244: Headlight Delay Function

    If the function does not work properly, we on when the vehicle is turned on. recommend that the system be inspected by an authorized HYUNDAI dealer. Do not • The interior button lights turn on for a attempt to inspect or replace the wiring while when the vehicle is turned off.

  • Page 245: Welcome System

    Welcome system Headlight and position light When the headlight switch is in the headlight or AUTO position and all the doors (and tailgate) are closed and locked, the position lights and headlights come on for about 15 seconds when the door unlock button is pressed on the smart key.

  • Page 246: High Beam Assist (Hba)

    Convenience Features High beam assist (HBA) NOTICE if equipped • Always keep the front view camera in good condition to maintain optimal performance of High Beam Assist. • For more information on the limitations of the front view camera, refer to the “Forward Collision-Avoidance Assist (FCA)”...

  • Page 247: High Beam Assist Operation

    When High Beam Assist is not working properly, the "Check driver assistance system" warning message may appear, and the X warning light may illuminate on the instrument cluster. We recommend that the system be inspected by an authorized HYUNDAI dealer. 5-69...
  • Page 248 Convenience Features Limitations of High Beam Assist Information High Beam Assist may not work properly For more information on the limitations of in the following situations if: the front view camera, refer to the • The headlights from an oncoming or “Forward Collision-Avoidance Assist front vehicle is damaged or out of the (FCA)”...

  • Page 249: Interior Lights

    Interior lights Front lights WARNING Do not use the interior lights when driving in the dark. The interior lights may obscure your view and result in a collision. Do not use the interior lights for extended periods when the vehicle is turned off. Otherwise, the battery discharges.

  • Page 250: Room Lamps

    Convenience Features Room lamps Vanity mirror lamp Type A 2C_SunvisorLamp 2C_RoomLamp Push the switch to turn the lamp on or off. Type B • ĉ: The lamp turns on if this button is pressed. • ċ: The lamp turns off if this button is pressed.

  • Page 251: Ambient Light

    Ambient light Cargo area lamp if equipped 2C_LuggageRoomLamp The cargo area lamp turns on when the 2C_MoodLamp tailgate is opened and off when the [A] Driver seat door, passenger seat door [B] Passenger seat open tray tailgate is closed. To set the brightness and color of the NOTICE ambient light, press the Ų...

  • Page 252: Wipers And Washers

    Convenience Features Wipers and washers Front windshield wipers Operates as follows when the vehicle is Front windshield wiper/washer turned on. • 2: The wiper runs at a higher speed. • 1: The wiper runs at a lower speed. • ---: Wiper operates intermittently at the same wiping intervals.

  • Page 253: Front Windshield Washers

    Front windshield washers AUTO (Automatic) control if equipped 2C_WasherSwitch In the O (off) position, pull the lever gently 2C_RainSensor toward you to spray washer fluid on the The rain sensor located on the upper end windshield and to run the wipers 1-3 of the windshield glass senses the cycles.

  • Page 254: Rear Windshield Wiper

    Convenience Features Auto rear wiper WARNING The rear wiper operates while the vehicle When the outside temperature is below is in reverse with the front wiper on. freezing, always warm the windshield You can select the function by pressing using the defroster to help prevent the the Ų...

  • Page 255: Automatic Climate Control System

    Automatic climate control system 1C_AutoAircon The climate control system buttons may differ depending on vehicle specification. (1) AUTO (automatic control) (2) OFF (3) Climate control information screen (4) A/C (air conditioning) (5) SYNC (6) DRIVER ONLY (7) Air intake control (8) Driver’s temperature control (9) Fan speed control (10)Mode selection...

  • Page 256: Automatic Heating And Air Conditioning

    Convenience Features Automatic heating and air 2. Push up or down the temperature control switch to set the desired conditioning temperature. If the temperature is set The Automatic Climate Control System is to the lowest setting, the air controlled by setting the desired conditioning system operates temperature.

  • Page 257: Manual Heating And Air Conditioning

    Mode selection NOTICE 2C_AirconModeSelection 2C_SolarRadiationSensor The mode selection switch controls the Never place anything near the sensor to direction of the air flow through the ensure better control of the heating and ventilation system. cooling system. Manual heating and air conditioning 1.
  • Page 258 Convenience Features Air flow direction Left-hand drive 1C_AutoAirconModeSelectionOverview 5-80...
  • Page 259 Right-hand drive 1C_AutoAirconModeSelectionOverview_RHD Symbol Operation Direction Air flow is directed toward the upper body and face. Additionally, each outlet can be controlled to direct the air B, D, F discharged from the outlet. Air flow is directed toward the face and the floor. B, C, D, E, F Most of the air flow is directed to the floor, with a small amount of the air being directed to the windshield and side...
  • Page 260 Convenience Features Front windshield defroster [A], [D] Instrument panel vents Front 2C_AirconFrontDefrostButton 2C_FrontVent Press the front windshield defroster Rear button (indicator light ON) to turn on the front windshield defroster. If the windshield defogging is set, outside (fresh) mode is automatically selected and the air conditioning turns on according to the detected ambient temperature.
  • Page 261 Temperature control Information Some of the airflow may be directed to other seating position to keep indoor air pleasant while using DRIVER ONLY . When using the front windshield defroster, the air flow on the both sides of windshield continues to operate regardless of the activation of DRIVER ONLY .
  • Page 262 Convenience Features Air intake control WARNING Recirculated air position To prevent serious injury or death: • Continued climate control system operation in the recirculated air position may allow humidity to increase inside the vehicle that could fog the windshield and the side windows and WL_RecirculationModeLamp With the recirculated air selected, air obscure visibility.

  • Page 263: System Operation

    System operation Air conditioning Cooling / Ventilation 1. Set the mode to the ĭ position. 2. Set the air intake control to the outside (fresh) air position. 3. Set the temperature control to the desired position. 4. Set the fan speed control to the desired speed.
  • Page 264 Air conditioning • If you operate air conditioner Your HYUNDAI vehicle air conditioning excessively, the difference between the system is filled with R-134a or R-1234yf temperature of the outside air and that refrigerant.

  • Page 265: System Maintenance

    It filters the dust or other pollutants that enter the vehicle through the heating and air conditioning system. We recommend that the cabin air filter be replaced by an authorized HYUNDAI dealer according to the maintenance WL_RefrigerantWarning schedule. If the vehicle is being driven in...

  • Page 266: Windshield Defrosting And Defogging

    Convenience Features Air conditioning refrigerant label (4) Caution (if equipped) (5) Flammable refrigerant (6) To require registered technician to service air conditioning system (7) Service manual Windshield defrosting and defogging WARNING 2C_RefrigerantTypeLabel Do not use the defrost level Ç position You can find out which air conditioning during cooling operation in extremely refrigerant is applied to your vehicle on...

  • Page 267: Automatic Climate Control System

    Automatic climate control To defrost outside windshield system To defog inside windshield 2C_InsideDefrostProcedure_2 (1) Set the fan speed to the highest position. (2) Set the temperature to the hottest 2C_InsideDefrostProcedure position. (1) Select any fan speed. Set the fan (3) Press the defroster button (Ç). speed to the highest position for quick defogging.

  • Page 268: Windshield Defrosting (Heater)

    Convenience Features Windshield defrosting Information (Heater) • If there is heavy accumulation of snow on the rear window, brush it off before operating the rear defroster. Rear window defroster • The rear window defroster automatically turns off after about 20 NOTICE minutes or when the Start/Stop button is in the OFF position.

  • Page 269: Climate Control Additional Features

    Climate control Operating conditions The Air conditioner auto-drying feature additional features operates under the following conditions: • The vehicle is turned off after operating Information the air conditioner for a certain period. The infotainment system may change • The battery level is sufficient and the after software updates.

  • Page 270: Auto Defogging System

    Convenience Features Auto defogging system Turning the Auto defogging system on or off Climate control system Press the front windshield defroster button for 3 seconds when the Start/Stop button is in the ON position. When the Auto defogging system is turned off, the Ž...

  • Page 271: Auto Dehumidify

    Auto dehumidify Turning Activation on a washer fluid use on or off if equipped To increase cabin air quality and reduce Climate control system windshield misting, recirculated air To turn the Activate on washer fluid use position turns off automatically after feature on or off, select Floor level ( about 5 to 30 minutes, depending on the mode, and then press the air intake...

  • Page 272: Link To Climate Settings For Auto-Adjustment

    Convenience Features Link to climate settings for Operating conditions auto-adjustment (if equipped) • The climate control system’s fresh mode is selected. The temperature of the driver's seat • The window(s) are open. The windows warmer, air ventilated seat and heated close automatically only when your steering wheel is automatically controlled vehicle is applied with the automatic...

  • Page 273: Center Console Storage

    Center console storage Glove box 2C_CenterConsoleBox 2C_GloveBox To open: To open: Press the button. Pull the lever (1). WARNING Removable partition ALWAYS close the glove box door after use. An open glove box door may cause serious injury to a passenger in a collision, even if the passenger is wearing a seat belt.

  • Page 274: Convenience Features

    Convenience Features Interior features WARNING • Avoid abrupt starting and braking when Cup holder the cup holder is used to prevent spilling your drink. If hot liquid spills, Cups or small beverages cups can be you may be burned. Such a burn to the placed in the cup holders.

  • Page 275: Sunvisor

    Sunvisor Power outlet Center console storage (inside) 2C_Sunvisor 2C_PowerOutlet To use the sunvisor, pull it downward. The power outlet is designed to provide To use the sunvisor to block the sun from power for mobile phones or other devices the side window, pull it rearward, release designed to operate with vehicle it from the bracket (1) and swing it to the electrical systems.

  • Page 276: Usb Charger

    Convenience Features USB charger NOTICE The USB charger is designed to recharge To prevent damage to the power outlets: batteries of small size electronic devices • Use the power outlet only when the using a USB cable. vehicle is running and remove the Front accessory plug after use.
  • Page 277 Using an unspecified cable may damage the vehicle’s USB charger or the connected devices. Contact an authorized HYUNDAI dealer for more information on accessories for HYUNDAI vehicles. • The use of non-genuine parts may damage the USB port and infotainment system.

  • Page 278: Wireless Smartphone Charging System

    Convenience Features Wireless smartphone Information charging system • Remove other items, including the if equipped smart key from the wireless charging pad. • For flip type smartphones, when using wireless charging, place the smartphone folded with the device’s back placed on the center of the wireless charging unit.
  • Page 279 • When charging some smartphones NOTICE with a self-protection feature, the wireless charging speed may decrease • The wireless smartphone charging and the wireless charging may stop. system may not support certain smartphones, that do not meet the Qi • If the smartphone has a thick case, it specification (þ).

  • Page 280: Vehicle To Load (V2L)

    Convenience Features Vehicle to load (V2L) Coat hook Rear if equipped 2C_CoatHook 2C_V2LInside This hook is not designed to hold large or V2L(Vehicle to Load) is installed at the heavy items. central rear seat. V2L is a convenient feature which provides enough electricity WARNING to use diverse household electrical appliances in the vehicle.

  • Page 281: Floor Mat Anchor(S)

    HYUNDAI recommends that Do not use the cargo net when the strap the HYUNDAI floor mat designed for use has visible signs of wear or damage. in your vehicle be installed.

  • Page 282: Cargo Area Cover

    Convenience Features Cargo area cover Increasing cargo area volume To increase cargo area volume: 1. Open the tailgate and remove the cover according to "Removing cargo area cover". 2. Push the cargo area cover in to reach the lower fixing part [A]. •...

  • Page 283: Cargo Tray

    Cargo tray Increasing cargo area volume To increase the cargo area volume: 1. Lift the top board with its handle and remove the board. 2C_CargoCompartment Use the cargo tray to organize and store small items such as tools. To use the tray, lift the top board with its handle.

  • Page 284: Exterior Features

    Convenience Features Exterior features WARNING • Loading cargo or luggage in excess of Roof side rails the specified weight limit on the roof side rails may damage your vehicle. if equipped 100 kg (220 lbs.) ROOF SIDE RAILS EVENLY DISTRIBUTED •...

  • Page 285: Infotainment System

    Connecting an unspecified cable may damage the vehicle’s USB port or the connected devices. We recommend that you contact an authorized HYUNDAI dealer for more information on accessories for 2C_USBPort HYUNDAI vehicles. Press the USB port selection button while •...

  • Page 286: Antenna

    Convenience Features Antenna SEEK/PRESET ( If the SEEK/PRESET switch is pushed up or down and held for 0.8 seconds or more, it functions in the following modes: • RADIO mode It functions as the AUTO SEEK select button. It seeks until you release the button.

  • Page 287: Infotainment System

    Infotainment system Bluetooth® wireless technology 2C_AVNOverview For more information, refer to the 2C_SteeringWheelCallButton separately supplied infotainment system manual. Voice recognition 2C_Microphone (1) Call/Answer/Call end button (2) Microphone For more information, refer to the 2C_SteeringWheelVoiceRecognitionButton separately supplied infotainment system manual. For more information, refer to the separately supplied infotainment system CAUTION manual.

  • Page 289: Driving Your Vehicle

    6. Driving your vehicle Before driving ........................6-4 Before entering the vehicle..................6-4 Before starting ......................6-4 Start/Stop button ......................6-5 Start/Stop button positions..................6-6 Starting the vehicle...................... 6-7 Turning off the vehicle....................6-8 Remote start.........................6-9 Reduction gear ........................6-9 Reduction gear operation ...................6-9 Cluster display messages..................6-13 Good driving practices ....................
  • Page 290 Braking system......................6-26 Power-assist brakes ....................6-26 Disc brakes wear indicator ..................6-27 Electronic Parking Brake (EPB)..................6-27 Auto Hold ........................6-31 Brake Disc Cleaning ....................6-33 Anti-Lock Brake System (ABS) ................. 6-33 Electronic Stability Control (ESC)................6-35 Vehicle Stability Management (VSM) ...............6-37 Hill-Start Assist Control (HAC)..................
  • Page 291 6. Driving your vehicle Reducing the risk of rollover..................6-48 Winter driving ....................... 6-48 Snow or icy conditions ..................... 6-48 Winter precautions ....................6-50 Trailer towing ......................... 6-51 If you decide to pull a trailer ..................6-53 Trailer equipment and accessories................6-55 Driving with a trailer....................6-56 Maintenance when towing a trailer................6-58 Vehicle weight .......................6-59 Overloading .......................

  • Page 292: Before Driving

    Driving your vehicle Before driving WARNING To reduce the risk of SERIOUS INJURY or Before entering the vehicle DEATH, take the following precautions: • ALWAYS wear your seat belt. All • Be sure all windows, outside rearview passengers must be properly belted mirror(s), and outside lights are clean whenever the vehicle is moving.

  • Page 293: Start/Stop Button

    Start/Stop button WARNING • NEVER press the Start/Stop button while the vehicle is in motion except in an emergency. This results in the vehicle turning off and loss of power assist for the steering and brake systems. This may lead to loss of directional control and braking function, which could cause an accident.

  • Page 294: Start/Stop Button Positions

    Driving your vehicle Start/Stop button positions Button Action Notes Position To turn off the vehicle, press the Start/Stop button with the vehicle is in P (Park). If the Start/Stop button is pressed with the vehicle is in D (Drive), R (Reverse) or N (Neutral), the gear automatically shifts to P (Park).

  • Page 295: Starting The Vehicle

    Starting the vehicle Starting the vehicle 1. Always carry the smart key with you. WARNING 2. Make sure the parking brake is applied. • Always wear appropriate shoes when 3. Make sure the gear is in P (Park). operating your vehicle. Unsuitable 4.

  • Page 296: Turning Off The Vehicle

    Driving your vehicle Emergency starting NOTICE To prevent damage to the vehicle: Do not press the Start/Stop button for more than 10 seconds except when the stop light fuse is blown. When the stop light fuse is blown, you cannot normally start the vehicle. Replace the fuse with a new one.

  • Page 297: Remote Start

    Reduction gear Remote start 2C_SmartKeyRemoteStartButton 2C_ShiftButtonOverview You can start the vehicle using the [A] Rotary gear shift dial Remote Start button of the smart key. [B] P button To start the vehicle remotely: 1. Press the door lock button within 10m Reduction gear operation (32 ft.) from the vehicle.
  • Page 298 Driving your vehicle R (Reverse) Rotary shifter/ Rotary gear shift dial Use this position to drive the vehicle P (Park) rearward. Always come to a complete stop before shifting into P (Park). 2C_ShiftButtonRPosition Use this position to drive the vehicle 2C_PressPButton backward.
  • Page 299 N (Neutral) D (Drive) 2C_ShiftButtonNPosition 2C_ShiftButtonDPosition To shift the gear to N (Neutral), rotate the To shift the gear to D (Drive), rotate the rotary gear shift dial to N (Neutral) while rotary gear shift dial to D (Drive) while depressing the brake pedal.
  • Page 300 Driving your vehicle To stay in N (Neutral) when vehicle is 3. When you take your foot off the brake pedal, the message "Press and hold the OK button on the steering wheel to stay in Neutral" appears on the cluster display.

  • Page 301: Cluster Display Messages

    "Jump starting (12 V battery)" section in gear in R (Reverse), D (Drive) or N chapter 8 or we recommend that you (Neutral). contact an authorized HYUNDAI dealer. • When the driver’s door is open with the vehicle running, the gear in R (Reverse), Parking...
  • Page 302 This message is displayed when the shift We recommend that your vehicle be gear does not properly operate in the P inspected by an authorized HYUNDAI (Park) position. dealer. We recommend that your vehicle be...

  • Page 303: Good Driving Practices

    P (Park) to keep roadway, do not steer sharply. Instead, the vehicle from moving. slow down before pulling back into the travel lanes. • HYUNDAI Vehicle recommends you to follow all posted speed limits. 6-15...

  • Page 304: Regenerative Braking System

    Driving your vehicle Regenerative braking • Pull and hold the left paddle shifter (°) for over 0.5 seconds to keep system raising the regenerative braking intensity level. Keep holding the paddle Regenerative braking system operates shifter stops the vehicle. (For more the paddle shifter to control the information, refer to the "One Pedal regenerative braking intensity of the...

  • Page 305: Regenerative Braking System Limitations

    Regenerative braking system One Pedal Driving limitations One pedal driving operates the paddle shifter while coasting to control the Regenerative braking intensity cannot be intensity of regenerative braking. It changed using the paddle shifter in the assists the driver to stop the vehicle following situations: without depressing the brake pedal.

  • Page 306: Using I-Pedal

    Driving your vehicle Using i-PEDAL One pedal driving limitations In the following conditions, the vehicle i-PEDAL assists the driver to accelerate, may not come to a stop although the one decelerate, and stop the vehicle with only pedal driving function is active. Depress the accelerator pedal.

  • Page 307: Smart Regeneration System

    Smart regeneration i-PEDAL limitations In the following conditions, the vehicle system may not come to a stop although the i-PEDAL is properly activated. Depress The smart regeneration system the brake to stop the vehicle. recognizes vehicle-to-vehicle distance, • When driving on a slope, or when the road gradient, and speed cameras and vehicle is repeatedly driven and controls the regenerative braking level...

  • Page 308: Smart Regeneration System On/Off

    Driving your vehicle Smart regeneration system Smart regeneration system on/off operating condition Operate the paddle shifter as shown When the regenerative braking level is below to use the smart regeneration displayed as 'AUTO' and the vehicle speed system. is above 10 km/h (6 mph), the system automatically controls the regenerative •...

  • Page 309: Smart Regeneration Level Settings

    Smart regeneration level Smart regeneration intensity setting settings Regenerative braking intensity of the smart regeneration system can be adjusted to match the driver’s preference. Adjust the braking intensity to make the decelerating faster or slower. 2C_SmartRegenerationBrakeIconInfo The instrument cluster displays ‘AUTO’ (1) when the smart regeneration system is ON.

  • Page 310: Front Sensors (Front Radar)

    (²) for over a second. If the smart regeneration system does not operate normally after the front radar has been uncovered or unblocked, we recommend that you visit an authorized HYUNDAI dealer for inspection. 6-22...

  • Page 311: Smart Regeneration System Precautions

    The impacts, we recommend that you visit smart regeneration system cannot an authorized HYUNDAI dealer for react to pedestrians, vehicles making a inspection. sudden stop, and vehicles coming from • The sensors and its surroundings, the the opposite lane.
  • Page 312 Driving your vehicle Precautions for vehicle recognition Precautions on the curves • The front sensors may suddenly recognize the foregoing vehicle when the smart regeneration system reacts slowly, or the vehicle is going through the end of a slope or curve. In this case, the regenerative braking intensity is increased and the vehicle may slow down.
  • Page 313 Precautions on the slope Precautions for shifting lanes 2C_SmartRegenerationSystemDrivingOnIncline • When the vehicle is coasting through the end of a slope or where the gradient is changing, the front sensors may be unable to recognize, or may suddenly recognize the vehicle ahead. It may adjust the regenerative braking intensity and change the vehicle speed.

  • Page 314: Braking System

    Driving your vehicle Braking system WARNING Take the following precautions: Power-assist brakes • Do not drive with your foot resting on the brake pedal. This may create Your vehicle has power-assisted brakes abnormal high brake temperatures, that adjust automatically through normal excessive brake lining and pad wear, usage.

  • Page 315: Disc Brakes Wear Indicator

    Electronic Parking Brake (EPB) NOTICE • Do not continue depressing the brake Applying the parking brake pedal if the vehicle is off (¢ indicator OFF). The battery may be discharged. To apply EPB (Electronic Parking Brake): • Noise and vibration generated during braking is normal.
  • Page 316 EPB is used for emergency N (Neutral) to D (Drive). Make sure the braking, we recommend that your vehicle doors, hood, and tailgate are closed be inspected by an authorized HYUNDAI and the seat belt is fastened. dealer. 6-28...
  • Page 317 Start/Stop button to the OFF vehicle be inspected by an authorized position. Take the key with you when HYUNDAI dealer. leaving the vehicle. • Do not drive your vehicle with EPB • Never allow anyone who is unfamiliar applied.
  • Page 318 EPB warning light is on, press the switch, and then pull it up. Repeat this one more time. If the EPB warning does not go off, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 6-30...

  • Page 319: Auto Hold

    Auto Hold To release: If you depress the accelerator pedal with Auto Hold maintains the vehicle in a the gear in D (Drive) or R (Reverse), the standstill even though the brake pedal is Auto Hold is released automatically and not depressed after the driver brings the the vehicle starts to move.
  • Page 320 Press the AUTO HOLD switch while malfunctions, Auto Hold does not work depressing the brake pedal. properly. We recommend that you contact an authorized HYUNDAI dealer. 6-32...

  • Page 321: Brake Disc Cleaning

    Brake Disc Cleaning Anti-Lock Brake System (ABS) Use the Brake Disc Cleaning function if WARNING noise is generated when depressing the brake while driving or if the brake disc Anti-Lock Braking System (ABS) or gets rusty. It helps reduce the noise and Electronic Stability Control (ESC) system rust.
  • Page 322 To reduce the risk of serious injury or Depress your brake pedal as hard as death it is recommended to contact your possible. authorized HYUNDAI dealer as soon as When you apply your brakes under possible. conditions that may lock the wheels, you...

  • Page 323: Electronic Stability Control (Esc)

    Electronic Stability Control ESC operation (ESC) ESC ON condition When the Start/Stop button is in the ON position, the ESC and the ESC OFF indicator lights illuminate for about 3 seconds. After both lights go off, ESC is enabled. When operating 2C_ESCOffButton The Electronic Stability Control (ESC) system helps stabilize the vehicle during...
  • Page 324 If the ESC indicator light stays on, we disabled" illuminates and a warning recommend that your vehicle be chime sounds. Both the traction control inspected by an authorized HYUNDAI function of ESC (electric vehicle control dealer as soon as possible. management) and the brake control...

  • Page 325: Vehicle Stability Management (Vsm)

    Vehicle Stability Management NOTICE (VSM) Driving with wheels and tires with Vehicle Stability Management is a different sizes may cause the ESC system function of the Electronic Stability to malfunction. Before replacing tires, Control (ESC) system. It helps the vehicle make sure all four tires and wheels are the stay stable when accelerating or braking appropriate size for your vehicle.

  • Page 326: Hill-Start Assist Control (Hac)

    Hill-Start Assist vehicle be inspected by an authorized Control activates only for about 2 HYUNDAI dealer as soon as possible. seconds. • Hill-Start Assist Control does not operate when the gear is shifted to P NOTICE (Park) or N (Neutral).

  • Page 327: Emergency Stop Signal (Ess)

    Emergency Stop Signal (ESS) Multi-Collision Brake (MCB) Emergency Stop Signal alerts the driver Multi-Collision Brake controls the brake behind by blinking the stop lights, while automatically in the event of an accident sharply and severely braking. where the airbag deploys to reduce the risk of additional accidents that may occur.

  • Page 328: Brake Assistant System (Bas)

    Driving your vehicle Brake Assistant System (BAS) MCB off Multi-Collision Brake is canceled in the The Brake Assistant System provides following situations: additional pressure when the brake pedal is momentarily and strongly depressed in • The accelerator pedal is depressed over a situation sudden braking is required a certain level.

  • Page 329: Good Braking Practices

    We recommend that your cluster, the drive mode is in NORMAL vehicle be inspected by an authorized mode and may not change to SPORT HYUNDAI dealer. mode. DO NOT drive with your foot resting on the brake pedal. Even light, but constant...
  • Page 330 Driving your vehicle SPORT mode Drive mode features SPORT mode provides sporty but firm NORMAL mode riding. NORMAL mode provides smooth driving In SPORT mode, the energy efficiency and comfortable riding. may decrease. NORMAL mode is selected, it does not •...

  • Page 331: Drive Mode Characteristic

    Drive mode characteristic The characteristic of each components varies depending on which drive mode is selected. Drive mode SNOW NORMAL SPORT Snow High electric optimizing Normal driving Sporty driving Characteristics energy available mode mode efficiency mode traction mode Switch activation Turn right or left Indicator on the instrument...

  • Page 332: Active Air Flap

    10 minutes. If the pop-up remains up we recommend that you contact an authorized HYUNDAI dealer. CAUTION • Regardless of the pop-up, if the air flaps aren't in the same position, stop the vehicle and wait for 10 minutes and start the vehicle and inspect the air flap.

  • Page 333: Active Sound Design

    Active sound design Special driving conditions if equipped • Active sound design provides various Hazardous driving conditions virtual driving sounds based on the When hazardous driving elements are driving mode, vehicle speed, and encountered such as water, snow, ice, accelerator pedal. You can adjust the mud and sand, take the following volume and change the settings for precautions:...

  • Page 334: Rocking The Vehicle

    Driving your vehicle Rocking the vehicle Smooth cornering If it is necessary to rock the vehicle to free Avoid braking or gear changing in it from snow, sand, or mud, first turn the corners, especially when roads are wet. steering wheel right and left to clear the Ideally, corners should always be taken area around your front wheels.

  • Page 335: Driving In The Rain

    Driving in the rain Driving in flooded areas Rain and wet roads can make driving Avoid driving through flooded areas dangerous. Here are a few things to unless you are sure the water is no higher consider when driving in the rain or on than the bottom of the wheel hub.

  • Page 336: Driving Your Vehicle

    Driving your vehicle Reducing the risk of WARNING rollover Fasten your seat belt properly. In a rollover crash, an unbelted person is Your multi-purpose passenger vehicle is significantly more likely to be seriously defined as a Sports Utility Vehicle (SUV). injured or killed than a person wearing a Some SUVs have higher ground clearance seat belt.
  • Page 337 When mounting snow chains, park the chains. If tire chains must be used, use vehicle on level ground away from traffic. genuine HYUNDAI Parts and install the Turn on the vehicle's Hazard Warning tire chains after reviewing the Flasher and place a triangular emergency instructions provided with the tire chains.

  • Page 338: Winter Precautions

    Chapter 9. The and wheels. battery charging level can be checked by • Use SAE “S” class or wire chains. an authorized HYUNDAI dealer or in a service station. • If you hear noise caused by chains contacting the body, retighten the...

  • Page 339: Trailer Towing

    Trailer towing Do not let ice and snow accumulate underneath Towing a trailer requires experience. The Under some conditions, snow and ice combination of the vehicle and trailer may build up under the fenders and itself is not as responsive as the vehicle by interfere with the steering.
  • Page 340 N1. The tow hitch harness installed to your • When a vehicle of category M1 is towing vehicle must be a genuine HYUNDAI a trailer, the additional load imposed at parts. For more information, consult an the trailer coupling device may cause authorized HYUNDAI dealer products.

  • Page 341: If You Decide To Pull A Trailer

    Refer to the table on control. the following page for the maximum • Hyundai recommends that you contact allowable trailer weight. an authorized HYUNDAI dealer for further information on additional WARNING requirements such as towing kit etc.
  • Page 342 Driving your vehicle How to weigh the trailer loads at a public Tongue load scale Fully load the vehicle and trailer before going to the public scale. You and passengers should remain in the vehicle when performing the measurement. 1. Measure the front gross axle weight. 2.

  • Page 343: Trailer Equipment And Accessories

    Make sure that all equipment is properly coupling device. installed and maintained, and that it • A HYUNDAI trailer hitch accessory is meets your country’s regulations. available at an authorized HYUNDAI Hyundai recommends that you have all dealer.

  • Page 344: Driving With A Trailer

    Driving your vehicle Driving with a trailer Safety chains Always attach chains between your Towing a trailer requires a certain amount vehicle and your trailer. of experience. Before driving, acquaint yourself with the feel of handling and Instructions about safety chains may be braking with the added weight of the provided by the hitch manufacturer or trailer.
  • Page 345 We recommend that you trailers, the steepness of the grade, and contact an authorized HYUNDAI dealer your trailer weight. for assistance. 6-57...

  • Page 346: Maintenance When Towing A Trailer

    Driving your vehicle Parking on hills Driving the vehicle after it has been parked on a hill Generally, if you have a trailer attached to your vehicle, you should not park your 1. With the gear in P (Park) or N (Neutral), vehicle on a hill.

  • Page 347: Vehicle Weight

    Vehicle Curb Weight NOTICE This is the weight of your new vehicle To prevent vehicle damage: when you picked it up from your dealer plus any aftermarket equipment. • Due to higher load during trailer use, overheating may occur on hot days or during uphill driving.

  • Page 348: Overloading

    Driving your vehicle Overloading WARNING The Gross Axle Weight Rating (GAWR) and the Gross Vehicle Weight Rating (GVWR) for your vehicle are on the Certification Label attached to the driver’s (or front passenger’s) door. Exceeding these ratings can cause an accident or vehicle damage.

  • Page 349: Driver Assistance System

    7. Driver Assistance System Driver assistance system notice..................7-4 Forward Collision-Avoidance Assist (FCA) ..............7-4 Forward Collision-Avoidance Assist settings............. 7-8 Forward Collision-Avoidance Assist operation............7-10 Forward Collision-Avoidance Assist malfunction and limitations......7-22 Lane Keeping Assist (LKA)..................... 7-30 Lane Keeping Assist settings..................7-31 Lane Keeping Assist operation..................
  • Page 350 Cruise Control (CC) ......................7-75 Cruise Control operation ................... 7-75 Smart Cruise Control (SCC)................... 7-78 Smart Cruise Control settings ................... 7-79 Smart Cruise Control operation ................7-80 Smart Cruise Control malfunction and limitations ..........7-90 Navigation-based Smart Cruise Control (NSCC)............7-96 Navigation-based Smart Cruise Control settings ...........
  • Page 351 7. Driver Assistance System Forward/Side/Reverse Parking Distance Warning (PDW)......... 7-141 Forward/Side/Reverse Parking Distance Warning Settings ........7-141 Forward/Side/Reverse Parking Distance Warning Operation.......7-142 Forward/Side/Reverse Parking Distance Warning Malfunction and Limitations 7-144 Reverse Parking Collision-Avoidance Assist (PCA) ............7-146 Reverse Parking Collision-Avoidance assist settings..........7-147 Reverse Parking Collision-Avoidance Assist operation..........

  • Page 352: Driver Assistance System Notice

    Driver Assistance System Driver assistance system Junction Turning function notice Due to the infotainment software version, the description of each function of the driver assistance system may differ from the owner's manual. Forward Collision-Avoidance 2C_FCAJunctionTurningFunction Assist (FCA) Junction Turning function can help avoid a collision with an oncoming vehicle and powered two-wheeler in an adjacent lane when turning left (left-hand drive) or right...
  • Page 353 Junction Crossing function Lane-Change Side function if equipped if equipped 2C_FCAJunctionCrossingFunction 2C_FCALaneChangeSideFunction Junction Crossing function can help avoid a collision with oncoming vehicles on the left or right side when crossing an intersection by applying emergency braking. Lane-Change Oncoming function if equipped 2C_FCALaneChangeSideFunction_2 [A] Front-side vehicle...
  • Page 354 Driver Assistance System Evasive Steering Assist function Detecting sensor if equipped 2C_FrontViewCamera 2C_FCAEvasiveSteeringAssistFunction • Driver steering assist Evasive Steering Assist function helps avoid a collision with a vehicle, powered two-wheeler, and pedestrian or cyclist ahead in the same lane. When a risk of collision is detected, Evasive Steering Assist function will warn the driver and if the driver steers to avoid...
  • Page 355 HYUNDAI dealer. HYUNDAI dealer. • Never install any accessories or stickers • Use only genuine parts to repair or on the front windshield, or tint the front replace a damaged front radar cover.

  • Page 356: Forward Collision-Avoidance Assist Settings

    Driver Assistance System Forward Collision-Avoidance Forward Cross-Traffic Safety Assist settings if equipped Forward Safety 2C_ForwardCrossTrafficSafetySettings With the vehicle on, press the Ų button and then select Vehicle > Driver 2C_ForwardSafetySetInfo assistance > Forward cross-traffic safety With the vehicle on, press the Ų in the infotainment system to turn on button and then select Vehicle >...
  • Page 357 Forward when Forward Collision-Avoidance Assist Collision-Avoidance Assist. The warning is on, we recommend that your vehicle be time can be set to either “Normal” or inspected by an authorized HYUNDAI “Late” dealer. • Use “Normal” in normal driving WARNING conditions.

  • Page 358: Forward Collision-Avoidance Assist Operation

    Driver Assistance System CAUTION Information • Even though “Normal” is selected for • If you change the Warning methods, Warning Timing, if the front vehicle the Warning methods of other Driver suddenly stops, the warning may seem Assistance systems may change. late.
  • Page 359 • If a vehicle or powered two-wheeler is • Pedestrian or cyclist: detected in front, the function will The function will operate when your operate when your vehicle speed is vehicle speed is between about 10-65 between about 10-200 km/h (6-124 km/h (6-40 mph).
  • Page 360 Driver Assistance System Emergency Braking Junction Turning function Junction Turning function will warn and help control the vehicle depending on the collision risk level: 'Collision Warning', 'Emergency Braking' and 'Stopping vehicle and ending brake control'. Collision Warning 2C_FCAJunctionTurningEmergencyBrakingInfo • To warn the driver that emergency braking will be assisted, the “Emergency braking”...
  • Page 361 Stopping vehicle and ending brake control Collision Warning 2C_FCABasicCollisionWarningInfo_2 2C_DriveCarefullyInfo • To warn the driver of a collision, • When the vehicle is stopped due to Forward Safety warning light (O) emergency braking, the “Drive carefully” warning message will appear blinking, the "Collision warning!"...
  • Page 362 Driver Assistance System Emergency Braking Stopping vehicle and ending brake control 2C_FCABasicEmergencyBrakingInfo 2C_DriveCarefullyInfo • To warn the driver that emergency • When the vehicle is stopped due to braking will be assisted, Forward Safety emergency braking, the "Drive warning light (O) blinking, the carefully"...
  • Page 363 Emergency Braking Junction Crossing function if equipped Junction Crossing function will warn and control the vehicle depending on collision risk level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’. Collision Warning 2C_FCAJunctionCrossingEmergencyBrakingInfo • To warn the driver that emergency braking will be assisted, Forward Safety warning light (O) blinking, the "Emergency braking"...
  • Page 364 Driver Assistance System Stopping vehicle and ending brake control Lane-Change Oncoming function if equipped Lane-Change Oncoming function will warn and control the vehicle depending on collision risk level: ‘Collision Warning’ and ‘Emergency Steering’. Collision Warning 2C_DriveCarefullyInfo • When the vehicle is stopped due to emergency braking, the "Drive carefully"...
  • Page 365 Emergency Steering Lane-Change Side function if equipped Lane-Change Side function will warn and control the vehicle depending on collision risk level: ‘Collision Warning’ and ‘Emergency Steering’ Collision Warning 2C_FCAJunctionCrossingEmergencyBrakingInfo • To warn the driver that emergency steering will be assisted, Emergency Steering warning light (O) blinking, the "Emergency braking"...
  • Page 366 Driver Assistance System Emergency Steering CAUTION • Lane-Change Side function does not operate if the vehicle speed of the preceding vehicle from the front side is 0 km/h (0 mph). • The detecting range of the front corner radar and the rear corner radar is determined by a standard road width, therefore, on a narrow road, Lane-Change Side function may detect...
  • Page 367 Emergency Steering (Evasive steering Information assist) • When an additional accident is expected, Lane-Change Side function will not assist with steering and only warn the driver of a collision. • If the driver’s seat is on the left side, collision warning will operate when you turn left, and when it is on the right side, the system will operate when you turn right.
  • Page 368 Driver Assistance System CAUTION WARNING • The steering wheel may turn Take the following precautions when automatically when emergency using Forward Collision-Avoidance steering is operating. Assist: • Emergency steering will automatically • For your safety, only change the cancel when risk factors disappear. If Settings after parking the vehicle at a necessary, the driver must steer the safe location.
  • Page 369 • You may not hear the warning sound of CAUTION Forward Collision-Avoidance Assist if the surrounding is noisy. • Depending on the condition of the vehicle and powered two-wheeler, • Forward Collision-Avoidance Assist pedestrian and cyclist in front and the may turn off or may not operate surroundings, the speed range to properly or may operate unnecessarily...

  • Page 370: Forward Collision-Avoidance Assist Malfunction And Limitations

    We system limited. Camera obscured." or recommend that your vehicle be the "Driver assistance system limited. inspected by an authorized HYUNDAI Radar blocked." warning message, and dealer. the O, P, or the X warning lights will illuminate on the instrument cluster.
  • Page 371 • Washer fluid is continuously sprayed, or WARNING the wiper is on • Even though the warning message or • Driving in heavy rain or snow, or thick warning light does not appear on the cluster, Forward Collision-Avoidance • The field of view of the front view Assist may not properly operate.
  • Page 372 Driver Assistance System • With a vehicle and powered • The front vehicle’s and powered two-wheeler's ground clearance is low two-wheeler in front, your vehicle or high changes lane at low speed • A vehicle, and powered two-wheeler, • The vehicle and powered two-wheeler and pedestrian or cyclist suddenly cuts in front is covered with snow in front...
  • Page 373 Junction Crossing, Lane-Change • The pedestrian or cyclist in front has Oncoming, Lane-Change Side, Evasive impaired mobility Steering Assist function (if equipped) • The pedestrian or cyclist in front is moving intersected with the driving • The temperature around the front direction corner radar or rear corner radar is high or low...
  • Page 374 Driver Assistance System • The lane suddenly disappears, such as • The vehicle and powered two-wheeler in the next lane moves two lanes away at the intersection from you, or when the vehicle and • The lane is very wide or narrow powered two-wheeler two lanes away •...
  • Page 375 • Driving on an inclined road When driving on a curve, you must maintain a safe braking distance, and if necessary, depress the brake pedal to reduce your driving speed in order to maintain a safe distance. 2C_FCADrivingOnIncline 2C_FCADrivingOnCurve_3 2C_FCADrivingOnIncline_2 2C_FCADrivingOnCurve_4 Forward Collision-Avoidance Assist may detect a vehicle, powered...
  • Page 376 Driver Assistance System • Changing lanes Forward Collision-Avoidance Assist may not detect other vehicles, powered two-wheelers, and pedestrians or cyclists in front of you while driving uphill or downhill, adversely affecting the performance of the sensors. This may result in unnecessary warning, braking assist or steering assist or no warning, braking assist or steering assist (if equipped) when necessary.
  • Page 377 • If the vehicle in front of you has cargo that extends rearward from the cab, or when the vehicle in front of you has higher ground clearance, additional special attention is required. Forward Collision-Avoidance Assist may not be able to detect the cargo extending from the vehicle.

  • Page 378: Lane Keeping Assist (Lka)

    Driver Assistance System Lane Keeping Assist (LKA) WARNING if equipped • When you are towing a trailer or another vehicle, turn off Forward While driving over a certain speed, Lane Collision-Avoidance Assist for safety Keeping Assist detects lane markings (or reasons.

  • Page 379: Lane Keeping Assist Settings

    Lane Keeping Assist settings Warning methods Lane Safety 2C_WarningTypeSetInfo With the vehicle on, press the Ų button and then select Vehicle > Driver 2C_LaneSafetySetInfo assistance > Warning methods in the With the vehicle on, press the Ų infotainment system to select following: button and then select Vehicle >...

  • Page 380: Lane Keeping Assist Operation

    Driver Assistance System Information Information • If you change the Warning methods, • When Lane Keeping Assist is ready to the Warning methods of other Driver operate, S indicator turns gray on the Assistance systems may change. cluster. • Warning method will maintain its last •...
  • Page 381 Lane Departure Warning Hands-off warning • To warn the driver that the vehicle is departing from the projected lane in front, the green S indicator light blinks on the cluster, the lane line blinks on the cluster depending on which direction the vehicle is veering, and an audible warning sounds.

  • Page 382: Lane Keeping Assist Malfunction And Limitations

    Lane Keeping Assist (S) warning light appears on the cluster. If this occurs, we 2C_LaneDetectionInfo recommend that your vehicle be Lane detected inspected by an authorized HYUNDAI dealer. 2C_LaneDetectionInfo_2 • The images and colors in the cluster may differ depending on the cluster type or theme selected from the infotainment system.
  • Page 383 HYUNDAI area dealer. • There are road markings, such as zigzag lanes, crosswalk markings and road...
  • Page 384 Driver Assistance System • Lane Keeping Assist may not operate Information for 15 seconds after the vehicle is started, or the front view camera is For more information on the limitations of initialized. the front view camera, refer to the "Forward Collision-Avoidance Assist •...

  • Page 385: Blind-Spot Collision-Avoidance Assist (Bca)

    Blind-Spot Blind-Spot Collision-Avoidance Assist helps detect and informs the driver that a Collision-Avoidance vehicle is approaching at high speed from the blind spot area. Assist (BCA) if equipped Blind-Spot Collision-Avoidance Assist detects approaching vehicles in the driver’s blind spot areas and warn you of a possible collision with a warning light and a warning sound.
  • Page 386 Blind-Spot Collision Avoidance Assist may not operate properly. We recommend that your vehicle be inspected by an authorized HYUNDAI dealer. • If the rear corner radars have been replaced or repaired, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer.

  • Page 387: Blind-Spot Collision-Avoidance Assist Settings

    Blind-Spot Collision-Avoidance Assist settings Blind-spot safety 2C_BlindspotSafetyOffMessage When the vehicle is restarted with Blind-Spot Collision-Avoidance Assist off, the “Blind spot safety system is Off” message will appear on the instrument cluster. 2C_BlindspotSafetySettings If you select “Blind-spot safety”, warning With the vehicle on, press the Ų light on the outside rearview mirror will button and then select Vehicle >...

  • Page 388: Blind-Spot Collision-Avoidance Assist Operation

    Driver Assistance System Blind-Spot Warning methods Collision-Avoidance Assist operation Driving-Warning 2C_WarningTypeSetInfo With the vehicle on, go to press the Ų button and then select Vehicle > Driver assistance > Warning methods from the infotainment system to select following: 2C_SideMirrorWaringLamp • Warning volume: The warning volume To warn the driver a vehicle is detected, can be adjusted.
  • Page 389 Collision-avoidance assist (while WARNING parallel parking exit) • The detecting range of the rear corner radar is determined by a standard road width, therefore, on a narrow road, Blind-Spot Collision-Avoidance Assist may detect other vehicles two lanes over and warn you. In contrast, on a wide road, Blind-Spot Collision-Avoidance Assist may not be able to detect a vehicle driving in the...
  • Page 390 Driver Assistance System • When the vehicle is stopped due to • During Blind-Spot Collision-Avoidance emergency braking, the "Drive Assist operation, the vehicle may stop carefully" warning message will appear suddenly injuring passengers and on the cluster. shifting loose objects. Always have the seat belt on and keep loose objects secured.

  • Page 391: Blind-Spot Collision-Avoidance Assist Malfunction And Limitations

    If this 2C_DriverAssistanceMalfunction occurs, we recommend that your vehicle When Blind-Spot Collision Warning is not be inspected by an authorized HYUNDAI working properly, the "Check driver dealer. assistance system.” warning message will appear on the instrument cluster for several seconds, and the master (X) warning light will appear on the instrument cluster.
  • Page 392 If Blind-Spot Collision-Avoidance Assist does not operate properly after it is removed, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 7-44...
  • Page 393 Limitations of Blind-Spot • The other vehicle drives very close Collision-Avoidance Assist behind your vehicle, or the other vehicle passes by your vehicle in close Blind-Spot Collision-Avoidance Assist proximity may not operate properly, or it may operate unexpectedly under the •...
  • Page 394 Driver Assistance System Blind-Spot Collision-Avoidance Assist WARNING may not operate properly, or it may operate unexpectedly when the following • Driving on a curved road objects are detected: • A motorcycle or bicycle is detected • A vehicle such as a flat trailer is detected •...
  • Page 395 • Driving where the road is WARNING merging/dividing • When you are towing a trailer or another vehicle, make sure that you turn off Blind-Spot Collision-Avoidance Assist. • Blind-Spot Collision-Avoidance Assist may not operate properly if interfered by strong electromagnetic waves. •...

  • Page 396: Safe Exit Warning (Sew)

    Driver Assistance System Safe Exit Warning (SEW) Detecting sensor if equipped 2C_RearRadar [A] Rear corner radar 2C_RearRadar 2C_SEWOperation Refer to the illustration above for the While your vehicle is stopped, and if Safe detailed location of the detecting Exit Warning detects a vehicle sensors.

  • Page 397: Safe Exit Warning Settings

    Safe Exit Warning settings Warning methods Safe Exit Warning 2C_WarningTypeSetInfo With the vehicle on, press the Ų button and then select Vehicle > Driver 2C_ExitSafetySettings assistance > Warning methods from the With the vehicle on, press the Ų infotainment system to select following: button and then select Driver assistance •...

  • Page 398: Safe Exit Warning Operation

    Driver Assistance System Safe Exit Warning operation WARNING Take the following precautions when Safe Exit Warning using Safe Exit Warning: • For your safety, change the Settings Collision warning when exiting vehicle after parking the vehicle at a safe location. •...

  • Page 399: Safe Exit Warning Malfunction And Limitations

    If Safe Exit Warning does not operate properly after it is removed, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 2C_CheckSideViewMirrorWarning When the outside rearview mirror warning light is not working properly, the "Check outside mirror warning icon"...
  • Page 400 Driver Assistance System Limitations of Safe Exit Warning WARNING Safe Exit Warning may not operate • Even though the warning message properly, or it may operate unexpectedly does not appear on the cluster, Safe under the following circumstances: Exit Warning may not properly operate. •...

  • Page 401: Manual Speed Limit Assist (Msla)

    Manual Speed Limit Manual Speed Limit Assist operation Assist (MSLA) Setting speed limit 1. Press and hold the Driving Assist (ĩ) button at the desired speed. The Speed Limit (Ý) indicator will appear on the cluster. 2C_MSLAOverviewInfo (1) Speed Limit indicator (2) Set speed 2C_MSLAOverviewInfo You can set the speed limit when you do...
  • Page 402 Driver Assistance System Temporarily pausing Manual Speed 3. The set speed limit will be displayed on the cluster. Limit Assist If you would like to drive over the preset speed limit, depress the accelerator pedal beyond the pressure point to activate the kickdown function.

  • Page 403: Intelligent Speed Limit Assist (Isla)

    Intelligent Speed Limit Turning off Manual Speed Limit Assist Assist (ISLA) if equipped Intelligent Speed Limit Assist uses information from the detected road signs and uses the navigation system data to inform you of the speed limit and to help maintain within the speed limit on the road.

  • Page 404: Intelligent Speed Limit Assist Settings

    Driver Assistance System Intelligent Speed Limit Assist Detecting sensor settings Speed Limit 2C_FrontViewCamera [A] Front view camera 2C_FrontViewCamera See the illustration above for the detailed 2C_SpeedLimitSetInfo location of the detecting sensor. With the vehicle on, press the Ų CAUTION button and then select or deselect Vehicle >...
  • Page 405 Warning methods WARNING • When the vehicle is restarted, Intelligent Speed Limit Assist will always turn on. However, if "Off" and the vehicle is restarted, "SLW (Speed Limit Warning)" is selected. • For your safety, only change the Settings after parking the vehicle at a safe location.

  • Page 406: Intelligent Speed Limit Assist Operation

    Driver Assistance System Intelligent Speed Limit Assist Information operation • If speed limit information of the road cannot be recognized, '---' sign will be Warning and control displayed. Please refer to Limitations of Intelligent Speed Limit Assist will warn Intelligent Speed Limit Assist section, if the road signs are difficult to recognize.
  • Page 407 Changing set speed Set Speed Auto Change (Navigation equipped) 2C_ISLAChangeSetSpeed 2C_ISLASetSpeedAutoChangeInfo Manual Speed Limit Assist or Smart Cruise Control assists the vehicle to adjust its speed according to the speed limit. When the cruising speed is set as same as the speed limit, the vehicle automatically adjusts its speed if the speed limit changes.

  • Page 408: Intelligent Speed Limit Assist Malfunction And Limitations

    When Intelligent Speed Limit Assist is not recommend that your vehicle be working properly, the "Check driver inspected by an authorized HYUNDAI assistance system" warning message will dealer. appear on the instrument cluster for...
  • Page 409 Limitations of Intelligent Speed • Intelligent Speed Limit Assist Limit Assist incorrectly recognizes numbers or illustrations in the street signs or other Intelligent Speed Limit Assist may not signs as the speed limit operate properly, or it may operate unexpectedly under the following •...

  • Page 410: Driver Attention Warning (Daw)

    Driver Assistance System Driver Attention Warning • The field of view of the front view camera is obstructed by sun glare (DAW) • Driving on a road that is sharply curved or continuously curved if equipped • Driving through speed bumps, or driving up and down or left to right on Driver Attention Warning steep inclines...

  • Page 411: Driver Attention Warning Settings

    Driver Attention Warning CAUTION operation • Always keep the front view camera in good condition to maintain optimal Driver Attention Warning performance of Driver Attention Warning. The basic function of Driver Attention Warning is to warn the driver "Consider • For more information on the taking a break".
  • Page 412 Driver Assistance System CAUTION WARNING • Driver Attention Warning may suggest • If any other system’s warning message a break depending on the driver’s appears or audible warning is driving pattern or habits, even if the generated, Leading Vehicle Departure driver doesn’t feel fatigue.

  • Page 413: Driver Attention Warning Malfunction And Limitations

    If this snow, rain or foreign material is removed. occurs, we recommend that your vehicle If Driver Attention Warning does not be inspected by an authorized HYUNDAI operate properly after it is removed, we dealer. recommend that your vehicle be inspected by an authorized HYUNDAI dealer.
  • Page 414 Driver Assistance System Limitations of Driver Attention • When the vehicle ahead sharply steers Warning Driver Attention Warning may not work properly in the following situations: • The vehicle is driven violently • The vehicle intentionally crosses over lanes frequently •...
  • Page 415 • When a pedestrian or bicycle is • When driving at a tollgate or between you and the vehicle ahead intersection, etc. 2C_DAWBetweenVehicles 2C_DAWInTollbooth If there is a pedestrian(s) or bicycle(s) in If you pass a tollgate or intersection between you and the vehicle in front, with lots of vehicles or you drive where Leading Vehicle Departure Alert may lanes are merged or divided frequently,...

  • Page 416: Forward Attention Warning (Faw)

    Driver Assistance System Forward Attention Forward Attention Warning settings Warning (FAW) if equipped Forward attention warning Forward Attention Warning uses the With the vehicle on, press the Ų in-cabin camera to help prevent the button and then select Vehicle > Driver driver from being distracted while driving assistance >...

  • Page 417: Forward Attention Warning Operation

    Forward Attention Warning Driver Drowsiness Attention Warning operation Forward Attention Warning Forward Attention Warning determines whether the driver is focused on the road depending on information, such as the amount of time the driver is looking elsewhere, the amount of time the eyes are closed, etc.

  • Page 418: Forward Attention Warning Malfunction And Limitations

    Attention Warning is working properly. If this occur, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. Information • Forward Attention Warning does not transmit recorded videos outside of the vehicle or store the video.
  • Page 419 - The outside brightness is dim or inspected by an authorized HYUNDAI driving at night dealer. - The vehicle drives inside a building, such as a basement parking lot,...
  • Page 420 Driver Assistance System Limitations of Forward Attention • The driver turns or lowers his/her head Warning so that the face or an eye is hidden from the camera Forward Attention Warning may not operate properly, or it may operate • The driver shakes his/her head up and unexpectedly under the following down, or adverse road conditions cause circumstances:...

  • Page 421: Blind-Spot View Monitor (Bvm)

    Blind-Spot View Monitor Detecting sensor (BVM) if equipped Left 2C_SideviewCamera [A] Wide-side view camera (camera located at bottom of the mirror) [B] Wide-side view camera (camera located at bottom of the mirror) 2C_SideviewCamera 2C_BVMLeftSideInfo See the illustration above for the detailed Right location of the detecting sensors.

  • Page 422: Blind-Spot View Monitor Operation

    Operating switch flickers, or the camera image does not display properly, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. WARNING • The image shown on the cluster may differ from the actual distance of the object. Make sure to directly check the vehicle's surroundings for safety.

  • Page 423: Cruise Control (Cc)

    Cruise Control (CC) Information if equipped • The vehicle may slightly slow down or speed up while driving uphill or downhill. • The Driving Assist button symbol may vary depending on your vehicle option. To increase speed ONE1071247 (1) Cruise indicator (2) Set speed Cruise Control will allow you to drive at speeds above 30 km/h (20 mph) without...
  • Page 424 If you push the + switch up or - switch authorized HYUNDAI dealer. down at increased speed, the set speed will be set to the current increased speed.
  • Page 425 Resuming Cruise Control Turning off Cruise Control 2C_SpeedControlResuming 2C_DrivingAssistButton Operate the +, - or ç switch. Press the Driving Assist (ĩ) button to turn Cruise Control off. The Cruise If you push the + switch up or - switch (Ü) indicator will go off. down, vehicle speed will be set to the current speed on the instrument cluster.

  • Page 426: Smart Cruise Control (Scc)

    Driver Assistance System Smart Cruise Control WARNING (SCC) Take the following precautions when using Cruise Control: Smart Cruise Control detects a vehicle • Always set the vehicle speed to the ahead and helps maintain the distance speed limit in your country. from the vehicle ahead and the set speed.

  • Page 427: Smart Cruise Control Settings

    Based on driving style CAUTION if equipped Always keep the front view camera and front radar in good condition to maintain optimal performance of Smart Cruise Control. For more information on the precautions of the front view camera and front radar, refer to the "Forward Collision-Avoidance Assist (FCA)"...

  • Page 428: Smart Cruise Control Operation

    Driver Assistance System Smart Cruise Control Warning methods operation Operating conditions Basic function Smart Cruise Control operates when the following conditions are satisfied. • The gear is in D (Drive) • Your vehicle speed is within the operating speed range 2C_WarningTypeSetInfo With the vehicle on, press the Ų...
  • Page 429 Operating conditions for Acceleration Turning on Smart Cruise Control Assist Overtaking Acceleration Assist operates when the turn signal indicator is turned on to the left (left-hand drive) or turned on to the right (right-hand drive) while Smart Cruise Control is operating, and the following conditions are satisfied: •...
  • Page 430 Driver Assistance System Setting vehicle distance Increasing set speed 2C_SCCDistanceButton 2C_SCCSpeedUp Press the button repeatedly to cycle • Push the + switch up and release it through the headway settings from immediately. The set speed will Distance 4 → Distance 3 → Distance 2 → increase by 1 km/h (1 mph) each time Distance 1 →...
  • Page 431 Decreasing set speed Resuming Smart Cruise Control 2C_SCCSpeedDown 2C_SpeedControlResuming • Push the - switch down and release it To resume Smart Cruise Control after the immediately. The set speed will function was cancelled, operate the +, - or decrease by 1 km/h (1 mph) each time ç...
  • Page 432 Driver Assistance System Turning off Smart Cruise Control Display and Control You can see the status of the Smart Cruise Control operation in the Driving Assist view on the cluster. Refer to "Cluster display" section in chapter 4. Smart Cruise Control will be displayed as below depending on the status of the function.
  • Page 433 WARNING Information • The distance of the front vehicle on the Be careful when accelerating temporarily, cluster is displayed according to the because the speed and distance is not actual distance between your vehicle controlled automatically even if there is a and the vehicle ahead.
  • Page 434 Driver Assistance System Temporarily cancelling Smart Cruise Information Control If Smart Cruise Control is temporarily cancelled while the vehicle is at a standstill with the function activated, EPB (Electronic Parking Brake) maybe applied. WARNING When Smart Cruise Control is temporarily cancelled, distance with the front vehicle will not be maintained.
  • Page 435 In traffic situation Warning road conditions ahead 2C_SCCRoadConditionWarningInfo 2C_SCCReStart In the following situation, the "Watch for In traffic, your vehicle will stop if the surrounding vehicles" warning message vehicle ahead of you stops. Also, if the will appear on the cluster, and an audible vehicle ahead of you starts moving, your warning will sound to warn the driver of vehicle will start as well.
  • Page 436 Driver Assistance System Collision Warning WARNING Take the following precautions when using Smart Cruise Control: • Smart Cruise Control does not substitute for proper and safe driving. It is the responsibility of the driver to always check the speed and distance to the vehicle ahead.
  • Page 437 • When you are towing a trailer or CAUTION another vehicle, turn off Smart Cruise Control for safety reasons. • The vehicle must be driven sufficiently to reflect the actual driving style of the • Turn off Smart Cruise Control when driver, such as inter-vehicle distance, your vehicle is being towed.

  • Page 438: Smart Cruise Control Malfunction And Limitations

    We recommend that Smart Cruise Control will operate your vehicle be inspected by an properly when snow, rain or foreign authorized HYUNDAI dealer. material is removed. WARNING Even though the warning message does not appear on the cluster, Smart Cruise Control may not properly operate.
  • Page 439 Limitations of Smart Cruise Control • Only part of the vehicle is detected Smart Cruise Control may not operate • The vehicle in front has no tail lights, tail properly, or it may operate unexpectedly lights are located unusually, etc. under the following circumstances: •...
  • Page 440 Driver Assistance System • Driving on a curved road • The vehicle in front is suddenly blocked by a obstacle • The vehicle in front suddenly changes lane or suddenly reduces speed • The vehicle in front is bent out of shape •...
  • Page 441 • Driving on an inclined road • Changing lanes 2C_FCADrivingOnIncline During uphill or downhill driving, the Smart Cruise Control may not detect a moving vehicle in your lane, and cause your vehicle to accelerate to the set speed. Also, vehicle speed will rapidly decrease when the vehicle ahead is detected suddenly.
  • Page 442 Driver Assistance System • Situations when detecting are limited - Vehicles with higher ground clearance or vehicles carrying loads that stick out of the back of the vehicle - Vehicles that has the front lifted due to heavy loads - Vehicles within about 2 m (6 ft.) from your vehicle - Oncoming vehicles - Stopped vehicles...
  • Page 443 • When a vehicle ahead disappears at an • Always look out for pedestrians when intersection, your vehicle may your vehicle is maintaining a distance accelerate. with the vehicle ahead. Always pay attention to road and driving conditions while driving. 2C_SCCPedestrianCaution 2C_SCCDrivingOnCrossroad •...

  • Page 444: Navigation-Based Smart Cruise Control (Nscc)

    Driver Assistance System Navigation-based Smart Navigation-based Smart Cruise Control settings Cruise Control (NSCC) if equipped Navigation-based Smart Cruise Control can help drive at a certain speed according to the road conditions when driving on highways (or motorways) by using road information from the navigation system while Smart Cruise Control is operating.

  • Page 445: Navigation-Based Smart Cruise Control Operation

    Navigation-based Smart Cruise Control Navigation-based Smart operating Cruise Control operation While the speed is being controlled, the green Û indicator light blinks. Operating conditions Navigation-based Smart Cruise Control is Temporarily canceled or interrupted by ready to operate if all of the following the driver conditions are satisfied: If Navigation-based Smart Cruise Control...

  • Page 446: Limitations Of Navigation-Based Smart Cruise Control

    Driver Assistance System Highway Curve Zone Auto Slowdown • GPS signals are blocked in areas such as a tunnel • Depending on the curve ahead on the highway (or motorway), the vehicle will • A road that divides into two or more decelerate, and after passing the curve, roads and joins again the vehicle will accelerate to Smart...
  • Page 447 • Driving on a road that is sharply curved • When the vehicle's driving route is recognized as the main road by maintaining the main road instead of the navigation set route, Highway Curve Zone Auto Slowdown function will operate. Depending on the distance to the curve and the current vehicle speed, vehicle deceleration may not be sufficient or may decelerate rapidly.
  • Page 448 Driver Assistance System • When it is judged that you are driving WARNING out of the route by entering the highway interchange or junction, • Navigation-based Smart Cruise Control Highway Curve Zone Auto Slowdown is not a substitute for safe driving function will not operate.

  • Page 449: Lane Following Assist (Lfa)

    Lane Following Assist • The vehicle will accelerate if the driver depresses the accelerator pedal while (LFA) Navigation-based Smart Cruise Control is operating, and the function will not if equipped decelerate the vehicle. However, if the Lane Following Assist detects lane accelerator pedal is depressed markings and/or a vehicle ahead on the insufficiently, the vehicle may...

  • Page 450: Lane Following Assist Settings

    Driver Assistance System Lane Following Assist settings Lane Following Assist operation Warning methods Turning Lane Following Assist On/Off 2C_WarningTypeSetInfo_2 With the vehicle on, press the Ų 2C_LaneSafetyButton button and then select Vehicle > Driver assistance > Warning methods in the With the vehicle on, shortly press the infotainment system to select following: Lane Driving Assist button located on the...
  • Page 451 CAUTION WARNING When the steering wheel is not assisted, • The steering wheel may not be assisted the white (º) indicator light blinks and if the steering wheel is held very tight or changes to grey. the steering wheel is steered over a certain degree.

  • Page 452: Lane Following Assist Malfunction And Limitations

    (X) warning light appears on the instrument cluster. If this occur, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 2C_LFALaneDetectInfo_2 Limitations of Lane Following Assist • The images and colors in the cluster...

  • Page 453: Highway Driving Assist (Hda)

    Highway Driving Assist Information (HDA) • Highway Driving Assist is available only certain highways. if equipped • Highway Driving Assist operates on main roads of highways, and does not Highway Driving Assist operate on interchanges or junctions. Highway Driving Assist detect lanes and •...

  • Page 454: Highway Driving Assist Settings

    Driver Assistance System Highway Driving Assist settings 2C_RearRadar_2 [A] Front view camera [B] Front radar [C] Front corner radar (if equipped) 2C_HDASettings [D] Rear corner radar (if equipped) With the vehicle on, press the Ų 2C_RearRadar_2 button and then select or deselect Refer to the picture above for the detailed Vehicle >...
  • Page 455 We With the vehicle on, press the Ų recommend that your vehicle be button and then select Vehicle > Driver inspected by an authorized HYUNDAI assistance > Warning methods in the dealer. infotainment system to select following: •...

  • Page 456: Highway Driving Assist Operation

    Driver Assistance System Highway Driving Assist Standby state operation Basic function Displaying operating status You can see the status of the Highway Driving Assist operation in the Driving Assist view on the instrument cluster. Refer to the “View modes” section in 2C_HDAReadyIndicatorInfo chapter 4.
  • Page 457 Highway Driving Assist operation Hands-off warning Highway Driving Assist operates when: • Driving on the main road of highways, and turning on Highway Driving Assist by pressing the Driving Assist button • Entering the main road of highways while Lane Following assist and Smart Cruise Control are operating Restarting after stopping 2C_HandOffWarningInfo...
  • Page 458 Driver Assistance System Driving speed limit Highway Driving Assist standby When the Smart Cruise Control is temporarily cancelled while Highway Driving Assist is operating, Highway Driving Assist will be in the standby state. At this time, Lane Following Assist will operate properly.
  • Page 459 Highway Lane Change Assist 2. Green lane line • The lane line is displayed same as the if equipped Highway Lane Change Assist Displaying operating status indicator (1). However, if the function is on standby, it displays whether the You can see the status of the Highway lane line is detected.
  • Page 460 Driver Assistance System Highway Lane Change Assist ready to Information operate • While Lane Change Assist function is turned on (indicator on), Lane Following Assist will not cancel even if the turn signal indicator or hazard warning flasher is operating. •...
  • Page 461 Highway Lane Change Assist operating Information • When the turn signal lever is positioned at [A]. If the turn signal lever is released to the center (1) before stepping on the lane, Highway Lane Change Assist cancels. If the turn signal lever is released to the center (1) after stepping on the lane, Highway Lane Change Assist changes the lane and turns off the turn signal...
  • Page 462 Driver Assistance System Highway Lane Change Assist cancel - Highway Lane Change Assist function is off (The function turns off The function will be canceled when: when the function is turned off, when • The turn signal lever is positioned at [A] the road changes to a one-way road, and it's released to the center (1) before when there is an intersection or...

  • Page 463: Highway Driving Assist Malfunction And Limitations

    - Driving on roads that Highway vehicle be inspected by an authorized Driving Assist does not operate, such HYUNDAI dealer. as a rest area, intersection, junction, etc. - The navigation does not operate properly such as when the navigation...
  • Page 464 Driver Assistance System Limitation of Highway Driving Assist • Highway Driving Assist may inadvertently operate or turn off Highway Driving Assist may not operate depending on road conditions properly, or may not operate under the (navigation information) and following circumstances: surroundings.

  • Page 465: Rear View Monitor (Rvm)

    Rear View Monitor (RVM) Information if equipped • If you change the Warning methods, Rear View Monitor shows the area behind the Warning methods of other Driver the vehicle to assist you when parking or Assistance systems may change. backing up. •...

  • Page 466: Rear View Monitor Operation

    Driver Assistance System Rear view reference lines Rear view If "Rear view reference lines" is selected, the rear view parking guide lines and rear top view guide lines will be displayed at the left side of the infotainment system screen. Information •...
  • Page 467 When operating Extended Rear View Monitor The rear view will maintain showing on If the gear is shifted to R (Reverse), when the screen to help you when parking. rear view while driving appears on the screen, the screen will change to rear Operating conditions view.

  • Page 468: Rear View Monitor Malfunction And Limitations

    HYUNDAI dealer. Detecting sensor Limitations of Rear View Monitor WARNING •...

  • Page 469: Surround View Monitor Settings

    Surround View Monitor Camera settings settings Warning methods 2C_SVMCameraSettings • You can change Surround View Monitor "Display contents" by touching the setup icon ( ) on the screen while 2C_WarningTypeSetInfo_4 Surround View Monitor is operating, or With the vehicle on, press the Ų pressing the Ų...

  • Page 470: Surround View Monitor Operation

    Driver Assistance System Top view reference lines Surround view monitor operation When the "Top view reference lines" is selected, parking distance warning is displayed on the right side of the Parking/View button Surround View Monitor screen. • The image will be displayed only when Parking Distance Warning is warning the driver.
  • Page 471 Operating conditions Rear view • The gear is shifted to N (Neutral) or D The rear view appears on the screen to (Drive) from R (Reverse) and the vehicle assist in parking. speed is 10 km/h (6 mph) or less. You may select top view, rear view, side •...
  • Page 472 Driver Assistance System Front view while driving Rear View while driving The driver is able to check the front view The driver is able to check the rear view on the screen for safe driving. on the screen while driving, it is to assist with backing up.

  • Page 473: Surround View Monitor Malfunction And Limitations

    When the 3D view is selected by pressing vehicle be inspected by an authorized the change view button (2): HYUNDAI dealer. • The gear is in P (Park), N (Neutral) or D (Drive) when vehicle speed is below 10 Limitations of Surround View km/h (6 mph).

  • Page 474: Rear Cross-Traffic Collision-Avoidance Assist (Rcca)

    Driver Assistance System Rear Cross-Traffic WARNING Collision-Avoidance • ALWAYS look around your vehicle to make sure there are no objects or Assist (RCCA) obstacles before moving the vehicle. What you see on the screen may differ if equipped from the actual vehicle’s location. Rear Cross-Traffic Collision-Avoidance •...

  • Page 475: Rear Cross-Traffic Collision-Avoidance Assist Settings

    Rear Cross-Traffic Detecting sensor Collision-Avoidance Assist settings Rear Cross-Traffic Safety 2C_RearRadar [A] Rear corner radar 2C_RearRadar Refer to the picture above for the detailed location of the detecting sensors. 2C_RCCASetInfo Information With the vehicle on, press the Ų For more information on the precautions button and then select Vehicle >...

  • Page 476: Rear Cross-Traffic Collision-Avoidance Assist Operation

    Driver Assistance System Rear Cross-Traffic Warning methods Collision-Avoidance Assist operation Rear Cross-Traffic Collision-Avoidance Assist warns and helps control the vehicle depending on collision risk level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’. Collision Warning 2C_WarningTypeSetInfo_2 With the vehicle on, press the Ų button and then select Vehicle >...
  • Page 477 Emergency Braking • Rear Cross-Traffic Collision-Avoidance Assist will operate when all the following conditions are satisfied: - The gear is shifted to R (Reverse) - Vehicle speed is below 8 km/h (5 mph) - The approaching vehicle is within approximately 25 m (82 ft.) from the left and right side of your vehicle - The speed of the vehicle approaching from the left and right is above 5...
  • Page 478 Driver Assistance System Stopping vehicle and ending brake • Rear Cross-Traffic Collision-Avoidance Assist operates when all the following control conditions are satisfied: - The gear is shifted to R (Reverse) - Vehicle speed is below 8 km/h (5 mph) - The approaching vehicle is within approximately 1.5 m (5 ft.) from the left and right side of your vehicle - The speed of the vehicle approaching...
  • Page 479 • You may not hear the warning sound of CAUTION Rear Cross-Traffic Collision-Avoidance Assist if the surrounding is noisy. The brake control may not operate properly depending on the status of ESC • Rear Cross-Traffic Collision-Avoidance (Electronic Stability Control). Assist may not operate if the driver applies the brake pedal to avoid There will only be a warning when: collision.

  • Page 480: Rear Cross-Traffic Collision-Avoidance Assist Malfunction And Limitations

    (X) warning light illuminates on the cluster. If this occur, we recommend that your vehicle be 2C_DriverAssistanceMalfunction inspected by an authorized HYUNDAI When Rear Cross-Traffic dealer. Collision-Avoidance Assist is not working properly, the "Check driver assistance system"...
  • Page 481 • Departing from where trees or grass are vehicle be inspected by an authorized overgrown HYUNDAI dealer. • Departing from where roads are wet WARNING • Speed of the approaching vehicle is fast or slow •...
  • Page 482 Driver Assistance System • When the vehicle is in a complex WARNING parking environment • Driving near a vehicle or structure 2C_RCCAVehicleInParkingLot Rear Cross-Traffic Collision-Avoidance 2C_RCCADrivingNearVehicle Assist may detect vehicles which are [A] Structure parking or pulling out near your vehicle Rear Cross-Traffic Collision-Avoidance (for example, a vehicle leaving beside Assist may be limited when driving near...
  • Page 483 • When the vehicle is on or near a slope • When the vehicle is parked rearward 2C_RCCANearSlope 2C_RCCAParkRearward Rear Cross-Traffic Collision-Avoidance Rear Cross-Traffic Collision-Avoidance Assist may be limited when the vehicle Assist may detect vehicles passing by is on a uphill or downhill slope, or near behind you when parking in reverse it, and may not detect the vehicle into a parking space.

  • Page 484: Forward/Reverse Parking Distance Warning (Pdw)

    Driver Assistance System Forward/Reverse Parking Forward/Reverse Parking Distance Warning settings Distance Warning (PDW) Forward/Reverse Parking Distance Warning Methods Warning uses the front and rear ultrasonic sensors to detect and warns you if a person, animal, or object is within a certain distance when your vehicle is stopped or driving at low speed.

  • Page 485: Forward/Reverse Parking Distance Warning Operation

    Auto PDW (Parking Distance Forward Parking Distance Warning Warning) Forward Parking Distance Warning To use Auto PDW (Parking Distance operates when one of the condition is Warning) function, press the Ų satisfied. button and then select Vehicle> Driver • The gear is shifted from R (Reverse) to assistance >...
  • Page 486 Driver Assistance System Reverse Parking Distance Warning Warning Reverse Parking Distance Warning indicator operates under the following conditions. Distance when driving Warning • The gear is shifted to R (Reverse). from forward sound object Information Infotai Cluster nment Reverse Parking Distance Warning operates when the vehicle’s reverse Buzzer beeps speed is below 10 km/h (6 mph).

  • Page 487: Forward/Reverse Parking Distance Warning Malfunction And Limitations

    If it still does not work blocked." warning message appears on properly we recommend that your vehicle the instrument cluster. Parking Distance be inspected by an authorized HYUNDAI Warning operates properly when snow, dealer. rain or foreign material is removed.
  • Page 488 - Attaching equipment or accessories animal, or object. next to the ultrasonic sensors • If the Parking Distance Warning does not operate properly, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 7-140...

  • Page 489: Forward/Side/Reverse Parking Distance Warning (Pdw)

    Forward/Side/Reverse Forward/Side/Reverse Parking Distance Warning Parking Distance Warning Settings (PDW) Warning methods Forward/Side/Reverse Parking Distance Warning uses the front, side, and rear ultrasonic sensors to detect and warns you if a person, animal, or object is within a certain distance when your vehicle is stopped or driving at low speed.

  • Page 490: Forward/Side/Reverse Parking Distance Warning Operation

    Driver Assistance System Parking Distance Warning Auto On Forward Parking Distance Warning To use Auto PDW (Parking Distance Forward Parking Distance Warning Warning) function, press the Ų operates under the following conditions. button and then select Vehicle> Driver • The gear is shifted from R (Reverse) to assistance >...
  • Page 491 • Shift to D (Drive) when the function is Warning indicator when (Only when Vehicle > Driver assistance Distance driving > Parking safety > Auto PDW (Parking Warning from forward Distance Warning) is selected from the sound object infotainment system Settings menu.) Infotai Cluster nment...

  • Page 492: Forward/Side/Reverse Parking Distance Warning Malfunction And Limitations

    If it still does not work sound object properly, your vehicle be inspected by an Infotain Cluster authorized HYUNDAI dealer. ment • The audible warning does not sound. 60-120 Buzzer beeps • The buzzer sounds intermittently. cm (24-48 intermittently in.)
  • Page 493 (including trailer, carrier, etc., from the washer rear bumper), your vehicle be inspected • Parking Distance Warning may by an authorized HYUNDAI dealer. malfunction when: Information - Heavy rain or water spray is present - Water flows on the surface of the sensor - Affected by another vehicle’s sensors...

  • Page 494: Reverse Parking Collision-Avoidance Assist (Pca)

    • If the Parking Distance Warning does not operate properly, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 7-146...

  • Page 495: Reverse Parking Collision-Avoidance Assist Settings

    Reverse Parking Parking Safety Collision-Avoidance assist With the vehicle on, press the Ų settings button and then select or deselect Vehicle > Driver assistance > Parking safety from the infotainment system to Warning methods set whether to use each function. •...
  • Page 496 Driver Assistance System Operating conditions Information If Reverse Parking Collision-Avoidance Reverse Parking Collision-Avoidance Assist detects a risk of collision behind the Assist operates only once after shifting vehicle with a pedestrian or an object, the gear to R (Reverse). To reactivate Reverse Parking Collision-Avoidance Parking Collision-Avoidance Assist, shift Assist warns the driver with an audible...

  • Page 497: Reverse Parking Collision-Avoidance Assist Malfunction And Limitations

    We recommend that Camera obscured." or "Driver assistance your vehicle be inspected by an system limited. Ultrasonic sensor authorized HYUNDAI dealer. blocked." warning message appears on the cluster if the following situations occur: • The rear view camera or rear ultrasonic sensor(s) is covered with foreign material, such as snow or rain, etc.
  • Page 498 Driver Assistance System Limitations of Reverse Parking • Problems with pedestrian or object Collision-Avoidance Assist - The pedestrians are difficult to detect Reverse Parking Collision-Avoidance - There is ground height difference Assist may not assist braking or warn the between the vehicle and the driver even if there are pedestrians or pedestrian objects under the following...
  • Page 499 • Problems with driving condition • Reverse Parking Collision-Avoidance Assist may not operate properly or may - The driver drives the vehicle operate unnecessarily depending on immediately after shifting to R the road conditions and the (Reverse) or D (Drive) surroundings.
  • Page 500 Reverse Parking Collision-Avoidance Assist may not operate properly if the wide angle cameras or the ultrasonic sensor(s) is forcibly moved out of proper alignment. We recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 7-152...

  • Page 501: Remote Smart Parking Assist (Rspa)

    Remote Smart Parking Detecting sensors Assist (RSPA) if equipped Remote Smart Parking Assist uses the front, front side, rear side, and rear ultrasonic sensors to detect parking spaces and control vehicle steering, speed, gear shifts, and help enter and exit parking spaces remotely from outside your vehicle.

  • Page 502: Remote Smart Parking Assist Settings

    • If the detecting sensors need repair, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. • Remote Smart Parking Assist may malfunction if the vehicle bumper...

  • Page 503: Remote Smart Parking Assist Operation

    Remote Smart Parking Assist operation Remote Smart Parking Assist button Parking/View button Parking Safety button Smart key Location Name Symbol Description Press and hold the Parking/View button to turn on Parking/View Remote Smart Parking Assist. Also, Forward/Reverse ā button Parking Distance warning will automatically turn on. Inside vehicle Press the Parking Safety button while Remote Smart...
  • Page 504 Driver Assistance System Remote Operation Method (2): Using the function with vehicle on Operating order • Park the vehicle in front of the space Remote Operation operates in the where you want to use Remote following order: Operation function, and shift the gear to P (Park).
  • Page 505 2. Remotely moving forward and Information backward • Check that all smart keys are outside the vehicle when using Remote Operation function. • Remote Operation function will operate only when the smart key is within 4 m (13 ft.) from the vehicle. If there is no vehicle movement even when the Forward or Backward button is pressed on the smart key, check the distance to...
  • Page 506 Driver Assistance System Remote Operation function operation WARNING status • When using Remote Operation Hazard function, make sure that all passengers Operation Smart key LED warning have gotten out of the vehicle. status light • If the vehicle's battery is discharged or Remote Smart Parking Assist Green LED Under...
  • Page 507 How to turn off Remote Operation function The function will cancel in the following while operating conditions when: When Remote Operation function is • Press the Parking/View (ā) button while the infotainment system guides canceled, the vehicle will automatically the driver using method 2. stop, shift the gear to P (Park) and engage EPB (Electronic Parking Brake).

  • Page 508: Remote Smart Parking Assist Malfunction And Limitations

    Remote Smart Parking Assist standby Parking Assist, and we recommend that your vehicle be inspected by an When "Parking Assist Conditions Not authorized HYUNDAI dealer. Met" message appears when Parking/View (ā) button has been pressed and held while Remote Smart Parking Assist is in standby.
  • Page 509 Limitations of Remote Smart Parking • The road is slippery Assist • The parking space is near a vehicle with In the following circumstances, Remote higher ground clearance or big, such as Smart Parking Assist performance to park a truck, etc. or exit the vehicle may be limited, there •...
  • Page 510 Driver Assistance System • Parking on inclines • Parking behind a truck 2C_RSPAParkingInclineInfo 2C_RSPAParkingBehindTruckInfo Park manually when parking on Do not use Remote Smart Parking inclines. Assist around vehicles with higher ground clearance, such as a bus, truck, • Parking on uneven road etc.
  • Page 511 • Parking in a parking space with a • Parking in snow vehicle on one side only 2C_RSPAParkingInSnowInfo 2C_RSPAParkingWithSideVehicleInfo Snow may interfere with sensor If Remote Smart Parking Assist is used, operation, or Remote Smart Parking when parking in a parking space with a Assist may cancel if the road is slippery vehicle only on one side, your vehicle while parking.
  • Page 512 We long time, the operation of Remote recommend that your vehicle be Smart Parking function may be delayed inspected by an authorized HYUNDAI or canceled depending on vehicle dealer. condition. • Noise may be heard when braking...

  • Page 513: Front Radar

    Declaration of conformity Rear corner radar The radio frequency components if equipped complies: • For Europe and CE certified countries Front radar The radio frequency components complies: • For Europe and other Europe territories 2C_DeclarationOfConformityRearRadar_EEE • For Japan 2C_DeclarationOfConformityFrontRadar_EU 2C_DeclarationOfConformityRearRadar_JPN •...
  • Page 514 Driver Assistance System • For Gana • For Paraguay 2C_DeclarationOfConformityRearRadar_GHA • For Singapore 2C_DeclarationOfConformityRearRadar_PRY 2C_DeclarationOfConformityRearRadar_SGP • For Oman • For United Arab Emirates 2C_DeclarationOfConformityRearRadar_ARE • For Morocco 2C_DeclarationOfConformityRearRadar_OMN • For Republic of South Africa 2C_DeclarationOfConformityRearRadar_MAR • For Zambia 2C_DeclarationOfConformityRearRadar_ZAF 2C_DeclarationOfConformityRearRadar_ZMB 7-166...
  • Page 515 • For Senegal • For Serbia 2C_DeclarationOfConformityRearRadar_SEN • For Jordan 2C_DeclarationOfConformityRearRadar_JOR • For Australia 2C_DeclarationOfConformityRearRadar_SRB • For Nigeria 2C_DeclarationOfConformityRearRadar_AUS • For United Kingdom 2C_DeclarationOfConformityRearRadar_NGA • For Malaysia 2C_DeclarationOfConformityRearRadar_GBR 2C_DeclarationOfConformityRearRadar_MYS 7-167...
  • Page 516 Driver Assistance System • For Pakistan • For Indonesia 2C_DeclarationOfConformityRearRadar_PAK • For Israel 2C_DeclarationOfConformityRearRadar_IDN 2C_DeclarationOfConformityRearRadar_ISR • For Mexico 2C_DeclarationOfConformityRearRadar_MEX 7-168...
  • Page 517 • For Taiwan • For Brazil 2C_DeclarationOfConformityRearRadar_BRA • For Philippines 2C_DeclarationOfConformityRearRadar_PHL 2C_DeclarationOfConformityRearRadar_TWN 7-169...
  • Page 518 Driver Assistance System • For Thailand • For Ukraine 2C_DeclarationOfConformityRearRadar_THA 2C_DeclarationOfConformityRearRadar_UKR • For China 2C_DeclarationOfConformityRearRadar_CHN 7-170...
  • Page 519 8. Emergency situations Hazard warning flasher ....................8-2 In case of an emergency while driving ................8-2 If the vehicle stalls while driving................. 8-2 If the vehicle stalls at a crossroad or crossing ............8-2 If you have a flat tire while driving................8-3 If the vehicle does not start ....................8-3 Confirm the EV battery is not low on the charge gauge...........8-3 Jump starting (12 V battery)....................8-4...

  • Page 520: Hazard Warning Flasher

    The hazard warning flasher serves as a that you contact an authorized warning to other drivers to exercise HYUNDAI dealer or seek other qualified extreme caution when approaching, assistance. overtaking, or passing your vehicle.

  • Page 521: If You Have A Flat Tire While Driving

    If the vehicle does not If you have a flat tire while driving start If a tire goes flat while you are driving: • Take your foot off the accelerator pedal Confirm the EV battery is not and let the vehicle slow down while driving straight ahead.

  • Page 522: Jump Starting (12 V Battery)

    Emergency situations Jump starting (12 V Hydrogen gas is always present in battery cells. It is highly combustible, and may battery) explode if ignited. Ĝ Jump starting can be dangerous if done incorrectly. Follow the jump starting procedure in this section to avoid serious injury or damage to your vehicle.
  • Page 523 Jump starting procedure • Never attempt to recharge the battery when the vehicle’s battery cables are Information connected to the battery. • The electrical ignition system works When you jump start your vehicle, use the with high voltage. jumper terminal in the motor compartment.
  • Page 524 We 9.Connect the second jumper cable to recommend that your vehicle be the black, negative (-) battery/jumper inspected by an authorized HYUNDAI terminal of the assisting vehicle (3). dealer. Disconnect the jumper cables in the exact reverse order you connected them: 1.

  • Page 525: Tire Pressure Monitoring System (Tpms)

    Tire pressure monitoring 2. Disconnect the other end of the jumper cable from the black, negative (-) system (TPMS) battery/jumper terminal of the assisting vehicle (3). 3. Disconnect the second jumper cable from the red, positive (+) battery/jumper terminal of the assisting vehicle (2).

  • Page 526: Resetting Tpms

    Emergency situations Resetting TPMS The Tire Pressure Monitoring System (TPMS) determines whether the tire To reset TPMS: pressure is low through sensors in the 1. Adjust all tire pressure to the wheel, which detects changes in tire recommended tire inflation pressures. radius and vibration while driving.

  • Page 527: Low Tire Pressure Light

    5. Check whether the "Standard tyre CAUTION pressures saved" message appears on the cluster and the L warning light • Be sure to reset after the inflation blinks for about 4 seconds. pressure of all four tires are set to the recommended inflation pressure.
  • Page 528 When an authorized HYUNDAI dealer is not nearby, stop at a safe place and check • The Low Tire Pressure warning light the condition and inflation pressure of all may illuminate when the TPMS is not four tires, then reset the TPMS.

  • Page 529: Tpms Malfunction Indicator

    TPMS is reset, we recommend apply the brakes gradually with light that your vehicle be inspected by an force, and slowly move to a safe authorized HYUNDAI dealer as soon as position off the road. possible. If there is a malfunction with the TPMS, the under-inflated tire cannot be detected.

  • Page 530: If You Have A Flat Tire (With Tire Mobility Kit)

    For this reason, you should avoid abrupt the tire we recommend the tire be steering or other driving maneuvers, inspected by an authorized HYUNDAI especially if the vehicle is heavily loaded dealer or the equivalent approved for or if a trailer is in use.

  • Page 531: Notes On The Safe Use Of The Tire Mobility Kit

    • If the tire cannot be made roadworthy with the Tire Mobility Kit, we recommend that you contact an authorized HYUNDAI dealer. • Do not use the Tire Mobility Kit if a tire is severely damaged by driving run flat or with insufficient air pressure.

  • Page 532: Components Of The Tire Mobility Kit

    Emergency situations Components of the Tire Mobility Kit 1C_TMKPartsOverview (1) Speed-restriction label (2) Sealant bottle and label with speed restriction (3) Filling hose (4) Connectors and cable for the power outlet direct connection (5) Holder for the sealant bottle (6) Compressor (7) ON/OFF switch (8) Pressure gauge for displaying the tire inflation pressure (9) Deflation valve to reduce the tire inflation pressure...

  • Page 533: Using The Tire Mobility Kit When A Tire Is Flat

    1. Shake the sealant bottle (2). WARNING Sealant • Keep out of reach of children. • Avoid contact with eyes. • Do not swallow. Using the Tire Mobility Kit When a tire is flat 2C_TMKprocedure CAUTION 2. Remove the sealant bottle (2) cap and open the sealant bottle holder (5) cap and screw the bottle onto the sealant bottle holder.
  • Page 534 Emergency situations 4. Unscrew the valve cap and screw the CAUTION filling hose (3) onto the tire valve. Tire pressure Do not attempt to drive your vehicle if the tire pressure is below 200 kPa (29 psi). This could result in an accident due to sudden tire failure.
  • Page 535 Then repeat steps 10 to 13. Use of the TMK may be ineffectual for tire damage larger than about 4 mm (0.16 in.). We recommend that you contact an authorized HYUNDAI dealer if the tire cannot be made roadworthy with the Tire Mobility Kit. WARNING 2C_TMKprocedure_6 12.Plug the compressor power cord into...

  • Page 536: How To Adjust Tire Pressure

    Emergency situations How to adjust tire pressure Information • The pressure gauge may show higher than actual reading when the compressor is running. To get an accurate tire reading, the compressor needs to be turned off. • When reinstalling the repaired or replaced tire and wheel on the vehicle, tighten the wheel lug nut to 11-13kgf·m (79-94 lbf·ft).

  • Page 537: Towing

    If emergency towing is necessary, we 2C_TowingBad recommend having it done by an • Do not tow vehicles with sling-type authorized HYUNDAI dealer or a equipment. Only use wheel lift or commercial tow-truck service. flatbed equipment. Proper lifting and towing procedures are necessary to prevent damage to the vehicle.

  • Page 538: Removable Towing Hook

    Emergency situations Removable towing hook Precautions when moving a short distance before towing a vehicle Front Move short distances within 10 m (33 at a speed of 5 km/h (3 mph) or less only when loading on a tow truck or if the vehicle needs to be repositioned.

  • Page 539: Emergency Situations

    If there is small fire and you know how to NOTICE use the fire extinguisher, follow these steps carefully. Failure to properly tighten the towing hook may result in vehicle damage and 1. Pull out the safety pin at the top of the deformation of related parts.

  • Page 540: Tire Pressure Gauge

    For your safety we recommend to call the fire station and or contact an authorized HYUNDAI dealer. • When the fire spread to the high voltage battery, the additional fire may occur. In this situation, be sure to accompany a fire truck when the vehicle is being towed.

  • Page 541: Pan-European Ecall System (For Europe)

    Pan-European eCall System (for Europe) if equipped The vehicle is equipped with a device connected with the Pan-European eCall system for making emergency call to response teams. The Pan-European eCall system is an automatic emergency call service made in event of a traffic accident or other accidents on the roads of Europe.
  • Page 542 Emergency situations Information Pan-European eCall device in the Owner’s Manual means equipment, installed in the vehicle, which provides connection with the Pan-European eCall system. “Other accidents” mean any accidents on the roads of Europe (only in countries with regulation on this system) resulted in injured people and/or necessity of provision of assistance.
  • Page 543 Description of the eCall in-vehicle system (for Europe) 1C_eCall_2 (1) SOS Button (2) Crash signal (3) Emergency Call System (4) Antenna (5) Mic (6) Speaker (7) LEDs 1C_eCall_2 Overview of the 112-based eCall in-vehicle system, its operation and functionalities: refer to this section.

  • Page 544: Information On Data Processing (For Europe)

    Emergency situations Information on data Recipients of data processed by the 112-based eCall in-vehicle system are the processing (for Europe) relevant public safety answering points Any processing of personal data through designated by the respective public the 112-based eCall in-vehicle system authorities of the country on which shall comply with the personal data territory they are located, to first receive...
  • Page 545 Arrangements for data processing Modalities for exercising data subject’s rights The 112-based eCall in-vehicle system is designed in such a way as to ensure that The data subject (the vehicle’s owner) has the data contained in the system memory a right of access to data and as is not available outside the system before appropriate to request the rectification, an eCall is triggered.

  • Page 546: Pan-European Ecall System (For Europe)

    Emergency situations Pan-European eCall System (for Europe) 2C_eCallSOSButton Elements of the Pan-European eCall system, installed in passenger compartment: (1) SOS button (2) LED SOS button: the driver/passenger makes an emergency call to the single duty dispatch service by pressing the button. LED: The LED illuminates for 3 seconds when the Start/Stop button is in the ON position.
  • Page 547 Automatic accident reporting (for Europe) 1C_eCall_3 The Pan-European eCall device automatically makes an emergency call to the Public Safety Answering Point (PSAP) for proper rescuing operations in event of vehicle accident. For proper emergency services and support the Pan-European eCall system automatically transmits the accident data to the Public Safety Answering Point (PSAP) when a traffic accident is detected.
  • Page 548 Emergency situations Manual accident reporting (for Europe) 1C_eCall_4 The driver or passenger manually can make an emergency call in the Public Safety Answering Point (PSAP), by pressing SOS button to call the necessary emergency services. A call to the emergency services through the Pan-European eCall system can be cancelled by pressing the SOS button again only before the call connection.
  • Page 549 If red LED illuminates in normal driving conditions, this can indicate malfunction of the Pan-European eCall system. We recommend to have the Pan-European eCall system checked at an authorized HYUNDAI dealer. Otherwise correct operation of the Pan-European eCall system device, installed in your vehicle is not guaranteed.
  • Page 551 9. Maintenance Motor compartment......................9-3 Maintenance services .....................9-4 Owner’s responsibility ....................9-4 Owner maintenance precautions ................9-4 Owner maintenance......................9-5 Owner maintenance schedule ..................9-6 Scheduled maintenance services................... 9-7 Normal maintenance schedule...................9-8 Normal maintenance schedule...................9-9 Maintenance under severe usage conditions............9-10 Explanation of scheduled maintenance items ............. 9-11 Cooling system......................
  • Page 552 Battery (12 V) ........................9-19 For best battery service .................... 9-20 Battery capacity label ....................9-20 Battery recharging ....................9-20 Reset items ......................... 9-21 Tires and wheels......................9-22 Tire care ........................9-22 Recommended cold tire inflation pressures ............9-22 Check tire inflation pressure..................9-23 Tire rotation .......................

  • Page 553: Motor Compartment

    Motor compartment 1C_MotorRoomOverview The actual motor compartment in the vehicle may differ from the illustration. (1) Coolant reservoir (2) Windshield washer fluid reservoir (3) Brake fluid reservoir (4) Fuse box (5) Battery (12 V) (6) Front trunk (7) Emergency cable 1C_MotorRoomOverview...

  • Page 554: Maintenance Services

    Such modifications may quality standards and receives technical adversely affect the performance, safety support from HYUNDAI in order to or durability of your vehicle and may, in provide you with a high level of service addition, violate conditions of the limited satisfaction.

  • Page 555: Owner Maintenance

    Owner maintenance The following lists are vehicle checks and inspections that should be performed by the owner or an authorized HYUNDAI WARNING dealer at the frequencies indicated to help ensure safe, dependable operation Performing maintenance work on a of your vehicle.

  • Page 556: Owner Maintenance Schedule

    Maintenance Owner maintenance schedule At least monthly: • Check coolant level in the coolant reservoir. When you stop for charging: • Check the operation of all exterior • Check the coolant level in the coolant lights, including the stoplights, turn reservoir.

  • Page 557: Scheduled Maintenance Services

    Scheduled maintenance services Follow Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply. If any of the following conditions apply, you must follow the Maintenance Under Severe Usage Conditions. • Repeated driving short distance of less than 8 km (5 mi.) in normal temperature or less than 16 km (10mi.) in freezing temperature •...

  • Page 558: Normal Maintenance Schedule

    Inspect 15,000 km (10,000 mi.) or 12 months Europe All electrical system Brake lines, hoses and connections Brake pedal Parking brake Brake fluid Brake discs and pads *1 When replacing or adding coolant, we recommend that you visit an authorized HYUNDAI dealer.
  • Page 559 Normal maintenance schedule I: Inspect and if necessary, adjust, correct, clean or replace. R: Replace or change. Number of months or driving distance, whichever comes first Months Maintenance Intervals mi.×1,000 km×1,000 Maintenance Item Steering gear rack, linkage and boots Driveshaft and boots Tire (pressure &...

  • Page 560: Maintenance Under Severe Usage Conditions

    Maintenance Maintenance under severe usage conditions The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. I: Inspect and if necessary, adjust, correct, clean or replace R: Replace Maintenance Maintenance item...

  • Page 561: Explanation Of Scheduled Maintenance Items

    Cooling system For more information on checking the Check the cooling system components, pads or lining wear limit, visit such as radiator, coolant reservoir, hoses, http://service.hyundai-motor.com and connections for leakage and damage. Replace any damaged parts. Suspension mounting bolts Coolant Check the suspension connections for looseness or damage.

  • Page 562: Coolant

    If frequent additions are required, motor automatically shuts off. This is a we recommend that your vehicle be normal condition. inspected by an authorized HYUNDAI dealer. Use only designated coolant water for electric vehicles, adding other types of water or antifreeze can damage the vehicle.
  • Page 563 1. Check if the coolant cap label is straight WARNING in front. WL_RadiatorHotWarning • Check the coolant level when the motor compartment is cooled. Coolant level is influenced by temperature, and if the 2C_CheckCoolantCapLocked coolant reservoir cap is removed when 2.

  • Page 564: Changing Coolant

    If the level is low, add the specified brake We recommend that the coolant be fluid to the MAX level. The level will fall changed by a authorized HYUNDAI dealer with accumulated kilometers. If the fluid according to the maintenance schedule.

  • Page 565: Reduction Gear Fluid

    HYUNDAI dealer. a collision. • Do not allow sparks or flame to contact the washer fluid or the washer fluid reservoir.

  • Page 566: Cabin Air Filter

    Maintenance Cabin air filter 3. Press and hold the lock on the right side of the cover. Filter inspection The cabin air filter must be replaced according to the Maintenance Schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, have it inspected more frequently and replaced immediately.

  • Page 567: Wiper Blades

    Wiper blades Front windshield wiper blade replacement This vehicle has a “hidden” wiper design Blade inspection that cannot be lifted when in their bottom resting position. Contamination of the windshield or wiper 1. Within 20 seconds after the vehicle is blades with foreign substances may turned off, push and hold the wiper reduce the effectiveness of the...
  • Page 568 Maintenance Rear window wiper blade 4. Install a new wiper blade assembly in the reverse order of removal. replacement 1. Within 20 seconds after the vehicle is turned off, push and hold the wiper lever down to the 1x position for about 2 seconds until the wipers move to the top wipe position.

  • Page 569: Battery (12 V)

    Battery (12 V) Keep batteries out of reach of children. ĝ WARNING To prevent serious injury or death to you or bystanders when working near or handling the battery: Batteries contain sulfuric acid that is Always read and follow instructions highly corrosive.

  • Page 570: For Best Battery Service

    The actual battery label in the vehicle may differ from the illustration. For best battery service 1. CMF60L-DIN: The HYUNDAI model name of battery 2. 12V: The nominal voltage 3. 60Ah (20HR): The nominal capacity (in Ampere hours) 4.

  • Page 571: Reset Items

    • Integrated memory system (refer to • We recommend that batteries are chapter 5) replaced from an authorized HYUNDAI • Power window (refer to chapter 5) dealer. • Sunroof (refer to chapter 5) • Climate control system (refer to chapter 5) •...

  • Page 572: Tires And Wheels

    Maintenance Tires and wheels Tire care For proper maintenance, safety, and WARNING maximum electric energy economy, always maintain the recommended tire Tire failure may cause loss of vehicle inflation pressures and stay within the control and result in a collision. To reduce load limits and weight distribution risk of serious injury or death: recommended for your vehicle.

  • Page 573: Check Tire Inflation Pressure

    Without the valve cap, dirt or moisture refilling, have it inspected by an may get into the valve core and cause air authorized HYUNDAI dealer. leakage. If a valve cap is missing, install a • Over-inflation produces a harsh ride, new one as soon as possible.

  • Page 574: Tire Rotation

    Maintenance Tire rotation WARNING To equalize tread wear, HYUNDAI • Do not use the compact spare tire for recommends that the tires be rotated tire rotation. every 12,000 km (7,500 mi.) or sooner if • Do not mix bias ply and radial ply tires irregular wear develops.

  • Page 575: Tire Replacement

    Replacing just one tire may seriously affect your vehicle’s handling. • Tires degrade over time, even when they are not being used. Regardless of the remaining tread, HYUNDAI recommends that tires be replaced after 6 years. • Driving in hot climates or excessive...

  • Page 576: Wheel Replacement

    Maintenance Wheel replacement Tire sidewall labeling When replacing the metal wheels for any This information identifies and describes reason, make sure the new wheels are the fundamental characteristics of the equivalent to the original factory units in tire and also provides the tire diameter, rim width, and offset.
  • Page 577 235/45 R19 99V Tire speed ratings 235: Tire width in millimeters. The chart below lists many different speed ratings currently being used for 45: Aspect ratio. The tire’s section height passenger vehicle tires. The speed rating as a percentage of its width. is part of the tire size designation on the R: Tire construction code (Radial).
  • Page 578 Maintenance 4. Tire ply composition and material 7. Uniform tire quality grading The number of layers or plies of Quality grades can be found where rubber-coated fabric in the tire. Tire applicable on the tire sidewall between manufacturers also must indicate the tread shoulder and maximum section materials in the tire, which include steel, width.

  • Page 579: Low Aspect Ratio Tires

    Grades B and A represent higher contact your authorized HYUNDAI levels of performance on the laboratory dealer to replace the tire test wheel than the minimum required by law.

  • Page 580: Fuses

    If the replacement fuse blows, this indicates an electrical problem. Avoid using the system involved and we recommend that you contact an authorized HYUNDAI dealer. WARNING 2C_FuseType_2 Never replace a fuse with anything but another fuse of the same rating.

  • Page 581: Instrument Panel Fuse Replacement

    If it is not tight, we recommend that you 1. Turn off the vehicle. contact an authorized HYUNDAI dealer. 2. Turn off all other switches. In an emergency, if you do not have a 3. Open the fuse panel cover.

  • Page 582: Motor Compartment Panel Fuse Replacement

    3. Remove the fuse panel cover by If the multi fuse or midi fuse is blown, pressing the tap and pulling up. contact an authorized HYUNDAI dealer. 4. Refer to the label on the inside of the fuse panel cover to locate the suspected fuse location.

  • Page 583: Fuse/Relay Panel Description

    Fuse/relay panel description Instrument panel fuse panel 2C_InstrumentPanelFuseLabel Inside the fuse panel cover, you can find the panel label describing fuse names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle. When you inspect the fuse panel on your vehicle, refer to the fuse panel label.
  • Page 584 Maintenance Instrument panel fuse panel Fuse Fuse name Symbol Circuit protected rating BATTERY BMS Control Module MANAGEMENT Rain Sensor, Data Link Connector, Hazard Switch, MODULE 9 10 A MODULE 10 10 A In Cabin Camera (ICC) Unit 15 A Driver Power Outside Mirror, Driver door Module Passenger Power Seat Switch, Passenger Relax P/SEAT PASS 30 A...
  • Page 585 Fuse Fuse name Symbol Circuit protected rating MODULE 7 7.5 A WASHER 15 A Multifunction Switch MODULE 6 7.5 A BRAKE SWITCH 7.5 A BDC, Stop Lamp Switch 10 A CCU (Central Communication Unit) TAILGATE OPEN 10 A Tailgate Relay AIR BAG 2 10 A SRS Control Module...
  • Page 586 Maintenance Fuse Fuse name Symbol Circuit protected rating SUNROOF 20 A Sunroof Blind Motor, Sunroof Glass Motor WIPER FRT 2 7.5 A BDC, Wiper LOW Relay START 7.5 A BDC, VCU BDC 2 7.5 A MODULE 5 10 A Crash Pad Switch, Headlight (Right, Left) Driver Door Module, Smartphone Wireless MODULE 3 10 A...
  • Page 587 Motor compartment fuse panel (Motor compartment junction block) 2C_EngineFuseLabel Inside the fuse panel cover, you can find the panel label describing fuse names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle. When you inspect the fuse panel on your vehicle, refer to the fuse panel label.
  • Page 588 Maintenance Motor compartment fuse panel (Motor compartment junction block) Fuse Type Fuse name Symbol Circuit protected rating MDPS 1 80 A MDPS Unit MULTI Motor Room Junction Block FUSE-1 180 A (FUSE-MODULE 3, WASHER, AIR BAG 2, BDC 1) COOLING 80 A Cooling Fan Controller FAN 1...
  • Page 589 Fuse Type Fuse name Symbol Circuit protected rating 60 A PCB Block (IG3 Main Relay, Wiper Front 60 A Relay, HEATED MIRROR) PDC (FUSE-BATTERY MANAGEMENT, P/WINDOW DRV, MODULE 9, E-SHIFTER 3, 60 A MODULE 10, DDM, ADM, P/SEAT PASS, S/HEATER FRT, P/WINDOW RH, P/SEAT DRV, P/WINDOW RH) IEB 1 60 A...
  • Page 590 Maintenance Fuse Type Fuse name Symbol Circuit protected rating PDC (Fuse-BRAKE SWITCH, CCU, 60 A TAILGATE OPEN, BDC 1, DOOR LOCK, S/HEATER RR) A/C 1 15 A A/C Control Module CHARGER 2 10 A Motor Room Junction Block CHARGER 1 15 A Charging Door Module Electronic Water Pump #1 (High Voltage...
  • Page 591 Motor compartment fuse panel (PCB block) Fuse Fuse Name Symbol Circuit Protected Rating POWER 20 A Power Outlet OUTLET WIPER FRT 1 30 A PCB Block (Wiper Front Low Relay), Front Wiper Motor IG3 3 15 A Inverter, VCU IG3 4 15 A EWP 2 20 A...

  • Page 592: Light Bulbs

    Light bulbs Information We recommend that you contact an This vehicle may be equipped with authorized HYUNDAI dealer to replace desiccant to reduce fogging inside the most vehicle light bulbs. It is difficult to headlight due to moisture. The desiccant...

  • Page 593: Headlight, Position Light, Turn Signal Light, Daytime Running Light (Drl) Replacement

    If the light Type A goes out, or continues to flicker, we recommend that you have the system inspected by an authorized HYUNDAI dealer. • The position light may not turn on when the position light switch is turned on,...
  • Page 594 If the turn signal light does not operate, we recommend that you have the system inspected by an authorized HYUNDAI dealer. Alternatively you can follow the below process (if available). 1. Apply the parking brake and turn off the vehicle.

  • Page 595: Headlight Aiming (For Europe)

    If the LED light does not operate, we and tools. recommend that you have the system 2. The vehicle should be placed on a flat inspected by an authorized HYUNDAI floor. dealer. 3. Draw vertical lines (vertical lines The LED light cannot be replaced as a passing through respective headlamp single unit.
  • Page 596 Maintenance Aiming point 1C_AimingPoint (1) H1: Height between the headlight center and ground (Low beam) (2) H2: Height between the headlight center and ground (High beam) (3) W1: Distance between the two headlights centers (Low beam) (4) W2: Distance between the two headlights centers (High beam) Vehicle condition Lamp type Type A...
  • Page 597 Headlight low beam Type A 1C_HeadLampLowBeamLHD 9-47...
  • Page 598 Maintenance Type B 1C_HeadLampLowBeamRHD (1) Vertical line of the left headlight bulb center (2) Car axis (3) Vertical line of the right headlight bulb center (4) cut-off line of left headlamp (5) cut-off elbow of left headlamp (6) cut-off line of right headlamp (7) cut-off elbow of right headlamp (8) W1 (Low beam) (9) H1 (High beam)

  • Page 599: Side Repeater Light Replacement

    2C_SideRepeaterLamp If the side repeater light (1) does not operate, we recommend that the system be inspected by an authorized HYUNDAI dealer. The LED light cannot be replaced as a single unit. A skilled technician should check or repair the LED light, for it may damage related parts of the vehicle.

  • Page 600: Interior Light Replacement

    Maintenance Interior light replacement Vanity mirror lamp Map lamp, room lamp, vanity mirror lamp, glove box lamp, mood lamp, and cargo area lamp (LED type) Map lamp 2C_SunvisorLampLED Glove box lamp 2C_MapLampLED Room lamp 2C_GloveBoxLampLED Mood lamp (Open tray (1), Front seat door (2)) 2C_RoomLampLED 2C_MoodLampLED 9-50...
  • Page 601 2C_MapLampBulb Room lamp 2C_LuggageRoomLampLED If the LED lamp does not operate, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer. 2C_RoomLampBulb The LED light cannot be replaced as a single unit. A skilled technician should Vanity mirror lamp check or repair the LED light, for it may damage related parts of the vehicle.

  • Page 602: Appearance Care

    Maintenance Appearance care Cargo area lamp Exterior care NOTICE If you park your vehicle near a stainless steel sign or glass facade building, the vehicle’s exterior plastic parts such as a bumper, spoiler, garnish, lamp or outside rearview mirror might be damaged due to 2C_LuggageRoomLampBulb sunlight reflected from the sign or Glove box lamp...
  • Page 603 Finish maintenance NOTICE Washing • Do not use strong soap, chemical detergents, or hot water, and do not To help protect your vehicle’s finish from wash the vehicle in direct sunlight or rust and deterioration, wash it thoroughly when the body of the vehicle is warm. and frequently at least once a month with lukewarm or cold water.
  • Page 604 Maintenance NOTICE NOTICE Matte paint finish vehicle (if equipped) • Do not wipe dust or dirt off the body with a dry cloth to prevent scratching To prevent damage the matte finish: the finish. • Do not go through an automatic car •...
  • Page 605 If the vehicle is damaged and painting is required, we Aluminum wheel maintenance recommend that you contact an authorized HYUNDAI dealer. The aluminum wheels are coated with a clear protective finish. • Do not use abrasive cleaner, polishing...
  • Page 606 By using the most advanced design and example, corrosion is accelerated by high construction practices to combat humidity, particularly when temperatures corrosion, HYUNDAI produces vehicles of are just above freezing. In such the highest quality. However, this is only conditions, the corrosive material is kept in contact with the vehicle surfaces by part of the job.

  • Page 607: Interior Care

    To help prevent corrosion Keep paint and trim in good condition Keep your vehicle clean Scratches or chips in the finish must be covered with “touch-up” paint as soon as The best way to prevent corrosion is to possible to reduce the possibility of keep your vehicle clean and free of corrosion.
  • Page 608 Maintenance Leather (if equipped) Cleaning the upholstery and interior trim • Features of seat leather - Leather is made from the outer skin Vehicle interior surfaces (if equipped) of an animal, which goes through a Remove dust and loose dirt from interior special process to be available for surfaces with a whisk broom or a vacuum use.
  • Page 609 Cleaning the seat belt webbing • Caring for the leather seats - Vacuum the seat periodically to Clean the belt webbing with any mild remove dust and sand on the seat. It soap solution recommended for cleaning prevents abrasion or damage of the upholstery or carpet.
  • Page 611 Appendix Vetrarakstur (íslenskur) ....................A-2 Snjór eða hálka ......................A-2 Barnaöryggisbúnaður (CRS) (ÍSLENSKA)...............A-4...
  • Page 612 úr skugga Vertu alltaf með neyðarbúnað. um að fylgja meðfylgjandi leiðbeiningum Hjólbarðakeðjur, dráttarólar eða keðjur, og aðeins nota ekta HYUNDAI varahluti. vasaljós, neyðarblys, sandur, skófla, Ef þú notar dekkjakeðjur rangt og veldur snúrur, rúðusköfu, hanskar, moldklæði, skemmdum á bílnum þínum mun yfirklæði, teppi og svo framvegis geta allt...
  • Page 613 ATHUGIÐ Upplýsingar Ekki setja á nagladekk án þess að athuga Við meðhöndlun hjólbarðakeðja: fyrst svæðisbundnar og landsbundnar • Skemmdir á bremsulínum, fjöðrun, reglur um takmarkanir á notkun þeirra. yfirbyggingu og hjólum ökutækisins geta stafað af því að keðjur eru notaðar af rangri stærð...
  • Page 614 Appendix Barnaöryggisbúnaður (CRS) (ÍSLENSKA) Hentugur hvers sætis fyrir belti og ISOFIX barnaöryggisbúnað samkvæmt reglum Sameinuðu þjóðanna (fyrir Evrópu). (Upplýsingar fyrir notendur ökutækja og CRS framleiðendur) • Já : Hentar fyrir búnað af tilnefndri CRS röð. • Nei: Ekki hægt að aðlaga að tilgreindum CRS flokki. •...
  • Page 615 Sætisnúmer Staðsetning í ökutækinu Sætisstaðir Framan til vinstri Miðja fram Á undan til hægri 2. röð til vinstri 2. röð miðja 2. röð til hægri Upplýsingar • Þegar CRS er sett upp getur verið nauðsynlegt að stilla eða fjarlægja höfuðpúða sætisins ef það...
  • Page 616 Appendix Ráðlagður aðhaldsbúnaður fyrir barna (fyrir Evrópu) Hæð barns eða Tegund CRS tegundarheiti viðurkenningarn massahópur Framleiðandi festingar úmer BABY-SAFE 3 i-SIZE ISOFIX með E1*129R03/04*0 40-83 cm Britax Romer með FLEX BASE stuðningsvöggu, i-Sense afturvísandi ISOFIX festur 76-105 cm Britax Romer Trifix 2 i-stærð...
  • Page 617 Index...
  • Page 618 Index About "Getting started with your electric vehicle" ..............1-4 Accessing your vehicle ....................... 5-6 Immobilizer system ........................5-11 Smart key ............................ 5-6 Active air flap ..........................6-44 Malfunction ..........................6-44 Active sound design ........................6-45 Air conditioner compressor label .................... 2-20 Air conditioning system ......................
  • Page 619 Blind-Spot View Monitor (BVM) ....................7-73 Blind-Spot View Monitor malfunction ..................7-74 Blind-Spot View Monitor operation ..................7-74 Blind-Spot View Monitor settings ....................7-73 Brake fluid ...........................9-14 Checking the brake fluid level ....................9-14 Braking system .......................... 6-26 Anti-Lock Brake System (ABS) ....................6-33 Auto Hold ...........................6-31 Brake Assistant System (BAS) ....................6-40 Brake Disc Cleaning ........................
  • Page 620 Index Coolant ............................9-12 Changing coolant ........................9-14 Countermeasures for accidents or fire ..................1-64 If the electric vehicle catches fire ....................1-64 If the electric vehicle is submerged ..................1-64 If the electric vehicle needs towing ..................1-65 Other precautions for electric vehicle accidents ..............1-66 Cruise Control (CC) ........................
  • Page 621 Explanation of scheduled maintenance items ............... 9-11 Air conditioning refrigerant ....................... 9-11 Brake discs, pads, calipers and rotors ..................9-11 Brake fluid ..........................9-11 Brake hoses and lines ........................ 9-11 Coolant ............................9-11 Cooling system .......................... 9-11 Drive shafts and boots ......................9-11 Reduction gear fluid ........................
  • Page 622 Highway Driving Assist settings .....................7-106 Hood ............................5-46 Closing the hood ........................5-47 Opening the hood ........................5-46 Hyundai Digital Key ........................5-12 Digital key (Card key) ........................ 5-17 Digital key (smartphone) ......................5-12 Limitations of the system ......................5-20 Used vehicle/Digital key maintenance ................... 5-20 If the vehicle does not start .......................
  • Page 623 Infotainment system ........................5-107 Antenna ........................... 5-108 Bluetooth® wireless technology .................... 5-109 Infotainment system ......................5-109 Steering wheel remote controls .................... 5-108 USB Port ...........................5-107 Voice recognition ........................5-109 Instrument cluster ........................4-2 Cluster display messages ......................4-19 Gauges and meters ........................4-3 Instrument cluster control ......................
  • Page 624 Index Jump starting (12 V battery) ....................... 8-4 Lane Following Assist (LFA) .....................7-101 Lane Following Assist malfunction and limitations .............. 7-104 Lane Following Assist operation ..................... 7-102 Lane Following Assist settings ....................7-102 Lane Keeping Assist (LKA) ......................7-30 Lane Keeping Assist malfunction and limitations ..............7-34 Lane Keeping Assist operation ....................7-32 Lane Keeping Assist settings ....................
  • Page 625 Pan-European eCall System (for Europe) ................8-23 Information on data processing (for Europe) ................. 8-26 Pan-European eCall System (for Europe) ................8-28 Power tailgate ..........................5-50 Emergency tailgate safety release ..................5-54 Operating the power tailgate ....................5-51 Power tailgate operating conditions ..................5-50 Resetting the power tailgate ....................
  • Page 626 Index Safe Exit Warning (SEW) ......................7-48 Safe Exit Warning malfunction and limitations ............... 7-51 Safe Exit Warning operation ....................7-50 Safe Exit Warning settings ....................... 7-49 Scheduled maintenance services ....................9-7 Maintenance under severe usage conditions .................9-10 Normal maintenance schedule ..................9-8, 9-9 Seat belts .............................
  • Page 627 Steering wheel ........................... 5-29 Haptic warning/Steering wheel vibration warning ..............5-32 Horn ............................5-32 Motor Driven Power Steering (MDPS) ..................5-29 Steering wheel heater ....................... 5-31 Tilt/Telescopic steering ......................5-30 Steering wheel control overview .....................2-10 Storage compartment ......................5-94 Center console storage ......................5-95 Glove box ..........................
  • Page 628 Index Understanding your electric vehicle ..................1-5 Characteristics of your electric vehicle ..................1-5 Other precautions for electric vehicle management ..............1-8 Precautions when using the high voltage battery ..............1-7 Using Electric Vehicle functions ....................1-30 Checking energy information ....................1-32 Checking the Electric Vehicle screen configuration ...............1-30 Setting a battery discharging limit when using Vehicle to Load (V2L) ........
  • Page 629 Washer fluid ..........................9-15 Checking the washer fluid level ....................9-15 Wide sunroof ..........................5-42 Automatic reversal ........................5-44 Power sunshade ........................5-43 Resetting the sunroof ....................... 5-45 Slide open/close ........................5-44 Sunroof open warning ......................5-46 Tilt open/close .......................... 5-43 Windows ............................. 5-38 Power windows .........................
  • Page 631 MATTE COLOR VEHICLE OWNER'S MANUAL Remark Div. Manual Hand wash using soft textile (Microfiber tower, Ÿ sponge) is recommended → When soap foaming cleaning, using wash pad sponge is recommended → When swipe out the water, using microfiber towel is recommended Microfiber Towel (O) ▶...

Table of Contents
