Summary of Contents for JXCT JX-TWV-PL
- Page 1 DN50 pulse solenoid valve instruction manual JX-TWV-PL Ver1.0 No. 1Page...
-
Page 2: Chapter 1 Product Introduction
Chapter 1 Product Introduction 1.1 Product overview Pulse solenoid valve is a pulse signal control fluid flow automation basic components, used in industrial control systems to adjust the direction of the medium, traffic . The pilot pulse solenoid valve changes the upper and lower pressure difference of the diaphragm by controlling the amount of water entering the upper and lower pressure of the diaphragm, and the diaphragm is deformed under the action of the pressure difference to realize the... - Page 3 temperature Diaphragm EPDM rubber (EPDM) material ≤ 50cSt Liquid medium 0-0.7MPA Pressure range Pilot Type principle No. 3Page...
- Page 4 第 2 章 Hardware connection 2.1 Equipment installation inspection Check the equipment list before installing the equipment: Name Quantity Pulse solenoid valve Warranty 1 serving Card/Certificate 2.2 Product structure No. 4Page...
- Page 5 Name Description Manual limit Regulating valve opening handle closing height control valve flow rate Knob switch The switch valve manually controlled, or it can be switched to pulse control Electromagne Pulse electromagnetic head, tic head receiving pulse signal, control valve opening and closing Manual For the pulse solenoid...
- Page 6 OPEN-manual CLOSE-manual off, AUTO-pulse control status 2.3 Product size 2.4 Installation and usage items 1. The installation direction is marked on the valve. As No. 6Page...
- Page 7 shown in the figure, if the installation is wrong, the actual control effect of the electromagnetic head knob switch will be opposite to the logo. 2. The valve needs to add a filter or debris filter device before entering the water to prevent the impact of debris in the liquid on the diaphragm impact damage or debris blocking the water inlet hole, endangering the safety of the valve.
- Page 8 power supply must be cut off. 7. Manual shut-off valves should be added before and after the solenoid valve, and a bypass should be provided to facilitate the maintenance of the solenoid valve in the event of failure, as shown in the figure below. No.
