Darfon B259-201 User Manual

SPECIFICATION
Model Name
Input Voltage
Output Voltage
Charging mode
CHARGING LED INDICATION
State
Battery unconnected
Initial pre-charge
Battery Capacity < 20%
Battery Capacity 20~39%
Battery Capacity 40~59%
Battery Capacity 60~79%
Battery Capacity >= 80%
Charge completed
Battery failure / Charger failure
LED is flashing
CHARGER OPERATING TEMPERATURE/HUMIDITY RANG
Operating
Non- Operating
TROUBLESHOOTING
When getting through AC power, please check the power LED
lighted "Green" first(not plug-in Battery yet), If power LED not
lighted "Green":
When getting through AC power, and the power LED lighted
"Green", then plug-in Battery, if power LED is Blinking Orange or
Green, please check:
Battery Charger
B259-201
AC100-240V
DC18-42V
Constant Power
-10 to 40 ℃
5 to 95 %RH
-20 to 65 ℃
5 to 95 %RH
50/60Hz
5.6A(168W Max.)
Red LED
Please confirm the AC power cord is well connected or not.
After check AC power cord is well, and LED still not lighted
"Green", please send back to repair.
If the output plug is well connected or is it with reverse polarity?
Please confirm the connection of the connector
If the battery is out of use? Please replace of the new battery.
If the charger broken?
Please send back to repair.
Please remove AC power and plug-in again if LED lighted Orange
blinking. However, if the LED Orange blinking symptom was still
occurred after doing charger reset, please return to the supplier.
Please avoid to plug in & out quickly in turns.
Green LED Orange LED
User's Manual
