Summary of Contents for uniview technologies MW35-U-CE Series
- Page 1 Smart Interactive Display (Wireless Module) Quick Guide V1.01...
-
Page 2: Safety Instructions
Safety Instructions The device must be installed, serviced, and maintained by a trained professional with necessary safety knowledge and skills. Be sure to read this manual carefully before use and strictly comply with this manual during operation. ⚫ Make sure the power supply meets the requirements indicated on the device, and the supply voltage is stable. -
Page 3: Packing List
Packing List Contact your local dealer if the package is damaged or incomplete. The package contents may vary with device model. Name Unit Smart interactive display Wireless module Power cable Touch pen Remote control Wall mount bracket Product documents Product Overview This guide is intended for multiple device models. - Page 4 Figure 3-2 Rear View 1. Front interfaces 2. Touch pen slot 3. Speaker 4. Front buttons 5. Mount bracket hole 6. Module connector 7. Handle 8. OPS PC slot 9. Side interfaces 10. Bottom interfaces 11. Wireless module slot 12. Power interface 3.2 Interfaces/Buttons Figure 3-3 Front Interface/Buttons Item...
- Page 5 Item Description Press and hold for more than 5 seconds to reset Android system RESET to the default factory settings. USB interface, connects to a USB device such as USB flash drive USB3.0 (used to receive files), keyboard and mouse (used to control the 1/2/3 display).
- Page 6 Item Description Power button, when the device is powered on but not started, press the button to start the device; when the device is operating, press the button to select the power status. You can check the device status through the indicator. Red: The device is powered on but not started.
- Page 7 Item Description Connects to the same video source device with video input ⚫ interfaces, such as PC, for touch control. Connects to an external device, which can use the display’s ⚫ USB2.0 device (USB flash drive, camera, MIC, etc). Gigabit Ethernet port, connects to a LAN device such as switch for LAN IN network access.
-
Page 8: Wireless Module
Item Description DP video input interface, connects to a video source device for DP IN video signal input. TF card slot, used to insert a TF card to expand the display’s TF CARD storage capacity. Analog audio input/output interface, connects to headphones, EARPHONE microphones, etc. -
Page 9: Remote Control
⚫ Wi-Fi module: Wi-Fi 6 + Wi-Fi 5; Wi-Fi 6 for uplink routing, Wi-Fi 5 serves as a hotspot, supports 2.4 and 5 GHz. ⚫ Bluetooth module: Integrated with Wi-Fi 6 module, built-in antenna, supports Bluetooth 5.2 protocol. Align and insert the wireless module into the PCIE slot at the bottom of the device. The wireless module supports hot-plug. -
Page 10: Bracket Installation
Button Description Diagram PLAN Reserved. Reserved. Installation 4.1 Bracket Installation The device supports wall installation and floor installation. You can use the included wall mount bracket to fix the device to the wall, or purchase our mobile stands. See the corresponding documents for details. 4.2 Cable Connection Connect cables and other devices as needed. -
Page 11: Troubleshooting
Icon Description Return to the home screen. View running apps and switch between them. Switch input signal sources. Set commonly used functions, network, etc. Select the power status. Various small tools, such as annotation, volume adjustment, etc. 6.2 Features Wireless screen mirroring, easy... - Page 12 Then no sound coming from the Check power button ⚫ display; the power supply display/remote control is normal. indicator is not lit. Check if the buttons cannot pop up due to Some buttons do not excessive force. Check if there is dust accumulated work.
- Page 13 Then area connection, click Properties, select Internet Protocol Version 4 (TCP/IPv4), double-click the protocol, enable Obtain an IP address automatically and Obtain DNS server address automatically. For Win10, go to Settings > Network & ⚫ Internet > Network and Sharing Center > Change adapter settings, right-click a local area connection, click Properties, select Internet Protocol Version 4 (TCP/IPv4),...
-
Page 14: Copyright Statement
©2023-2024 Zhejiang Uniview Technologies Co., Ltd. All rights reserved. No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from Zhejiang Uniview Technologies Co., Ltd (referred to as Uniview or us hereafter). - Page 15 features, etc, of the product. ⚫ This manual is intended for multiple software versions, and the illustrations and descriptions in this manual may be different from the actual GUI and functions of the software. ⚫ Despite our best efforts, technical or typographical errors may exist in this manual. Uniview cannot be held responsible for any such errors and reserves the right to change the manual without prior notice.
- Page 16 including all three elements: digits, letters and special characters. ⚫ Keep firmware up to date: It is recommended that your device is always upgraded to the latest version for the latest functions and better security. Visit Uniview's official website or contact your local dealer for the latest firmware.
- Page 17 including and not limited to, temperature, humidity, dust, corrosive gases, electromagnetic radiation, etc. ⚫ Make sure the device is securely installed or placed on a flat surface to prevent falling. ⚫ Unless otherwise specified, do not stack devices. ⚫ Ensure good ventilation in the operating environment. Do not cover the vents on the device. Allow adequate space for ventilation.
-
Page 18: Regulatory Compliance
⚫ Disposer la batterie utilisée conformément à vos règlements locaux ou aux instructions du fabricant de la batterie. Regulatory Compliance FCC Statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
