PHOENIX
DIGITAL CONTROL OPERATION
EnTEr
To start the system push on/off button.
Display will show current mode/ temperature setting / battery level.
ON/OFF Button
Initial default setting is low blower/AUTO/60 °F.
NOTE: Control will always default to the last setting when the unit is turned on.
Choose MoDE – press EnTEr. Use up or down arrows to select AUTO/COOL/HEAT.
After 5 seconds selection will be set.
If Auto mode is selected the system can cycle between AC and Heat only if your heater is
connected to the Phoenix unit. If your heater was factory installed check with your dealer for details.
If Heat mode is selected, after a safety systems check you'll hear the heater blower start up gradually. Next the fuel pump
starts and delivers fuel to the combustion chamber in pulses.
If heater fails to ignite turn heater off and on again to restart.
NOTE: when shutting the heater down, the combustion air blower continues to run through a cool down cycle then switches off
completely.
Choose BLOWER SPEED – press EnTEr until display shows FAN and SPEED. Press up or down arrows to select 1 – 2 – 3 speed. After
5 seconds selection will be set. Blower speed is for AC only and is always manually set.
Set TEMPERATURE set point. – anytime temperature set point is displayed on the screen push the up or down arrows to change.
Temperature range is from 60 °F (coolest) to 85 °F (warmest).
To view/reset system runtime/hours – press EnTEr until HOURS show on display. To reset hours to 0; while viewing hours hold
ENTER for 7 seconds.
To change from °F to °C – press EnTEr until only temperature symbol is showing. Push the up or down arrow to change. After 5
seconds selection will be locked.
Anytime the control is idle for 5 seconds the screen will return to the temperature set point screen.
1000251583 Rev 2 ©2011
