- Page 2 Congratulation on your purchase. The quality team at CARREFOUR cares for its products to meet conformity and performances. Paying close attention to your satisfaction, our experts work all day on the improvement of our products. For assembly and/or maintenance and/or use of your product, you can use: These products are available in CARREFOUR stores.
- Page 3 Pictograms used Warning symbols with information on damage and injury prevention. Read the operation instructions carefully. Read and understand all instructions before operating the product. Follow all warnings and safety instructions. Electrical products must not be disposed of with the domestic waste. Protect the rechargeable battery from sunlight and heat (max.50ºC) .
-
Page 4: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS ........................... 5 PRODUCT DESCRIPTION ........................10 INTENDED USE ............................13 BEFORE USE ............................14 OPERATION ............................17 CLEANING & MAINTENANCE ......................... 18 STORAGE AND TRANSPORTATION ......................18 REPLACEMENT PARTS/ACCESSORIES ..................... 19 TROUBLESHOOTING ..........................19 DISPOSAL ............................. 20 DECLARATION OF CONFORMITY ...................... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS GENERAL POWER TOOL SAFETY WARNINGS WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"... - Page 6 f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
- Page 7 specified range may damage the battery and increase the risk of fire. 6. Service a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. b) Never service damaged battery packs.
- Page 8 Therefore, only hold the saw by its insulated handle. 16. Check that the ventilation slots are not blocked. 17. Never remove dust, obstructions or the like from the work area while the blade is operating. 18. Never stop the saw blade by applying pressure to the saw or to the side of the blade. 19.
-
Page 9: Safety Instructions For Charger
16. Not allow the battery to contact with water or gets wet, it may short-circuit, overheat, rust or lose its functions. 17. Do not expose the battery to mechanical shock, for example, by dropping, throwing or crushing, causing electrolyte leakage, cell and battery heating, bursting and fire. 18. -
Page 10: Product Description
PRODUCT DESCRIPTION (Fig. A) (Fig. B) (Fig. C) - Page 11 (Fig. E) (Fig. G) (Fig. F) (Fig. I) (Fig .H)
-
Page 12: Device Description
OVERVIEW (Fig. A) 1. Lock-off button 15. Lock screws for rip fence 2. ON/OFF switch 16. Protection cover 3. Dust extraction connection 17. Charger 4. Splinter blow-off/suction selector switch 18. Battery level indication (LED) 5. Pendulum action selector switch 19. Battery 6. -
Page 13: Intended Use
Rated input Power Rated output 21.5V d.c. Charging current 2.4A Charging time Approx. 60min Protection class Noise emission value Noise measurement value determined in accordance with EN 62841-2-11 79dB(A) Uncertainty K 90dB(A) Uncertainty K Vibration emission value Vibration value determined in accordance with EN 62841-2-11 Cutting bore mode: a 11.4 m/s Cutting sheet metal mode: a... -
Page 14: Before Use
BEFORE USE UNPACKING 1. Unpack all parts and lay them on a flat stable surface 2. Make sure the delivery contents are complete and free of damage. If you find that parts are missing or show damage, do not use the product but contact your dealer/service center. Do not use the product unless missing parts have been delivered in addition or defective parts have been replaced. -
Page 15: Removing /Inserting The Battery
5. Take the battery (19) out of the charger (17) by pressing and holding the battery release button (23) and pulling the battery pack (8) out of the charger (17). REMOVING /INSERTING THE BATTERY 1. Slide the battery pack (19), place it on a guide track and push it back into the battery holder. It will audibly snap in. -
Page 16: Adjusting The Cutting Angle
4. Slowly push the sliding block (25) forward while carefully detaching the front part of the sliding block from the base plate (6). 5. Pull the sliding block (25) downwards carefully. 6. To reattach the sliding block (25), first push it onto the front part of the base plate (6). 7. -
Page 17: Operation
ADJUSTING THE PENDULUM ACTION (FIG.G) You can adjust the pendulum movement of the saw blade. Levels 1 to 3 allows for a faster work progress and level 0 (pendulum movement off) enables fine and clean cutting edges. The ideal pendulum level for the respective application can be determined by way of field- testing. Please observe the following instructions: 1. -
Page 18: Cleaning & Maintenance
- The device operates with the previously selected settings. - The LED work lamp (26) is illuminated. 6. Let go of the on/off switch (2) to stop the device. The LED work lamp (26) goes out. SETTING THE SPLINTER BLOW-OFF/SUCTION FUNCTION (FIG. H) You can choose whether the splinters shall be blown off towards the front or sucked off with an optionally connectable vacuum cleaner. -
Page 19: Replacement Parts/Accessories
4. Remove the battery form the device. 5. Remove the saw blade. 6. Clean the devices as described in the maintenance part. 7. For storing the device, use the transport case included in the scope of the delivery in order to protect the device from external influences. -
Page 20: Disposal
The tool won’t On/Off switch defective Send in to Service Centre for repair start Battery terminals on dirt Remove the dirt. blade Saw blade is not firmly locked in the place Fix the saw blade firmly experiences difficulties penetrating The pendulum setting is not suitable for Set the correct pendulum. -
Page 21: Declaration Of Conformity
Datum van afgifte en plaats: Firmado por y en nombre de: Lugar y fecha de expedición: Carrefour Marchandises Internationales - CMI - SAS au capital de 40.000€ 93 Avenue de Paris - 91300 MASSY - France RCS Evry 385 171 582... -
Page 22: Warranty
WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor. -
Page 23: Product Failure
PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: • Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. •... -
Page 24: Warranty Exclusions
WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
